AEP Ohio Combined Heat and Power and Waste Energy Recovery Program Energy Utilization in the Utility Sector Source: http://www1.eere.energy.gov/manufacturing/distributedenergy/pdfs/chp_report_12 CHP: A Key Part of Our Energy Future Form
SLIDE 2
SLIDE 3
CHP: A Key Part of Our Energy Future
- Form of Distributed
Generation (DG)
- An integrated system
- Located at or near a
building/facility
- Provides at least a
portion of the electrical load and
- Uses thermal energy
for:
– Space Heating/Cooling – Process Heating/Cooling – Dehumidification
CHP provides efficient, clean, reliable, affordable energy – today and for the future
SLIDE 4
Defining Combined Heat and Power (CHP)
The on-site simultaneous generation of two forms of energy (heat and electricity) from a single fuel/energy source
SLIDE 5
CHP System Schematic
SLIDE 6
Common CHP Technologies and Generating Capacity Ranges
SLIDE 7
What Are the Benefits of CHP?
- CHP is more efficient than separate
generation of electricity and heat
- Higher efficiency translates to lower
- perating costs
- Higher efficiency reduces emissions of all
pollutants
- CHP can also increase energy reliability and
enhance power quality
SLIDE 8
CHP is Used Nationwide in Several Types of Buildings
81 GW installed at > 4,300 sites Avoids 241M tons
- f CO2 each year
SLIDE 9
CHP Today in Ohio
- 527 MW of installed CHP at
- ver 59 industrial and
commercial facilities
- Primary Metals comprises 226
MW of CHP capacity
SLIDE 10
AEP Ohio’s CHP Program
AEP Ohio is offering incentives to customers for eligible CHP projects
- AEP Ohio business customers
- Targeting Industrial, Institutional and
Commercial
SLIDE 11
Ohio Law states what systems can receive an incentive
As Defined by SB 310
- Combined Heat and Power is “the coproduction
- f electricity and useful thermal energy from the
same fuel source…”
– “…designed to achieve thermal-efficiency levels of at least sixty percent” – “…with at least twenty percent of the system's total useful energy in the form of thermal energy”*
*Source legislature.state.oh.us
SLIDE 12
AEP Ohio CHP Program Incentives
Systems > 1000 kW
- Incentive rate – 3.5 cents per Net kWh generated in the 1st year
- Payment may be split over 1 to 5 years
Systems < 1000 kW
- Incentive rate - 5 cents per Net kWh generated in the 1st year
- Payment period of 1 year
Caps
- $400,000 cap per project per year
SLIDE 13
Current Projects
2 projects have completed 2 projects are in the 12- month metering period 4 projects are under construction 3 projects are pending application completion
Increasing interest in CHP technology Projects total 302,000,000 kWh generated annually
SLIDE 14
AEP Ohio CHP Program Process
Payment Approval Process Complete Application
AEP Ohio and customer complete and sign application
Payment NOT completed within Plan period will be filed for PUCO approval Payment completed within Plan period will NOT be filed with Commission
Incentive payments begin after 12 months
- f meter
readings.
SLIDE 15
CHP Project Development Steps
Visit our website at aepohio.com/solutions for a free screening
SLIDE 16
Project Snapshot
https://www.puco.ohio.gov/industry-information/industry-topics/combined-heat-and-power-in-
- hio/chp-case-studies-voices-of-experience-workshop-june-20-2012/#sthash.MRLZAQNR.dpbs
Lima Wastewater Treatment Plant Lima, Ohio Application/Industry: Wastewater Treatment Capacity (MW): 130 kW Prime Mover: Microturbines Fuel Type: Biomass Thermal Use: Heat for the Digestion Process Installation Year: 2012 Testimonial: The CHP project was determined to provide:
- Best avenue for reductions of V.O.C.;s
- Best return of electrical energy
- Best capture of the heat for use in the
WWTP
SLIDE 17
Project Snapshot
Solvay Specialty Polymers Marietta, Ohio Application Industry: Chemical Manufacturing CHP Capacity (MW): 100% of steam needs and 97% of electrical load Fuel Type: Natural Gas Thermal Use: Process Heat Installation Year: 2015 Value Added Reduced energy cost; Increase in reliability of steam and energy sources; Economic development Testimonial: “We landed in a much better place than where we started.”
- Alan Wanosky, Operations Manager, Solvay Specialty
Polymers
