Adapting to Rising Tides Bay Area

Second Regional Working Group Meeting November 8, 2017

ART Bay Area Regional Working Group Meeting #2

Working Group Meeting #2 – November 8, 2017 Objectives

• Confirm project goals, team and scope
• Continue to identify who and what is missing
• Obtain feedback on draft resilience goals
• Introduce ART Maps and mapping process
• Learn more about the assessment approach

Agenda 1:00 Introduction RWG 2 Objectives and Agenda, RWG 1 Recap 1:10 Announcements about related projects 1:20 Presentation and Discussion: Resilience Goals 1:40 Update on the public participation plan 1:45 Presentation: ART maps and exposure analysis 2:10 Break 2:25 Presentation: Vulnerability Assessment Approach 2:50 Exercise: Vulnerabilities and Dependencies 3:45 Wrap-up and Next Steps

ART Bay Area

ART Bay Area RWG Meeting #1 Recap

RWG Meeting #1 Recap

ü We described and discussed the project goals, team and scope ü We described and hopefully confirmed regional working group roles and responsibilities ü We asked RWG members at both meetings who is missing and to help us fill any gaps in issues or assets and in the analysis and approach ü We had a poster session intended to provide information on assets to be evaluated and approach and we heard it was not long enough ü Engaged in an exercise to help us draft resilience goals

ART Bay Area

ART Bay Area Project Timeline

Project Initiation – Fall 2017 Determine Assessment Outcomes – Summer/Fall 2018 Finalize Indicators and Framework – Winter/Spring 2019 Evaluate and Prioritize Adaptation Responses and Identify Opportunities for Implementation – Spring/Summer 2019 Transition to Adaptation – Fall 2018 Conduct Assessment – Fall/Spring 2017-18 Project Scoping – Fall/Winter 2017

Working Group Meeting Individual or small group meetings

Develop Adaptation Responses – Fall/Winter 2018-19

Public meetings

ART Bay Area

Purpose of the ART Bay Area project includes:

• Increase the resilience of the Bay Area’s

transportation system

• Preserve and restore healthy and vibrant

ecological systems which are necessary for the health and safety of the region’s natural and human communities

• Improve the safety and sustainability of our

communities, particularly our most vulnerable and disadvantaged communities

• Develop an adaptation planning framework

for future efforts

• Increase public outreach, participation and

engagement

Revised ART Bay Area Purpose

ART Bay Area

Related Efforts and Projects

ART Bay Area

Resilient by Design

A year-long collaborative design challenge bringing together local residents, public officials and local, national and international experts to develop 10 innovative community- based solutions that will strengthen our region’s resilience to sea level rise, severe storms, flooding and earthquakes. Collaborative Research Phase: September–December 2017 Collaborative Design Phase: Begins in December 2017 Next Event: November 15th, Design Opportunities Open House from 5pm to 7pm at the Contemporary Jewish Museum in San Francisco

Related Efforts and Projects

ART Bay Area

Plan Bay Area

A state-mandated, integrated long-range transportation, land-use and housing plan that is designed to:

• support a growing economy
• provide more housing and transportation choices
• reduce transportation-related pollution in the nine-county San

Francisco Bay Area.

• develop an efficient transportation network and grow in a financially

and environmentally responsible way

• Finalizing the Raising the Bar Report and a

presentation to the Bay Area Regional Collaborative Governing Board on November 17th

• Beginning to meet to discuss resilience approach

for the next Plan Bay Area

Related Efforts and Projects

ART Bay Area

SF Bay Watershed Coastal Resilience Assessment An assessment to map resilience hubs that identify restoration projects to increase the resilience of both human communities and wildlife habitat to the effects

• f coastal and inland storms

Pre-workshop Info Webinar: November 29th, 1-2 pm

• Registration and agenda coming soon

Two identical stakeholder workshops to choose from:

• December 13th OR 14th
• Oakland OR San Francisco (venue TBD)

ART Bay Area

Other announcements, questions

Purpose of Project Resilience Goals

Project resilience goals help guide the project

• Goals based on project scope,

flooding impacts and scenarios, assets, project area

• Opportunity for working group to

help define the project scope

• Should include all four frames of

sustainability

• Evaluate midway and change if

appropriate

• Use to develop evaluation criteria

to evaluate and prioritize action

ART Bay Area

Developing Project Resilience Goals

Process of developing project resilience goals

1.

Functions and Values mapping exercise at RWG Meeting #1

2.

ART and PMT reviewed exercise outcomes and relevant regional goals from other planning efforts

3.

Draft project resilience goals presented to RWG for review and input (today!)

4.

Will be revisited and refined by the RWG at key periods during the project, including the end of the assessment phase, development

• f evaluation criteria, prioritization of actions

ART Bay Area

Resilience Goals Recap

Functions and Values Mapping: Engagement Exercise

Goal: Identify the functions and values within the project area that are important to consider when assessing current and future flooding

ART Bay Area

Project Resilience Goals Preamble

Draft Preamble

ART Bay Area

The Adapting to Rising Tides Bay Area project is a regional adaptation planning process focused on regional assets and

• issues. Although regional in scope and scale, the resilience of

the region depends upon the resilience of local communities. Because of the interdependence of the regional and local scales, the following resilience goals reflect issues at both scales and are intended to be used in a way that acknowledges the similarities and differences among the region’s local communities and the importance of the scales.

Draft Project Resilience Goals

Society and Equity

ART Bay Area

Protect and improve Bay Area communities’ ability to access services, affordable and safe housing, a healthy environment, diverse jobs, transportation, information, and opportunities for advancement. Focus on identifying and assisting vulnerable communities who endure disproportionate environmental burdens or exhibit socioeconomic characteristics that increase their risk to hazards.

Draft Project Resilience Goals

Environment

ART Bay Area

Preserve and enhance healthy and vibrant ecological systems to provide multiple benefits, including habitat for native and endangered species, biodiversity, clean water, flood protection, and recreation to maintain high quality of life for natural and human communities. Mitigate environmental risks, such as contaminated lands and poor air quality, and encourage emissions reductions through transitioning to alternative forms of transport and energy to minimize the effects of future climate change. Promote the long-term vitality of natural areas, including wetlands, tidal marshes, creeks, and transition zones, by ensuring they remain resilient and adaptable in a changing future climate.

Draft Project Resilience Goals

Economy

ART Bay Area

Create and support vibrant local and regional economies that provide living wage jobs, tax revenues to cities, affordable housing, goods, and services, are adaptable to changing conditions, and are supportive of both local and global businesses. Focus on maintaining the function of regional job centers, recreation and tourism destinations, transportation networks, and infrastructure. Maintain robust local linkages in a multi-modal transportation network to deliver people, goods, and services throughout the region, nation, and world.

Draft Project Resilience Goals

Governance

ART Bay Area

Build capacity for resilience in local and regional Bay Area communities, agencies, and non-governmental and private

• rganizations by facilitating broad participation at critical points in

climate adaptation processes, including scoping, framing, decision making, program development, and project implementation. Understand and improve upon on current governance challenges by building consensus around appropriate and distinct areas of responsibility for regional entities and local jurisdictions. Build collaboration within the Bay Area by forming coalitions, collaboratives, and JPAs among agencies, organizations, and communities to address issues of flood protection, environmental restoration, infrastructure maintenance, and affordable housing.

ART Bay Area

• Revise based on RWG input received

today

• Provide new version for comment to

RWG for further revisions from people who were unable to attend today or for those of you who want more time

• Provide final draft version to RWG at

RWG Meeting #3 in January

• Present to public at the first public

participation meeting and obtain input

Project Resilience Goals

Next Steps:

• Revise based on RWG input received today
• Provide new version for comment to RWG for further

revisions from people who were unable to attend today

• r for those of you who want more time
• Provide final draft version to RWG at RWG Meeting #3

in January

• Present to public at the first public participation meeting

and obtain input

Public Participation Approach

ART Bay Area

19

Public Engagement and Participation

Obtain direction and input from the public at least seven public meetings at key times during the project, provide multiple ways for the public to engage in the project

Role of the public in the project Public Participation Approach

• In person project meetings
• Attendance at existing community

meetings and events

• Participate in RBD and other

meetings where appropriate

• Other ways to engage: on-line or

telephone town halls, etc.

RWG request: Sign up for a Communication Subcommittee meeting to assist the PMT with refining the public participation plan, communication approach and identifying community groups to engage

ART Regional Sea Level Rise Maps

• Uniform mapping for all 9 counties

including 10 total water level scenarios of current and future flooding

• An effective planning tool to:
• Communicate temporary and

permanent flooding

• Identify low spots on the

shoreline that can lead to inland flooding

• Stakeholder reviewed and

validated

• High resolution topographic data

(1 meter DEM)

ART’s One Map = Many Futures

Source: AECOM

• Uses an equivalent water level approach to reduce the

number of maps needed to understand flooding

• Communicates that areas that may be permanently

inundated will first be temporarily flooded

• Provides information that allows local jurisdictions and

agencies to develop thresholds for action

100-year storm surgeà 1/100 chance of occurrence in any yearà 1% chance The smaller the chance of occurrence, the larger the storm, the larger the area flooded.

Storm Surge Event Intervals in Santa Clara County

ART’s One Map = Many Futures

This single map depicts:

High tide permanent inundation from 36” SLR

• r

Temporary flooding from:

• 2-year storm surge

with 18” SLR

• 5-year storm surge

with 12” SLR

• Today’s conditions

with 50-year storm surge

SLR Inundation & Overtopping -36”

January, 2017

Belvedere

Sausalito

0.2 0.4 0.6 0.8 1 Miles

$

Projection: Universal Transverse Mercator NAD83 Zone 10N The inundation maps and the associated analyses provide a regional-scale illustration of inundation and coastal flooding due to specific sea level rise and storm surge scenarios, and are intended to improve sea level rise awareness and

• preparedness. The maps are not detailed to the parcel-scale and should not be used for navigation, permitting, regulatory, or other legal uses. Flooding due to sea level rise and storm surges is possible in areas outside of those predicted in

these maps, and the maps do not guarantee the safety of an individual or structure. Nor do the maps model flooding from other sources, such as riverine or surface water flooding from rainfall-runoff events. The contributors and sponsors of this product do not assume liability for any injury, death, property damage, or other effects of flooding. The maps relied on a 1-meter digital elevation model created from LiDAR data collected in 2010 and additional survey data (where available). Although reasonable care was taken to capture all relevant topographic features and structures that may impact coastal inundation, it is possible that structures may not be fully represented, especially those that are narrower than the 1-meter horizontal map scale. The maps are based on model outputs and do not account for all of the complex and dynamic San Francisco Bay processes or future conditions such as erosion, subsidence, future construction or shoreline protection upgrades, or other changes to San Francisco Bay or the region that may occur in response to sea level rise. These inundation maps should not be used for detailed design or construction and users should consult a licensed engineer for information regarding existing and future flood risk at an individual site. For more context about the maps and analyses, including a description of the data and methods used, please see the Adapting to Rising Tides Bay Area Sea Level Rise Analysis and Mapping project report. The inundation maps and associated analyses are provided "as is.” Neither BATA, the Metropolitan Transportation Commission, the Bay Conservation and Development Commission, the California Coastal Conservancy, the San Francisco Public Utilities Commission, nor their contractors, make any warranty whatsoever, whether expressed or implied, as to the accuracy, thoroughness, value, quality, validity, merchantability, suitability, condition, or fitness for a particular purpose of the inundation maps and associated analyses, nor as to whether the inundation maps and associated analyses are error-free, up-to-date, complete or based upon accurate or meaningful facts. SLR + STORM SURGE SCENARIOS LISTED BELOW COULD BE APPROXIMATED BY THE INUNDATION SHOWN ON THIS MAP.

Sea Level Rise Inundation

Disconnected Areas > 1 Acre

Depth in Feet

0 - 2 2 - 4 4 - 6 6 - 8 8 - 10 10 - 12 12 - 14 16+ 14 - 16

Shoreline Overtopping Potential

No Overtopping Depth in Feet

1 - 2 2 - 3 3 - 4 4 - 5 0.5 - 1 > 5

1:45,000

ART’s One Map = Many Futures

Each map represents a number of projected sea level rise and extreme tides (storm surge) combinations

ART Shoreline Studies

Seven shoreline types identified

• Engineered Flood Protection
• Engineered Shoreline

Protection

• Embankments
• Transportation Structures
• Non Engineered Berms
• Wetlands
• Natural Shoreline/Beach

Identifies shoreline locations that may be too low, which helps prioritize where further study or immediate actions may be necessary

ART Shoreline Overtopping Analysis

SF Bay Water Level Freeboard Overtopping

January, 2017

Belvedere

Sausalito

0.2 0.4 0.6 0.8 1 Miles

$

Projection: Universal Transverse Mercator NAD83 Zone 10N The inundation maps and the associated analyses provide a regional-scale illustration of inundation and coastal flooding due to specific sea level rise and storm surge scenarios, and are intended to improve sea level rise awareness and

• preparedness. The maps are not detailed to the parcel-scale and should not be used for navigation, permitting, regulatory, or other legal uses. Flooding due to sea level rise and storm surges is possible in areas outside of those predicted in

these maps, and the maps do not guarantee the safety of an individual or structure. Nor do the maps model flooding from other sources, such as riverine or surface water flooding from rainfall-runoff events. The contributors and sponsors of this product do not assume liability for any injury, death, property damage, or other effects of flooding. The maps relied on a 1-meter digital elevation model created from LiDAR data collected in 2010 and additional survey data (where available). Although reasonable care was taken to capture all relevant topographic features and structures that may impact coastal inundation, it is possible that structures may not be fully represented, especially those that are narrower than the 1-meter horizontal map scale. The maps are based on model outputs and do not account for all of the complex and dynamic San Francisco Bay processes or future conditions such as erosion, subsidence, future construction or shoreline protection upgrades, or other changes to San Francisco Bay or the region that may occur in response to sea level rise. These inundation maps should not be used for detailed design or construction and users should consult a licensed engineer for information regarding existing and future flood risk at an individual site. For more context about the maps and analyses, including a description of the data and methods used, please see the Adapting to Rising Tides Bay Area Sea Level Rise Analysis and Mapping project report. The inundation maps and associated analyses are provided "as is.” Neither BATA, the Metropolitan Transportation Commission, the Bay Conservation and Development Commission, the California Coastal Conservancy, the San Francisco Public Utilities Commission, nor their contractors, make any warranty whatsoever, whether expressed or implied, as to the accuracy, thoroughness, value, quality, validity, merchantability, suitability, condition, or fitness for a particular purpose of the inundation maps and associated analyses, nor as to whether the inundation maps and associated analyses are error-free, up-to-date, complete or based upon accurate or meaningful facts. SLR + STORM SURGE SCENARIOS LISTED BELOW COULD BE APPROXIMATED BY THE INUNDATION SHOWN ON THIS MAP.

Sea Level Rise Inundation

Disconnected Areas > 1 Acre

Depth in Feet

0 - 2 2 - 4 4 - 6 6 - 8 8 - 10 10 - 12 12 - 14 16+ 14 - 16

Shoreline Overtopping Potential

No Overtopping Depth in Feet

1 - 2 2 - 3 3 - 4 4 - 5 0.5 - 1 > 5

1:45,000

ART Maps: Disconnected Areas

Models and Methods

• MIKE21 Model of San Francisco

Bay

• Tides
• Ocean-driven swell
• Wind-wave generation within the

Bay

• Continuous modeling
• 1973 – 2003 (Central & North Bay)
• 1956 – 2009 (South Bay)
• Calibrated and validated to 11

large storm events

Models and Methods: Tidal Datums

Methods: Terrain

• 2010/2011 LiDAR collected by the USGS and NOAA
• 1-meter bare earth digital elevation model (DEM)
• Captures most features that provide flood protection

features

• Local knowledge from the FEMA Bay Area Coastal

Study used to refine DEM to better represent flood protection features

• Stakeholder review and feedback to further refine

DEM

• If an area is displayed as flooded with 12” of SLR, and it has

never flooded during a King Tide or storm event, the area is reviewed

Stakeholder Input is Key!

Will OAK flood with 12 inches of sea level rise? If so, flooding would have been observed during a King Tide

When to use the data?

• Support robust, local-scale vulnerability

assessments in San Francisco Bay

• Support development of both near-term and

long-term adaptation strategies for San Francisco Bay

• Regional scale vulnerability assessments in

San Francisco Bay

Where to get the data? www.adaptingtorisingtides.org

• Geodatabases
• Map books
• Technical documentation
• Example analysis
• Webviewer coming Spring 2018

For more information contact: eliza.berry@bcdc.ca.gov

ART Planning Process

ART Bay Area

ART Bay Area

At the first RWG meeting, the project area was described as the nine county Bay Area, including both coastal and riverine flooding, with a focus on the bay side

Scope and Scale: Project Area

Scope and Scale: Project Team

ART Bay Area

Project Management Team: Bay Conservation and Development Commission’s Adapting to Rising Tides Program team (BCDC ART), Bay Area Regional Collaborative (BARC), Metropolitan Transportation Commission and Caltrans Consultant Team: Natural Capital (NatCap), AECOM Regional Working Group: Issue, asset, geographic and community experts and stakeholders who provide guidance, input and contribute to collaborative decision-making throughout the process

• More frequent flooding of existing flood-

prone areas

• Flooding in areas that are not currently

at risk

• Elevated groundwater

and increased salinity intrusion

• Permanent inundation along the

shoreline, in particular tidal wetland systems

• Shoreline erosion and overtopping
• Tidal creek and channel flooding

Impacts from coastal and/or riverine flood events including:

Scope and Organize: Flooding Impacts and Scenarios

ART Bay Area

The ART Bay Area project is a regional scale adaptation planning effort that includes the following assets:

• Transportation assets (bridges,

highways, Bay Trail, transit, airports)

• Priority Development Areas and

residential areas

• Priority Conservation Areas and

natural areas

• Disadvantaged and vulnerable

community members

ART Bay Area

Scope and Scale: List of Included Assets

Numerous assets, networked systems and/or limited information

Scope and Scale: Asset List

ART Bay Area

• Major highways (US 101, I-80, I-880, I-580, SR-37, SR-237)
• Airports and Ports
• Toll plazas and bridge approaches
• Rail service (heavy and commuter)
• Transit Services
• Bay Area Rapid Transit
• San Francisco Bay Trail.
• Local Roads

The challenge of the regional scale: Transportation Example

How do we focus

• n the vulnerable

assets that we care most about?

The region is large Each city has a lot of assets!

ART Planning Process

Scope and Organize: Identify the scale of the project and working group

• members. Determine assets

to be included and resilience goals for the project Assess: Use ART assessment questions to understand vulnerability & consequences Define: describe and communicate assessment

• utcomes

Plan: Develop multi-objective adaptation responses at various scales Implement and Monitor:

Actors, funding and actions from plan step The assessment step helps

ART Bay Area

What is the Assess Step?

• A step-wise exposure analysis that

saves time and resources by pinpointing the most pressing issues and areas to explore further

• Assessment questions that help

efficiently gather information needed for action identification

• Review and validation of

assessment outcomes by stakeholders, asset managers, local and topical experts

The assessment has three parts:

The assess step builds upon the decisions made in scope and organize and is a critical part of the filtering process of what gets carried through to the adaptation responses and prioritizing action phases

• f the project

ART Bay Area

ART Assessment Questions

Assessment questions are a tool to efficiently gather information about vulnerability and risk

• Preliminary answers are

gathered using readily available data, reports and studies

• Findings are validated by

working group members, topical experts, and those with local knowledge

ü Written surveys ü Individual meetings ü Phone interviews ü Field visits

ART$Assessment$Questions:$Stormwater/Flood-Control-Infrastructure- Asset-name:-Walnut-Creek- !

GOVERNANCE VULNERABILITIES$describe challenges with management, regulatory authority, or funding.-- Questions- Answers (include data sources)-

• 1. Is the asset managed to achieve multiple

goals or objectives e.g., habitat, water quality, flood control, recreation, shoreline access, etc.? If yes, are their conflicts among them?

• Yes,-flood-protection-and-habitat-goals-conflict-–-leaving-the-habitat-in-place-was-

not-an-acceptable-maintenance-practice-in-the-eyes-of-USACE,-so-CCCFC&WCD-had- to-decide-whether-to-a)-remove-all-the-vegetation-and-habitat-in-the-channel-to- restore-it-to-its-1960s-configuration,-or-b)-allow-the-sediment,-vegetation-and- habitat-to-remain-but-be-out-of-conformance-with-the-USACE.-

• 2. If the asset owner and manager are

different, what is the relationship between them, e.g., a legal agreement such as a lease, right-of-way, access easement, JPA, MOU or MOA?

• NA-
• 3. Describe any plans that are relevant to

asset management or improvement, e.g., Master Plan, Capital Improvement Plan, and if/how they consider sea level rise.

• CCCFC&WCD-has-developed-a-restoration-vision-to-reduce-flood-risk,-

accommodate-sea-level-rise,-work-with-nature-(to-handle-sediment-loads),- improve-habitat-for-all-species,-and-provide-more-recreational-opportunities,-and- hired-ESA-PWA-to-complete-the-following-scope-of-work-to-support-the-project:-

• 1.-Data-Review/Stakeholder-Assessment-

2.-Feasibility-Study-(evaluation/selection-of-Project-alternatives-based-on-hydraulic- modeling,-geomorphic-assessment,-geotechnical-evaluation,-biological-resources- and-wetlands-review,-public-access-plan,-estimated-project-costs,-and-more- stakeholder-engagement- 3.-Conceptual-Design-and-Project-Study-(suitable-for-environmental-review-under- CEQA-and-NEPA)-

• 4. If the asset is protected from flooding by

land or assets owned or managed by

• thers (e.g., natural areas, structural

protection, roadways), what is the relationship between the asset

• wner/manager and these entities? Do

they coordinate information, funding or decision-making?

• NA-
• 5. What types of permits (and from which

agencies) are necessary to maintain, repair

• r improve the asset? Are there special

processes for emergency repairs?

Permits-from-local,-state,-and-federal-agencies-are-required,-e.g.,-BCDC,-RWQCB,- CDFW,-NMFS,-USFWS-and-USACE,-both-to-complete-maintenance-dredging-and- capital-projects.-

ART Bay Area

ART Assessment Questions

Existing conditions questions describe the asset or asset category and highlight any current conditions

• r stressors that could affect its vulnerability

Examples

• Where is the asset located?
• Who owns and manages it?
• What are the underlying

conditions (seismic vulnerability, lack of funding, displacement, contaminated lands, etc) that are important to consider?

ART Bay Area

EXISTING CONDITIONS: PDAs

• Presence of affordable housing in

surrounding area

• Presence of housing and

transportation cost burden in surrounding area

• Type of PDA (City center, mixed

use corridor, regional center, suburban center, transit neighborhood, transit town center, urban neighborhood) and primary goal (housing, jobs, transit center)

• Surrounding land uses and

community facilities

ART Bay Area

Information questions determine if data or information is lacking, incomplete, poorly coordinated, or difficult to access

Examples

• What types of information sources are

publicly available?

• What is the quality of available information?
• What types of mechanisms exist to share

information between owners of connected infrastructure?

ART Assessment Questions

ART Bay Area

INFORMATION: State/Interstate Roads

• Most Caltrans planning-grade data

(e.g., the location of storm drain and bridge crossings) is readily available and can easily be shared

• Caltrans design and survey-grade

data (e.g., as-built plans with elevation information) can be challenging to access because they are created and stored on a project-by-project basis

• Caltrans has a searchable

repository of records (e.g., as-built and layout plan sheets), however these are shared as PDFs that are not geo-referenced

ART Bay Area

Governance questions identify challenges with management, regulatory authority, or funding

• ptions for adapting to impacts

Examples

• What systems are in place to manage

the assets?

• What funding sources exist that can be

used for adaptation?

• What types of permits are needed to

make changes?

ART Assessment Questions

ART Bay Area

GOVERNANCE: Communities

• What capacity do the non-profits, faith-based

and community based organizations in the project area have to actively participate in adaptation planning? What processes are in place for the local jurisdiction and these groups to engage in existing planning and decision making?

• If the community is protected from flooding by

land or assets owned or managed by others (e.g., structural protection, roadways, rail embankments), what is the relationship between the asset owner/manager and these entities? Do they coordinate information, funding or decision-making?

• Local plans (General Plans, Hazard

Mitigation Plans, etc.) that are in process, or soon to be in process, of updating? ART Bay Area

Examples

• Does the asset provide functions or

services that are limited?

• What services does the asset rely on?
• Is it physically connected to other

assets such that failure in one part of the system disrupts the entire system?

Functional questions consider the function of the assets and their relationship to or dependence

• n other assets

ART Assessment Questions

ART Bay Area

FUNCTIONAL: PCAs

• Does the PCA provide or protect habitat

for threatened or endangered species?

• Would disruption from flooding

potentially impact the open space/wildlife/habitat network’s ability to function?

• Does the PCA provide recreational
• pportunities that are unique or limited

in the area and/or region, e.g., access for persons with limited mobility, interpretive programs, access to the Bay, etc.? Could functions be easily replaced in other areas?

ART Bay Area

Physical questions identify conditions or design aspects that make an asset particular vulnerable

Examples

• To what extent is the asset exposed to tidal, wind or

wave erosion or scour?

• Does the asset have openings are at-grade or below-

grade that are entry points for flooding? Are there pumps

• r other systems in place to remove floodwaters?
• What water- or salt-sensitive components of the asset

are located at- or below-grade?

ART Assessment Questions

ART Bay Area

PHYSICAL: Transportation

• Does the asset have openings are

at-grade or below-grade that are entry points for flooding, e.g., entryways, tubes, tunnels, ventilation grates?

• Has the asset been impacted by

flooding from storm surge or large rain events? What components were impacted? How? (e.g. flooding of components, groundwater intrusion)

• Was the asset designed to be

exposed to salt water? For what period of time?

ART Bay Area

Consequences questions informs how climate change may impact society and equity, the economy and environment.

Examples § How would the community, particularly at-risk members, be affected by damage, disruption,

• r loss of asset function?

§ What critical emergency services would be affected if the asset was damaged, disrupted

• r failed?

§ If the asset was damaged, disrupted or failed would there be a loss of public access, recreational, educational or interpretation?

ART Assessment Questions

ART Bay Area

CONSEQUENCES: PCAs

• Are any of the vulnerable habitats scarce

in the region? Could the habitat be established in other areas?

• What would consequences to ecological

services be if the PCA habitat is damaged

• r lost (e.g. habitat or species benefits,

public access to the shoreline, or water quality)? What would the effect of this loss be locally? Regionally?

• Are the surrounding communities/users of

the PCA underserved in terms of open space/green/recreational areas? How would the potential disruption or loss affect the PCA users and stakeholders?

ART Bay Area

Preliminary Assessment Answers

• Using readily available

data, maps, studies

• By contacting working

group members for additional information

ART staff has begun to compile preliminary assessment information

Examples Information Sources Integrated Regional Water Management Plan CA Department of Transportation California Energy Commission California Public Utilities Commission County and city plans (General Plans, Capitol Plans, Emergency Operations Plans, Zoning Code, Climate Action, Vulnerability Assessments) County and city special studies County Tax Assessor Parcel Data Local Agency Formation Commission MTC TeleAtlas National Pipeline Mapping System PG&E Plan Bay Area’s Sustainable Community Strategy Regional Housing Needs Assessment State Employment Statistics State Water Resources Control Board Geotracker U.S. Census / American Community Survey Urban Water Management Plans US EPA Envirofacts

ART Bay Area

Working Group Review and Input

Answers to the assessment questions will be ready for working group review and input Draft profile sheets that summarize the assessment findings will be ready for working group feedback at the next RWG meeting All materials communicating the assessment outcomes will be available for working group review before they are finalized

ART Bay Area

Asset List Revisited

ART Bay Area

While the assessment step will help us identify the vulnerable assets, we return to the initial problem: the region is big and the assets and assessment questions are numerous.

The region is large Each city has a lot of assets!

Proposal:

• Evaluate and use completed assessments
• Short list of assessment questions that will

build toward indicators

• RWG participation in assisting in the

development of indicators

• Use indicators to

assess at regional scale

• Deeper assessment

conducted with selected assets

Engagement Exercise Understanding Vulnerabilities and Dependencies

• Identify the relationships and connections among

assets

• Explore the vulnerabilities of assets, particularly those

related to asset function and connections

• Discuss the consequences of the vulnerabilities and

how they affect different assets, sectors, and scales

• Provide input on most important characteristics

(indicators) to consider during the assessment

ART Bay Area

Vulnerabilities and Dependencies Engagement Exercise Report Back

ART Bay Area

• Did your table uncover any surprising relationships
• r dependencies?
• Were the dependencies and relationships among

the assets included in the project identified and highlighted at all? Where there critical assets that are not part of the project that people feel need to be considered?

• Which three to five characteristics were identified

by your table that the ART team and the PMT should consider highlighting in the short list of assessment questions? As indicators?

Next Steps

ART Bay Area

ART Bay Area Regional Working Group Meeting #3

• Sign up to assist with Communications Advisory Committee
• Your input on project resilience goals
• Asset owner, manager or topical expert meetings, interviews to

gain input and review of assessments and potential indicators

• Visit the project webpage!
• Next meeting: Middle of January
