Apache HBase, the Scaling Machine

Jean-Daniel Cryans Software Engineer at Cloudera @jdcryans

Tuesday, June 18, 13

• Introduction to Apache HBase
• HBase at StumbleUpon
• Overview of other use cases

Agenda

2

Tuesday, June 18, 13

About le Moi

• At Cloudera since October 2012.
• At StumbleUpon for 3 years before that.
• Committer and PMC member for Apache HBase

since 2008.

• Living in San Francisco.
• From Québec, Canada.

3

Tuesday, June 18, 13

4

Tuesday, June 18, 13

What is Apache HBase

Apache HBase is an

• pen source

distributed scalable consistent low latency random access non-relational database built on Apache Hadoop

5

Tuesday, June 18, 13

Inspiration: Google BigTable (2006)

• Goal: Low latency, consistent, random read/

write access to massive amounts of structured data.

• It was the data store for Google’s crawler web

table, gmail, analytics, earth, blogger, …

6

Tuesday, June 18, 13

HBase is in Production

• Inbox
• Storage
• Web
• Search
• Analytics
• Monitoring

7

Tuesday, June 18, 13

HBase is in Production

• Inbox
• Storage
• Web
• Search
• Analytics
• Monitoring

7

Tuesday, June 18, 13

HBase is in Production

• Inbox
• Storage
• Web
• Search
• Analytics
• Monitoring

7

Tuesday, June 18, 13

HBase is in Production

• Inbox
• Storage
• Web
• Search
• Analytics
• Monitoring

7

Tuesday, June 18, 13

HBase is Open Source

• Apache 2.0 License
• A Community project with committers and

contributors from diverse organizations:

• Facebook, Cloudera, Salesforce.com, Huawei, eBay,

HortonWorks, Intel, Twitter …

• Code license means anyone can modify and use

the code.

8

Tuesday, June 18, 13

So why use HBase?

9

Tuesday, June 18, 13

10

Tuesday, June 18, 13

Old School Scaling

• Find a scaling problem.
• Beef up the machine.
• Repeat until you cannot find a big enough

machine or run out of funding.

11

=>

Tuesday, June 18, 13

“Get Rid of Everything” Scaling

• Remove text search queries (LIKE)
• Remove joins
• Joins due to Normalization require expensive seeks
• Remove foreign keys and encode your relations
• Avoid constraint checks
• Put all parts of a query in a single table.
• Use read slaves to scale reads.
• Shard to scale writes.

12

Tuesday, June 18, 13

We “optimized the DB” by discarding some fundamental SQL/relational databases features.

13

Tuesday, June 18, 13

HBase is Horizontally Scalable

• Adding more servers

linearly increases performance and capacity

• Storage capacity
• Input/output operations
• Store and access data
• n 1-1000’s

commodity servers

14

• Largest cluster:

>1000 nodes, >1PB

• Most clusters:

10-40 nodes, 100GB-4TB

Tuesday, June 18, 13

HBase is Consistent

• Brewer’s CAP theorem
• Consistency:
• DB-style ACID

guarantees on rows

• Availability:
• Favor recovering from

faults over returning stale data

• Partition Tolerance:
• If a node goes down,

the system continues.

15

Tuesday, June 18, 13

HBase Dependencies

• Apache Hadoop HDFS for data

durability and reliability (Write- Ahead Log).

• Apache ZooKeeper for distributed

coordination.

• Apache Hadoop MapReduce

support built-in support for running MapReduce jobs.

16

ZK HDFS App MR

Tuesday, June 18, 13

HBase on a Cluster

17

Tuesday, June 18, 13

Tables and Regions

18

Tuesday, June 18, 13

Load Distribution

19

RegionServer Region Region RegionServer Region

Tuesday, June 18, 13

Load Distribution

20

RegionServer Region Region RegionServer Region

This region is getting too big and afgects the balancing (more about writing in a moment)

Tuesday, June 18, 13

Load Distribution

21

RegionServer Region Region RegionServer Region

Let’s split the region in order to split the load

Tuesday, June 18, 13

Load Distribution

22

RegionServer Region RegionServer Region

Now that we have smaller pieces, it’s easier to move the load around

Region A Region B

Tuesday, June 18, 13

Load Distribution

23

RegionServer Region RegionServer Region

Region A Region B

No data was actually moved during this process, only its responsibility!

Tuesday, June 18, 13

24

The region is the unit of load distribution in HBase.

Tuesday, June 18, 13

25

So HBase can scale, but what about Hadoop?

Tuesday, June 18, 13

HDFS Data Allocation

26

Client Name node

Locations?

Tuesday, June 18, 13

HDFS Data Allocation

27

Client Data node Data node Data node Name node

Here you go

Tuesday, June 18, 13

HDFS Data Allocation

28

Client Data node Data node Data node Name node

Data is sent along the pipeline

Tuesday, June 18, 13

HDFS Data Allocation

29

Client Data node Data node Data node Name node

ACKs are sent back as soon as the data is in memory in the last node

Tuesday, June 18, 13

Machine

Putting it Together

30

Region server Data node Data node Data node Name node

Tuesday, June 18, 13

31

Data locality is extremely important for Hadoop and HBase.

Tuesday, June 18, 13

32

Scaling is just a matter of adding new nodes to the cluster.

Tuesday, June 18, 13

Sorted Map Datastore

33

Tuesday, June 18, 13

Sorted Map Datastore

34

Row key info:height info:state roles:hadoop roles:hbase cutting ‘9ft’ ‘CA’ ‘Founder’ tlipcon ‘5ft7’ ‘CA’ ‘PMC’ @ts=2011 ‘Committer’ @ts=2010 ‘Commiter’ Implicit PRIMARY KEY

Tuesday, June 18, 13

Sorted Map Datastore

35

Row key info:height info:state roles:hadoop roles:hbase cutting ‘9ft’ ‘CA’ ‘Founder’ tlipcon ‘5ft7’ ‘CA’ ‘PMC’ @ts=2011 ‘Committer’ @ts=2010 ‘Commiter’ Implicit PRIMARY KEY Format is family:qualifier

Tuesday, June 18, 13

Sorted Map Datastore

36

Row key info:height info:state roles:hadoop roles:hbase cutting ‘9ft’ ‘CA’ ‘Founder’ tlipcon ‘5ft7’ ‘CA’ ‘PMC’ @ts=2011 ‘Committer’ @ts=2010 ‘Commiter’ Implicit PRIMARY KEY Data is all byte[] in HBase Format is family:qualifier

Tuesday, June 18, 13

Sorted Map Datastore

37

Row key info:height info:state roles:hadoop roles:hbase cutting ‘9ft’ ‘CA’ ‘Founder’ tlipcon ‘5ft7’ ‘CA’ ‘PMC’ @ts=2011 ‘Committer’ @ts=2010 ‘Commiter’ Implicit PRIMARY KEY Data is all byte[] in HBase A single cell might have difgerent values at difgerent timestamps Format is family:qualifier

Tuesday, June 18, 13

Sorted Map Datastore

38

Row key info:height info:state roles:hadoop roles:hbase cutting ‘9ft’ ‘CA’ ‘Founder’ tlipcon ‘5ft7’ ‘CA’ ‘PMC’ @ts=2011 ‘Committer’ @ts=2010 ‘Commiter’ Implicit PRIMARY KEY Data is all byte[] in HBase A single cell might have difgerent values at difgerent timestamps Difgerent rows may have difgerent sets of columns (table is sparse) Format is family:qualifier

Tuesday, June 18, 13

Anatomy of a row

• Each row has a primary key
• Lexicographically sorted byte[]
• Timestamp associated for keeping multiple

versions of data (MVCC for consistency)

• Row is made up of columns.
• Each (row,column) referred to as a Cell
• Contents of a cell are all byte[]’s.
• Apps must “know” types and handle them.
• Rows are Strongly consistent.

39

Tuesday, June 18, 13

Access HBase data via an API

• Data operations
• Get
• Put
• Delete
• Scan
• Compare-and-swap
• DDL operations
• Create
• Alter
• Enable/Disable
• Access via HBase shell, Java API, REST proxy

40

Tuesday, June 18, 13

Java API

byte[] row = Bytes.toBytes(“jdcryans”); byte[] fam = Bytes.toBytes(“roles”); byte[] qual = Bytes.toBytes(“hbase”); byte[] putVal = Bytes.toBytes(“PMC”); Configuration config = HBaseConfiguration.create(); HTable table = new HTable(config, “employees”); Put p = new Put(row); p.add(fam, qual, putVal) table.put(p); Get g = new Get(row); Result r = table.get(g); byte[] jd = r.getValue(col);

41

HBase provides utilities for easy conversions

Tuesday, June 18, 13

Java API

byte[] row = Bytes.toBytes(“jdcryans”); byte[] fam = Bytes.toBytes(“roles”); byte[] qual = Bytes.toBytes(“hbase”); byte[] putVal = Bytes.toBytes(“PMC”); Configuration config = HBaseConfiguration.create(); HTable table = new HTable(config, “employees”); Put p = new Put(row); p.add(fam, qual, putVal) table.put(p); Get g = new Get(row); Result r = table.get(g); byte[] jd = r.getValue(col);

42

HBase provides utilities for easy conversions This reads the configuration files

Tuesday, June 18, 13

Java API

byte[] row = Bytes.toBytes(“jdcryans”); byte[] fam = Bytes.toBytes(“roles”); byte[] qual = Bytes.toBytes(“hbase”); byte[] putVal = Bytes.toBytes(“PMC”); Configuration config = HBaseConfiguration.create(); HTable table = new HTable(config, “employees”); Put p = new Put(row); p.add(fam, qual, putVal) table.put(p); Get g = new Get(row); Result r = table.get(g); byte[] jd = r.getValue(col);

43

HBase provides utilities for easy conversions This reads the configuration files This creates a connection to the cluster, no master needed

Tuesday, June 18, 13

Java API

byte[] row = Bytes.toBytes(“jdcryans”); byte[] fam = Bytes.toBytes(“roles”); byte[] qual = Bytes.toBytes(“hbase”); byte[] putVal = Bytes.toBytes(“PMC”); Configuration config = HBaseConfiguration.create(); HTable table = new HTable(config, “employees”); Put p = new Put(row); p.add(fam, qual, putVal) table.put(p); Get g = new Get(row); Result r = table.get(g); byte[] jd = r.getValue(col);

44

HBase provides utilities for easy conversions This reads the configuration files This creates a connection to the cluster, no master needed By default all operations are persisted

Tuesday, June 18, 13

Java API

byte[] row = Bytes.toBytes(“jdcryans”); byte[] fam = Bytes.toBytes(“roles”); byte[] qual = Bytes.toBytes(“hbase”); byte[] putVal = Bytes.toBytes(“PMC”); Configuration config = HBaseConfiguration.create(); HTable table = new HTable(config, “employees”); Put p = new Put(row); p.add(fam, qual, putVal) table.put(p); Get g = new Get(row); Result r = table.get(g); byte[] jd = r.getValue(col);

45

HBase provides utilities for easy conversions This reads the configuration files This creates a connection to the cluster, no master needed By default all operations are persisted From the moment the call to put() came back, the data became visible to all the readers

Tuesday, June 18, 13

46

Tuesday, June 18, 13

StumbleUpon is...

47

Tuesday, June 18, 13

48

The Product

Tuesday, June 18, 13

The Product

49

Pushing this button takes you to your next recommendation

Tuesday, June 18, 13

The Product

50

You can tell the recommendation engine if you liked the page or not

Tuesday, June 18, 13

The Product

51

You can also browse specific interests

Tuesday, June 18, 13

Business Model

52

Users are showed sponsored pages that are relevant to their interests

Tuesday, June 18, 13

53

If HBase goes down, the site goes down

Tuesday, June 18, 13

Architecture

54

Load Balancer Apache Thrift Apache HTTP Apache HBase

Tuesday, June 18, 13

Architecture

55

Load Balancer Apache Thrift Apache HTTP Apache HBase PHP

Tuesday, June 18, 13

Architecture

56

Load Balancer Apache Thrift Apache HTTP Apache HBase ~40 nodes PHP

Tuesday, June 18, 13

A Few Use Cases

• A/B testing framework

57

Tuesday, June 18, 13

A Few Use Cases

• A/B testing framework
• Realtime counters for dashboards

58 56

Tuesday, June 18, 13

A Few Use Cases

• A/B testing framework
• Realtime counters for dashboards
• Queueing

59 56

Tuesday, June 18, 13

A Few Use Cases

• A/B testing framework
• Realtime counters for dashboards
• Queueing
• Page sharing with comments

60 56

Tuesday, June 18, 13

A Few Use Cases

• A/B testing framework
• Realtime counters for dashboards
• Queueing
• Page sharing with comments
• User lists of stumbles

61 56

Tuesday, June 18, 13

A Few Use Cases

• A/B testing framework
• Realtime counters for dashboards
• Queueing
• Page sharing with comments
• User lists of stumbles
• Thumbnails serving

62 56

Tuesday, June 18, 13

A Few Use Cases

• A/B testing framework
• Realtime counters for dashboards
• Queueing
• Page sharing with comments
• User lists of stumbles
• Thumbnails serving
• Badges serving

63 56

Tuesday, June 18, 13

Analytics

64

MR Cluster HBase Prod Apache Logs MySQL >100 nodes Pig, Hive, Cascading, and pure MapReduce

Tuesday, June 18, 13

Analytics

65

MR Cluster HBase Prod Apache Logs MySQL HBase Replication Sub-second lag

Tuesday, June 18, 13

Analytics

66

MR Cluster HBase Prod Apache Logs MySQL Cron’d copy

Tuesday, June 18, 13

Analytics

67

MR Cluster HBase Prod Apache Logs MySQL Cron’d dump and load

Tuesday, June 18, 13

Monitoring With HBase

• OpenTSDB

68

Tuesday, June 18, 13

69

Tuesday, June 18, 13

Facebook Messages

70

Tuesday, June 18, 13

Facebook Messages

• Facebook needed a real email solution.
• Originally the data was stored in MySQL.
• They have the biggest HBase deployment.
• All the emails, SMS, and chats are stored in

HBase.

• Users are sharded by pods of machines, each

pod is configured the same way.

71

Tuesday, June 18, 13

Opower

72

Tuesday, June 18, 13

Opower

73

Tuesday, June 18, 13

Opower

• Perfect use case for HBase.
• Follows a time series pattern.
• Live traffjc served with short scans.
• New data constantly being fed.

74

Tuesday, June 18, 13

What now?

• Download HBase: http://www.hbase.org
• Read HBase: The Definitive Guide by Lars

George

• Watch the videos from last week’s conference

(available within a few weeks): http://www.hbasecon.com/

• Have a chat on #hbase hosted by

irc.freenode.net

75
