Annual Facility Visit World Leader in Platinum ANGLO AMERICAN PLATINUM CORPORATION ANNUAL FACILITY VISIT 1 March 2002 A member of the Anglo American plc group Annual Facility Visit World Leader in Platinum WESTERN BUSHVELD OPERATIONS

slide-1
SLIDE 1

World Leader in Platinum Annual Facility Visit

ANGLO AMERICAN PLATINUM CORPORATION ANNUAL FACILITY VISIT

1 March 2002

A member of the Anglo American plc group

slide-2
SLIDE 2

World Leader in Platinum Annual Facility Visit

WESTERN BUSHVELD OPERATIONS

Peter Kinver Divisional Director: West Mines

slide-3
SLIDE 3

World Leader in Platinum Annual Facility Visit

Safety Current performance Key issues

slide-4
SLIDE 4

World Leader in Platinum Annual Facility Visit

SAFETY

We are making progress : A reduction in fatality rate (FR) and Lost Time Injury Frequency Rate FR = 0.03 (Last year 0.04) LTIFR = 2.95 (3.75) Target 2002 =1.4 Rates compare favourably to platinum and gold industry. Behavioural based safety / continuous business Improvement. Mechanisation (quantum improvement)

slide-5
SLIDE 5

World Leader in Platinum Annual Facility Visit

RUSTENBURG SECTION

A good operational year – cost increase / Pt oz refined– 2.0% Expansion phase – despite Merensky slow depletion Exploit the shallow massive UG2 reserve Take current production from 1.123m oz (4E) to ±1.5moz (4E) Restructured management, greater focus and accountability Reduce and dilute fixed central costs and maintain a good cost performance Infrastructure investment (shafts, haulages, rolling stock etc) Mechanisation – productivity/costs (it’s working i.e. labour as total % of cost is decreasing)

slide-6
SLIDE 6

World Leader in Platinum Annual Facility Visit

MECHANISATION

Long term view Engaged supplier Extensive R & D Phased implementation Wide ranging benefits

slide-7
SLIDE 7

World Leader in Platinum Annual Facility Visit

UNION SECTION

Reinforced management team Infrastructure bottlenecks being fixed Cost controls working – big manpower reduction Good quality Merensky – grade improved Better performance this year

slide-8
SLIDE 8

World Leader in Platinum Annual Facility Visit

BAFOKENG-RASIMONE

Team in place – HRD Accelerated development programme North of mine – complex geology; however, deeper and southern ore – good quality Mining and milling rates building up During the year will be up to design throughput Trackless Merensky – started. Looks promising

slide-9
SLIDE 9

World Leader in Platinum Annual Facility Visit

AMANDELBULT SECTION

An excellent performance Tonnage/grade and recovery up Costs well controlled Started mechanisation in shallow UG2 Exciting safety initiatives Synergy with neighbouring mines

slide-10
SLIDE 10

World Leader in Platinum Annual Facility Visit

CONCLUSION

Solid base production Expansion in place and delivering Continuous Business Improvement paying off

slide-11
SLIDE 11

World Leader in Platinum Annual Facility Visit

WATERVAL PROJECT

Peter van Dorssen Business Manager

slide-12
SLIDE 12

World Leader in Platinum Annual Facility Visit

AGENDA

Safety Waterval as component of RPM(R) Mining overview Concentrator overview Key benefits

slide-13
SLIDE 13

World Leader in Platinum Annual Facility Visit

SAFETY REPORT TO DATE

2001 Ytd Cumulative 3 482 016 Total Man Hours 392 986 3 089 030 Shifts Worked 386 129 49 123 435 252 Non Lost Time Injuries 44 44 3 3 Lost Time Accidents (One Day or More) 1 1 Serious Injuries (14 Days or More) Fatal Accidents

slide-14
SLIDE 14

World Leader in Platinum Annual Facility Visit

WORLD CLASS SAFETY ACHIEVEMENTS

Cementation Mining:

  • 4 Star NOSA grading
  • Won competition for highest 4 star

grading mine in the Bushveld region

  • 365 injury free days (18 March 2002)

Concor/Group Five Civil Joint venture:

  • 5 star grading from MBA during

safety audit

  • Won regional and national

competition for the best safety system audited by MBA

slide-15
SLIDE 15

World Leader in Platinum Annual Facility Visit

WATERVAL PROJECT

Announced in September 2000 Brakspruit, Bleskop and Paardekraal vertical shafts – 200 000 tpm Waterval Mine – 200 000 tpm UG2 concentrator – 400 000 tpm Capital cost R1,310 bn (2000 terms)

slide-16
SLIDE 16

World Leader in Platinum Annual Facility Visit

WATERVAL MINE KEY FEATURES

200 ktpm of UG2 ore Two mining sections (East & Central) 3 dip roadways/ shaft, changing to 5 Room and pillar mining method 20 LHD’s and 14 drill rigs Each shaft to be developed 420m on dip Full production from 3 strike levels/ shaft 20 months construction to get to full production (December 2000 to June 2002)

slide-17
SLIDE 17

World Leader in Platinum Annual Facility Visit

GEOMETRY

Reef dip 9º Mining width 1,8 m Relative density (reef) 3,34 tons/m³ Steady state production 268 000 tons

slide-18
SLIDE 18

World Leader in Platinum Annual Facility Visit

SALIENT POINTS

Earthworks: 776 000 m³ incl rock Civils: 30 000 m³ Steelwork: 3 400t Platework: 750t Piping: 60km

slide-19
SLIDE 19

World Leader in Platinum Annual Facility Visit

400 KTPM UG2 CONCENTRATOR FLOW SHEET

Rustenburg Waterval Silo 5000 t Primary Crushing Stockpile 50 000 t Primary Crushing Floats Waste Silo 7 000t (Coarse) Silo 11 000t (Fines) Screening Sinks Crushing/ DMS Rail Bin 2 000 t

slide-20
SLIDE 20

World Leader in Platinum Annual Facility Visit

ORE RECEIVING AND CRUSHING PRIMARY FLOTATION SECONDARY MILLING SECONDARY FLOTATION TAILINGS THICKENING CONCENTRATE CONCENTRATE PRIMARY MILLING CONCENTRATE DEWATERING SMELTER SLIMES DAM

slide-21
SLIDE 21

World Leader in Platinum Annual Facility Visit

WATERVAL MINE KEY BENEFITS

Shallow UG2 Dedicated UG2 Concentrator Mechanised mining High efficiencies

slide-22
SLIDE 22

World Leader in Platinum Annual Facility Visit

ANGLO PLATINUM CONVERTING PROCESS (ACP)

Keith Hines – Plant Manager

slide-23
SLIDE 23

World Leader in Platinum Annual Facility Visit

STRATEGY ‘95

Increasing regulatory pressure Historical role of SO2 in environmentalism Worldwide trends in smelter technology Make virtue of necessity

  • Improve technology
  • Better process
  • Lower costs
  • Solve problem
  • No “Bandages”
slide-24
SLIDE 24

World Leader in Platinum Annual Facility Visit

STRATEGY NOW

Production expanding Regulatory pressure here External interest focus

  • Local environment
  • Regulators
  • International groups
  • Anglo American plc
slide-25
SLIDE 25

World Leader in Platinum Annual Facility Visit

STRATEGY NOW

Decouple furnace / converting operations Creates

  • Operational flexibility
  • Siting flexibility
slide-26
SLIDE 26

World Leader in Platinum Annual Facility Visit

PROJECT DESIGN CRITERIA - ENVIRONMENTAL

Reduce sulphur emissions

  • Current situation = 130 tpd SO2
  • DEAT requirements < 20 tpd SO

Implications

  • Acid plant downtime = Smelter downtime
  • Collection and treatment of converter and

furnace off-gas

  • New acid plant technology
  • Improved containment
  • Process robustness
slide-27
SLIDE 27

World Leader in Platinum Annual Facility Visit

PROJECT DESIGN CRITERIA - ENVIRONMENTAL

Hourly SO2 ground level concentrations (GLC) exceedences < 2 per year Implications

  • Collection of substantially all secondary
  • ff-gas sources and emit via stack(s)
  • Improved containment at source
slide-28
SLIDE 28

World Leader in Platinum Annual Facility Visit

PROJECT DESIGN CRITERIA - PROCESS

Increase capacity for future production forecasts

Material Union Furnace Matte (UFM) Nickel in Cathode Platinum Production * Waterval Furnace Matte (WFM) Annual Capacity (tpa) Minimum Production Design

122 000 tpa 186 000 tpa 26 800 tpa 26 800 tpa 21 000 tpa 30 000 tpa ~2.1 million oz ~3.6 million oz

slide-29
SLIDE 29

World Leader in Platinum Annual Facility Visit

Monthly Average Output of Plant for '99

PRESENT DESIGN

Monthly Average Output of Plant for Future Design

FUTURE DESIGN

Numbers have been rounded to the nearest whole number

Waterval Converter Matte 21% Waterval Furnace Slag 3% Sulphuric Produced 73% Gas Emissions Controlled 2% Gas Emissions Fugitive 1% Waterval Converter Matte 20% Waterval Furnace Slag 4% Sulphuric produced 26% Gas Emissions Controlled 28% Gas Emissions Fugitive 22%

slide-30
SLIDE 30

World Leader in Platinum Annual Facility Visit

COMPARATIVE OPERATIONAL COMPLEXITY

Granulated Matte Multi furnace feed Molten Waterval Furnace Matte and Cold UFM Feed Material 3 hrs (min) O2 Enrich. 3% ± 0.5% Fe 22% ± 0.2% S 7 hrs - 12 hrs (ave) Cycle Time/End Pt 3.5 million Pt oz 2.3 million Pt oz Capacity 1 Running 1 S/by within 7 Days 3 Running, 1 Hot S/by 2 Rebuilding

  • No. of Units

ACP PIERCE SMITH

slide-31
SLIDE 31

World Leader in Platinum Annual Facility Visit

PROJECT TIMETABLE

Phase 2 Phase 1

Design and Construction for Granulation, Converter, Acid Plant and Ancillaries Hot Commissioning and Optimisation

Stage A Stage B Phase 3 Phase 4

Design and construction for Electric Furnace Gas Treatment Hot Com & Opt 2002 2001 2000 First Tap 88% Fixation Potent. Twin streams to Acid Plant 98% Fixation 2003 2004

slide-32
SLIDE 32

World Leader in Platinum Annual Facility Visit

PROJECT BENEFITS

Meets environmental emission requirements – sustainable development Maximises economic recovery Provides scope to satisfy Anglo Platinum’s short and medium term expansion goals

slide-33
SLIDE 33

World Leader in Platinum Annual Facility Visit

ANGLO AMERICAN PLATINUM CORPORATION ANNUAL FACILITY VISIT

1 March 2002

A member of the Anglo American plc group
