SLIDE 1

Approximate information state for partially observed systems

Jayakumar Subramanian and Aditya Mahajan

McGill University

Thanks to Amit Sinha and Raihan Seraj for simulation results IEEE Conference on Decision and Control 11 December 2019

SLIDE 2

Approx. info. state–(Subramanian and Mahajan)

1

Many successes of RL in recent years

Algorithms based on comprehensive theory

SLIDE 3

Approx. info. state–(Subramanian and Mahajan)

1

Alpha Go

Many successes of RL in recent years

Algorithms based on comprehensive theory

SLIDE 4

Approx. info. state–(Subramanian and Mahajan)

1

Alpha Go Arcade games

Many successes of RL in recent years

Algorithms based on comprehensive theory

SLIDE 5

Approx. info. state–(Subramanian and Mahajan)

1

Alpha Go Arcade games Robotics

Many successes of RL in recent years

Algorithms based on comprehensive theory

SLIDE 6

Approx. info. state–(Subramanian and Mahajan)

1

Alpha Go Arcade games Robotics

Many successes of RL in recent years

Algorithms based on comprehensive theory restricted almost exclusively to systems with perfect state observations.

Applications with partially observed state

Healthcare Autonomous driving Finance (portfolio management) Retail and marketing

SLIDE 7

Approx. info. state–(Subramanian and Mahajan)

1

Alpha Go Arcade games Robotics

Many successes of RL in recent years

Algorithms based on comprehensive theory restricted almost exclusively to systems with perfect state observations.

Applications with partially observed state

Healthcare Autonomous driving Finance (portfolio management) Retail and marketing

Develop a comprehensive theory of approximate DP and RL for partially observed systems

SLIDE 8

Notion of information state for partially observed systems

SLIDE 9

Approx. info. state–(Subramanian and Mahajan)

2 Stochastic System Controlled input: Ut Stochastic input: Wt Output: Yt

Yt = ft(U1:t, W1:t).

Notion of state in partially observed stochastic dynamical systems

SLIDE 10

Approx. info. state–(Subramanian and Mahajan)

2 Stochastic System Controlled input: Ut Stochastic input: Wt Output: Yt

Yt = ft(U1:t, W1:t).

STOCHASTIC INPUT IS NOT OBSERVED

Let Ht = (Y1:t−1, U1:t−1) denote the history

f inputs and OUTPUTS until time t.

Notion of state in partially observed stochastic dynamical systems

SLIDE 11

Approx. info. state–(Subramanian and Mahajan)

2 Stochastic System Controlled input: Ut Stochastic input: Wt Output: Yt

Yt = ft(U1:t, W1:t).

STOCHASTIC INPUT IS NOT OBSERVED

Let Ht = (Y1:t−1, U1:t−1) denote the history

f inputs and OUTPUTS until time t.

TRADITIONAL SOLUTION: BELIEF STATES

Step 1 Identify a state {St}t≥0 for predicting output assuming that the stochastic inputs are observed. Step 2 Defjne a BELIEF STATE Bt ∈ Δ(𝒯): Bt(s) = ℙ(St = s | Ht = ht), s ∈ 𝒯.

Notion of state in partially observed stochastic dynamical systems

Astrom, “Optimal control of Markov decision processes with incomplete state information,” 1965. Striebel, “Suffjcient statistics in the optimal control of stochastic systems,” 1965. Baum and Petrie, “Statistical inference for probabilistic functions of fjnite state Markov chains,” 1966. Stratonovich, “Conditional Markov processes,” 1960.

SLIDE 12

Approx. info. state–(Subramanian and Mahajan)

3

Value function is piecewise linear and convex. Is exploited by various effjcient algorithms.

Partially observed Markov decision processes (POMDPs): Pros and Cons of belief state representation

Smallwood and Sondik, “The optimal control of partially observable Markov process over a fjnite horizon,” 1973. Chen, “Algorithms for partially observable Markov decision processes,” 1988. Kaelbling, Littmam, Cassandra, “Planning and acting in partially observable stochastic domains,” 1998. Pineau, Gordon, Thrun, “Point-based value iteration: an anytime algorithm for POMDPs,” 2003.

SLIDE 13

Approx. info. state–(Subramanian and Mahajan)

3

Value function is piecewise linear and convex. Is exploited by various effjcient algorithms. When the state space model is not known analytically (as is the case for black-box models and simulators as well as some real world application such as healthcare), belief states are diffjcult to construct and diffjcult to approximate from data.

Partially observed Markov decision processes (POMDPs): Pros and Cons of belief state representation

Smallwood and Sondik, “The optimal control of partially observable Markov process over a fjnite horizon,” 1973. Chen, “Algorithms for partially observable Markov decision processes,” 1988. Kaelbling, Littmam, Cassandra, “Planning and acting in partially observable stochastic domains,” 1998. Pineau, Gordon, Thrun, “Point-based value iteration: an anytime algorithm for POMDPs,” 2003.

SLIDE 14

Is there another ways to model partially observed systems which is more amenable to approximations? Let’s go back to first principles.

SLIDE 15

Approx. info. state–(Subramanian and Mahajan)

4 Stochastic System Controlled input: Ut Stochastic input: Wt Output: Yt

Yt = ft(U1:t, W1:t).

WHEN THE STOCHASTIC INPUT IS NOT OBSERVED

Let Ht = (Y1:t−1, U1:t−1) denote the history

f inputs and OUTPUTS until time t.

Notion of state in partially observed stochastic dynamical systems

SLIDE 16

Approx. info. state–(Subramanian and Mahajan)

4 Stochastic System Controlled input: Ut Stochastic input: Wt Output: Yt

Yt = ft(U1:t, W1:t).

WHEN THE STOCHASTIC INPUT IS NOT OBSERVED

Let Ht = (Y1:t−1, U1:t−1) denote the history

f inputs and OUTPUTS until time t.

PREDICTING OUTPUTS ALMOST SURELY

H(1)

t

∼ H(2)

t

if for all future inputs (Ut:T, Wt:T), Y(1)

t:T = Y(2) t:T ,

a.s.

Notion of state in partially observed stochastic dynamical systems

SLIDE 17

Approx. info. state–(Subramanian and Mahajan)

4 Stochastic System Controlled input: Ut Stochastic input: Wt Output: Yt

Yt = ft(U1:t, W1:t).

WHEN THE STOCHASTIC INPUT IS NOT OBSERVED

Let Ht = (Y1:t−1, U1:t−1) denote the history

f inputs and OUTPUTS until time t.

PREDICTING OUTPUTS ALMOST SURELY

H(1)

t

∼ H(2)

t

if for all future inputs (Ut:T, Wt:T), Y(1)

t:T = Y(2) t:T ,

a.s.

FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

Notion of state in partially observed stochastic dynamical systems

Grassberger, “Complexity and forecasting in dynamical systems,” 1988. Cruthfjeld and Young, “Inferring statistical complexity,” 1989.

SLIDE 18

Approx. info. state–(Subramanian and Mahajan)

4 Stochastic System Controlled input: Ut Stochastic input: Wt Output: Yt

Yt = ft(U1:t, W1:t).

WHEN THE STOCHASTIC INPUT IS NOT OBSERVED

Let Ht = (Y1:t−1, U1:t−1) denote the history

f inputs and OUTPUTS until time t.

PREDICTING OUTPUTS ALMOST SURELY

H(1)

t

∼ H(2)

t

if for all future inputs (Ut:T, Wt:T), Y(1)

t:T = Y(2) t:T ,

a.s.

FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

Too restrictive . . . Notion of state in partially observed stochastic dynamical systems

Grassberger, “Complexity and forecasting in dynamical systems,” 1988. Cruthfjeld and Young, “Inferring statistical complexity,” 1989.

SLIDE 19

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

Now let’s consturct the state space

SLIDE 20

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut).

Now let’s consturct the state space

SLIDE 21

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut). Same complexity as identifying the state suffjcient for forecasting outputs for the case of perfect observations (which was Step 1 for belief state formulations)

Now let’s consturct the state space

SLIDE 22

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut). Same complexity as identifying the state suffjcient for forecasting outputs for the case of perfect observations (which was Step 1 for belief state formulations)

KEY QUESTIONS

Can this be used for dynamic programming? What is the right notion of approximations in this framework?

Now let’s consturct the state space

SLIDE 23

An information state for dynamic programming

SLIDE 24

Approx. info. state–(Subramanian and Mahajan)

6 Stochastic System Controlled input: Ut Stochastic input: Wt Output: Yt Reward: 𝐒𝐮

Yt = ft(U1:t, W1:t), Rt = rt(U1:t, W1:t). Choose Ut = gt(Y1:t−1, U1:t−1) to max 𝔽 [

T

∑

t=1

Rt]

Predicting output vs optimizing expected rewards over time

SLIDE 25

Approx. info. state–(Subramanian and Mahajan)

6 Stochastic System Controlled input: Ut Stochastic input: Wt Output: Yt Reward: 𝐒𝐮

Yt = ft(U1:t, W1:t), Rt = rt(U1:t, W1:t). Choose Ut = gt(Y1:t−1, U1:t−1) to max 𝔽 [

T

∑

t=1

Rt]

PROPERTIES OF INFORMATION STATE (SUFFICIENT FOR DYNAMIC PROGRAMMING)

The info state Zt at time t is a “compression” of past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO ESTIMATE EXPECTED REWARD:

𝔽[Rt | Ht, Ut] = 𝔽[Rt | Zt, Ut].

Predicting output vs optimizing expected rewards over time

SLIDE 26

Approx. info. state–(Subramanian and Mahajan)

7

PROPERTIES OF INFORMATION STATE (SUFFICIENT FOR DYNAMIC PROGRAMMING)

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO ESTIMATE EXPECTED REWARD:

𝔽[Rt | Ht, Ut] = 𝔽[Rt | Zt, Ut].

Dynamic programming using information state

SLIDE 27

Approx. info. state–(Subramanian and Mahajan)

7

PROPERTIES OF INFORMATION STATE (SUFFICIENT FOR DYNAMIC PROGRAMMING)

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO ESTIMATE EXPECTED REWARD:

𝔽[Rt | Ht, Ut] = 𝔽[Rt | Zt, Ut].

PRELIMINARY THEOREM

If {Zt}t≥1 is any information state process. Then: There is no loss of optimality in restricting attention to policies of the form Ut = ˜ gt(Zt).

Dynamic programming using information state

Bohlin (1970) David and Varaiya (1972) Kumar and Varaiya (1984).

SLIDE 28

Approx. info. state–(Subramanian and Mahajan)

7

PROPERTIES OF INFORMATION STATE (SUFFICIENT FOR DYNAMIC PROGRAMMING)

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO ESTIMATE EXPECTED REWARD:

𝔽[Rt | Ht, Ut] = 𝔽[Rt | Zt, Ut].

PRELIMINARY THEOREM

If {Zt}t≥1 is any information state process. Then: There is no loss of optimality in restricting attention to policies of the form Ut = ˜ gt(Zt). Let {Vt}T+1

t=1 denote the solution to the following

dynamic program: VT+1(zT+1) = 0 and for t ∈ {T, . . . , 1}, Qt(zt, ut) = 𝔽[Rt + Vt+1(Zt+1) | Zt = zt, Ut = ut], Vt(zt) = max

ut∈𝒱 Qt(zt, ut).

A policy { ˜ gt}T

t=1, ˜

gt∶ 𝒶t → 𝒱, is optimal if it satisfjes ˜ gt(zt) ∈ arg max

ut∈𝒱 Qt(zt, ut).

Dynamic programming using information state

Bohlin (1970) David and Varaiya (1972) Kumar and Varaiya (1984).

SLIDE 29

What about approximations?

SLIDE 30

Approx. info. state–(Subramanian and Mahajan)

8 INTEGRAL PROBABILITY METRIC (IPM)

Let 𝒬 denote the set of probability measures

n a measurable space (𝒴, 𝔋).

Given a class 𝔊 of real-valued bounded measureable functions on (𝒴, 𝔋), the integral probability metric (IPM) between two probability distributions μ, ν ∈ 𝒬 is given by: d𝔊(μ, ν) = sup

f∈𝔊|∫ 𝒴

fdμ − ∫

𝒴

fdν | .

Preliminary: A family of pseudometrics on probability distributions

Müller, “Integral probability metrics and their generating classes of functions,” 1997.

SLIDE 31

Approx. info. state–(Subramanian and Mahajan)

8 INTEGRAL PROBABILITY METRIC (IPM)

Let 𝒬 denote the set of probability measures

n a measurable space (𝒴, 𝔋).

Given a class 𝔊 of real-valued bounded measureable functions on (𝒴, 𝔋), the integral probability metric (IPM) between two probability distributions μ, ν ∈ 𝒬 is given by: d𝔊(μ, ν) = sup

f∈𝔊|∫ 𝒴

fdμ − ∫

𝒴

fdν | .

EXAMPLES

If 𝔊 = {f : ‖f‖∞ ≤ 1}, d𝔊 = Total variation distance. If 𝔊 = {f : |f|L ≤ 1}, d𝔊 = Wasserstein distance. If 𝔊 = {f : ‖f‖∞ + |f|L ≤ 1}, d𝔊 = Dudley metric. . . . We say a function f has a 𝔊-constant K if f/K ∈ 𝔊.

Preliminary: A family of pseudometrics on probability distributions

Müller, “Integral probability metrics and their generating classes of functions,” 1997.

SLIDE 32

Approx. info. state–(Subramanian and Mahajan)

9

(ε, δ)-APPROXIMATE INFORMATION STATE (AIS) Given a function class 𝔊, a compression {Zt}t≥1 of history (i.e., Zt = φt(Ht)) is called an {(εt, δt)}t≥1 AIS if there exist: a function ˜ Rt(Zt, Ut), and a stochastic kernel νt(Zt+1|Zt, Ut) such that |𝔽[Rt|Ht = ht, Ut = ut] − ˜ Rt(φt(ht), ut)| ≤ εt For any Borel set A of 𝒶t, defjne μt(A) = ℙ(Zt+1 ∈ A | Ht = ht, Ut = ut) Then, d𝔊(μt, νt(⋅ |φt(ht), ut)) ≤ δt.

Approximate information state

SLIDE 33

Approx. info. state–(Subramanian and Mahajan)

10 MAIN THEOREM

Given a function class 𝔊, let {Zt}t≥1, where Zt = φt(Ht), be an {(εt, δt)}t≥1 AIS. Recursively defjne the following functions: ˆ VT+1(zT+1) = 0 and for t ∈ {T, . . . , 1}: ˆ Vt(zt) = max

ut∈𝒱{˜

Rt(zt, ut) + ∫ Vt+1(zt+1)νt(dzt+1 | zt, ut)}. Let π = (π1, . . . , πT) denote the corresponding policy.

Approximate dynamic programming using AIS

SLIDE 34

Approx. info. state–(Subramanian and Mahajan)

10 MAIN THEOREM

Given a function class 𝔊, let {Zt}t≥1, where Zt = φt(Ht), be an {(εt, δt)}t≥1 AIS. Recursively defjne the following functions: ˆ VT+1(zT+1) = 0 and for t ∈ {T, . . . , 1}: ˆ Vt(zt) = max

ut∈𝒱{˜

Rt(zt, ut) + ∫ Vt+1(zt+1)νt(dzt+1 | zt, ut)}. Let π = (π1, . . . , πT) denote the corresponding policy. Then, if the value function ˆ Vt has 𝔊-constant Kt, then for any history ht, |Vt(ht) − ˆ Vt(φt(ht))| ≤ εT +

T

∑

s=t

(εs + Ksδs). for any history ht, |Vt(ht) − Vπ

t (ht)|

≤ 2[εT +

T

∑

s=t

(εs + Ksδs)].

Approximate dynamic programming using AIS

SLIDE 35

Approx. info. state–(Subramanian and Mahajan)

11

In the defjnition of AIS, we can replace d𝔊(ℙ(μt, νt(⋅|Zt = φt(ht), Ut = ut)) ≤ δt by Zt+1 = function(Zt, Yt+1, Ut) d𝔊(ℙ(Yt|Ht = ht, Ut = ut), ℙ(Yt|Zt = φt(ht), Ut = ut)) ≤ δt.

AIS: Some remarks

SLIDE 36

Approx. info. state–(Subramanian and Mahajan)

11

In the defjnition of AIS, we can replace d𝔊(ℙ(μt, νt(⋅|Zt = φt(ht), Ut = ut)) ≤ δt by Zt+1 = function(Zt, Yt+1, Ut) d𝔊(ℙ(Yt|Ht = ht, Ut = ut), ℙ(Yt|Zt = φt(ht), Ut = ut)) ≤ δt. The AIS process {Zt}t≥1 need not be Markov !!

AIS: Some remarks

SLIDE 37

Approx. info. state–(Subramanian and Mahajan)

11

In the defjnition of AIS, we can replace d𝔊(ℙ(μt, νt(⋅|Zt = φt(ht), Ut = ut)) ≤ δt by Zt+1 = function(Zt, Yt+1, Ut) d𝔊(ℙ(Yt|Ht = ht, Ut = ut), ℙ(Yt|Zt = φt(ht), Ut = ut)) ≤ δt. The AIS process {Zt}t≥1 need not be Markov !! Two ways to interpret the results: Given the information state space 𝒶, fjnd the best compression φt∶ ℋt → 𝒶 Given any compression function φt∶ ℋt → 𝒶t, fjnd the approximation error.

AIS: Some remarks

SLIDE 38

Approx. info. state–(Subramanian and Mahajan)

11

In the defjnition of AIS, we can replace d𝔊(ℙ(μt, νt(⋅|Zt = φt(ht), Ut = ut)) ≤ δt by Zt+1 = function(Zt, Yt+1, Ut) d𝔊(ℙ(Yt|Ht = ht, Ut = ut), ℙ(Yt|Zt = φt(ht), Ut = ut)) ≤ δt. The AIS process {Zt}t≥1 need not be Markov !! Two ways to interpret the results: Given the information state space 𝒶, fjnd the best compression φt∶ ℋt → 𝒶 Given any compression function φt∶ ℋt → 𝒶t, fjnd the approximation error. Results naturally extend to infjnite horizon

AIS: Some remarks

SLIDE 39

Some examples

SLIDE 40

Approx. info. state–(Subramanian and Mahajan)

12

Consider an MDP with state space 𝒴 and per-step reward Rt = r(Xt, Ut). Suppose 𝒴 is quantized to a discrete set 𝒶 using φ∶ 𝒴 → 𝒶. Let z = φ(x) denote the label for x. Then φ−1(z) denote all states which have label z.

Example 1: Error bounds on state aggregation

SLIDE 41

Approx. info. state–(Subramanian and Mahajan)

12

Consider an MDP with state space 𝒴 and per-step reward Rt = r(Xt, Ut). Suppose 𝒴 is quantized to a discrete set 𝒶 using φ∶ 𝒴 → 𝒶. Let z = φ(x) denote the label for x. Then φ−1(z) denote all states which have label z. {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

(x,u)∈𝒴×𝒱|r(x, u) − r(φ(x), u)|

r, equivalently, r(⋅, u) has a 𝔊-cosntant Kr

δ = sup

(x,u)∈𝒴×𝒱

d𝔊(ℙ(X+ | X = x, U = u), ℙ(X+ | X ∈ φ−1(φ(x)), U = u)).

r, equivalently, ℙ(X+|X = ⋅, U = u) has a 𝔊-constant of Kd.

Example 1: Error bounds on state aggregation

Bertsekas, “Convergence of discretization procedures in dynamic programming,” 1975.

SLIDE 42

Approx. info. state–(Subramanian and Mahajan)

13

Example 2: Approximation bounds for using quantized obs.

Ha, Schmidhuber, “World Models”, 2018.

Video observation Vision Vision Memory RL agent Yt ˆ Yt Zt

SLIDE 43

Approx. info. state–(Subramanian and Mahajan)

13

Proposed as a heuristic algorithms No performance bounds

Example 2: Approximation bounds for using quantized obs.

Ha, Schmidhuber, “World Models”, 2018.

Video observation Vision Vision Memory RL agent Yt ˆ Yt Zt

SLIDE 44

Approx. info. state–(Subramanian and Mahajan)

13

Proposed as a heuristic algorithms No performance bounds {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

ht,ut|𝔽[Rt|ht, ut] − ˜

Rt(φt(ht), ut)| δ = sup

ht,ut

d𝔊(ℙ(ˆ Yt+1|ht, ut), ℙ(ˆ Yt+1|φt(ht), ut))

Example 2: Approximation bounds for using quantized obs.

Ha, Schmidhuber, “World Models”, 2018.

Video observation Vision Vision Memory RL agent Yt ˆ Yt Zt

SLIDE 45

Approx. info. state–(Subramanian and Mahajan)

14

n agents: state Xi

t, control Ui t.

Empirical mean-fjeld: Mt(x) = 1 n

n

∑

i=1

δXi

t(x).

Statistical mean-fjeld: ¯ mt(x) = ℙ(Xi

t = x).

Example 3: Approximation bounds for mean-field teams

SLIDE 46

Approx. info. state–(Subramanian and Mahajan)

14

n agents: state Xi

t, control Ui t.

Dynamics ℙ(𝐘t+1|𝐘t, 𝐕t) =

n

∏

i=1

P(Xi

t+1|Xi t, Ui t, Mt)

Per-step reward R(𝐘t, 𝐕t) = 1 n

n

∑

i=1

r(Xi

t, Ui t, Mt)

Empirical mean-fjeld: Mt(x) = 1 n

n

∑

i=1

δXi

t(x).

Statistical mean-fjeld: ¯ mt(x) = ℙ(Xi

t = x).

Example 3: Approximation bounds for mean-field teams

SLIDE 47

Approx. info. state–(Subramanian and Mahajan)

14

n agents: state Xi

t, control Ui t.

Dynamics ℙ(𝐘t+1|𝐘t, 𝐕t) =

n

∏

i=1

P(Xi

t+1|Xi t, Ui t, Mt)

Per-step reward R(𝐘t, 𝐕t) = 1 n

n

∑

i=1

r(Xi

t, Ui t, Mt)

Empirical mean-fjeld: Mt(x) = 1 n

n

∑

i=1

δXi

t(x).

Statistical mean-fjeld: ¯ mt(x) = ℙ(Xi

t = x).

Info structure: Ii

t = {Xi t}.

Example 3: Approximation bounds for mean-field teams

SLIDE 48

Approx. info. state–(Subramanian and Mahajan)

14

n agents: state Xi

t, control Ui t.

Dynamics ℙ(𝐘t+1|𝐘t, 𝐕t) =

n

∏

i=1

P(Xi

t+1|Xi t, Ui t, Mt)

Per-step reward R(𝐘t, 𝐕t) = 1 n

n

∑

i=1

r(Xi

t, Ui t, Mt)

Empirical mean-fjeld: Mt(x) = 1 n

n

∑

i=1

δXi

t(x).

Statistical mean-fjeld: ¯ mt(x) = ℙ(Xi

t = x).

Info structure: Ii

t = {Xi t}.

Expanded info structure: ˜ Ii

t = {Xi t, Mt}.

𝒦∗ ≤ ˜ 𝒦∗

Example 3: Approximation bounds for mean-field teams

SLIDE 49

Approx. info. state–(Subramanian and Mahajan)

14

n agents: state Xi

t, control Ui t.

Dynamics ℙ(𝐘t+1|𝐘t, 𝐕t) =

n

∏

i=1

P(Xi

t+1|Xi t, Ui t, Mt)

Per-step reward R(𝐘t, 𝐕t) = 1 n

n

∑

i=1

r(Xi

t, Ui t, Mt)

Empirical mean-fjeld: Mt(x) = 1 n

n

∑

i=1

δXi

t(x).

Statistical mean-fjeld: ¯ mt(x) = ℙ(Xi

t = x).

Info structure: Ii

t = {Xi t}.

Expanded info structure: ˜ Ii

t = {Xi t, Mt}.

𝒦∗ ≤ ˜ 𝒦∗ (A) r(x, u, m) and P(y|x, u, m) are Lipschitz in m. { ¯ mt}t≥1 is an (ε, δ) AIS for expanded info structure, where ε, δ ∈ 𝒫(1/√n).

Example 3: Approximation bounds for mean-field teams

SLIDE 50

Approx. info. state–(Subramanian and Mahajan)

14

n agents: state Xi

t, control Ui t.

Dynamics ℙ(𝐘t+1|𝐘t, 𝐕t) =

n

∏

i=1

P(Xi

t+1|Xi t, Ui t, Mt)

Per-step reward R(𝐘t, 𝐕t) = 1 n

n

∑

i=1

r(Xi

t, Ui t, Mt)

Empirical mean-fjeld: Mt(x) = 1 n

n

∑

i=1

δXi

t(x).

Statistical mean-fjeld: ¯ mt(x) = ℙ(Xi

t = x).

Info structure: Ii

t = {Xi t}.

Expanded info structure: ˜ Ii

t = {Xi t, Mt}.

𝒦∗ ≤ ˜ 𝒦∗, ˜ 𝒦∗ − ¯ 𝒦∗ ≤ K/√n ¯ 𝒦∗ ≤ 𝒦∗ ≤ ¯ 𝒦∗ + K/√n. (A) r(x, u, m) and P(y|x, u, m) are Lipschitz in m. { ¯ mt}t≥1 is an (ε, δ) AIS for expanded info structure, where ε, δ ∈ 𝒫(1/√n).

Example 3: Approximation bounds for mean-field teams

SLIDE 51

Now to reinforcement learning for partially observed systems.

SLIDE 52

Approx. info. state–(Subramanian and Mahajan)

15

State aggregator: ℒAIS = αt|˜ Rt − Rt| + (1 − αt)d𝔊(νt, μt) ξ: Parameters of the aggregator Updated using SGD with LR ak

Reinforcement learning setup

AIS Encoder AIS Decoder Zt State aggregator Yt Ut−1 ˜ Rt νt

SLIDE 53

Approx. info. state–(Subramanian and Mahajan)

15

State aggregator: ℒAIS = αt|˜ Rt − Rt| + (1 − αt)d𝔊(νt, μt) ξ: Parameters of the aggregator Updated using SGD with LR ak Value approximator: φ: parameters of Q(z, u) approximator. Updated using TD(0) or TD(λ) with LR bk.

Reinforcement learning setup

AIS Encoder AIS Decoder Zt State aggregator Yt Ut−1 ˜ Rt νt Value approx. Critic Ut

SLIDE 54

Approx. info. state–(Subramanian and Mahajan)

15

State aggregator: ℒAIS = αt|˜ Rt − Rt| + (1 − αt)d𝔊(νt, μt) ξ: Parameters of the aggregator Updated using SGD with LR ak Value approximator: φ: parameters of Q(z, u) approximator. Updated using TD(0) or TD(λ) with LR bk. Policy approximator: θ: parameters of π(u | z) Updated using policy gradient with LR ck.

Reinforcement learning setup

AIS Encoder AIS Decoder Zt State aggregator Yt Ut−1 ˜ Rt νt Value approx. Critic Ut Policy approx. Actor

SLIDE 55

Approx. info. state–(Subramanian and Mahajan)

16 CONVERGENCE RESULT

If the learning rates satisfy conditions for three time-scale stochastic approximation, the compatibility condition ∂Q(z, u) ∂φ = 1 π(u|z) ∂π(u|z) ∂θ and additional mild technical conditions hold. Then, State aggregator converges (with some approximation error) The critic converges to the best approximator within the specifjed family. The actor converges to a local maximizer within the family of policy approximators.

Reinforcement learning setup

AIS Encoder AIS Decoder Zt State aggregator Yt Ut−1 ˜ Rt νt Value approx. Critic Ut Policy approx. Actor

SLIDE 56

Approx. info. state–(Subramanian and Mahajan)

17

Numerical Results: 𝟓 × 𝟓 Grid Environment

SLIDE 57

Approx. info. state–(Subramanian and Mahajan)

18

𝟓 × 𝟓 Grid Environment

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Samples ×106 1 2 3 4 5 Performance Planning solution RPG AIS

SLIDE 58

Approx. info. state–(Subramanian and Mahajan)

19

Numerical Results: Tiger Environment

SLIDE 59

Approx. info. state–(Subramanian and Mahajan)

20

Tiger Environment

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Samples ×106 −40 −30 −20 −10 10 20 Performance Planning solution RPG AIS

SLIDE 60

Approx. info. state–(Subramanian and Mahajan)

21

Numerical Results: Cheese Maze Environment

SLIDE 61

Approx. info. state–(Subramanian and Mahajan)

22

Cheese Maze Environment

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Samples ×106 0.0 0.1 0.2 0.3 0.4 0.5 0.6 Performance Planning solution RPG AIS

SLIDE 62

Approx. info. state–(Subramanian and Mahajan)

23

Summary

SLIDE 63

Approx. info. state–(Subramanian and Mahajan)

23

Summary

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut). Same complexity as identifying the state suffjcient for forecasting outputs for the case of perfect observations (which was Step 1 for belief state formulations)

KEY QUESTIONS

Can this be used for dynamic programming? What is the right notion of approximations in this framework?

Now let’s consturct the state space

SLIDE 64

Approx. info. state–(Subramanian and Mahajan)

23

Summary

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut). Same complexity as identifying the state suffjcient for forecasting outputs for the case of perfect observations (which was Step 1 for belief state formulations)

KEY QUESTIONS

Can this be used for dynamic programming? What is the right notion of approximations in this framework?

Now let’s consturct the state space

Approx. info. state–(Subramanian and Mahajan)

9

(ε, δ)-APPROXIMATE INFORMATION STATE (AIS) Given a function class 𝔊, a compression {Zt}t≥1 of history (i.e., Zt = φt(Ht)) is called an {(εt, δt)}t≥1 AIS if there exist: a function ˜ Rt(Zt, Ut), and a stochastic kernel νt(Zt+1|Zt, Ut) such that |𝔽[Rt|Ht = ht, Ut = ut] − ˜ Rt(φt(ht), ut)| ≤ εt For any Borel set A of 𝒶t, defjne μt(A) = ℙ(Zt+1 ∈ A | Ht = ht, Ut = ut) Then, d𝔊(μt, νt(⋅ |φt(ht), ut)) ≤ δt.

Approximate information state

SLIDE 65

Approx. info. state–(Subramanian and Mahajan)

23

Summary

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut). Same complexity as identifying the state suffjcient for forecasting outputs for the case of perfect observations (which was Step 1 for belief state formulations)

KEY QUESTIONS

Can this be used for dynamic programming? What is the right notion of approximations in this framework?

Now let’s consturct the state space

Approx. info. state–(Subramanian and Mahajan)

9

(ε, δ)-APPROXIMATE INFORMATION STATE (AIS) Given a function class 𝔊, a compression {Zt}t≥1 of history (i.e., Zt = φt(Ht)) is called an {(εt, δt)}t≥1 AIS if there exist: a function ˜ Rt(Zt, Ut), and a stochastic kernel νt(Zt+1|Zt, Ut) such that |𝔽[Rt|Ht = ht, Ut = ut] − ˜ Rt(φt(ht), ut)| ≤ εt For any Borel set A of 𝒶t, defjne μt(A) = ℙ(Zt+1 ∈ A | Ht = ht, Ut = ut) Then, d𝔊(μt, νt(⋅ |φt(ht), ut)) ≤ δt.

Approximate information state

Approx. info. state–(Subramanian and Mahajan)

10 MAIN THEOREM

Given a function class 𝔊, let {Zt}t≥1, where Zt = φt(Ht), be an {(εt, δt)}t≥1 AIS. Recursively defjne the following functions: ˆ VT+1(zT+1) = 0 and for t ∈ {T, . . . , 1}: ˆ Vt(zt) = max

ut∈𝒱{˜

Rt(zt, ut) + ∫ Vt+1(zt+1)νt(dzt+1 | zt, ut)}. Let π = (π1, . . . , πT) denote the corresponding policy. Then, if the value function ˆ Vt has 𝔊-constant Kt, then for any history ht, |Vt(ht) − ˆ Vt(φt(ht))| ≤ εT +

T

∑

s=t

(εs + Ksδs). for any history ht, |Vt(ht) − Vπ

t (ht)|

≤ 2[εT +

T

∑

s=t

(εs + Ksδs)].

Approximate dynamic programming using AIS

SLIDE 66

Approx. info. state–(Subramanian and Mahajan)

23

Summary

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut). Same complexity as identifying the state suffjcient for forecasting outputs for the case of perfect observations (which was Step 1 for belief state formulations)

KEY QUESTIONS

Can this be used for dynamic programming? What is the right notion of approximations in this framework?

Now let’s consturct the state space

Approx. info. state–(Subramanian and Mahajan)

9

(ε, δ)-APPROXIMATE INFORMATION STATE (AIS) Given a function class 𝔊, a compression {Zt}t≥1 of history (i.e., Zt = φt(Ht)) is called an {(εt, δt)}t≥1 AIS if there exist: a function ˜ Rt(Zt, Ut), and a stochastic kernel νt(Zt+1|Zt, Ut) such that |𝔽[Rt|Ht = ht, Ut = ut] − ˜ Rt(φt(ht), ut)| ≤ εt For any Borel set A of 𝒶t, defjne μt(A) = ℙ(Zt+1 ∈ A | Ht = ht, Ut = ut) Then, d𝔊(μt, νt(⋅ |φt(ht), ut)) ≤ δt.

Approximate information state

Approx. info. state–(Subramanian and Mahajan)

10 MAIN THEOREM

Given a function class 𝔊, let {Zt}t≥1, where Zt = φt(Ht), be an {(εt, δt)}t≥1 AIS. Recursively defjne the following functions: ˆ VT+1(zT+1) = 0 and for t ∈ {T, . . . , 1}: ˆ Vt(zt) = max

ut∈𝒱{˜

Rt(zt, ut) + ∫ Vt+1(zt+1)νt(dzt+1 | zt, ut)}. Let π = (π1, . . . , πT) denote the corresponding policy. Then, if the value function ˆ Vt has 𝔊-constant Kt, then for any history ht, |Vt(ht) − ˆ Vt(φt(ht))| ≤ εT +

T

∑

s=t

(εs + Ksδs). for any history ht, |Vt(ht) − Vπ

t (ht)|

≤ 2[εT +

T

∑

s=t

(εs + Ksδs)].

Approximate dynamic programming using AIS

Approx. info. state–(Subramanian and Mahajan)

12

Consider an MDP with state space 𝒴 and per-step reward Rt = r(Xt, Ut). Suppose 𝒴 is quantized to a discrete set 𝒶 using φ∶ 𝒴 → 𝒶. Let z = φ(x) denote the label for x. Then φ−1(z) denote all states which have label z. {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

(x,u)∈𝒴×𝒱|r(x, u) − r(φ(x), u)|

r, equivalently, r(⋅, u) has a 𝔊-cosntant Kr

δ = sup

(x,u)∈𝒴×𝒱

d𝔊(ℙ(X+ | X = x, U = u), ℙ(X+ | X ∈ φ−1(φ(x)), U = u)).

r, equivalently, ℙ(X+|X = ⋅, U = u) has a 𝔊-constant of Kd.

Example 1: Error bounds on state aggregation

Bertsekas, “Convergence of discretization procedures in dynamic programming,” 1975.

SLIDE 67

Approx. info. state–(Subramanian and Mahajan)

23

Summary

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut). Same complexity as identifying the state suffjcient for forecasting outputs for the case of perfect observations (which was Step 1 for belief state formulations)

KEY QUESTIONS

Can this be used for dynamic programming? What is the right notion of approximations in this framework?

Now let’s consturct the state space

Approx. info. state–(Subramanian and Mahajan)

9

(ε, δ)-APPROXIMATE INFORMATION STATE (AIS) Given a function class 𝔊, a compression {Zt}t≥1 of history (i.e., Zt = φt(Ht)) is called an {(εt, δt)}t≥1 AIS if there exist: a function ˜ Rt(Zt, Ut), and a stochastic kernel νt(Zt+1|Zt, Ut) such that |𝔽[Rt|Ht = ht, Ut = ut] − ˜ Rt(φt(ht), ut)| ≤ εt For any Borel set A of 𝒶t, defjne μt(A) = ℙ(Zt+1 ∈ A | Ht = ht, Ut = ut) Then, d𝔊(μt, νt(⋅ |φt(ht), ut)) ≤ δt.

Approximate information state

Approx. info. state–(Subramanian and Mahajan)

10 MAIN THEOREM

Given a function class 𝔊, let {Zt}t≥1, where Zt = φt(Ht), be an {(εt, δt)}t≥1 AIS. Recursively defjne the following functions: ˆ VT+1(zT+1) = 0 and for t ∈ {T, . . . , 1}: ˆ Vt(zt) = max

ut∈𝒱{˜

Rt(zt, ut) + ∫ Vt+1(zt+1)νt(dzt+1 | zt, ut)}. Let π = (π1, . . . , πT) denote the corresponding policy. Then, if the value function ˆ Vt has 𝔊-constant Kt, then for any history ht, |Vt(ht) − ˆ Vt(φt(ht))| ≤ εT +

T

∑

s=t

(εs + Ksδs). for any history ht, |Vt(ht) − Vπ

t (ht)|

≤ 2[εT +

T

∑

s=t

(εs + Ksδs)].

Approximate dynamic programming using AIS

Approx. info. state–(Subramanian and Mahajan)

12

Consider an MDP with state space 𝒴 and per-step reward Rt = r(Xt, Ut). Suppose 𝒴 is quantized to a discrete set 𝒶 using φ∶ 𝒴 → 𝒶. Let z = φ(x) denote the label for x. Then φ−1(z) denote all states which have label z. {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

(x,u)∈𝒴×𝒱|r(x, u) − r(φ(x), u)|

r, equivalently, r(⋅, u) has a 𝔊-cosntant Kr

δ = sup

(x,u)∈𝒴×𝒱

d𝔊(ℙ(X+ | X = x, U = u), ℙ(X+ | X ∈ φ−1(φ(x)), U = u)).

r, equivalently, ℙ(X+|X = ⋅, U = u) has a 𝔊-constant of Kd.

Example 1: Error bounds on state aggregation

Bertsekas, “Convergence of discretization procedures in dynamic programming,” 1975.

Approx. info. state–(Subramanian and Mahajan)

13

Proposed as a heuristic algorithms No performance bounds {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

ht,ut|𝔽[Rt|ht, ut] − ˜

Rt(φt(ht), ut)| δ = sup

ht,ut

d𝔊(ℙ(ˆ Yt+1|ht, ut), ℙ(ˆ Yt+1|φt(ht), ut))

Example 2: Approximation bounds for using quantized obs.

Ha, Schmidhuber, “World Models”, 2018.

Video observation Vision Vision Memory RL agent Yt ˆ Yt Zt

SLIDE 68

Approx. info. state–(Subramanian and Mahajan)

23

Summary

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut). Same complexity as identifying the state suffjcient for forecasting outputs for the case of perfect observations (which was Step 1 for belief state formulations)

KEY QUESTIONS

Can this be used for dynamic programming? What is the right notion of approximations in this framework?

Now let’s consturct the state space

Approx. info. state–(Subramanian and Mahajan)

9

(ε, δ)-APPROXIMATE INFORMATION STATE (AIS) Given a function class 𝔊, a compression {Zt}t≥1 of history (i.e., Zt = φt(Ht)) is called an {(εt, δt)}t≥1 AIS if there exist: a function ˜ Rt(Zt, Ut), and a stochastic kernel νt(Zt+1|Zt, Ut) such that |𝔽[Rt|Ht = ht, Ut = ut] − ˜ Rt(φt(ht), ut)| ≤ εt For any Borel set A of 𝒶t, defjne μt(A) = ℙ(Zt+1 ∈ A | Ht = ht, Ut = ut) Then, d𝔊(μt, νt(⋅ |φt(ht), ut)) ≤ δt.

Approximate information state

Approx. info. state–(Subramanian and Mahajan)

10 MAIN THEOREM

Given a function class 𝔊, let {Zt}t≥1, where Zt = φt(Ht), be an {(εt, δt)}t≥1 AIS. Recursively defjne the following functions: ˆ VT+1(zT+1) = 0 and for t ∈ {T, . . . , 1}: ˆ Vt(zt) = max

ut∈𝒱{˜

Rt(zt, ut) + ∫ Vt+1(zt+1)νt(dzt+1 | zt, ut)}. Let π = (π1, . . . , πT) denote the corresponding policy. Then, if the value function ˆ Vt has 𝔊-constant Kt, then for any history ht, |Vt(ht) − ˆ Vt(φt(ht))| ≤ εT +

T

∑

s=t

(εs + Ksδs). for any history ht, |Vt(ht) − Vπ

t (ht)|

≤ 2[εT +

T

∑

s=t

(εs + Ksδs)].

Approximate dynamic programming using AIS

Approx. info. state–(Subramanian and Mahajan)

12

Consider an MDP with state space 𝒴 and per-step reward Rt = r(Xt, Ut). Suppose 𝒴 is quantized to a discrete set 𝒶 using φ∶ 𝒴 → 𝒶. Let z = φ(x) denote the label for x. Then φ−1(z) denote all states which have label z. {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

(x,u)∈𝒴×𝒱|r(x, u) − r(φ(x), u)|

r, equivalently, r(⋅, u) has a 𝔊-cosntant Kr

δ = sup

(x,u)∈𝒴×𝒱

d𝔊(ℙ(X+ | X = x, U = u), ℙ(X+ | X ∈ φ−1(φ(x)), U = u)).

r, equivalently, ℙ(X+|X = ⋅, U = u) has a 𝔊-constant of Kd.

Example 1: Error bounds on state aggregation

Bertsekas, “Convergence of discretization procedures in dynamic programming,” 1975.

Approx. info. state–(Subramanian and Mahajan)

13

Proposed as a heuristic algorithms No performance bounds {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

ht,ut|𝔽[Rt|ht, ut] − ˜

Rt(φt(ht), ut)| δ = sup

ht,ut

d𝔊(ℙ(ˆ Yt+1|ht, ut), ℙ(ˆ Yt+1|φt(ht), ut))

Example 2: Approximation bounds for using quantized obs.

Ha, Schmidhuber, “World Models”, 2018.

Video observation Vision Vision Memory RL agent Yt ˆ Yt Zt

Approx. info. state–(Subramanian and Mahajan)

14

n agents: state Xi

t, control Ui t.

Dynamics ℙ(𝐘t+1|𝐘t, 𝐕t) =

n

∏

i=1

P(Xi

t+1|Xi t, Ui t, Mt)

Per-step reward R(𝐘t, 𝐕t) = 1 n

n

∑

i=1

r(Xi

t, Ui t, Mt)

Empirical mean-fjeld: Mt(x) = 1 n

n

∑

i=1

δXi

t(x).

Statistical mean-fjeld: ¯ mt(x) = ℙ(Xi

t = x).

Info structure: Ii

t = {Xi t}.

Expanded info structure: ˜ Ii

t = {Xi t, Mt}.

𝒦∗ ≤ ˜ 𝒦∗, ˜ 𝒦∗ − ¯ 𝒦∗ ≤ K/√n ¯ 𝒦∗ ≤ 𝒦∗ ≤ ¯ 𝒦∗ + K/√n. (A) r(x, u, m) and P(y|x, u, m) are Lipschitz in m. { ¯ mt}t≥1 is an (ε, δ) AIS for expanded info structure, where ε, δ ∈ 𝒫(1/√n).

Example 3: Approximation bounds for mean-field teams

SLIDE 69

Approx. info. state–(Subramanian and Mahajan)

23

Summary

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut). Same complexity as identifying the state suffjcient for forecasting outputs for the case of perfect observations (which was Step 1 for belief state formulations)

KEY QUESTIONS

Can this be used for dynamic programming? What is the right notion of approximations in this framework?

Now let’s consturct the state space

Approx. info. state–(Subramanian and Mahajan)

9

(ε, δ)-APPROXIMATE INFORMATION STATE (AIS) Given a function class 𝔊, a compression {Zt}t≥1 of history (i.e., Zt = φt(Ht)) is called an {(εt, δt)}t≥1 AIS if there exist: a function ˜ Rt(Zt, Ut), and a stochastic kernel νt(Zt+1|Zt, Ut) such that |𝔽[Rt|Ht = ht, Ut = ut] − ˜ Rt(φt(ht), ut)| ≤ εt For any Borel set A of 𝒶t, defjne μt(A) = ℙ(Zt+1 ∈ A | Ht = ht, Ut = ut) Then, d𝔊(μt, νt(⋅ |φt(ht), ut)) ≤ δt.

Approximate information state

Approx. info. state–(Subramanian and Mahajan)

10 MAIN THEOREM

Given a function class 𝔊, let {Zt}t≥1, where Zt = φt(Ht), be an {(εt, δt)}t≥1 AIS. Recursively defjne the following functions: ˆ VT+1(zT+1) = 0 and for t ∈ {T, . . . , 1}: ˆ Vt(zt) = max

ut∈𝒱{˜

Rt(zt, ut) + ∫ Vt+1(zt+1)νt(dzt+1 | zt, ut)}. Let π = (π1, . . . , πT) denote the corresponding policy. Then, if the value function ˆ Vt has 𝔊-constant Kt, then for any history ht, |Vt(ht) − ˆ Vt(φt(ht))| ≤ εT +

T

∑

s=t

(εs + Ksδs). for any history ht, |Vt(ht) − Vπ

t (ht)|

≤ 2[εT +

T

∑

s=t

(εs + Ksδs)].

Approximate dynamic programming using AIS

Approx. info. state–(Subramanian and Mahajan)

12

Consider an MDP with state space 𝒴 and per-step reward Rt = r(Xt, Ut). Suppose 𝒴 is quantized to a discrete set 𝒶 using φ∶ 𝒴 → 𝒶. Let z = φ(x) denote the label for x. Then φ−1(z) denote all states which have label z. {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

(x,u)∈𝒴×𝒱|r(x, u) − r(φ(x), u)|

r, equivalently, r(⋅, u) has a 𝔊-cosntant Kr

δ = sup

(x,u)∈𝒴×𝒱

d𝔊(ℙ(X+ | X = x, U = u), ℙ(X+ | X ∈ φ−1(φ(x)), U = u)).

r, equivalently, ℙ(X+|X = ⋅, U = u) has a 𝔊-constant of Kd.

Example 1: Error bounds on state aggregation

Bertsekas, “Convergence of discretization procedures in dynamic programming,” 1975.

Approx. info. state–(Subramanian and Mahajan)

13

Proposed as a heuristic algorithms No performance bounds {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

ht,ut|𝔽[Rt|ht, ut] − ˜

Rt(φt(ht), ut)| δ = sup

ht,ut

d𝔊(ℙ(ˆ Yt+1|ht, ut), ℙ(ˆ Yt+1|φt(ht), ut))

Example 2: Approximation bounds for using quantized obs.

Ha, Schmidhuber, “World Models”, 2018.

Video observation Vision Vision Memory RL agent Yt ˆ Yt Zt

Approx. info. state–(Subramanian and Mahajan)

14

n agents: state Xi

t, control Ui t.

Dynamics ℙ(𝐘t+1|𝐘t, 𝐕t) =

n

∏

i=1

P(Xi

t+1|Xi t, Ui t, Mt)

Per-step reward R(𝐘t, 𝐕t) = 1 n

n

∑

i=1

r(Xi

t, Ui t, Mt)

Empirical mean-fjeld: Mt(x) = 1 n

n

∑

i=1

δXi

t(x).

Statistical mean-fjeld: ¯ mt(x) = ℙ(Xi

t = x).

Info structure: Ii

t = {Xi t}.

Expanded info structure: ˜ Ii

t = {Xi t, Mt}.

𝒦∗ ≤ ˜ 𝒦∗, ˜ 𝒦∗ − ¯ 𝒦∗ ≤ K/√n ¯ 𝒦∗ ≤ 𝒦∗ ≤ ¯ 𝒦∗ + K/√n. (A) r(x, u, m) and P(y|x, u, m) are Lipschitz in m. { ¯ mt}t≥1 is an (ε, δ) AIS for expanded info structure, where ε, δ ∈ 𝒫(1/√n).

Example 3: Approximation bounds for mean-field teams

Approx. info. state–(Subramanian and Mahajan)

18

𝟓 × 𝟓 Grid Environment

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Samples ×106 1 2 3 4 5 Performance Planning solution RPG AIS

SLIDE 70

Approx. info. state–(Subramanian and Mahajan)

23

Summary

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut). Same complexity as identifying the state suffjcient for forecasting outputs for the case of perfect observations (which was Step 1 for belief state formulations)

KEY QUESTIONS

Can this be used for dynamic programming? What is the right notion of approximations in this framework?

Now let’s consturct the state space

Approx. info. state–(Subramanian and Mahajan)

9

(ε, δ)-APPROXIMATE INFORMATION STATE (AIS) Given a function class 𝔊, a compression {Zt}t≥1 of history (i.e., Zt = φt(Ht)) is called an {(εt, δt)}t≥1 AIS if there exist: a function ˜ Rt(Zt, Ut), and a stochastic kernel νt(Zt+1|Zt, Ut) such that |𝔽[Rt|Ht = ht, Ut = ut] − ˜ Rt(φt(ht), ut)| ≤ εt For any Borel set A of 𝒶t, defjne μt(A) = ℙ(Zt+1 ∈ A | Ht = ht, Ut = ut) Then, d𝔊(μt, νt(⋅ |φt(ht), ut)) ≤ δt.

Approximate information state

Approx. info. state–(Subramanian and Mahajan)

10 MAIN THEOREM

Given a function class 𝔊, let {Zt}t≥1, where Zt = φt(Ht), be an {(εt, δt)}t≥1 AIS. Recursively defjne the following functions: ˆ VT+1(zT+1) = 0 and for t ∈ {T, . . . , 1}: ˆ Vt(zt) = max

ut∈𝒱{˜

Rt(zt, ut) + ∫ Vt+1(zt+1)νt(dzt+1 | zt, ut)}. Let π = (π1, . . . , πT) denote the corresponding policy. Then, if the value function ˆ Vt has 𝔊-constant Kt, then for any history ht, |Vt(ht) − ˆ Vt(φt(ht))| ≤ εT +

T

∑

s=t

(εs + Ksδs). for any history ht, |Vt(ht) − Vπ

t (ht)|

≤ 2[εT +

T

∑

s=t

(εs + Ksδs)].

Approximate dynamic programming using AIS

Approx. info. state–(Subramanian and Mahajan)

12

Consider an MDP with state space 𝒴 and per-step reward Rt = r(Xt, Ut). Suppose 𝒴 is quantized to a discrete set 𝒶 using φ∶ 𝒴 → 𝒶. Let z = φ(x) denote the label for x. Then φ−1(z) denote all states which have label z. {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

(x,u)∈𝒴×𝒱|r(x, u) − r(φ(x), u)|

r, equivalently, r(⋅, u) has a 𝔊-cosntant Kr

δ = sup

(x,u)∈𝒴×𝒱

d𝔊(ℙ(X+ | X = x, U = u), ℙ(X+ | X ∈ φ−1(φ(x)), U = u)).

r, equivalently, ℙ(X+|X = ⋅, U = u) has a 𝔊-constant of Kd.

Example 1: Error bounds on state aggregation

Bertsekas, “Convergence of discretization procedures in dynamic programming,” 1975.

Approx. info. state–(Subramanian and Mahajan)

13

Proposed as a heuristic algorithms No performance bounds {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

ht,ut|𝔽[Rt|ht, ut] − ˜

Rt(φt(ht), ut)| δ = sup

ht,ut

d𝔊(ℙ(ˆ Yt+1|ht, ut), ℙ(ˆ Yt+1|φt(ht), ut))

Example 2: Approximation bounds for using quantized obs.

Ha, Schmidhuber, “World Models”, 2018.

Video observation Vision Vision Memory RL agent Yt ˆ Yt Zt

Approx. info. state–(Subramanian and Mahajan)

14

n agents: state Xi

t, control Ui t.

Dynamics ℙ(𝐘t+1|𝐘t, 𝐕t) =

n

∏

i=1

P(Xi

t+1|Xi t, Ui t, Mt)

Per-step reward R(𝐘t, 𝐕t) = 1 n

n

∑

i=1

r(Xi

t, Ui t, Mt)

Empirical mean-fjeld: Mt(x) = 1 n

n

∑

i=1

δXi

t(x).

Statistical mean-fjeld: ¯ mt(x) = ℙ(Xi

t = x).

Info structure: Ii

t = {Xi t}.

Expanded info structure: ˜ Ii

t = {Xi t, Mt}.

𝒦∗ ≤ ˜ 𝒦∗, ˜ 𝒦∗ − ¯ 𝒦∗ ≤ K/√n ¯ 𝒦∗ ≤ 𝒦∗ ≤ ¯ 𝒦∗ + K/√n. (A) r(x, u, m) and P(y|x, u, m) are Lipschitz in m. { ¯ mt}t≥1 is an (ε, δ) AIS for expanded info structure, where ε, δ ∈ 𝒫(1/√n).

Example 3: Approximation bounds for mean-field teams

Approx. info. state–(Subramanian and Mahajan)

18

𝟓 × 𝟓 Grid Environment

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Samples ×106 1 2 3 4 5 Performance Planning solution RPG AIS

Approx. info. state–(Subramanian and Mahajan)

20

Tiger Environment

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Samples ×106 −40 −30 −20 −10 10 20 Performance Planning solution RPG AIS

SLIDE 71

Approx. info. state–(Subramanian and Mahajan)

23

Summary

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut). Same complexity as identifying the state suffjcient for forecasting outputs for the case of perfect observations (which was Step 1 for belief state formulations)

KEY QUESTIONS

Can this be used for dynamic programming? What is the right notion of approximations in this framework?

Now let’s consturct the state space

Approx. info. state–(Subramanian and Mahajan)

9

(ε, δ)-APPROXIMATE INFORMATION STATE (AIS) Given a function class 𝔊, a compression {Zt}t≥1 of history (i.e., Zt = φt(Ht)) is called an {(εt, δt)}t≥1 AIS if there exist: a function ˜ Rt(Zt, Ut), and a stochastic kernel νt(Zt+1|Zt, Ut) such that |𝔽[Rt|Ht = ht, Ut = ut] − ˜ Rt(φt(ht), ut)| ≤ εt For any Borel set A of 𝒶t, defjne μt(A) = ℙ(Zt+1 ∈ A | Ht = ht, Ut = ut) Then, d𝔊(μt, νt(⋅ |φt(ht), ut)) ≤ δt.

Approximate information state

Approx. info. state–(Subramanian and Mahajan)

10 MAIN THEOREM

Given a function class 𝔊, let {Zt}t≥1, where Zt = φt(Ht), be an {(εt, δt)}t≥1 AIS. Recursively defjne the following functions: ˆ VT+1(zT+1) = 0 and for t ∈ {T, . . . , 1}: ˆ Vt(zt) = max

ut∈𝒱{˜

Rt(zt, ut) + ∫ Vt+1(zt+1)νt(dzt+1 | zt, ut)}. Let π = (π1, . . . , πT) denote the corresponding policy. Then, if the value function ˆ Vt has 𝔊-constant Kt, then for any history ht, |Vt(ht) − ˆ Vt(φt(ht))| ≤ εT +

T

∑

s=t

(εs + Ksδs). for any history ht, |Vt(ht) − Vπ

t (ht)|

≤ 2[εT +

T

∑

s=t

(εs + Ksδs)].

Approximate dynamic programming using AIS

Approx. info. state–(Subramanian and Mahajan)

12

Consider an MDP with state space 𝒴 and per-step reward Rt = r(Xt, Ut). Suppose 𝒴 is quantized to a discrete set 𝒶 using φ∶ 𝒴 → 𝒶. Let z = φ(x) denote the label for x. Then φ−1(z) denote all states which have label z. {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

(x,u)∈𝒴×𝒱|r(x, u) − r(φ(x), u)|

r, equivalently, r(⋅, u) has a 𝔊-cosntant Kr

δ = sup

(x,u)∈𝒴×𝒱

d𝔊(ℙ(X+ | X = x, U = u), ℙ(X+ | X ∈ φ−1(φ(x)), U = u)).

r, equivalently, ℙ(X+|X = ⋅, U = u) has a 𝔊-constant of Kd.

Example 1: Error bounds on state aggregation

Bertsekas, “Convergence of discretization procedures in dynamic programming,” 1975.

Approx. info. state–(Subramanian and Mahajan)

13

Proposed as a heuristic algorithms No performance bounds {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

ht,ut|𝔽[Rt|ht, ut] − ˜

Rt(φt(ht), ut)| δ = sup

ht,ut

d𝔊(ℙ(ˆ Yt+1|ht, ut), ℙ(ˆ Yt+1|φt(ht), ut))

Example 2: Approximation bounds for using quantized obs.

Ha, Schmidhuber, “World Models”, 2018.

Video observation Vision Vision Memory RL agent Yt ˆ Yt Zt

Approx. info. state–(Subramanian and Mahajan)

14

n agents: state Xi

t, control Ui t.

Dynamics ℙ(𝐘t+1|𝐘t, 𝐕t) =

n

∏

i=1

P(Xi

t+1|Xi t, Ui t, Mt)

Per-step reward R(𝐘t, 𝐕t) = 1 n

n

∑

i=1

r(Xi

t, Ui t, Mt)

Empirical mean-fjeld: Mt(x) = 1 n

n

∑

i=1

δXi

t(x).

Statistical mean-fjeld: ¯ mt(x) = ℙ(Xi

t = x).

Info structure: Ii

t = {Xi t}.

Expanded info structure: ˜ Ii

t = {Xi t, Mt}.

𝒦∗ ≤ ˜ 𝒦∗, ˜ 𝒦∗ − ¯ 𝒦∗ ≤ K/√n ¯ 𝒦∗ ≤ 𝒦∗ ≤ ¯ 𝒦∗ + K/√n. (A) r(x, u, m) and P(y|x, u, m) are Lipschitz in m. { ¯ mt}t≥1 is an (ε, δ) AIS for expanded info structure, where ε, δ ∈ 𝒫(1/√n).

Example 3: Approximation bounds for mean-field teams

Approx. info. state–(Subramanian and Mahajan)

18

𝟓 × 𝟓 Grid Environment

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Samples ×106 1 2 3 4 5 Performance Planning solution RPG AIS

Approx. info. state–(Subramanian and Mahajan)

20

Tiger Environment

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Samples ×106 −40 −30 −20 −10 10 20 Performance Planning solution RPG AIS

Approx. info. state–(Subramanian and Mahajan)

22

Cheese Maze Environment

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Samples ×106 0.0 0.1 0.2 0.3 0.4 0.5 0.6 Performance Planning solution RPG AIS

SLIDE 72

Approx. info. state–(Subramanian and Mahajan)

23

Summary

Approx. info. state–(Subramanian and Mahajan)

5 FORECASTING OUTPUTS IN DISTRIBUTION

H(1)

t

∼ H(2)

t

if for all future CONTROL inputs Ut:T, ℙ(Y(1)

t:T | H(1) t

, Ut:T) = ℙ(Y(2)

t:T | H(2) t

, Ut:T)

PROPERTIES OF INFORMATION STATE

The info state Zt at time t is a “compression”

f past inputs that satisfjes the following:

SUFFICIENT TO PREDICT ITSELF:

ℙ(Zt+1 | Ht, Ut) = ℙ(Zt+1 | Zt, Ut).

SUFFICIENT TO PREDICT OUTPUT:

ℙ(Yt | Ht, Ut) = ℙ(Yt | Zt, Ut). Same complexity as identifying the state suffjcient for forecasting outputs for the case of perfect observations (which was Step 1 for belief state formulations)

KEY QUESTIONS

Can this be used for dynamic programming? What is the right notion of approximations in this framework?

Now let’s consturct the state space

Approx. info. state–(Subramanian and Mahajan)

9

(ε, δ)-APPROXIMATE INFORMATION STATE (AIS) Given a function class 𝔊, a compression {Zt}t≥1 of history (i.e., Zt = φt(Ht)) is called an {(εt, δt)}t≥1 AIS if there exist: a function ˜ Rt(Zt, Ut), and a stochastic kernel νt(Zt+1|Zt, Ut) such that |𝔽[Rt|Ht = ht, Ut = ut] − ˜ Rt(φt(ht), ut)| ≤ εt For any Borel set A of 𝒶t, defjne μt(A) = ℙ(Zt+1 ∈ A | Ht = ht, Ut = ut) Then, d𝔊(μt, νt(⋅ |φt(ht), ut)) ≤ δt.

Approximate information state

Approx. info. state–(Subramanian and Mahajan)

10 MAIN THEOREM

Given a function class 𝔊, let {Zt}t≥1, where Zt = φt(Ht), be an {(εt, δt)}t≥1 AIS. Recursively defjne the following functions: ˆ VT+1(zT+1) = 0 and for t ∈ {T, . . . , 1}: ˆ Vt(zt) = max

ut∈𝒱{˜

Rt(zt, ut) + ∫ Vt+1(zt+1)νt(dzt+1 | zt, ut)}. Let π = (π1, . . . , πT) denote the corresponding policy. Then, if the value function ˆ Vt has 𝔊-constant Kt, then for any history ht, |Vt(ht) − ˆ Vt(φt(ht))| ≤ εT +

T

∑

s=t

(εs + Ksδs). for any history ht, |Vt(ht) − Vπ

t (ht)|

≤ 2[εT +

T

∑

s=t

(εs + Ksδs)].

Approximate dynamic programming using AIS

Approx. info. state–(Subramanian and Mahajan)

12

Consider an MDP with state space 𝒴 and per-step reward Rt = r(Xt, Ut). Suppose 𝒴 is quantized to a discrete set 𝒶 using φ∶ 𝒴 → 𝒶. Let z = φ(x) denote the label for x. Then φ−1(z) denote all states which have label z. {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

(x,u)∈𝒴×𝒱|r(x, u) − r(φ(x), u)|

r, equivalently, r(⋅, u) has a 𝔊-cosntant Kr

δ = sup

(x,u)∈𝒴×𝒱

d𝔊(ℙ(X+ | X = x, U = u), ℙ(X+ | X ∈ φ−1(φ(x)), U = u)).

r, equivalently, ℙ(X+|X = ⋅, U = u) has a 𝔊-constant of Kd.

Example 1: Error bounds on state aggregation

Bertsekas, “Convergence of discretization procedures in dynamic programming,” 1975.

Approx. info. state–(Subramanian and Mahajan)

13

Proposed as a heuristic algorithms No performance bounds {Zt}t≥1 IS AN (ε, δ) AIS ε = sup

ht,ut|𝔽[Rt|ht, ut] − ˜

Rt(φt(ht), ut)| δ = sup

ht,ut

d𝔊(ℙ(ˆ Yt+1|ht, ut), ℙ(ˆ Yt+1|φt(ht), ut))

Example 2: Approximation bounds for using quantized obs.

Ha, Schmidhuber, “World Models”, 2018.

Video observation Vision Vision Memory RL agent Yt ˆ Yt Zt

Approx. info. state–(Subramanian and Mahajan)

14

n agents: state Xi

t, control Ui t.

Dynamics ℙ(𝐘t+1|𝐘t, 𝐕t) =

n

∏

i=1

P(Xi

t+1|Xi t, Ui t, Mt)

Per-step reward R(𝐘t, 𝐕t) = 1 n

n

∑

i=1

r(Xi

t, Ui t, Mt)

Empirical mean-fjeld: Mt(x) = 1 n

n

∑

i=1

δXi

t(x).

Statistical mean-fjeld: ¯ mt(x) = ℙ(Xi

t = x).

Info structure: Ii

t = {Xi t}.

Expanded info structure: ˜ Ii

t = {Xi t, Mt}.

𝒦∗ ≤ ˜ 𝒦∗, ˜ 𝒦∗ − ¯ 𝒦∗ ≤ K/√n ¯ 𝒦∗ ≤ 𝒦∗ ≤ ¯ 𝒦∗ + K/√n. (A) r(x, u, m) and P(y|x, u, m) are Lipschitz in m. { ¯ mt}t≥1 is an (ε, δ) AIS for expanded info structure, where ε, δ ∈ 𝒫(1/√n).

Example 3: Approximation bounds for mean-field teams

Approx. info. state–(Subramanian and Mahajan)

18

𝟓 × 𝟓 Grid Environment

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Samples ×106 1 2 3 4 5 Performance Planning solution RPG AIS

Approx. info. state–(Subramanian and Mahajan)

20

Tiger Environment

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Samples ×106 −40 −30 −20 −10 10 20 Performance Planning solution RPG AIS

Approx. info. state–(Subramanian and Mahajan)

22

Cheese Maze Environment

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 Samples ×106 0.0 0.1 0.2 0.3 0.4 0.5 0.6 Performance Planning solution RPG AIS

AIS provides a conceptually clean framework for approximate DP and

nline RL in partially observed systems
