USE ENERGY RIGHT

With Green Solutions on Waste Heat Recovery Cooling/Heating Technology Waste Heat Recovery Cooling/Heating Technology

Topic: Use Energy Right, Energy Efficiency

• p c Use

e gy g t, e gy c e cy Part I Waste Heat Recovery Cooling Technology Part II Typical Application of WHRC Part III Waste Heat Recovery Heating Technology Part III Waste Heat Recovery Heating Technology

What Exhausted is What Exhausted is not Waste, but not Waste, but Money Money ! Wh What at shall w ll we do? do? at at s a e do

Shuangliang Solutions HR HRC System C System

Produce

• 5 ℃< t <25 ℃

Waste

HR HRC System C System

5 ℃< t <25 ℃ Chilled water

heat

Produce

HRH HRH Syste System

Plus 40 ℃, Maximum 175 ℃ H t t t Hot water or up to 6bar steam

Part I Waste Heat Recovery Part I Waste Heat Recovery Cooling Technology

Major HRC Equipments Flue Gas Based Multi Energy Absorption Chiller

• - Flue Gas Based Multi-Energy Absorption Chiller

Variable Combination:

• Flue Gas only
• Flue Gas + Jacket Water
• Flue Gas + Make-Up Burner
• Flue Gas + Jacket Water + Make-Up Burner

Flue Gas + Jacket Water + Make Up Steam

• Flue Gas + Jacket Water + Make-Up Steam

Flue gas source:

• Gas turbine/engine exhaust
• Gas turbine/engine exhaust

Cooling Capacity Range: 99RT—2000RT

Hot water operated Absorption Chiller

Hot water can be used: From 70 ℃ to 180 ℃ Cooling Capacity Range: 99RT—1488RT

Steam Operated Absorption Chiller

Steam can be used: From 0bar to 8bar Cooling Capacity Range: 99RT—3000RT

Direct Fired Absorption Chiller

Fuel:

• Biogas
• Natural gas
• LNG
• LPG

Di l

• Diesel

Cooling Capacity Range: 99RT 3000RT 99RT—3000RT

Part II Typical Application of WHRC Part II Typical Application of WHRC

• - Co-gen/Tri-gen System

Purpose of CCHP, Co-Gen & Tri-Gen: Raise energy efficiency Main method: Waste Heat Recovery Cooling/Absorption Cooling Technology Main method: Waste Heat Recovery Cooling/Absorption Cooling Technology

85%

Types of Cogen/Trigen

Flue gas only

g y

Flue gas + Make-up burner/steam Flue gas + Jacket water Flue gas + Jacket water + Make up burner/steam Flue gas + Jacket water + Make-up burner/steam Flue gas Steam Flue gas Hot water

g

Flue gas Hot water + Jacket water Jacket water only

Flue gas chiller with or without make-up burner

PT SMART, , Indonesia, 594RT, flue gas only, 3 gas engines + 3 chillers

Hainan Hairan Hi-Tech Energy Co,Ltd., China 1157RT flue gas + make-up burner chiller 1157RT, flue gas + make-up burner chiller 3 gas engines + 1 chiller

Flue gas + jacket water chiller with or without make-up burner

National Laboratory, Italy 896RT, flue gas + jacket water , g j 6 gas engines + 2 chillers

2008 Olympic Games y p Media Center, China

CCHP Load Plan Power Summer: Max load is 2.8 MW and the min load is 1.0 MW. Winter: Max load is 2.4 MW and the min load is 0.5MW. C li d H ti Cooling and Heating Summer: Max cooling load is 6840KW/h and supply/return water temp is 7-12℃. Winter: Max heating load is 5900KW/h and supply/return water temp is 60-50℃. System System Power Gas engine for independent power supply, utility power acts as standby and make-up Cooling Cooling 1 unit of flue gas + jacket water with burner chiller 1 unit of direct-fired chiller as standby Flue gas temp: about 500℃, Jacket water temp: 90℃. Heating Exhausted flue gas from chiller produces hot water for a 65m3 hot water tank for 24 hours sanitary hot water supply, 1 unit of 1.86 MW gas fired-boiler makes up inadequate hot water.

Sinha Rotor Spinning Mills Limited, Bangladesh

1500RT, 3 gas engines + 1 chiller, 8 bar steam as make-up

Design Machine room picture

Steam chiller + HRSG for gas/diesel engine/turbine

Automatic Diverter Valve Exhaust 10 Bar STEAM TO STEAM Chillers Exhaust WASTE HEAT RECOVERY Exhaust WASTE HEAT RECOVERY BOILER/HRSG Engine Engine Engine Engine Engine Engine

Financial Trade Center Karachi Pakistan 3 x 992 USRT 2 x 496 USRT 2 x 496 USRT 5 Steam Chillers Co-Gen System Gas Engines with HRSG

Pfizer, Singapore, 661RT, 1 steam chiller + HRSG for turbine

Hot water chiller + Waste Heat Recovery Boiler for gas/diesel engine /turbine

EXPANSION TANK

CHILLER

Chiller Output- 250 TR 76 ℃

POWER

Bypass port >105 ℃.

CHILLING

120 ℃

TI

To Atm >450 ℃

FINNED TUBE EXHAUST HEAT RECOVERY UNIT TI JACKET WATER HEAT RECOVERY

91 ℃. 93 ℃. 76 ℃ 78 ℃

Zee Television, India

270RT 1 gas engine + 1 hot Water chiller Hot water: 105/68 ℃

Combine all jacket water to one chiller

Engine Engine Engine

To chiller 91 ℃

70DC 90DC

Primary Circuit

To chiller 91 ℃

Secondary Circuit

Return 76 ℃ Colony Mills Ltd. Multan , Pakistan, 2800RT 8 gas engines + 4 hot water chillers 2800RT, 8 gas engines + 4 hot water chillers

GSK Biologics Vaccine Manufacture Singapore GSK Biologics Vaccine Manufacture, Singapore 223RT, 1 hot water chiller + 1 gas engine

Part III Waste Heat Recovery Part III Waste Heat Recovery Heating Technology – Absorption Heat Pump

65℃ 250℃ 20℃ 130℃ Waste heat Source Temperature 65 130 250 Waste heat 20 70 Waste heat boiler 2nd category heat pump 1st category heat pump

Heat source can be steam, hot water, heat-conducting oil, , , g , multi component gas and other related media.

Type of Absorption Heat Pump

First-category:

• Gas, oil, steam, hot water.
• COP: 1 8~2 2

COP: 1.8 2.2

• Waste hot water 20~70 Deg.C
• Hot water 40 plus less 100 Deg.C
• Capacity Range: 2-35MW

Capacity Range: 2 35MW Secondary-category:

• Waste heat above 65 Deg.C

g

• COP: 0.48
• Hot water 40 plus less 175 Deg.C
• Capacity Range: 1-15MW

All system is Tailor Made

Working Principle of 1st Category Heat Pump

60% heat

90 ℃

60% heat Output 100% heat

66 ℃ 30 ℃

40% heat

66 ℃ 40 ℃ 50 ℃

Application in District/City Heating Network in China

Working Principle of 2nd Category Heat Pump

Output 52% of heat from 109 ℃ hot water

37 ℃

p

32 ℃ 109 ℃ 85 ℃ 85 ℃ 140 ℃ 109 ℃ 130 ℃

Output 48% of heat from 109 ℃ hotwater

Application in Petroleum and Chemical - Butadiene Rubber Producing

Daqing Petrochemical Co Daqing Petrochemical Co., China Heating Capacity: 3370KW Benefit: save 48000 tons of steam/year and save li t cooling water
