An introduction to the theory of SDDP algorithm V. Lecl` ere (ENPC) - - PowerPoint PPT Presentation

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

An introduction to the theory of SDDP algorithm

• V. Lecl`

ere (ENPC) August 1, 2014

• V. Lecl`

ere Introduction to SDDP August 1, 2014 1 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Introduction

Large scale stochastic problem are hard to solve. Two ways of attacking such problems :

decompose (spatially) the problem and coordinate solutions, construct easily solvable approximations (Linear Programming).

Behind the name SDDP there is three different things:

a class of algorithms, a specific implementation of the algorithm, a software implementing this method develloped by PSR.

The aim of this talk is to give you an idea of how the class of algorithm is working and give a convergence result.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 2 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Introduction

Large scale stochastic problem are hard to solve. Two ways of attacking such problems :

decompose (spatially) the problem and coordinate solutions, construct easily solvable approximations (Linear Programming).

Behind the name SDDP there is three different things:

a class of algorithms, a specific implementation of the algorithm, a software implementing this method develloped by PSR.

The aim of this talk is to give you an idea of how the class of algorithm is working and give a convergence result.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 2 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Introduction

Large scale stochastic problem are hard to solve. Two ways of attacking such problems :

decompose (spatially) the problem and coordinate solutions, construct easily solvable approximations (Linear Programming).

Behind the name SDDP there is three different things:

a class of algorithms, a specific implementation of the algorithm, a software implementing this method develloped by PSR.

The aim of this talk is to give you an idea of how the class of algorithm is working and give a convergence result.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 2 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

An introductive application

A dam is seen as a stock of energy with uncertain inflows, valorized at an uncertain price. The objective is to minimize the expected cumulated cost.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 3 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Contents

1

Technical Preliminaries Problem Formulation and Dynamic Programming Duality Approach

2

SDDP Algorithm The SDDP algorithm Miscellaneous

3

Convergence and Numerical Results

4

Conclusion

• V. Lecl`

ere Introduction to SDDP August 1, 2014 3 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Problem Formulation

min

A0x0=b0 x0≥0

• cT

0 x0 + E

• min

B1(ξ1)x0+A1(ξ1)x1=b1 x1≥0

• cT

1 (ξ1)x1 + E

• · · ·

+ E

• min

BT (ξT )xT−1+AT (ξT )xT =bT (ξT ) xT ≥0

cT

T (ξT)xT

• Key “practical” assumption: the noise
• ξ1, . . . , ξT
• is

independent from time to time. If it is not the case we can often extend the state x to obtain an independent noise

• V. Lecl`

ere Introduction to SDDP August 1, 2014 4 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Problem Formulation

min

A0x0=b0 x0≥0

• cT

0 x0 + E

• min

B1(ξ1)x0+A1(ξ1)x1=b1 x1≥0

• cT

1 (ξ1)x1 + E

• · · ·

+ E

• min

BT (ξT )xT−1+AT (ξT )xT =bT (ξT ) xT ≥0

cT

T (ξT)xT

• Key “practical” assumption: the noise
• ξ1, . . . , ξT
• is

independent from time to time. If it is not the case we can often extend the state x to obtain an independent noise

• V. Lecl`

ere Introduction to SDDP August 1, 2014 4 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Dynamic Programming Approach

This problem can be solved by Dynamic Programming with: QT−1(xT−1, ξT) = min

BT (ξT )xT−1+AT (ξT )xT =bT (ξT ) xT ≥0

cT

T (ξT)xT

VT−1 = E

• QT−1(xT−1, ξT)
• Qt−1(xt−1, ξt) =

min

Bt(ξt)xt−1+At(ξt)xt=bt(ξt) xt≥0

cT

t xt + Vt(xt)

Vt−1(xt−1) = E

• Qt−1(xt−1, ξt)
• Note that:

the resolution can be done backward in time but require a priori discretization; functions Qt and Vt are convex in x; functions Qt and Vt are pieciewise linear, hence above problems are linear programming problems.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 5 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Dynamic Programming Approach

This problem can be solved by Dynamic Programming with: QT−1(xT−1, ξT) = min

BT (ξT )xT−1+AT (ξT )xT =bT (ξT ) xT ≥0

cT

T (ξT)xT

VT−1 = E

• QT−1(xT−1, ξT)
• Qt−1(xt−1, ξt) =

min

Bt(ξt)xt−1+At(ξt)xt=bt(ξt) xt≥0

cT

t xt + Vt(xt)

Vt−1(xt−1) = E

• Qt−1(xt−1, ξt)
• Note that:

the resolution can be done backward in time but require a priori discretization; functions Qt and Vt are convex in x; functions Qt and Vt are pieciewise linear, hence above problems are linear programming problems.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 5 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Contents

1

Technical Preliminaries Problem Formulation and Dynamic Programming Duality Approach

2

SDDP Algorithm The SDDP algorithm Miscellaneous

3

Convergence and Numerical Results

4

Conclusion

• V. Lecl`

ere Introduction to SDDP August 1, 2014 5 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Subgradient of a Value Function 1/2

Consider the following problem: Qt(x, ξ) = min

xt,xt+1

cT

t (ξ)xt + Vt+1(xt+1)

s.t. xt = x λt(ξt) Bt(ξ)xt−1 + At(ξ)xt = bt(ξ) Note λt(ξt) the Lagrangian multiplier associated to the constraint xt = x. Marginalist interpretation of the multiplier (and convexity

• f Qt) implies that λt(ξt) ∈ ∂Qt(xt, ξ) is a subgradient of Qt(·, ξ).

In other words Qt(·, ξ) ≥ Qt(xt, ξ) +

• λt, · − xt
• .
• V. Lecl`

ere Introduction to SDDP August 1, 2014 6 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Subgradient of a Value Function 2/2

We have: ∀x, Qt(x, ξ) ≥ Qt(xt, ξ) +

• λt, x − xt
• .

Recall that Vt(x) = E

• Qt(x, ξ)
• .

By linearity we obtain Vt(·) ≥ E

• Qt(xt, ξ)
• +
• E
• λt(ξt)
• , · − xt
• .
• V. Lecl`

ere Introduction to SDDP August 1, 2014 7 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Constructing a Cut from a Lower Approximation 1/2

Assume that we have ˇ V (k)

t+1 ≤ Vt+1. Choose a point x(k) t

. Recall that Qt(xt, ξ) = min

Bt+1(ξ)xt+At+1(ξ)xt+1=bt+1(ξ) xt+1≥0

cT

t+1xt + Vt+1(xt+1)

For any possible ξ, consider β(k)(ξ) = min

xt,xt+1

cT

t (ξ)xt + ˇ

V (k)

t+1(xt+1)

s.t. xt = x(k)

t

λ(k)

t

(ξ) Bt(ξ)xt−1 + At(ξ)xt = bt(ξ) Hence we have, β(k)

t

(ξ) +

• λt(ξ), · − x(k)

t

• ≤ Qt(·, ξ) .

then, E

• β(k)

t

(ξt)

• +
• E
• λt(ξt)
• , · − x(k)

t

• ≤ Vt(·) .
• V. Lecl`

ere Introduction to SDDP August 1, 2014 8 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Constructing a Cut from a Lower Approximation 2/2

Recall that, Vt(x) = E

• Qt(x, ξt+1)
• .

Hence β(k)

t

(ξ) +

• λt(ξ), · − x(k)

t

• ≤ Qt(·, ξ) ,

leads to E

• β(k)

t

(ξt)

• +
• E
• λt(ξt)
• , · − x(k)

t

• ≤ Vt(·)
• V. Lecl`

ere Introduction to SDDP August 1, 2014 9 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Contents

1

Technical Preliminaries Problem Formulation and Dynamic Programming Duality Approach

2

SDDP Algorithm The SDDP algorithm Miscellaneous

3

Convergence and Numerical Results

4

Conclusion

• V. Lecl`

ere Introduction to SDDP August 1, 2014 9 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Probabilistic Assumption

The noise process (ξ1, · · · , ξT) is assumed to be independent in time. If the actual noise process is autoregressive, i.e. Wt = a0 + a1Wt−1 + · · · + aτWt−τ + ξt we can extend the state of the problem by considering (xt, Wt−1, · · · , Wt−τ) as the new state, and ξ as the new (independent) noise. The noise is assumed to be discrete. At time t the noise affecting the system is assumed to be known before the decision xt is made (Hazard-Decision information structure).

• V. Lecl`

ere Introduction to SDDP August 1, 2014 10 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Global Scheme

Assume that we have lower approximation V (k)

t

Forward Phase Replacing the actual value functions Vt by their approximation V (k)

t

, and selecting a scenario of noise (ξ(k)

0 , . . . , ξ(k) T ) we derive a state trajectory

x(k)

0 , . . . , x(k) T .

Backward Phase Recursively backward compute a new cut (i.e. affine function lower than Vt) of Vt at x(k)

t

. The new approximation is given by V (k+1)

t

= max

• V (k)

t

, β(k)

t

+ λ(k)

t

, · − x(k)

t

• .
• V. Lecl`

ere Introduction to SDDP August 1, 2014 11 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Forward Phase

The forward phase of iteration k find a “good state trajectory”, given a sequence of lower approximation V (k)

t

:

1 Select a sequence of noise (ξ(k)

0 , . . . , ξ(k) T ).

2 Fix x(k)

= x0.

3 Solve, recursively forward in time,

min

xt+1

cT

t (ξ)xt + ˇ

V (k)

t+1(xt+1)

s.t. xt = x(k)

t

Bt(ξ(k)

t

)xt−1 + At(ξ)xt = bt(ξ(k)

t

) to obtain a sequence

• x(k)

0 , · · · , x(k) T

• .

This is the optimal trajectory given by the approximation of the Bellman function along the given scenario.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 12 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Backward Phase

For any time step t

1 For any ξ in the support of ξt+1, solve

β(k)

t

(ξ) = min

xt,xt+1

cT

t (ξ)xt + ˇ

V (k)

t+1(xt+1)

s.t. xt = x(k)

t

λ(k)

t

(ξ) Bt(ξ)xt−1 + At(ξ)xt = bt(ξ)

2 Compute the exact expectations

β(k)

t

= E

• β(k)

t

(ξt+1)

• ,

λ(k)

t

= E

• λ(k)

t

(ξt+1)

• .

3 Update the approximation at time t:

V (k+1)

t

:= max

• V (k)

t

, β(k)

t

+ λ(k)

t

, · − x(k)

t

• .
• V. Lecl`

ere Introduction to SDDP August 1, 2014 13 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Contents

1

Technical Preliminaries Problem Formulation and Dynamic Programming Duality Approach

2

SDDP Algorithm The SDDP algorithm Miscellaneous

3

Convergence and Numerical Results

4

Conclusion

• V. Lecl`

ere Introduction to SDDP August 1, 2014 13 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Bounds

Lower Bound At any stage of the algorithm we have an exact lower bound of the problem given by V (k) (x0). Upper Bound From the collection of value functions approximations we derive a policy

• X(k)

0 , · · · , X(k) T

• that can be simulated. Hence, an

upper bound of the value of the problem is given by E T

• t=1

cT

t X(k) t

• ,

which can be estimated by Monte-Carlo method.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 14 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Stopping Rule

A number of stopping rules for the SDDP method has been

• proposed. In practice it is often simply a given number of iteration

(or a given computation time). An interesting stopping rule is the following. Fix an objective gap ε. Compute the lower bound v(k) = V (k)

t

(x0). Estimate by Monte-Carlo the upper bound v(k). It is easy to

• btain an (asymptotic) 90% confiance interval for the upper

bound [v(k) − e(k), v(k) + e(k)]. Stop if the difference v(k) + e(k) − v(k) between the upper estimation of the upper bound and the lower bound is lower than the objective gap, in which case we can certified, with 95% confidence that the solution of the algorithm is less than ε from the optimal.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 15 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

A Number of Approximations

1 We fit on the data available an autoregressive process

representing the noise. first uncontrollable error.

2 We discretize the stochastic process to obtain a scenario tree

• representation. second error controlable through Sampling

Average Approximation (SAA) theory.

3 We compute approximations ˇ

V (k)

t

• f the real value functions
• Vt. third error controlable by bounds from the SDDP

algorithm.

4 The upper bound is obtained through Monte Carlo. fourth

error controlable through central limit theorem.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 16 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Convergence result - linear case

Convergence result Assume that: the admissible sets of states are compact, we are in the relatively complete recourse case, the random selection in the forward phase satisfy some independence condition, every value function is updated an infinite number of time. Then the upper and lower bounds converges almost surely toward the value of the problem.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 17 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Convergence result - convex case

Convergence result Assume that: the admissible sets of states are compact convex, the cost functions are convex, we are in the extended relatively complete recourse case, the random selection in the forward phase satisfy some independence condition, every value function is updated an infinite number of time. Then the upper and lower bounds converges almost surely toward the value of the problem.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 18 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Numerical Results

Widely used in the energy community (management of dam, sizing of network etc...) Efficient up to 10-15 dams. Numerical experiments available on A. Shapiro website:

120 time-step, 4 dams for a state of dimension 8, each ξt is discretized in 100 points, hence there is 100119 scenarios, 3000 iterations runs in 15 minutes, 20% gap, 4% in dimension 4.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 19 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Contents

1

Technical Preliminaries Problem Formulation and Dynamic Programming Duality Approach

2

SDDP Algorithm The SDDP algorithm Miscellaneous

3

Convergence and Numerical Results

4

Conclusion

• V. Lecl`

ere Introduction to SDDP August 1, 2014 19 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Conclusion

SDDP is an algorithm, more precisely a class of algorithms that exploit convexity of the value functions (from convexity of costs...); does not require discretization; construct outer approximations of Vt, those approximations being precise only “in the right places”; gives bounds :

real lower bound V (k) (x0), estimated (by Monte-Carlo) upper bound;

construct linear-convex approximations, thus enabling the use

• f linear solver like CPLEX,

have proofs of asymptotic convergence.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 20 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

Available Extensions

Cut dropping methods are studied. Hot start by bypassing the forward phase and selecting artificial trajectories are numerically efficient. Work is done to apply SDDP in some non-convex cases. Risk aversion (through CVAR - either as constraint or as an element of the objective function) can be taken into account (by extending the state). Non linear convex cost can be used (convergence result).

• V. Lecl`

ere Introduction to SDDP August 1, 2014 21 / 21

Technical Preliminaries SDDP Algorithm Convergence and Numerical Results Conclusion

• M. Pereira, L.Pinto (1991).

Multi-stage stochastic optimization applied to energy planning. Mathematical Programming Z.Chen, W. Powell (1999). A convergent cutting plane and partial-sampling algorithm for multistage linear programs with recourse. Journal of Optimization Theory and Applications A.Philpott, Z. Guan (2008). On the convergence of stochastic dual dynamic programming and related methods. Operations research letters P.Girardeau, V.Lecl` ere, A. Philpott (2014). On the convergence of decomposition methods for multi-stage stochastic convex programs. accepted in Mathematics of Operations Research.

• V. Lecl`

ere Introduction to SDDP August 1, 2014 21 / 21
