Analyzing Big Data From Complex Systems:

Smart Cards in Urban Transportation Networks Soong Moon Kang

School of Management University College London

smkang@ucl.ac.uk

The Institute for Korean Regional Studies Seoul National University

September 6, 2016

Transport for London (TfL) Oyster Card

Wikicommons

• Introduced in 2003
• By June 2012: - More than 43 million cards issued
• Used by more than 80% of all public transport

Agenda:

• Study 1: Patterns of Urban Movement
• Study 2: Predicting Traffic Volumes and Estimating Effects
• f Disruptions
• Study 3: Extensions of the Study on the Patterns of Urban

Movement

• Study 4: Extensions of the Study on the Effects of

Disruptions

• Discussions

Study 1: Patterns of Urban Movement

• "Structure of Urban Movements: Polycentric Activity

and Entangled Hierarchical Flows” PLoS ONE, January 7, 2011, 6(1):e15923. (with Camille Roth, Michael Batty and Marc Barthélémy)

Data:

• March 31, 2008 — April 6, 2008 (1 week)
• 11.22 million journeys (trips)
• 2.03 million individual users (IDs)
• Information for each ID:
• time and location of tap-in and tap-out

 individual movements

Descriptives:

Distribution of travel distances

9.28 km

can be fitted with a negative binomial function distribution of journeys distribution of distances between stations

Descriptives:

Travel propensity

random simulation (given in- and

• ut-flow at

stations)  null-model of randomized journeys actual flow (wij) vs random

Descriptives:

wij: flow of passengers between stations i and j

Flow distribution: normalized histogram of flows of individuals

power law with exponent ≈ 1.3  strong heterogeneity of individual movements

Descriptives:

Distribution of total flows: Zipf plot

for morning peak hours (7am – 10am)

• Exponential decay  most of total flows concentrated on few stations

with

Polycenters:

Identifying polycenters:

• 1. Arrange stations by decreasing order of inflow

 definition of centers by decreasing importance

• 2. Account for geographical proximity

 aggregate all stations within a distance (1,500 meters) within the defined center

• 3. Continue until we capture a large percentage of total flow

(60% of total flow)

Polycenters:

Hierarchical organization

Polycenters:

Western Stations West End Northern Stations City Docklands West London Museums Government Parliament Mid-Town

Polycenters:

anisotropy

Anisotropy

• Use random simulation

from travel propensity to study relative orientation

• f incoming flow

 if no bias, fully isotropic (= 1)

Polycenters:

Structure of Flows:

How flows from single stations (sources) go to centers

• squares: sources (single stations)
• circles: centers
• grey: 20% of total inflow
• red: 40% of total inflow

Structure of Flows:

Proportion of links going from sources to centers (group)

• For more than 80% of the sources, the most important link (1st link)

connects to a center of Group I

• For more than 80% of the sources, the least important link (10th link)

connects to a center of Group III.

Group I Group II Group III

Study 1: Patterns of Urban Movement

• Contributions:
• application of complex systems analytical tools to

a novel data

• a new approach to determine polycenters
• attempt to model hierarchical nature of urban

movements

• Limitations:
• exploratory
• naive

Study 2: Predicting Traffic Volumes and Estimating Effects of Disruptions

• "Predicting Traffic Volumes and Estimating the Effects of

Shocks in Massive Transportation Systems” Proceedings of the National Academy of Sciences (PNAS) May 5, 2015, 112(18): 5643–5648. (with Ricardo Silva and Edoardo M. Airoldi)  Introducing statistical analysis into complex systems

Data:

• February 2011 — February 2012
• 70 weekdays and 25 weekend days
• 211 million journeys (trips)
• 10.7 million individual users (IDs)

 1.71 journeys per user per day  1.76 million users per day  3 million journeys per day

• 374 stations open during the period

(underground + overground + DLR)

Data:

• Weekdays only

Statistical Model:

Basic Idea:

Statistical Model:

Basic Idea:

Statistical Model:

Basic Idea:

Statistical Model:

Basic Idea: Smart Card Data Network Structure Data

Disruption Logs Passenger Route Surveys

“Natural Regime” Model “Disruption” Model

“Natural Regime” Model:

Smart Card Data Network Structure Data

Disruption Logs Passenger Route Surveys

“Natural Regime” Model “Disruption” Model

“Natural Regime” Model:

Basic Idea:

“Natural Regime” Model:

Assessment:

• Fivefold cross-validation (i.e., 14 days of test data for each fold):

Test if the fine-grained model with 374×374 ≅140,000 components

• verfits as compared to the fully aggregated (blackbox) models, and

under which conditions the model does better

“Disruption” Model:

Smart Card Data Network Structure Data

Disruption Logs Passenger Route Surveys

“Natural Regime” Model “Disruption” Model

“Disruption” Model:

Basic Model:

“Disruption” Model:

Results:

Average number of exits per minute at Victoria LU station on Tuesday, January 17, 2012. The blue curve represents the 1-min-ahead prediction under the natural regime using the tracking model. Given a disruption from 6:00 PM to 7:00 PM between Victoria station and Brixton station in the Victoria line,

• blue horizontal line: the average expected exit rate given by the tracking model under the natural regime,
• red horizontal line: the averaged observed exit count, and
• black horizontal line: the prediction given by the disruption model

“Disruption” Model:

Assessment:

(A) Relative errors for line segment events. The absolute error of tracking model for the line segment disruption varies from 3.0 (all stations) to 12.2 (stations with 85 tap-outs per minute or more) persons per minute. (B) Relative errors for station events. The absolute error varies from 3.5 (all stations) to 10.5 (stations with 75 tap-outs per minute or more) persons per minute.

Station Sensitivity Index:

How sensitive stations are to line closures:

Red dots: top 10% by number of tap-outs

• Contributions:
• application of statistical and machine learning

techniques to complex systems

• good model to describe and predict the effects
• f disruptions
• Limitation:
• simplistic

Study 2: Predicting Traffic Volumes and Estimating Effects of Disruptions

Study 3: Extensions of the Study on the Patterns of Urban Movement

• with Michael Batty, Hae Ran Shin, Ricardo Silva and

Chen Zhong  Introducing statistical analysis into the study of urban movement patterns

Study 3a: Passenger Travel Distributions

Basic Idea:

Study 3a: Passenger Travel Distributions

Basic Idea:

frequency frequency distance distance

Station A Station B

Study 3a: Passenger Travel Distributions

Basic Idea:

frequency frequency distance distance

Station A Station B

Study 3a: Passenger Travel Distributions

Some Research Questions:

• Do travel distributions of the passengers entering specific

stations reveal a more generic pattern?  “local” versus “global”

• If a generic pattern exist, how it relates to the urban geography?

 “center” versus “periphery”

Study 3b: Passenger Travel Distributions and Geographic Socio-Economic Characteristics

Basic Idea:

• Correlate passenger travel distributions with geographic socio-

economic characteristics such as income, education, age, employment and family composition.

Study 3: Extensions of the Study on the Patterns of Urban Movement

• Data:

 London and Seoul  Major challenges:

• Only one day of data from Seoul
• Fine grained socio-economic data for Seoul

Study 4: Extensions of the Study on the Effects of Disruptions

• with Ricardo Silva

 Refining the statistical analyses  Ultimate goal: real-time assessment of effects

• f disruptions system-wide

Study 4a: Probabilistic and Causal Approaches

Basic Idea:

Study 4a: Probabilistic and Causal Approaches

Basic Ideas:

• provide a full probabilistic model of movement inside the subway

network system

• estimate the distribution (instead of only the expectation) of travel

times, link loads and exit numbers given a disruption  causal inference

Study 4b: Passenger-level modeling

Basic Ideas:

• model by taking into account the behaviour of individual travellers,

instead of aggregated counts

• collect fine-grained passenger movement data using mobile apps

Discussion
