ANGELS ARC Ambulance for Rescuing Children A HOPE for Honduras and RIT MSD/ID Collaboration MEET THE TEAM Rebecca Bonamico (BME) Lead / Systems Engineer Ankha Khosbayar (ID) Designer Gage Ellis (EE) Purchasing Lead Charlee Lefkovich (ME)
Ambulance for Rescuing Children
A HOPE for Honduras and RIT MSD/ID Collaboration
Rebecca Bonamico (BME)
Lead / Systems Engineer
Ankha Khosbayar (ID)
Designer
Gage Ellis (EE)
Purchasing Lead
Charlee Lefkovich (ME)
Project Manager
Alexa Boyd (INDE)
Customer Relations
Austin Zuercher (BME)
Communications / Facilitator
1. Project Background 2. Problem Overview 3. Updated Customer Requirements 4. Function Breakdown 5. Equipment Selection
a. Incubator b. Ventilator c. Power Systems
6. Vehicle Selection 7. Interior Design 8. Cost Breakdown 9. Project Risks 10. Future Direction
in Honduras (Tegucigalpa & San Pedro Sula)
closest lower tier hospital, then are transported to Tier 3 location for more intensive care
transport the infant and/or mother
In Honduras, there is currently a lack of quick, safe, and reliable transportation between hospitals for infants with serious medical conditions.
○ Transportation between hospitals
○ Be within a reasonable budget ■ Consider costs of build, maintenance, and repair ○ Parts for repair must be readily accessible in Honduras ○ Durable - keep repair cost low and effectiveness high ○ Easy to operate
○ Contain all necessary equipment ○ Provide power for all necessary systems
Limitations
Scenario
1. Hospital calls for ambulance 2. Ambulance makes 4 hour drive to hospital 3. Picks up multiple infants and family members 4. Transports back to Hospital Escuela
a. No in-transport care b. Driver has no medical training
5. Ambulance arrives and infants are removed for care Servicing 2 hospitals (Comayagua and La Esperanza)
Extended Truck Chassis with Box
space for monitor ○ Shows driver infant conditions ○ Removes distractions
○ Removes access to equipment
infants (more area to work)
personnel
Many Things Have Changed...
1. Comayagua calls Hospital Escuela with critical care infant(s) 2. Doctors at Escuela consult on necessary care 3. Vehicle is loaded with...
a. Required number of incubators (flexible) b. Driver c. Medical personnel
4. Vehicle travels to Comayagua 1 hour away 5. Infant is loaded into Incubator 6. Vehicle returns to Escuela The idea is to take ONLY critical care infants, as Comayagua needs to learn how to handle more complicated cases
Servicing Comayagua (~1.5 hour journey)
with driver
Equipment
Large Equipment
Small Equipment
Parameter Specification Importance
Max Number of Infants in a Single Trip 2-3 9 Appropriate temperature for infants (in incubator) 17-38.9 degrees C 9 Safe storage of oxygen tanks Ability to be secured during transport 9 Incubator Power Duration 4 hours 9 Self-sustaining Power at least 4 hours 9 Power Requirements 120AC Voltage with DC Voltages 9 Oxygen Tank Duration 4 hours 9 Extra movable seating for medical professional 1 8 Calibration range of monitoring equipment Capable of Calibration 8 Pressure of oxygen tanks at least 2000psi 8 Interior Light LED 8 Storage space Cabinets secured for movement 7
Medical Equipment Needed
Incubator
Heart Rate Monitor
Oxygen Masks
Ventilator
Blood pressure monitor
Temperature Sensors
Various Drugs
IV supplies
Small Medical Equipment (scissors, gauze, etc.)
Infant Equipment (blankets, diapers, etc)
AirBorne Voyager Transport Incubator International Biomedical 185+ Transport Incubator Welch Allyn Baby Active T1-401 Incubator
Function Requirements American Standards Goal Transport Infant Effectiveness Yes Yes Securements Attaches to stretcher secured into ambulance Custom Frame with locking mechanism Durability Dimensions 20.9 x 19.0 x 39.2 (H x W x L) 20.9 x 19.0 x 39.2 (H x W x L) Maintain Safety Safety 4 point belt system for infant 5 point belt system for infant Cleanliness Sanitize with chlorine or alcohol agent Sanitize with chlorine or alcohol agent Warmth Temperature 32-36±0.05 degrees C 32-36±0.05 degrees C Power Usage 120V, 50-400Hz (has extendable battery to 6 hours) 120V, 50-400Hz (has extendable battery to 6 hours)
Concentration, Blood Pressure
battery (3 hours)
Concentration, Blood Pressure
Welch Allyn Propaq LT Patient Monitor Philips Intellivue x2 Unknown Option
Something more affordable
Function Requirements American Standards Goal
Sensors NonInvasive Blood Pressure (NIBP) Dias 10-105mmHg, Syst 25-120mmHg, Mean 10-110mmHg Dias 10-105mmHg, Syst 25-120mmHg, Mean 10-110mmHg Oxygen Monitor (oxygen saturation monitor) 50-98% Saturation before alarm sounds 50-98% Saturation before alarm sounds Pulse Rate error <5% error <5%
0-50 0-51 Mains power Operating specs Always operate within + or -2% nominal Always operate within + or -2% nominal Power requirement 12-28Volts, 25W 12-28Volts, 25W Battery Charge Time 8-12Hrs while running, 6-8Hrs while not 8-12Hrs while running, 6-8Hrs while not Life span 3Hrs running full, 5Hrs monitor and SpO2 3Hrs running full, 5Hrs monitor and SpO3 Information Output ECG Leads and print
Based on ISO Standard 18778
airflow rate
Crossvent 2i+
lungs w/o cycling airflow
initiation of breaths
Honduras Crossvent 2i+ Infant Ventilator TXP-2D High Frequency Ventilation F&P Neopuff Infant T-Piece Resuscitator (CPAP)
F&P Neopuff Infant T-Piece Resuscitator with MSD modifications Functionality
putting finger over hole in gas
Modification
Add a automated settable mechanical attachment to the gas outlet in order to provide pressure control without the need for constant human interaction while maintaining the same functionality of the equipment
Function Requirements American Standards Goal Power Battery 7-11 Hours(TV-100), 5-7 Hours Plug DC has AC adaptor(TV-100), AC Voltage
DC has AC adaptor(TV-100), AC Voltage -25,+15% of nominal, DC Voltage -15,+25%, AC Frequency
Air Supply Tank 50psi 50psi Compressor 50psi 50psi Adjustability Pressure 1-60cmH20 1-60cmH21 Natal TV 2-100mL 2-100mL Oxygen content 21-100% 21-100% Air Flow I:E 3:1 to 1:99, TV of 5-100mL TV 5-100mL Maintain Safety Durability Meets EN794-3 safety specifications Meets EN794-3 safety specifications
TV-100 Ventilator (Bio-Med Devices)
○
○ Amplitude: 0.35/49m/s2 ○ Sweep Rate: 1 octave/min ○ Sweep Cycles: 4 per axis
○ Peak accel.: 15g ○ Pulse Duration: 6ms ○ Number of bumps:4000
○ Height: 0.75m ○ Number: 1 fall for each face
○ Run for time of 2 hours without interruption ○ Run on battery until it runs out
Before and after every test the ventilator shall function within stated parameters.
Criteria EVS ltd 1769 Flip-Up/Tilt Forward Seat EVS 17407 sewn attendant seat EVS 1750 Attendant Seat Safety 4 or 6 point belting No belting None Comfort ABS seatback Foam back Molded foam with lumbar and neck support Placement Designed for confined spaces No specifications No specifications Cost Weight supported 300 lbs when folded down No additional functionality besides person No additional functionality besides person Seat dimensions 51.75"H x 21"W x 24.375" D (inches, H includes standard base) 49.3" H with Base, 19.25" wide, 23-26" deep depending on degree 50.13" with base, 19.25" W, 23-26" Deep depending on degree reclined Cleaning Standards Seamless None Meets OSHA
and Power Inverter
Generator Power Inverter System
Incubator (x2) Monitor/Screen (x2) Ventilator (x2)
120Vac 60Hz Power 120Vac 60Hz Power 120Vac 60Hz Power 12Vdc External DC Power, 10A Maximum Average Instantaneous Power of 50W Average Instantaneous Power of 100W 12Vdc Internal Battery, 26A-Hours UPS Back Up System Internal Battery Current of 1A Current of 0.4A Current of 0.8A
Power Calculations
Total Output Current of 4.4A Total Output Power of 528W Input Power = Output Power Input Power of 528W out of a 13Vdc Vehicle Battery Input Current of 40A
Standard Vehicle Battery
13Vdc 50A-Hours
Standard Vehicle Alternator
30A
Power Assumptions
Total Output Power of 1kW for Feasibility Plenty of Extra Power for HVAC System 180A Alternator 12Vdc to 120Vac 1kW Power Inverter Or 1kW Power Generator
Type I
Square Patient compartment mounted on Truck Chassis
Type II
Van Chassis with raised roof
Type III
Square Patient compartment mounted on cutaway Van Chassis
Braun Industries, Inc Chief XL, Ford F-450 Medix Specialty Vehicles, Inc SRH-148, Ford Transit 250 MR Crestline Coach Ltd. Summit 170, Chevy G4500
US Neonatal Ambulance Current Honduran Ambulance
Vehicle Technical Specifications
○ 5.07 x 1.77 x 2.12 m
Dimensions (L x W x H) ○ 2.05 x 1.44 x 1.23 m
storage
SIGHT SMELL TOUCH SOUND
Description
hard surface in back of vehicle
depressions will keep the incubator from moving around
be integrated to the incubator to provide extra stability and safety
Vehicle Chassis -$ 40,000 Incubator (x2) - $ 70,000 CPAP with Modification (x2) - $ 1,000 Monitors (x2) - $ 6,000 Power Systems - Maximum of $500 (~$200 Inverter, ~ $250 Alternator) Other Equipment - $5,000 Interior Customization - $15,000
Total Anticipated Budget: ~$ 140,000 (Assuming new equipment)
1. Time 2. Budget / Cost 3. Availability of Technology (in Honduras) 4. Design Functionality 5. Customer Constraints 6. Equipment/Power Failure
Risk Category Severity (1-9) Likelihood (1-9) Importance (1-81)
Equipment fails Safety 8 6 48 Injuries to infants resulting from transport Safety 9 5 45 Medical professional is not secured during transit Safety 7 6 42 Equipment needed is not present during transport Technical 8 5 40 Incubator becomes unsecured during transport Safety 9 4 36 Equipment is not sterile Safety 4 8 32 Vehicle crashed/flips Safety 9 3 27 Vehicle is designed to be top heavy Safety 9 3 27 Time constraint with customers Resources 9 3 27 Flammable equipment malfunctions Safety/Environmental 9 3 27
Options
1. Refine internal layout design 2. Design large equipment securements 3. Investigate and prototype options for CPAP modification 4. Develop more extensive cost profile 5. Prototype electrical systems
Austin Zuercher (Communications) awz8563@rit.edu Charlee Lefkovich (Project Manager) cdl3646@rit.edu Gage Ellis (Purchasing Lead) gee2072@rit.edu
