April 23 QUARTERLY MEETING

Today’s Agenda • Welcome/Introduction of Guests and Elected Officials • Guest Speaker: Fort Worth Assistant City Manager Jay Chapa • NTE/35W Construction Update • General 35W Corridor Update • Quarterly Meeting Business/Board Member Update • Closing Comments

35W Development Guidelines Fort Worth Assistant City Manager Jay Chapa

35W Coalition 2018 Bond Program 4

Presentation Overview • Overall Proposed Bond Program • Streets and Mobility Program • North Fort Worth Transportation Related Projects • 2018 Bond Program Projects • Other Funded Projects • 2018 Bond Election Date 5

2018 Bond Program Projects - Funding by Category Total - $399,500,000 Includes Public Art Funding - 1% for Streets & Mobility Infrastructure and 2% for all other Categories 6

Streets and Mobility Focus Key Safety Improvements • Neighborhood/School Safety • Bridge Replacement • Rail Road Crossings • Street Lights Added Network Capacity • Corridors • Intersections • Sidewalks/Bicycle Facilities Maintain Network • Thoroughfare, Neighborhood & Park Roads • Revitalize Established Thoroughfare Corridors • Traffic Signals

Streets and Mobility Infrastructure Improvements

Streets and Mobility • Map to be Infrastructure inserted Improvements 9

2018 Bond -Added Capacity Projects Project Project Limit Project Scope Construct 3-lane roadway -Willow Springs (east) to Sendera Ranch; Roundabouts at *Avondale Haslet Rd. Willow Creek to eastern City Limit Willow Springs (east), Sendera Ranch *Bailey Boswell FM 156 to N. Tarrant Alignment Design & Environmental Permitting Construct Roundabouts at Bowman Roberts & Huffines Blvd with pavement rehabilitation *Cromwell Marine Creek Rd. Boat Club to Marine Creek of existing travel lanes Alignment Design & Construction of Roundabout at Harmon Rd with associated *Golden Triangle Misty Redwood to IH 35W infrastructure Construct 5/4-lane from US 287 to Golden Triangle; Roundabouts at US 287, Presidio, Harmon Rd. US 287 to Golden Triangle Heritage Trace, Golden Triangle with associated infrastructure *Kroger Dr. Ray White to US 377 Construct Intersection Improvements at US 377 & Roundabout at Park Vista Cir. (west) Riverside Dr. Golden Triangle to Keller Hicks Construct 4-lane roadway, with associated infrastructure *Westport Pkwy Alta Vista to Keller Haslet Construct 4-lane roadway with associated infrastructure *Willow Springs & Blue Construct 4-lane roadways & Roundabouts at US 287/Blue Mound with associated Eagle Dr. to US 287 Mound Roads infrastructure Construct 4-lane roadway - US 287 to Shire Meadow; Roundabouts at US 287, Shire *Bonds Ranch Rd. US 287 to FM 156 Meadow, FM 156 – Developer Partnership Construct 3-lane from Lauren Way to US 377 & Roundabout at Katy – City of Keller and *Keller Hicks Rd. Lauren Way to US 377 Developer Partnership

2018 Bond – Intersection Improvements • Park Vista Blvd / Keller Haslet Rd • NW Loop 820 / Marine Creek Pkwy • Beach St / Basswood Blvd • Basswood Blvd / US 377 11

TIF 7 Projects Construction TIF 7 Project Design ROW/Land Utilities Start Complete Comments Dalton & North Riverside Traffic Signal Operational Golden Triangle to Shiver Landscape Oct-18 Nov-18 Harmon Road Phase 1 Golden Triangle to Heritage Trace Mar-20 Feb-21 90% Public Meeting Summer 2018 Nov-20 Oct-21 Harmon Road Phase 2 Heritage Trace to US 287 Harmon Road Phase 3 RABS at US 287 Feb-21 Jun-22 Delayed to allow TXDOT changes Heritage Trace Sidewalks Feb-19 Jun-19 in conditions Riverside Drive Phase 4, N. Tarrant to Shiver Jun-20 Dec-21 Approaching 60% Design Tehama Ridge & Heritage Trace RAB Jul-16 Aug-17 Operational Sewer line conflict. Lane of traffic Tehama Ridge & Heritage Trace Headwall Nov-17 Sep-18 remains closed to manage vehicle safety. 12

North Fort Worth Projects North Fort Worth Projects Design ROW/Land Utilities Start Complete Comments Blue Mound Road Phase 1, 2 Intersections @ US 287 & Blue Mound Aug-18 Interchange Blue Mound Road Phase 2, Blue Mound Rd. from US 287 to Willow Oct-18 Aug-20 Springs, Willow Springs from Blue Mound to Eagle Blvd. Blue Mound Road Phase 3, 2 RABS @ US 287 & Blue Mound May-21 Sep-22 Interchange Bonds Ranch Phase 1, 2-RABs @ US 287 Jun-17 Operational Bonds Ranch Phase 2, 4-lane divided arterial NBFR to Shire Meadow Sep-18 Sep-19 Bonds Ranch Phase 3, RAB 156 @ Bonds Ranch Feb-20 Feb-21 Developer/City of Keller/City of Fort Worth Keller Hicks @ Katy May-20 Dec-21 Partnership Marine Creek/Old Decatur Rd. Oct-16 Jun-18 Mark IV Parkway Operational North Beach Street Phase 5, Fossil Creek to Loop 820 Jan-16 May-18 Operational; Traffic Signals (May) Old Decatur Rd. Phase 1 May-18 Operational Old Decatur Rd. Phase 2 Aug-17 Jul-18 Bridge Section Park Vista - Keller Hcks to Ray White Apr-18 Riverside Drive North Nov-18 Sep-20 Timberland Phase 1, N. Caylor to Park Vista and Park Vista from Apr-17 Operational Timberland to Caylor Timberland Phase 2, N. Caylor to Excelsior Nov-17 Aug-18 Timberland Phase 3, Park Vista to US 377 Oct-18 Nov-19 13

2018 Bond Program Schedule and Information • March 29 – April 26, 2018 Public education of Bond Propositions • April 23 – May 1, 2018 – Early Voting Period • May 5, 2018 – Election Day For more information on the 2018 Bond Program please visit: www.fortworthtexas.gov/2018bond/ 14

2018 Bond Program 15

35W Development Guidelines Robert Hinkle North Tarrant Infrastructure 35W Update

PLACEHOLDER (ROBERT HINKLE’S VIDEO)

Russell Laughlin General 35W Corridor Update

Russell Laughlin Quarterly Meeting Business and Board Member Update

35W Development Guidelines 35W Coalition April 23 Quarterly Meeting Thank you for your membership and support!
