SLIDE 1

S2Graph : A large-scale graph database

with Hbase

daumkakao

SLIDE 2

2

Reference

1. HBase Conference 2015

1.http://www.slideshare.net/HBaseCon/use-cases-session-5 2.https://vimeo.com/128203919

2. Deview 2015
3. Apache Con BigData Europe

1.http://sched.co/3ztM

4. Github: https://github.com/daumkakao/s2graph

SLIDE 3

3

Our Social Graph

Message Write length : Read Coupon price : Present price : 3

affinity affinity: affinity affinity affinity affinity affinity affinity affinity

Friend

Group size : 6 Emoticon Eat rating : View count : Play level: 6 Style share : 3 Advertise Search keyword : Listen count : Like count : 7 Comment

affinity

SLIDE 4

4

Our Social Graph

Message length : 9 Write length : 3

affinity 6 affinity: 9 affinity 3 affinity 3 affinity 4 affinity 1 affinity 2 affinity 2 affinity 9

Friend

Play level: 6 Style share : 3 Advertise ctr : 0.32 Search keyword : “HBase" Listen count : 6

Comment length : 15

affinity 3

Message ID : 201 Ad ID : 603 Music ID : 603 Item ID : 13 Post ID : 97 Game ID : 1984

SLIDE 5

5

Technical Challenges

1. Large social graph constantly changing
a. Scale

more than, social network: 10 billion edges, 200 million vertices, 50 million update on existing edges. user activities: over 1 billion new edges per day

SLIDE 6

6

Technical Challenges (cont)

2. Low latency for breadth first search traversal on connected data.
a. performance requirement

peak graph-traversing query per second: 20000 response time: 100ms

SLIDE 7

7

Technical Challenges (cont)

3. Realtime update capabilities for viral effects

Person A

Post Fast

Person B

Comment

Person C

Sharing

Person D

Mention Fast Fast

SLIDE 8

8

Technical Challenges (cont)

4. Support for Dynamic Ranking logic
a. Push strategy: Hard to change data ranking logic dynamically.
b. Pull strategy: Enables user to try out various data ranking logics.

SLIDE 9

9

Before

Each app server should know each DB’s sharding logic. Highly inter-connected architecture

Friend relationship SNS feeds Blog user activities Messaging

Messaging App SNS App Blog App

SLIDE 10

10

After

SNS App Blog App Messaging App

S2Graph DB

stateless app servers

SLIDE 11

What is S2Graph?

daumkakao

SLIDE 12

12

What is S2Graph? Storage-as-a-Service + Graph API = Realtime Breadth First Search

SLIDE 13

13

Example: Messanger Data Model

Participates

Chat Room Message 1 Message 1 Message 1

Contains Recent messages in my chat rooms.

SELECT a.* FROM user_chat_rooms a, chat_room_messages b WHERE a.user_id = 1 AND a.chat_room_id = b.chat_room_id WHERE b.created_at >= yesterday

SLIDE 14

14

Example: Messanger Data Model

Participates

Chat Room Message 1 Message 1 Message 1

Contains Recent messages in my chat rooms.

curl -XPOST localhost:9000/graphs/getEdges -H 'Content-Type: Application/json' -d ' { "srcVertices": [{"serviceName": "s2graph", "columnName": “user_id", "id":1}], "steps": [ [{"label": "user_chat_rooms", "direction": "out", "limit": 100}], // step [{"label": "chat_room_messages", "direction": "out", "limit": 10, “where”: “created_at >= yesterday”}] ] } '

SLIDE 15

15

Example: News Feed (cont) Friends

Post1 Post 2 Post 3

create/like/share posts

Posts that my friends interacted.

SELECT a.*, b.* FROM friends a, user_posts b WHERE a.user_id = b.user_id WHERE b.updated_at >= yesterday and b.action_type in (‘create’, ‘like’, ‘share’)

SLIDE 16

16

Example: News Feed (cont)

Friends

Post1 Post 2 Post 3

create/like/share posts

Posts that my friends interacted.

curl -XPOST localhost:9000/graphs/getEdges -H 'Content-Type: Application/json' -d ' { "srcVertices": [{"serviceName": "s2graph", "columnName": “user_id", "id":1}], "steps": [ [{"label": "friends", "direction": "out", "limit": 100}], // step [{"label": “user_posts", "direction": "out", "limit": 10, “where”: “created_at >= yesterday”}] ] } '

SLIDE 17

17

Example: Recommendation(User-based CF) (cont) Similar Users

Product 1 Product2 Product 3

user-product interaction (click/buy/like/share)

Products that similar user interact recently.

SELECT a.* , b.* FROM similar_users a, user_products b WHERE a.sim_user_id = b.user_id AND b.updated_at >= yesterday

Batch

SLIDE 18

18

Example: Recommendation(User-based CF) (cont)

Products that similar user interact recently.

curl -XPOST localhost:9000/graphs/getEdges -H 'Content-Type: Application/json' -d ' { “filterOut”: {“srcVertices”: [{“serviceName”: “s2graph”, “columnName”: “user_id”, “id”: 1}], “steps”: [[{“label”: “user_products_interact”}]] }, "srcVertices": [{"serviceName": "s2graph", "columnName": “user_id", "id":1}], "steps": [ [{"label": “similar_users", "direction": "out", "limit": 100, “where”: “similarity > 0.2”}], // step [{"label": “user_products_interact”, "direction": "out", "limit": 10, “where”: “created_at >= yesterday and price >= 1000”}] ] } '

Similar Users

Product 1 Product2 Product 3

user-product interaction (click/buy/like/share) Batch

SLIDE 19

19

Example: Recommendation(Item-based CF) (cont) Similar Products

Product 1 Product2 Product 3

user-product interaction (click/buy/like/share)

Product 1 Product 1 Product 1

Products that are similar to what I have interested.

SELECT a.* , b.* FROM similar_ a, user_products b WHERE a.sim_user_id = b.user_id AND b.updated_at >= yesterday

Batch

SLIDE 20

20

Example: Recommendation(Item-based CF) (cont)

Products that are similar to what I have interested.

curl -XPOST localhost:9000/graphs/getEdges -H 'Content-Type: Application/json' -d ' { "srcVertices": [{"serviceName": "s2graph", "columnName": “user_id", "id":1}], "steps": [ [{"label": “user_products_interact", "direction": "out", "limit": 100, “where”: “created_at >= yesterday and price >= 1000”}], [{"label": “similar_products”, "direction": "out", "limit": 10, “where”: “similarity > 0.2”}] ] } '

Example: Recommendation(Content + Most popular) (cont)

TopK(k=1) product per timeUnit(day)

Product1 Product2 Product 3

user-product interaction (click/buy/like/share)

Daily top product per categories in products that I liked.

SELECT c.* FROM user_products a, product_categories b, category_daily_top_products c WHERE a.user_id = 1 and a.product_id = b.product_id and b.category_id = c.category_id and c.time between (yesterday, today)

Category1 Category2 Product10 Product20 Product20

Today

Product10

Yesterday Today Yesterday

SLIDE 22

22

Example: Recommendation(Content + Most popular) (cont)

Daily top product per categories in products that I liked.

curl -XPOST localhost:9000/graphs/getEdges -H 'Content-Type: Application/json' -d ' { "srcVertices": [{"serviceName": "s2graph", "columnName": “user_id", "id":1}], "steps": [ [{"label": “user_products_interact", "direction": "out", "limit": 100, “where”: “created_at >= yesterday and price >= 1000”}], [{“label”: “product_cates”, “direction”: “out”, “limit”: 3}], [{"label": “category_products_topK”, "direction": "out", "limit": 10] ] } '

TopK(k=1) product per timeUnit(day)

Product1 Product2 Product 3

user-product interaction (click/buy/like/share)

Category1 Category2 Product10 Product20 Product20

Today

Product10

Yesterday Today Yesterday

SLIDE 23

23

Example: Recommendation(Spreading Activation) (cont)

Product 1 Product2 Product 3

user-product interaction (click/buy/like/share)

Products that is interacted by users who interacted on products that I interact

SELECT b.product_id, count(*) FROM user_products a, user_products b WHERE a.user_id = 1 AND a.product_id = b.product_id GROUP BY b.product_id

SLIDE 24

24

Example: Recommendation(Spreading Activation) (cont)

Product 1 Product2 Product 3

user-product interaction (click/buy/like/share)

Products that is interacted by users who interacted on products that I interact

curl -XPOST localhost:9000/graphs/getEdges -H 'Content-Type: Application/json' -d ' { "srcVertices": [{"serviceName": "s2graph", "columnName": “user_id", "id":1}], "steps": [ [{"label": “user_products_interact", "direction": "out", "limit": 100, “where”: “created_at >= yesterday and price >= 1000”}], [{"label": “user_products_interact", "direction": "in", "limit": 10, “where”: “created_at >= today”}], [{"label": “user_products_interact", "direction": "out", "limit": 10, “where”: “created_at >= 1 hour ago”}], ] } '

SLIDE 25

25

Realization

1. These examples resemble graphs.
2. Object isVertex, Relationship is Edge.
3. Necessary APIs: breadth first search on large scale graph.

SLIDE 26

26

S2Graph API: Vertex Vertex:

1. insert, delete, getVertex
2. vertex id: what user

provided(string/int/long)

ID 1231-123 Prop1 Val1 Prop2 Val2 … …

SLIDE 27

27

S2Graph API: Edge Edges:

1. Insert, delete, update, getEdge(like

CRUD in RDBMS)

2. Edge reference: (from, to, label,

direction)

3. Multiple props on edge.
4. Every edges are ordered (details

follow).

Edge Reference 1,101,”friend”,”out” Prop1 Val1 Prop2 Val2 … …

SLIDE 28

28

S2Graph API: indices

Degree Q1 Q2 Q3 1-friend-

ut-PK

3 c-103 b-102 a-101

1 101 102 103

Name: a Name: b Name: c Ordered(DESC) Indices:

1. addIndex, createIndex 2. Automatically keep edges ordered for multiple indices. 3. Support int/long/float/string data types.

class Index { // define how to order edges. String indexName; List[Prop] indexProps; }

SLIDE 29

29

S2Graph API: Query Query: getEdges, countEdges, removeEdges

Class Query { // Define breadth first search List[VertexId] startVertices; List[Step] steps; } Class Step { // Define one breadth List[QueryParam] queryParams; } Class QueryParam { // Define each edges to traverse for current breadth String label; String direction; Map options; }

QueryParam Step1 Step2 Query

SLIDE 30

30

What is S2Graph Not support global computation(not like Apache Giraph, graphX). Not support graph algorithm like page rank, shortest path. Storage-as-a-Service + Graph API = Realtime Breadth First Search S2Graph is Not

SLIDE 31

31

Why S2Graph: Push vs Pull. Feeds with Push

1. Only timestamp can be used as scoring
2. Hard to change scoring function dynamically

Post

Like Write(Fanout) Friends

Feed Queue Feed Queue Feed Queue

Write # of friends Read O(1) for friends Storage AVG(# of friends) * total user activity Query O(1)

SLIDE 32

32

1.Different weights to different action types: Like = 0.8, Click = 0.1… 2.Client can change scoring dynamically.

Post

Like Friends Why S2Graph: Push vs Pull. Feeds with Pull

Write O(1) Read None Storage total user activity Query O(1) for friends + O(# of friends)

SLIDE 33

33

Pull >> push only if

1. fast response time: 10 ~ 100ms
2. throughput: 10K ~ 20K QPS

S2Graph provide linear scalability on

1. number of machine.
2. bfs search space(how many edges that single query will traverse).

more detail on benchmark section later. Why S2Graph: S2Graph Supports Pull + Push

SLIDE 34

34

Why S2Graph: Simplify Data Flow

S2Graph

Write API + Query DSL

WAL log

OpenSourced User/Item Similarity Apache Spark (Batch Computing Layer) TopK Counter Others S2Graph Bulk Loader will be open sourced soon

SLIDE 35

35

Why S2Graph: Built in A/B test

1. Register Query Template: Each Query template have impressionId.
2. Insert Click/Impression event into S2Graph as Edge insert.

SLIDE 36

36

Why S2Graph: Just Insert Edge

S2Graph

1. user activity history.
2. friends feed.
3. user-item based collaborative filtering.
4. topK ranking(most popular, segmented most popular).

and many many more. just think your service as graph model.

SLIDE 37

S2Graph Internal

daumkakao

SLIDE 38

38

How to store the data - Edge

Logical View

a. Fetching an edge between two specific vertex
b. Lookup Table to reach indexed edges for update, increment, delete operations
1. Snapshot edges : Up-to-date status of edge

Tgt Vertex ID1 Tgt Vertex ID2 Tgt Vertex ID3 Src Vertex ID1 Properties Properties Properties Src Vertex ID2 Properties Properties Properties

2. Indexed edges : Edges with index

Index Values | Tgt Vertex ID1 Index Values | Tgt Vertex ID2 Src Vertex ID1 Non-index Properties Non-index Properties

a. Fetches edges originating from a certain vertex in order of index

SLIDE 39

39

How to store the data - Vertex

Logical View

1. Vertex : Up-to-date status of Vertex

column row Property Key1 Property Key2 Src Vertex ID1 Value1 Value2 Vertex ID2 Value1 Value2

SLIDE 40

40

Problem

Update/Delete edge is hard.

it is not feasible to traverse all edges to find edges to delete.
indexedEdge is ordered, so in worst case, client need to fetch all edges to find edge to delete.
this make delete/update edge become O(N).

Backtracking from snapshotEdge

read snapshot edge, then random access to indexed edge to delete. O(1)

Problem

need atomicity on update snapshot edge and indexed edge.
this require atomic operation(transaction) on multiple rows on HBase.
some times partial failure on this update yield broken states, such as zombie edges.

SLIDE 41

41

How to update edge

IndexedEdge Degree Q1 Q2 Q3 1-friend-out-PK 3 c-103 b-102 a-101

age:30, gender:M age:21 age:15, gender:F

SnapshotEdge Degree Q1 Q2 Q3 1-friend-out-PK 3 103 102 101

name:c:t0 age:30:t0 gender:M:t0

name:b:t0 age:21:t0 name:a:t0 age:15:t0 gender:F:t0

curl -XPOST localhost:9000/graphs/edges/insert -H ‘Content-Type: Application/json’ -d ‘ [ {“timestamp”: t0, “from”: 1, “to”: 101, “label”: “friend”, “props”: {“name”: “a”, “age”: 15, “gender”: “F”}}, {“timestamp”: t0, “from”: 1, “to”: 102, “label”: “friend”, “props”: {“name”: “b”, “age”: 21}}, {“timestamp”: t0, “from”: 1, “to”: 103, “label”: “friend”, “props”: {“name”: “c”, “age”: 30, “gender”: “M”} ] ‘

SLIDE 42

42

SnapshotEdge Degree Q1 Q2 Q3 1-friend-out-PK 3 103 102 101

name:c:t0 age:30:t0 gender:M:t0

name:b:t0 age:21:t0

name:a:t0 name:d:t1 age:15:t0 age:26:t1 gender:F:t0 IndexedEdge: delete(1, (a-101)) insert(1, (d-101))

curl -XPOST localhost:9000/graphs/edges/update -H ‘Content-Type: Application/json’ -d ‘ [ {“timestamp”: t-1, “from”: 1, “to”: 101, “label”: “friend”, “props”: {“name”: “k”, “age”: -10}} {“timestamp”: t1, “from”: 1, “to”: 101, “label”: “friend”, “props”: {“name”: “d”, “age”: 26}} ] ‘

How to update edge (cont)

1.Fetch SnapshotEdge 2.check pending mutations and retry 3.Build Update on Snapshot/ Indexed Edge 4.CAS on new SnapshotEdge 5.Mutate indexedEdge 6.CAS on new SnapshotEdge if pending mutations exist, other thread mutate this, so commit pending mutations and retry. If CAS is failed at 4, other thread lock this, so retry.

SnapshotEdge Degree Q1 Q2 Q3 1-friend-out-PK 3 103 102 101

name:c:t0 age:30:t0 gender:M:t0

name:b:t0 age:21:t0 name:a:t0 age:15:t0 gender:F:t0

SLIDE 43

43

IndexedEdge Degree Q0 Q1 Q2 Q3 1-friend-out- PK 3 d-101 c-103 b-102 a-101

age:26,gender:F age:30, gender:M age:21 age:15, gender:F

SnapshotEdge Degree Q1 Q2 Q3 1-friend-out-PK 3 103 102 101

name:c:t0 age:30:t0 gender:M:t0

name:b:t0 age:21:t0 name:a:t0 name:d:t1 age:15:t0 age:26:t1 gender:F:t0 IndexedEdge: delete(1, (a-101)) insert(1, (d-101))

1.Fetch SnapshotEdge 2.Apply mutations stored in SnapshotEdge if exist 3.Build Update on Snapshot/ Indexed Edge 4.CAS on new SnapshotEdge 5.Mutate indexedEdge 6.CAS on new SnapshotEdge If any failure exist on 5, abort and retry from 1. it is safe to issue same mutation multiple time since s2graph is idempotent.

How to update edge (cont)

SLIDE 44

44

IndexedEdge Degree Q0 Q1 Q2 1-friend-out-PK 3 d-101 c-103 b-102

age:26,gender:F age:30, gender:M age:21

SnapshotEdge Degree Q1 Q2 Q3 1-friend-out-PK 3 103 102 101

name:c:t0 age:30:t0 gender:M:t0

name:b:t0 age:21:t0 name:d:t1 age:26:t1 gender:F:t0

1.Fetch SnapshotEdge 2.Apply mutations stored in SnapshotEdge if exist 3.Build Update on Snapshot/ Indexed Edge 4.CAS on new SnapshotEdge 5.Mutate indexedEdge 6.CAS on new SnapshotEdge If CAS is failed at 6, retry from 1

How to update edge (cont)

SLIDE 45

45

1.Fetch SnapshotEdge 2.Build Update on Snapshot/ Indexed Edge 3.CAS on new SnapshotEdge 4.Mutate indexedEdge 5.CAS on new SnapshotEdge

IndexedEdge Degree Q0 Q1 Q2 1-friend-out-PK 3 d-101 c-103 b-102

age:26,gender:F age:30, gender:M age:21

SnapshotEdge Degree Q1 Q2 Q3 1-friend-out-PK 3 103 102 101

name:c:t0 age:30:t0 gender:M:t0

name:b:t0 age:21:t0 name:d:t1 age:26:t1 gender:F:t0

How to update edge (cont)

SLIDE 46

46

Summary No atomic update between SnapshotEdge and IndexedEdge.

this can yield failure on update/delete on edge, and this is problem.

Then should we use transaction? Pros: solve our problem. no failure on update/delete edge. Cons: need one more read even though there is no contention. The probability of contention on edge is very low. stick to our retry logic with CAS.

SLIDE 47

Benchmarks

daumkakao

SLIDE 48

48

HBase Table Configuration

1. setDurability(Durability.ASYNC_WAL)
2. setCompressionType(Compression.Algorithm.LZ4)
3. setBloomFilterType(BloomType.Row)
4. setDataBlockEncoding(DataBlockEncoding.FAST_DIFF)
5. setBlockSize(32768)
6. setBlockCacheEnabled(true)
7. pre-split by (Intger.MaxValue / regionCount). regionCount = 120 when create table(on 20 region server).

SLIDE 49

49

HBase Cluster Configuration

each machine: 8core, 32G memory, SSD
hfile.block.cache.size: 0.6
hbase.hregion.memstore.flush.size: 128MB
otherwise use default value from CDH 5.3.1
s2graph rest server: 4core, 16G memory

SLIDE 50

50

Performance

1. Total # of Edges: 100,000,000,000(100,000,000 row x 1000 column)
2. Test environment
a. Zookeeper server: 3
b. HBase Masterserver: 2
c. HBase Regionserver: 20
d. App server: 4 core, 16GB Ram
e. Write traffic: 5K / second

SLIDE 51

51

Benchmark Query : src.out(“friend”).limit(100).out(“friend”).limit(10)
Total concurrency: 20 * # of app server

Performance

2. Linear scalability

Latency 50 100 150 200 QPS 1,000 2,000 3,000 4,000

# of app server

1 2 4 8

QPS(Query Per Second) Latency(ms)

46 45 45 43 3,491 1,763 885 464 43 45 45 46

# of app server

1 2 3 4 5 6 7 8 500 1000 1500 2000 2500 3000

QPS

SLIDE 52

Performance

3. Varying width of traverse (tested with a single server)

Latency 87.5 175 262.5 350 QPS 500 1,000 1,500 2,000 Limit on first step 20 40 80 200 400 800

QPS Latency(ms)

327 164 84 35 19 11 61 122 237 570 1,023 1,821 11 19 35 84 164 327

Benchmark Query : src.out(“friend”).limit(x).out(“friend”).limit(10)
Total concurrency = 20 * 1(# of app server)

SLIDE 53

53

All query touch 1000 edges.
each step` limit is on x axis.
Can expect performance with given query`s search space.

Performance

4. Different query path(different I/O pattern)

Latency 37.5 75 112.5 150 QPS 80 160 240 320 400 limits on path 10 -> 100 100 -> 10 10 -> 10 -> 10 2 -> 5 -> 10 -> 10 2 -> 5 -> 2 -> 5 -> 10

QPS Latency(ms)

32 34 36 23 14 307.5 292.1 274.4 435.3 695 14 23 36 34 32

SLIDE 54

54

Performance

5. Write throughput per operation on single app server

Insert operation

Latency 1.25 2.5 3.75 5 Request per second 8000 16000 800000

SLIDE 55

55

Performance

6. write throughput per operation on single app server

Update(increment/update/delete) operation

Latency 2 4 6 8 Request per second 2000 4000 6000

SLIDE 56

56

Stats

1. HBase cluster per IDC (2 IDC)
3 Zookeeper Server
2 HBase Master
(20 + 40) HBase Slave
2. App server per IDC
10 server for write-only
30 server for query only
3. Real traffic
read: 10K ~ 20K request per second
now mostly 2 step queries with limit 100 on first step.
write: over 5k ~ 10k request per second

SLIDE 57

57

SLIDE 58

58

Through S2Graph !

SLIDE 59

59

Now Available As an Open Source

https://github.com/daumkakao/s2graph
Finding contributors and mentors

Contact

Doyoung Yoon : shom83@gmail.com
