ACR 3413 BASIC STRUCTURAL ENGINEERING 3 Lecture 2 Univers rsit ity y Putra a Malaysia ysia - Communication - Talk to Architect, M&E Engineer and Other Consultants of their Requirements Item Verti tical Load {V} Horizon zonta tal

slide-1
SLIDE 1

Univers rsit ity y Putra a Malaysia ysia

ACR 3413 BASIC STRUCTURAL ENGINEERING 3 Lecture 2

slide-2
SLIDE 2

2

  • Communication - Talk to Architect, M&E Engineer and Other

Consultants of their Requirements

  • Quality Control (QA) (V & H) - Do It All Again and Again

Item Verti tical Load {V} Horizon zonta tal Load {H} Conceptual Design  X Loading TODAY’S LECTURE X Scheme Design X X Analysis X X Design X X

slide-3
SLIDE 3

3

  • Communication - Talk to Architect, M&E Engineer and Other

Consultants of their Requirements

  • Conceptual Design (V & H)
  • Loading Estimation (V & H) (Hand, Spreadsheet, Commercial

Software)

  • Scheme Design (V & H) (Hand, Data Tables from Books)
  • Analysis (V & H) (Hand, Spreadsheets, Commercial Software)
  • Design (V & H) (Hand, Spreadsheets, Commercial Software)
  • Quality Control (QA) (V & H) - Do It All Again and Again
slide-4
SLIDE 4

Types of Loading DL, SDL, LL, NHL, WL, EQ Nature of Loading Mass, Pressure, UDL and Point Load Dead Load, Superimposed Dead Load and Live Load Definition, Code Value Load Path Concepts of Load Paths

  • Page | 4
  • Load Calculation

Examples

slide-5
SLIDE 5

5

slide-6
SLIDE 6

Types of Loading

Dead Load Self Weigh ght t / Dead d Load ad (Member Weight) t), , DL Supe perimpo pose sed d Dead d Load ad (Soi

  • il,

, Water, Ceiling, , Etc.), , SDL Live Load ad Live Load ad (Human an, Furnitu ture, , Etc.), LL

6

slide-7
SLIDE 7

7

slide-8
SLIDE 8

8

slide-9
SLIDE 9

9

Live Load, LL Self Weight / Dead Load, DL Superimposed Dead Load, SDL

slide-10
SLIDE 10

10

slide-11
SLIDE 11

11

slide-12
SLIDE 12

12

1) 1) Mass (kg) (3-D) D) The mass of an object is a measure how heavy the

  • bject

is. It is measured in units of grams (g) or kilograms (kg). 2) Pressure (kN kN/m /m2) (2-D) D) Pressure is the force applied perpendicular to the surface of an

  • bject per unit area (kN/m2) over

which that force is distributed. 3) Unifor

  • rml

mly y Distr tribu bute ted Load (UDL) (kN kN/m) m) (1-D) D) UDL is a load that is evenly spread along a length such as brick wall on

  • slab. It is

measured in units of (kN/m). 4) Point t Load (kN kN) (0-D) D) A point load is a load applied to a single, specific point on a structural

  • member. It is

measured in units of (kN).

slide-13
SLIDE 13

13

1) 1) Mass (kg) (3-D) D) Made e up of the e followi

  • wing

g types es of loading  DL DL, SDL, LL, NHL, WL, EQ 2) Pressure (kN kN/m /m2) (2-D) D) Made up of the followi

  • wing

g types of loading  DL, SDL, LL, NHL, WL, EQ 3) Unifor

  • rml

mly y Distr tribu bute ted Load (UDL) (kN kN/m) m) (1-D) D) Made up of the followi

  • wing

g types of loading  DL, SDL, LL, NHL, WL, EQ 4) Point t Load (kN kN) (0-D) D) Made up of the followi

  • wing

g types of loading  DL, SDL, LL, NHL, WL, EQ

slide-14
SLIDE 14

14

Mass 3-D (tonnes / kN / kg) Pressure 2-D (kN/m2) UDL 1-D (kN/m) Point Load 0-D (kN) Flow Path

slide-15
SLIDE 15

15

Mercedes One car = 2500 kg = 2.5 tonnes = 25kN Proton Saga One car = 1000 kg = 1.0 tonnes = 10kN Normal Person Average one person mass = 80 kg = 0.8kN Heavy Person Average one person mass = 100 kg = 1.0kN

[LL]

slide-16
SLIDE 16

16

Burj Khalifa 171 Storeys (659m High) Tower = 946,000 tonnes = 946,000 Proton Saga’s = 9,460,000 kN = 9,460,000 Heavy Persons Area = 280,000 m2

CTBUH, Tall and Super Tall Buildings

[SLS]=[DL+SDL+LL]

slide-17
SLIDE 17

17

Sears Tower 113 Storeys (454.8m High) Tower = 380,000 tonnes = 380,000 Proton Saga’s = 3,800,000 kN = 3,800,000 Heavy Persons Area = 408,922 m2

CTBUH, Tall and Super Tall Buildings

[SLS]=[DL+SDL+LL]

slide-18
SLIDE 18

18

Taipei 101 94 Storeys (405.8m High) Tower = 365,000 tonnes = 365,000 Proton Saga’s = 3,650,000 kN = 3,650,000 Heavy Persons Area = 187,110 m2

http://skyscraperpage.com/cities/?buildingID=18

[SLS]=[DL+SDL+LL]

slide-19
SLIDE 19

19

Petronas Twin Tower 93 Storeys (403.8m High) One tower = 330,000 tonnes = 330,000 Proton Saga’s = 3,300,000 kN = 3,300,000 Heavy Persons Area = 213,750 m2

CTBUH, Tall and Super Tall Buildings

[SLS]=[DL+SDL+LL]

slide-20
SLIDE 20

20

Skyview Penang 43 Storeys (147.3m High) Block A = 114,000 tonnes = 114,000 Proton Saga’s = 1,140,000 kN = 1,140,000 Heavy Persons Area = 66,365 m2

[SLS]=[DL+SDL+LL]

slide-21
SLIDE 21

21

Ampang Condo 18 Storeys (63.4m High) Block B = 69,000 tonnes = 69,000 Proton Saga’s = 690,000 kN = 690,000 Heavy Persons Area = 51,621 m2

[SLS]=[DL+SDL+LL]

slide-22
SLIDE 22

22

Ipoh Hospital New Block 10 Storeys (46.1m High) Hospital = 183,000 tonnes = 183,000 Proton Saga’s = 1,830,000 kN = 1,830,000 Heavy Persons Area = 103,717 m2

[SLS]=[DL+SDL+LL]

slide-23
SLIDE 23

23

Average Car Pressure (LL) = 2.5 kN/m2

  • Eg. 2000kg / (2.0m x 4.8m)

= 210kg/m2  250kg/m2 = 2.5kN/m2.

[LL]

slide-24
SLIDE 24

24

Humans in Congregation (LL)= 5.0 kN/m2 This means 5 Heavy Persons in 1 m2 !

[LL]

slide-25
SLIDE 25

25

Building Functi tion

  • n

Load (kPa)

Classrooms, lecture rooms, tutorial rooms, computer rooms 3.0 Domestic uses & residential activities 2.0 Wards, bedrooms and toilet rooms in hospitals, nursing homes and residential care homes. 2.0 Kitchens 2.0 Floors for offices 3.0 Conference rooms 5.0 Stair Case 4.0 Department stores, supermarkets, markets, shops for display and sale

  • f merchandise.

5.0 Cold storage 5.0 for each meter height

[LL]

slide-26
SLIDE 26

26

[LL]

slide-27
SLIDE 27

27

[LL]

slide-28
SLIDE 28

28

[LL]

slide-29
SLIDE 29

29

[LL]

slide-30
SLIDE 30

30

[LL]

slide-31
SLIDE 31

31

[SDL]

slide-32
SLIDE 32

32

[SDL]

slide-33
SLIDE 33

33

[SDL]

slide-34
SLIDE 34

34

[DL]

slide-35
SLIDE 35

35

[DL]

Worksh kshop What is the Pressure From a 1m x 1m x 0.2m Solid Concrete Slab ?

slide-36
SLIDE 36

36

[DL+SDL]

slide-37
SLIDE 37

37

[DL+SDL]

slide-38
SLIDE 38

38

[DL+SDL]

These figures do not include vertical elements but is the DL+SDL for the floor !!!

slide-39
SLIDE 39

39 Burj Khalifa 171 Storeys (659m High)  Concrete Building Load = 9,460,000 kN Area = 280,000 m2 Pressure = 33.8 kN/m2 Sears Tower 113 Storeys (454.8m High)  Steel Building Load = 3,800,000 kN Area = 408,922 m2 Pressure = 9.3 kN/m2 Taipei 101 94 Storeys (405.8m High) Load = 3,650,000 kN Area = 187,110 m2 Pressure = 19.5 kN/m2 Petronas Twin Tower 93 Storeys (403.8m High) Load = 3,300,000 kN Area = 213,750 m2 Pressure = 15.5 kN/m2 Skyview Penang 43 Storeys (147.3m High) Load = 1,140,000 kN Area = 66,365 m2 Pressure = 17.2 kN/m2 Ampang Condo 18 Storeys (63.4m High) Load = 690,000 kN Area = 51,621 m2 Pressure = 13.3 kN/m2 Ipoh Hospital New Block 10 Storeys (46.1m High) Load = 1,830,000 kN Area = 103,717 m2 Pressure = 17.7 kN/m2

Note All Figures Are Indicative and Not Exact and Should Not Be Relied Upon for Detailed Structural Analysis.

These figures now include vertical elements as well in DL+SDL+LL !!!

[SLS]=[DL+SDL+LL]

slide-40
SLIDE 40

40

On Eleva vati tion

  • n

Brick Wall Load on Slab = kN/m Depends on Wall Thickness and Height. On Plan Loading on Beam kN/m.

slide-41
SLIDE 41

41

Uniform Load Concentrated Load

slide-42
SLIDE 42

42

Worksh kshop How to Obtain UDL on Beam from On Plan Loading and from On Elevation Loading ? On Plan Loading – DL, SDL, LL On Elevation Loading - SDL

[DL+SDL+LL+NHL+WL+EQ]

slide-43
SLIDE 43

43

Worksh kshop Meth thod

  • d 1

How to Obtain Point Load on Column from On Plan Loading and from On Elevation Loading ? On Plan Loading – DL, SDL, LL On Elevation Loading – SDL Meth thod

  • d 2

How to Obtain Point Load on Column From Beam UDL ?

[DL+SDL+LL+NHL+WL+EQ]

slide-44
SLIDE 44

Slab (kN/m2) Beam (kN/m) Column (kN) Foundation (kN)

44

Load start on big area, and end up on small area.

slide-45
SLIDE 45

45

slide-46
SLIDE 46

46

slide-47
SLIDE 47

47

One Way Slab Two Way Slab

slide-48
SLIDE 48

48

slide-49
SLIDE 49

 One Way Slab: 90% of load transfer to short

direct.

 Two Way Slab: Load transfer in all direction

equally.

49

slide-50
SLIDE 50

50

slide-51
SLIDE 51

51

Find Load on Column ? 5 x 3/2 = 7.5 kN/m 7.5kN/m x 7/2 = 26.25 kN 7 m 26.25 kN Find Load on Beam ?

slide-52
SLIDE 52

52

Definitions

  • 1. Slab – Horizontal flat member supporting loads
  • 2. Beam - Horizontal member supporting slabs
  • 3. Column / Wall – Vertical member supporting

beams and/or slabs

  • 4. Foundations – Vertical member supporting

columns Conc nceptua ual Design

  • 1. Discretization of Physical Model - Mechanism /

Determinate / Indeterminate Structures Loading ng

  • 1. Load – externally applied load
  • mass - kg / tonnes
  • load – kN
  • pressure - kPa
  • 2. Dead load - externally applied v. DL (self-

weight)

  • 3. Superimposed dead load - externally applied v.

SDL

  • 4. Live load - externally applied v. LL
  • 5. NHL load - externally applied h. NHL
  • 6. Wind load - externally applied h. WL
  • 7. EQ load - externally applied h. EQ

Scheme Design

  • 1. RC Two-Way Slab With RC Beams
  • 2. RC One-Way Slab With RC Beams
  • 3. RC Flat Slab
  • 4. PT Flat Slab
  • 5. ST Composite Slab With ST Beams

Analys ysis

  • 1. ULS and SLS loading combinations
  • 2. Structural analysis - mathematics
  • 3. Force – internal distribution of effects
  • bending moment (kNm)
  • axial (kN)
  • shear (kN)
  • torsion (kNm)
  • 4. Deflections – externally displacements

Design

  • 1. ULS Capacity
  • Stress
  • normal (direct) stress
  • shear stress
  • 2. SLS Capacity
