APPENDIX 4: STAKEHOLDER MEETING PRESENTATION DECK George Massey Tunnel Replacement Project PHASE 3 CONSULTATION Project Definition Report 16 Dec 2015 28 Jan 2016 2 Overview New 3.3 km bridge Cost: $3.5 billion (8 lanes plus 2

slide-1
SLIDE 1

APPENDIX 4: STAKEHOLDER MEETING PRESENTATION DECK

slide-2
SLIDE 2
slide-3
SLIDE 3

George Massey Tunnel Replacement Project

PHASE 3 CONSULTATION Project Definition Report

16 Dec 2015 – 28 Jan 2016

slide-4
SLIDE 4

New 3.3 km bridge

(8 lanes plus 2 transit/HOV lanes)

Replace 3 key interchanges 24 km of Highway 99 improvements 50 km of dedicated transit/HOV lanes

(transit priority to Canada Line at Bridgeport)

Bike and pedestrian pathway Allow for future rapid transit Decommission Tunnel

Cost: $3.5 billion Benefit/Cost Ratio: 2.1 to 1 Funding: Funded through user tolls

Overview

30-year public private partnership Procurement to begin in 2016

2

slide-5
SLIDE 5

Project Chronology

2013 2014-2015 2012

November: Phase 1 Consultation (understanding the need) March: Phase 2 Consultation (exploring the options); technical work September: New bridge within the existing corridor announced, subject to a Project Definition Report and Business Case Technical work; cost estimate; business case analysis Consultation with municipalities, stakeholders and First Nations Alternative Corridor Studies

1991-1995 2001/2004

Tunnel Seismic Reviews

3

slide-6
SLIDE 6

Condition of Existing Tunnel

4

Opened in 1959 Designed to highway standards of the 1950s Electrical/mechanical system is 50+ years 30+ year old counterflow system Partial seismic upgrade completed spring 2006 Vulnerable to seismic event; 1950s approach Additional seismic upgrades are high risk

slide-7
SLIDE 7

George Massey Tunnel

40%

Vancouver

59%

Richmond

1%

Burnaby/ New Westminster

19%

North Delta/Surrey

8%

Tilbury

2%

Deltaport

19%

Tsawwassen

17%

Ladner

35%

U.S. Border/ White Rock/ South Surrey ORIGIN DESTINATION

Traffic Analysis: Northbound Traffic

slide-8
SLIDE 8

George Massey Tunnel

34%

Vancouver

65%

Richmond

1%

Burnaby/ New Westminster

21%

North Delta/Surrey

7%

Tilbury

36%

U.S. Border/ White Rock/ South Surrey

34%

Ladner/ Tsawwassen

2%

Deltaport

Traffic Analysis: Southbound Traffic

ORIGIN DESTINATION

slide-9
SLIDE 9

Project Goals

Improve safety Reduce congestion Enhance the Environment Support improved transit on Hwy 99 Support trade and commerce Support options for pedestrians and cyclists

7

slide-10
SLIDE 10

Project Scope

8

Bridgeport Road to Highway 91

  • 200 lane km of roadway
  • 50 km of new dedicated

transit/HOV lanes

  • Replace 3 interchanges
  • Construct new bridge
  • Replace 5 overpasses
  • Decommission Tunnel
slide-11
SLIDE 11

New Bridge Scope

9

slide-12
SLIDE 12

Major Bridges in the Lower Mainland

10

3.3 km long 660 m clear span over the Fraser River 200 m high towers Design for future rapid transit

slide-13
SLIDE 13

1 Dedicated transit/HOV lanes 3 Regular traffic lanes

(same as today in rush hour)

1 Lane for slow, merging traffic

Benefits:

  • Improved merging safety
  • Reduced weaving
  • Reduced congestion/increased

reliability

  • Improved emergency response

access

Why Five Lanes in Each Direction?

11

Four lanes in each direction would result in congestion on

  • pening day
slide-14
SLIDE 14

50 LANE KILOMETRES OF DEDICATED/MEDIAN TRANSIT LANES

Project Scope – Transit

12

Dedicated Transit connection between Highway 99 and Bridgeport Canada Line Station Integrated Transit Stop: Steveston Highway Integrated Transit Stop: Highway 17A

RICHMOND DEL DELTA A

slide-15
SLIDE 15

Shell Road

  • Improved access from Odlin Street,

parallel to Highway 99

  • Improved cross Highway 99 access

Westminster Highway

  • Improved cross Highway 99 access

Steveston Highway

  • Improved cross Highway 99 access

(south side only)

  • Access to new crossing from both sides
  • f Highway 99
  • Improved access to Rice Mill Road and

Dyke Trail

  • Access to median transit stop platforms

River Road

  • Access to new crossing from both sides
  • f Highway 99 via River Road and 64th
  • Improved access to Millennium Trail

Project Scope – Cycling and Pedestrian Access

13

slide-16
SLIDE 16

Benefit/Cost Analysis

  • User Benefits:
  • Congestion reduction, travel time savings, improved

reliability, vehicle operating cost savings

  • Traffic safety (35% reduction in collisions)
  • Reduced seismic risk
  • Cyclist/pedestrian, transit, marine traffic

improvements

  • Long-term Economic Benefits

14

Cost: $3.5 billion Benefit/Cost Ratio: 2.1 to 1

slide-17
SLIDE 17

Why Tolling?

  • Significant benefits for those using the

new Bridge

  • Allows project to proceed now, without

taking away from government funding for health and education

  • Similar format to Port Mann Bridge
  • Working with federal government on

potential contributions

15

slide-18
SLIDE 18

Anticipated Effects of Tolling New Crossing

16

TUNNEL TODAY

“Rush Hour” (6-8 hours):

  • The Tunnel and Alex Fraser

Bridge (AFB) are heavily congested Midday (6 hours):

  • Tunnel, AFB and Richmond

Connector near congestion; incident sensitive Overnight/Weekends:

  • Free-flowing traffic

WITH A NEW BRIDGE

Rush Hour:

  • New Bridge free-flowing
  • Traffic in queues at AFB will

move to new Bridge Midday:

  • Limited traffic diversion to

AFB due to congestion on East/West Connector Overnight/Weekends:

  • Some traffic diversion to AFB
slide-19
SLIDE 19

Environmental Benefits

17

  • Transit enhancements to increase ridership
  • Multi-use pathway to encourage cycling/walking
  • Less idling; reduced GHG emissions
  • Restoring Green Slough to historic alignment
  • Bio-filtration marshes for stormwater

management

  • Environmental enhancements in Deas Slough
  • Improvements to Millennium Trail
slide-20
SLIDE 20

What Happens at the Oak Street Bridge?

  • Morning queues will continue as today; traffic patterns may

change somewhat but no significant change in total traffic

  • 60% of tunnel users end their trip in Richmond
  • Efficiency of Oak Street Bridge will

continue to be governed by traffic lights at 70th Street

  • Traffic volumes on the Oak Street

Bridge have been relatively constant

  • r declining over the past decade

(Canada Line effect)

18

slide-21
SLIDE 21

Navigation/River Depth Effects

19

slide-22
SLIDE 22

PDR Consultation Topics

  • 1. Feedback on Project scope, including:
  • HOV and Transit lanes
  • New general purpose lanes
  • Multiuse pathway
  • 2. Suggestions for traffic management during construction
  • 3. Questions about upcoming environmental review
  • 4. Feedback on framework to evaluate project success
  • 5. Feedback on tolling as a funding source

20

slide-23
SLIDE 23

Project Definition Report

16 Dec – 28 Jan

  • Online:

masseytunnel.ca

  • In person:

Project Office in Richmond Open Houses

  • Email: masseytunnel@gov.bc.ca

EA Project Review

Part 1: 15 Jan – 15 Feb Part 2: Spring

  • Online:

http://www.eao.gov.bc.ca/pcp/ index.html

  • Mail:

Michael Shepard Project Assessment Manager Environmental Assessment Office PO Box 9426 Stn Prov Govt Victoria BC V8W 9V1

  • Fax: 250-387-0230

Current Consultation

21

slide-24
SLIDE 24

Open Houses

22

Tuesday, January 26, 2016

2:00 p.m. to 8:00 p.m. Sandman Signature Hotel Vancouver Airport Round Room 10251 St. Edwards Drive, Richmond BC

Wednesday, January 27, 2016

2:00 p.m. to 8:00 p.m. Delta Town & Country Inn Ballroom 6005 Highway 17A, Delta BC

slide-25
SLIDE 25

w: www.masseytunnel.ca t: 1-8-555-MASSEY e: masseytunnel@gov.bc.ca

Phase 3 Consultation December 16, 2015 to January 28, 2016 EA Comment Period January 15 to February 15, 2016 For more information:
