Application-level Firewalling with eBPF Alexander Kurtz September 18, 2017 Problem statement Server applications generally bind(2) to the wildcard address Most dont actually need all packets from everywhere but Firewalling is a

slide-1
SLIDE 1

Application-level Firewalling with eBPF

Alexander Kurtz September 18, 2017

slide-2
SLIDE 2

Problem statement

◮ Server applications generally bind(2) to the wildcard address ◮ Most don’t actually need all packets from everywhere

but

◮ Firewalling is a system-wide and root-only operation ◮ No plugin-mechanism to install application-specific rules ◮ Even if there where, we would still need root priviledges

slide-3
SLIDE 3

Motivation

What if we could install firewalling rules onto an application socket?

◮ Application developers could ship default rules with their

program

◮ Users would have a generic way to control the network

exposure of their applications

◮ Everything would be nicely isolated, no need for complex,

system-wide rules

slide-4
SLIDE 4

Solution (1/3): eBPF

◮ eBPF is a general purpose VM in the Linux kernel ◮ eBPF bytecode can be attached to a socket to filter incoming

packets

◮ communication with user-space and local state possible with

eBPF maps

◮ arbitrary code execution in kernel-space, yet secure™ ◮ many other applications, e.g. tracing, load-balancing, . . .

slide-5
SLIDE 5

Solution (2/3): bcc

◮ eBPF is byte code (although very high level) ◮ eBPF maps are file descriptors ◮ byte code needs to embed the value of these file descriptors ◮ did I mention you’ll have to write assembly?

bcc:

◮ LLVM/clang has a backend for eBPF ◮ bcc makes this available as an easy-to-use library

slide-6
SLIDE 6

Solution (3/3): systemd socket activation

Old inetd-style socket activation:

◮ inetd calls bind(), listen(), and accept() ◮ the connection socket gets passed to the application as

stdin/stdout

◮ nice and simple, but also not very fast

New systemd-style socket activation

◮ systemd calls bind() and listen() ◮ the listening socket gets passed to the application as FD 3 ◮ still have dynamic server startup, but no performance penalty

slide-7
SLIDE 7

Summary

  • 1. Write an eBPF filter in C
  • 2. Create a server socket / (take server socket from systemd)
  • 3. Load and attach filter to socket with bcc
  • 4. Pass socket to application via systemd socket activation
slide-8
SLIDE 8

Overview

I n t e r n e t N e t w

  • r

k

  • l

e v e l F i r e w a l l T C P / U D P P

  • r

t s S y s t e m

  • l

e v e l F i r e w a l l A p p l i c a t i

  • n
  • l

e v e l F i r e w a l l H

  • s

t A p p l i c a t i

  • n
  • l

e v e l F i r e w a l l A p p l i c a t i

  • n
  • l

e v e l F i r e w a l l A p p l i c a t i

  • n

A p p l i c a t i

  • n

A p p l i c a t i

  • n

A p p l i c a t i

  • n
  • l

e v e l F i r e w a l l A p p l i c a t i

  • n
  • s

p e c i f i c r u l e s w r i t t e n i n C e B P F B y t e c

  • d

e A p p l i c a t i

  • n

S

  • c

k e t F

  • r

w a r d p a c k e t t

  • a

p p l i c a t i

  • n

D r

  • p

p a c k e t L L V M / B C C A t t a c h a s f i l t e r K e r n e l V M

s y s t e m d S

  • c

k e t P a s s i n g s y s t e m d S

  • c

k e t P a s s i n g s y s t e m d S

  • c

k e t P a s s i n g

Figure 1: Overview

slide-9
SLIDE 9

Demo

A generic port-knocking filter

slide-10
SLIDE 10

Questions

Questions?
