Presentation

KURVER

Alpal FlexBin

Industrial Packaging

A New Packaging Solution for Bulk Storage Needs at Your Factory, Warehouse, and in your Distribution Network

Do you use FIBC’s in your operations? Do you use plastic or metal barrels for liquid products? Do you use 5 to 25 kg bags for goods in progress? Would you like to be able to stack any of these four to nine high in your warehouse, factory for better space utilization in trucks, railcars and ocean containers?

Alpal FlexBin

Alpal FlexBin Features and Benefits

• Adjustable Height

Flexibility and shipping efficiencies

• lighter than comparable containers

Lightweight construction with no walls

• 6:1 Return Ratio

Return trip cost effective

• FDA Approved Material

Safe for food product

• Smooth Surfaces

Easy to sanitize

• Expendable Liner

No cross-contamination

• Rotationally molded LLDPE material

Extremely durable

Rotationally Molded from Linear low- density polyethylene (LLDPE) Fully Recyclable Hygienic and Easy to Clean Life Expectancy of 7-10 Years Successfully undergone Extensive Testing Worldwide Patent and Design Registrations Represented in Most Major Industrial Centers

Simple Design & Easy to Use

Eight tonnes Load Capacity Stackable up to nine high Suitable for Road, Rail and Sea Transport UN Certification for Dangerous Dry Goods

Strong

Unlimited Applications for Dry Goods

Dry Goods, Powders, Granules, Minerals, Agricultural goods, Food products Eliminates Product-on- Product Stacking

Agricultural Seed & Dry Goods

Alpal FlexBin allows for secure and safe stacking Unique Interlocking System

FIBC Containment Dry Goods

Place FIBC above Alpal FlexBin Lower into Alpal FlexBin Then stack Up To 5-9 High

FIBC Containment Dry Goods

Remove Top Ring first Then fork the FIBC on lifting loops Then Lift out and process

Versatile

Fruit & Vegetable Concentrate - Juices Eliminates Steel or Plastic Drums Increases Stacking Density in Containers Reduces Freight Cost

In use for Liquids

Fruit & Vegetable Concentrates

Two open top liquid liners pictured

On the outside of the liner is a woven PP bag with Velcro straps to keep it attached to the ring beam.

Valve for Side Discharge; 2” and 3” are the standard valve sizes

Stackable with Heavy Liquids

Dense Tomato Paste Replaces Wooden Bins Stacks More Efficiently than all plastic alternatives

Woven PP Bag shown closed with zipper bag top and valve pictured

Conveyable

Fully conveyable with most Roller Conveyors. HDPE outer bag for Liquids.

Note: Unit in picture is strapped for rail transport of tomato paste

Cold Storage Capable

IQF Frozen Produce Stack up to Nine High Will not fail from Moisture like corrugated boxes in Cold Storage Eliminates the need for Additional Racking and Pallets

Use in Fresh Produce Industry

Available with our special designed polypropylene sleeve which allows airflow through the product Potatoes, Unions, Oranges, Corn and many

• ther Fresh Produce

Applications Produce Industry

Citrus, Fruits, Vegetables No Wood Cardboard or strapping required Better Ventilation than Corrugated or Wood With 6:1 Stackability, Reduces number of Bin Deliveries to Field when empty

Fresh or Frozen Produce

Fresh or Frozen Produce Reduced Weight Load on Product Different Protective Sleeves Reduces Packaging Waste through Re-use

Fresh Produce

40 percent Shadecloth containment bag available for product that requires Airflow Provides consistent temperatures in Cold Storage with fast pull-down

• f temperatures

Unlimited Applications

Ship 50-100 bags securely in a palletized Stack Reduces damages from unstable stacks Improves transportation efficiencies

Transport

• Maximizes transport efficiencies in Ocean Containers, Rail Cars and
• ver-the- road Trucks compared to Corrugated or FIBC’s

Return Shipping

Optimal stacking of Empties Empty Transport Costs kept to a Minimum with 6:1 Return Ratio Up to 420 empties in Truck Self Locking Design for secure Stacks

6 Model Sizes for Dry Goods and Liquids available

Specifications on request
