Agent Update & Training 29-Apr-19

Kenall Confidential

Agenda

• Indigo-Clean full product line review
• Understand the difference between Indigo-Clean

disinfecting luminaires and Kenall luminaires that use Indigo-Clean Technology

• Key selling points
• Application guide and quotation process for Indigo-

Clean and Kenall Luminaires with ICT

• Success stories – new design wins
• Case study review for Indigo-Clean
• Navigating Indigo-Clean.com and Kenall.com

2

Kenall Confidential

What is Indigo-Clean?

• A continuous environmental disinfection system which:
• Uses safe, visible light
• Can be integrated into normal, overhead lighting

3

Safe for Human Occupancy Safe for Human Occupancy

Mixed-White

White Disinfection Mode

Ambient White Light + Low-Power Disinfection

Indigo-Only

Indigo Disinfection Mode

High-Power Disinfection Only

Kenall Confidential

What is Visible Light Disinfection?

Kenall Confidential

How Does Indigo-Clean Work?

5

• 3. Pathogen inactivation breaks the

environmental chain of infection

• 1. Continuous, automatic, safe system creates hostile

environment for bacteria

• 2. Environment creates Reactive Oxygen Species

within bacteria causing inactivation

=

Kenall Confidential

• 4. Clinically Proven Infection Reduction

*Murrell, L.., et. al Influence of a visible-light continuous environmental disinfection system on microbial contamination and surgical site infections in an orthopedic operating room Am. J. Inf. Control In Press (2018)

Kenall Confidential

Indigo-Clean Safety Summary

Kenall Confidential

+ Episodic Disinfection

7

High Low Bacteria Levels Time

Benefit from Continuous + Episodic vs. Episodic-Only Disinfection

Additional Bacteria Removed

Up to 85% reduction beyond normal cleaning measures Bacteria Regrowth

= Indigo-Clean + Episodic = Episodic Only

Kenall Confidential

Applications

Waiting Areas OR Patient Bathroom SPD or Pharmacy ED Trauma/ Triage Procedure/ Exam

8

Kenall Confidential

Why Indigo-Clean in the OR?

19% 33% 32% 15% 1%

CLABSI (+MRSA) SSI (+MRSA) VAP CDI CAUTI

1Zimlichman, E. et al. “Health Care-Associated Infections: A Meta-analysis of Costs and Financial Impact on the US Health

Care System”, JAMA Intern Med 2013; 173:2039-46

• Average cost of an SSI = $20,7811
• Orthopedic SSI > $100K2

2Kurtz, et al. “Economic burden of periprosthetic joint infection in the United States”, Arthroplasty 2012; 27 (8 Suppl), 61-5.e.1

Kenall Confidential

Why Indigo-Clean in the OR?

Kenall Confidential

Control is Automatic

• Switching between modes can be automatically

performed using room occupancy sensors

• Eliminates potential training and compliance issues

11 Indigo-Only Mixed White

White Disinfection Mode = Ambient White Light + Disinfection Indigo Disinfection Mode = Increased Disinfection Only

Kenall Confidential

IC 100 Control Solution

• “Maximize Dose Without Impacting Visual Acuity”

12

Passive Infrared Sensor detects larger motions over a larger area Ultrasonic Sensor detects small motions in a focused area (over the table)

Kenall Confidential

Indigo-Clean Operating Room Solutions

13

2’x4’- M4SEDIC24 2’x2’- M4SEDIC22 1’x4’- M4SEDIC14 6” DL – M4DL6 $1,800* $1,200* $500* $1,200*

Book Pricing per Fixture @ 10%

Kenall Confidential

Visible Light Disinfection- More Than Just the LED

• Airflow creates a

dynamic environment for pathogens

• Can exist in the air and
• n surfaces
• How do you determine

the dose required for disinfection (and SSI reduction)?

• What is (are) the

reference point(s)?

14 ? ? ? ? ? ? ?

Kenall Confidential

VLD Is More Than Lighting...

15

Maximum Disinfecting Efficacy Luminaire Design Room Design

Irradiance = Disinfecting Power/Area

Ensures sufficient disinfecting power against challenging organisms (C. diff) on a single surface

@ of Fixtures in Room + Room Occupancy Considerations

Ensures sufficient disinfecting power against target organism(s) throughout a room

Per Photon Efficacy

Indigo-Clean Wavelength

400nm 420nm

Range of Disinfecting Wavelengths Maximum Disinfecting Wavelength

Kenall Confidential

Indigo-Clean Application: Operating Rooms

• Apply standard IES lighting guidelines to determine

number of fixtures per room and layout:

16

~625 sq. ft. ~625 sq. ft. ~625 sq. ft. 1:1 Replacement

Kenall Confidential

How to Specify Dual-Mode IC

• Determine application
• OR, Sterile Processing, Pharmacy, ED, Patient Bathroom
• Secure RCP (Reflected Ceiling Plan) and room

dimensions

• Include ceiling height (from light fixture to floor)
• Establish room occupancy patterns
• Is it occupied 24/7, 12 hrs./day, etc. (needed to determine if

Indigo-only mode is possible)

• Contact your Kenall RSM or Kenall Applications for

dosing and layout

• Required to ensure product performance
• Can try to “cross” the product, but some lighting designs may

require additional fixtures

17

Kenall Confidential

How to Sell Dual-Mode IC

• “Get as high up in the selling process as early as

possible”

• Get connected to the medical staff
• Ask the engineers and/or facilities for an introduction to

Surgical Services or Infection Prevention

• Emphasize the following points:
• Safe – no UV
• Automatic – no additional staff or training required
• Clinically proven to reduce surgical site infections by 73%
• It costs about $20-$25K per room (~$15K adder to regular

lighting)

• “Prevent one infection in 10 years, it pays for itself”
• Installed at over 100 OR’s across the US

18

Clinical Studies

19

Kenall Confidential

Maury Regional Medical Center

• ~500 sq. ft.
• Primarily used for
• rthopedic applications
• Sampling conducted over

30 day period in two rooms

• 15 days prior to installation
• 15 days after installation
• Contact agar (BPA) media

used

• Sampling performed on M,

W, F of each week

• 50 samples per room per

sampling day

20

Kenall Confidential

Room Adjacency and Airflow

21

Control

• Bacteria: ↓65%
• SSI: ↓75%

Common procedures, equipment, and staff

Test

• Bacteria: ↓88%
• SSI: ↓73%

Distant Control

• Bacteria: N/A
• SSI: ↑17%

Kenall Confidential

SSI Reduction

• Results published in AJIC 2019

22

Oct-15 to Oct-16 Oct-16 to Oct-17 P-Value

Room # of Cases # of SSI # of Cases # of SSI SSI Change Bacterial Reduction OR-1 (Adjacent Control) 662 8 660 2 >= -75% >= -56% 0.029 OR-2 (w/IC) 788 11 850 3 >= -73% >= -88% 0.011 OR-3 (Distant Control) 751 6 809 7 +17% Not measured Not measured Total 2201 2319

Kenall Confidential

Reduction of S. Aureus Infections

23

Kenall Confidential

1st Published Study Showing SSI Reduction

24

Kenall Confidential

Clinically Proven ROI

Kenall Confidential

Indigo-Clean Clinical Data Summary

Institution Location Area Studied Result Case Study Available? Froedtert Milwaukee, WI Waiting Room 70% No Allegheny General Pittsburgh, PA Patient Room 95% Poster Maury Regional Columbia, TN OR 88% Poster, In press Holy Family Manitowoc, WI OR 82% Yes Facility #1 AZ OR 70% In process ASC Spartanburg Spartanburg, SC OR 65%* Yes Geisinger Danville, PA OR 70% In press Facility #2 CA ED 53%-75% In process UNC (Rutala) Raleigh, NC Office NA Yes

26 *= Measured ATP, not bacterial reduction

Kenall Confidential

Additional Case Studies + Info

27

www.indigo-clean.com

Kenall Confidential

Installed at over 100 OR’s in the US!

Additional Dual-Mode Products

29

Kenall Confidential

Applications

Waiting Areas OR Patient Bathroom SPD or Pharmacy ED Trauma/ Triage Procedure/ Exam

30

Kenall Confidential

Indigo-Clean MEIC

• Disinfection for:
• Emergency departments
• Waiting rooms
• Procedural rooms
• 2’x2’ and 2’x4’ versions
• White & Indigo modes
• White mode:
• 3700K and 4300K
• 2,788 to 8,122 lumens
• Use with IC100 controls
• Input power 36 – 83W

31

Kenall Confidential

Indigo-Clean Sealed Downlight

• Disinfection for:
• Restrooms
• Patient Rooms
• Effective against C.diff
• 6” sealed downlight
• Regressed & flush lenses
• White & Indigo modes
• White mode:
• 3000K, 3500K, 4000K, 5000K
• Provides up to 2,000 lm
• Use with IC100, IC75 or existing controls (contact factory for

compatibility)

• Input power 29 – 40W

Indigo-Clean Technology

33

Kenall Confidential

Expanding the Use of Indigo-Clean

• What if a customer wants the benefits of Indigo-

Clean but can’t afford it or if the area is occupied 24/7?

• Kenall can put the White Disinfection mode into

any of its enclosures

• Single white disinfection-mode (no Indigo-only mode)
• 25% more than the cost of a regular Kenall fixture
• Useful in areas which are occupied 24/7
• Provides a “best effort” type of approach
• Some disinfection but not as much as the dual-mode

product

34

Kenall Confidential

Indigo-Clean Technology

35

• On-Demand disinfection
• Ambient light that

disinfects

• Single white disinfection

mode

• Automatic, whole-room

environmental disinfection

• Kills harmful bacteria

including staph such as MRSA

• Laboratory tested

disinfection

Kenall Confidential

Indigo-Clean Technology

• Healthcare
• Patient rooms
• Waiting rooms
• Corridors
• Therapy
• Pharmacy
• Cleanrooms
• Series:
• 6” downlights
• MPCADE 2x4
• ME 1x4, 2x2, 2x4
• AMB 2x2, 2x4

36

Kenall Confidential

Indigo-Clean Technology

• Behavioral health
• Patient rooms
• Dayrooms
• Infirmaries
• Exercise areas
• Series:
• HASEDI
• MMAC
• RMCD
• CC and CD

37

Kenall Confidential

Indigo-Clean Technology

• Correctional
• Cells
• Dayrooms
• Showers
• Exercise areas
• Series:
• SDSA
• SSA
• RMCD
• CC and CD

38

Kenall Confidential

Indigo-Clean Technology

• High Abuse
• Sport facilities
• Locker rooms
• Gymnasiums
• Natatoriums
• Series:
• 6” downlights
• HASEDI
• 1X4, 2X2, 2X4
• MLHA 5, 8, 12
• 4’ lengths

39

Kenall Confidential

IC vs. – Product Comparison

Indigo-Clean (Dual-Mode)

• Disinfection device that makes

functional/ambient white light

• Dual Mode: White disinfection

mode & Indigo disinfection mode

• Automatic, whole-room

Environmental Disinfection

• Kills harmful bacteria up to 6x

faster in Indigo-only mode

• Clinically Proven level (70%+) of

24/7 Disinfection

Indigo-Clean Technology (Single-Mode)

• Functional/Ambient light that

provides some disinfection

• Single Mode: White disinfection

mode only

• Automatic, whole-room

Environmental Disinfection

• Kills harmful bacteria including

staph such as MRSA

• Laboratory Tested Disinfection

per NSF Protocol: AESOP 18130, Issue 2

Kenall Confidential

IC vs. – Application Guide

Continuous

• OR, ED, Bathrooms, Pharmacy
• Indigo-only mode provides

highest levels of disinfection

• Use when highest levels of

disinfection are needed

• Use when disinfecting

challenging organisms such as C.diff

• Performance claim is based on

room occupancy, usage, 24 hour use cycle

On-Demand

• “Anywhere except the OR”
• Single Mode: White disinfection

mode only provides some disinfection

• Use when price is the primary

concern

• Use when primary concern is

common bacteria such as Staph

• Performance claim is based on

extension of laboratory results

• Results can vary based on actual use

cycle and room occupancy

Kenall Confidential

ICT Application Guide - Guidelines

• How do I design a space with ICT products?
• Simple...
• Light the room to 50-75 fc (average illuminance across

room at task plane with reflective walls, 9 ft. ceiling, etc.)

• Dosing is not performed separately as with IC
• Kenall does not review designs for dosing
• Make all fixtures in the room ICT to ensure color-

matching

• What do I get?
• You will achieve the laboratory claim on a surface of

~60% reduction in MRSA in 24 hours

42

Kenall Confidential

ICT Application Guide - FAQ

• What if the light doesn’t run for the 24 hours continuously?
• You won’t get 60% disinfection
• Why would you turn it off if it’s killing bacteria?
• Can we just turn off the white portion of the light when it’s

not in use to save energy?

• Not at this time. That’s a more complicated and expensive fixture

design

• What if 50-75 fc is too much light for the space?
• Design the space as you normally would, you’ll get less disinfection

43

Kenall Confidential

ICT Application Guide - FAQ

• How much bacteria does it kill if I don’t light the

space to 50-75 fc?

• We can’t estimate every possible condition of room

usage and light levels as many of these spaces are uncontrolled (compared to an OR)

• Use the laboratory test (60% in 24 hr. at 50-75 fc) as a

benchmark

• What happens if I mix ICT and non-ICT fixtures?
• It will look like you used two different CCT’s to light the

room.

44

Kenall Confidential

ICT Application Guide - FAQ

• Does ICT kill other bacteria besides Staph?
• Yes, the 405nm light can kill other bacteria just as

Indigo-Clean does

• How much of other types of bacteria can it kill?
• We can’t make a numerical statement related to other

bacteria types

• Given the potential range of bacteria and the number of

different fixture types, we have tested against Staph as a benchmark for comparison

• Is ICT as safe as IC?
• Yes, it uses less 405nm light than IC’s Indigo-only mode

45

Kenall Confidential

IC and Application Guide - Example

46

Kenall Confidential

ICT Application Guide - Example

47

Kenall Confidential

How to Specify (Single-Mode IC)

• Lighting Layout
• Light the space to 50-75 fc or as you normally would
• Obtain IES files for ICT fixtures from Kenall.com
• Contact your Kenall RSM for assistance
• Ask Kenall for a quote based on the layout
• Identical to normal quotation process
• Can “cross” the product based on wattage or lumen
• utput using book price
• Adder is typically $50-$60 per 55W engine

48

Kenall Confidential

How to Sell (Single-Mode IC)

• This is a spec lock- use it as such
• “Get as high up in the selling process as early as

possible”

• Emphasize the following points:
• Safe – no UV
• Automatic – no additional staff or training required
• Proven to kill bacteria
• Minimal cost adder per fixture – more disinfection that

your lights are providing today

• Installed in over 100 OR’s across the US

49

Kenall Confidential

ICT Supporting Literature

• Brochures and Spec

Sheets

• Available at Kenall.com
• Lab Test Data available

upon request

50

Kenall Confidential

Success Stories

• Henderson Hospital
• Henderson ASC
• Spring Valley
• Maury Regional
• Holy Family Memorial
• ASC Spartanburg
• New Century
• Geisinger
• Sutter
• Northern Arizona
• St. Marks
• Forsyth
• Texas Health
• KCH
• …

51

> $1M in Q1 2019 >500,000 hours of operation in the field

Kenall Confidential

Navigating Our Websites

• Live demonstration

52

Kenall Confidential

Indigo-Clean (Dual-Mode)

• Safe – no UV
• Automatic – no additional staff or

training required

• White = Low-Power
• Indigo-only = High-Power
• Clinically proven to reduce surgical

site infections by 73%

• It costs about $20-$25K per room

(~$15K adder to regular lighting)

• “Prevent one infection in 10 years, it

pays for itself”

• Installed at over 100 OR’s across

the US

• Kills in the air, on hard and soft

surfaces

• Available in 2’x4’, 2’x2’, 1’x4’, and 6”

DL

Kenall Confidential

ICT (Single-Mode)

• Safe – no UV
• Automatic – no additional

staff or training required

• Proven to reduce bacteria
• It costs about 25% more than

a regular fixture

• Adder is typically $50-$60 per

55W engine

• Installed at over 100 locations

across the US

• Kills in the air, on hard and

soft surfaces

• Available in any Kenall fixture

Kenall Confidential

FAQs

• What is the cost per room?
• This depends upon the size of the room and the number of

fixtures

• Can use $20K as an average value
• Deduct cost of white lights for “adder” in new construction
• How many lights do you need in a room?
• Kenall has determined the number of fixtures required in a

room based on its clinical studies

• All room designs must be reviewed by Kenall to ensure

proper dosage

• How long do the lights need to be on?
• The lights must be on 24/7. They are controlled automatically

via ultrasonic and PIR occupancy sensors

Kenall Confidential

FAQs

• How often do the bulbs need to be replaced?
• The lights are 100% LED so there is no bulb. They are

designed to last for 10 years

• What is the warranty?
• All of Kenall’s products come with our standard 5-year

warranty

• Is it safe?
• Indigo-Clean does NOT contain UV. It uses safe visible
• light. This safety is certified by 3rd party standards

Kenall Confidential

FAQs

• Who’s using it?
• Indigo-Clean is installed in over 100 OR’s across the US

and has been in clinical use since 2014.

• What type of bacteria does it kill?
• Indigo-Clean has been clinically shown to affect

numerous types of bacteria including MRSA and C.diff

• endospores. For specific questions regarding a specific
• rganism, contact Indigo-Clean
• How much bacteria does it kill?
• Using our automated controls and our reference

configuration, Indigo-Clean will see a 70% reduction of the bacteria in the room after 24 hours

Kenall Confidential

FAQs

• Do I still have to clean the room?
• Yes
• What about the 30% it doesn’t kill
• Any disinfection strategy will leave some amount of

bacteria in the room

• Indigo-Clean removes 70% in addition to what you’re

already doing

• Does this product reduce infections
• Yes, it has been clinically shown to reduce SSI’s by 73%

Questions!!!

• For more information, visit www.indigo-clean.com
• r www.kenall.com

59
