About Us

KaiGO – A part of Arvind Limited

Our Business is Water

Arvind Limited (established in 1931 as a part of Lalbhai Group) is a $1.7 billion conglomerate with business interests across Textiles – fabric & garment manufacturing , Branded apparel & Retail , Environment Solutions, Agriculture, Engineering, Telcom and Real Estate. KaiGO is a combination of the words “Kai” meaning ocean and “Go” meaning

• force. Together, it combines to reflect our organization - Arvind KaiGO which is

driving with great intent and speed towards offering a large bouquet of products related to water treatment to OEMs and end customers. Our sister concern Arvind Envisol, established in 2011, is a world class water management company providing end to end solutions for water treatment, industrial waste water treatment, sewage treatment, zero liquid discharge solutions at minimal cost.

The genesis behind the idea “KaiGO”

With single window resolution and localized manufacturing, no longer do you need to fire fight separately for different components. We are democratic and confident in our product designs and

• service. Our standard products will not lock you into unreasonable

maintenance contracts. If you are not happy with our service, you can easily migrate to any other provider.

Genuine service, no lock-in

Time is money, a fact Indian industries are acutely aware of on account of high cost of capital, time taken for compliances etc. A by-product of localization is that we give upto 50% shorter lead times.

Agile supply chain, shorter lead times

ZLD and effluent treatment technologies have been historically very expensive since all know-how and technologies are imported. KaiGO aims to break the shackles by localization of technologies, making it more affordable and worthwhile for Indian industries to invest in.

Making ‘ZLD/ETP’ affordable

KaiGO aims to introduce the highest quality products to Indian markets

Highest Quality Design support Best in class after sales support Indigenous Collaborations In house design “Make in India”. Dedicated 40,000 sqft fabrication house Tech collaborations with the best in the world High investments in R&D. 20+ projects under primary research In house design One stop solution Proven 20 member strong team assists you in the right selection 360 degree solutions across different components / techs Proven and practical experience of over 100+ projects Near you! Clientele Guarantee On ground staff in 6 offices in India. Single window all products >200 happy client partners for O&M Best in class warranty and guarantee terms

KaiGO presence – domestic and worldwide. Sales team of 20 in India Global footprint National footprint

Offices / Partner locations Warehouse Manufacturing

KaiGO has a diverse and rapidly expanding range of products

Membranes and Filters

• RO, NF & UF

Membrane

• MBR
• MCF

Screens and Press

• Filter press
• Belt press and

thickeners

Mixers and aerators

• Jet mixers
• Diffusers
• Ozonator
• Blower

Pressure tubes and tanks

• Pressure tubes
• FRP Tanks

Chemicals and Resins

• Chemicals
• Resins

Instruments

• Flowmeters

Pumps and valves

• HPP
• Dosing pump
• Valves
• Multiport valve

Textiles Pharma F&B Chemicals Oil & Gas ..& Other Industries

DAF and media

• Dissolved air

flotation

• MBBR

Automobiles

Overview of products in Arvind KaiGO

MBR (Membrane Bio Reactor)

KaiMBR is a combination of membrane processes like UF with the ASP process. It has a small footprint, easy retrofit and enables upgrade. USPs – Symmetric TIPS PVDF technology manufactured in-house, long membrane life, lower energy consumption due to double decker skid design, extreme pH and oxidant tolerance to remove severe fouling.

RO, UF and NF Membranes

KaiGO is an authorized distributor for Hydranautics, one of the most technologically advanced manufacturers of membranes worldwide. It is highly energy saving and low fouling on account of its composite polyamide membrane. We offer RO, UF and NF membranes in various sizes as per specification.

MCF (Micron Cartridge Filter)

KaiCF cartridge is constructed of thermally bonded polypropylene microfibers to ensure high efficiency. The filter incorporates a rigid polypropylene center core for increased collapse strength and durability. USPs – Excellent flow with low pressure drop, high dirt holding capacity, 100% polypropelene for wide chemical compatibility

Overview of products in Arvind KaiGO

Pressure tubes

KaiTUBE FRP pressure vessels are membrane housings for industrial and commercial water treatment applications such as desalination and reverse osmosis (RO). USPs – Quick lock system, multi porting, mirror finish internal diameter, meets ASME standards

FRP tanks

KaiTank FRP Pressure vessel is a container made of Fiber reinforced plastic designed to hold filter media at a pressure substantially different from the ambient pressure. These are widely used in Water softening & RO pre-treatment filtration application. USPs – High quality FRP resin, suitable for drinking water, light in weight, provided with Vacum breaker as a standard accessory, 100% tanks are hydro tested and supplied with test certificate

Overview of products in Arvind KaiGO

Motorized Dosing pump

KaiDOSE motorized dosing pumps are driven by an electrical motor which is generally coupled outside the pump and suitable for larger volume dosing application. USPs – Wide MOCs available – PP, SS, Alloy 20 etc., both single and double diaphragm options available for hydraulic pumps, in built PRV

High pressure pump

KaiPUMP can be used to convey a variety of mediums from tap water to industrial liquid at diverse temperatures and with different flow rates and pressure. It can be used for both positive and negative displacement application. USPs – Pump casing thickness is 1.5 mm compared to 1.0 mm, Top and bottom casings are made of SS304 investment casting, Cartridge type & split type mechanical seal is given as option, Pump shaft has 4-grooves for fitment of impellers

Electronic dosing pump

KaiDOSE electronic dosing pump is a positive displacement pump. It pumps a very precise flow rate of a chemical

• r substance into either a tank or stream.

USPs – Air relief valve, solid PTFE diaphragm, Double NRV check valves, min SPM of 120

Overview of products in Arvind KaiGO

Valves

KaiVALVES are mechanical devices that control the flow and pressure within a system or process. KaiVALVE can be provided as manually operated or be automated (with Actuator, Pneumatic or Hydraulic) USPs – Available from 1” to 40” in size and 150# to 2500# Class, meets universal defined standards BS / API / ASME / AWWA. Types available - Gate/Glove/Check/Butterfly/Ball/NRV/Diaphragm/Strainer

Multi port valves

KaiMPV offers a variety of functions with a simple twist of the valve handle. These are used in pools with sand or DE filtering systems, RO Pre-treatment filtration systems & Water Softener application for regeneration. USPs – Virgin plastic, UV resistant, top and side mounting options, 100% hydro tested with certificate

Overview of products in Arvind KaiGO

DAF

The KaiGO DAF is high efficiency two phase separation machine which removes the suspended solids, grease, oil and the non-non soluble organics. This is combined process of flocculation and floatation. It replaces the traditional gravity clarification method giving an advantage of speed, lower footprint, consistent effluent quality and lower sludge volume due to higher solid concentration in it. USPs – Prefabricated and preassembled leading to minimum site erection time, guaranteed 90% TSS reduction, compact and modular design.

MBBR

KaiMBBR has 3 variants – PVA, Biochip and PU media, with surface areas ranging from 3000 m2/m3 to 47000 m2/m3. The surface characteristics make them highly resistant to wear and tear and a life of > 5 years. Due to the high surface areas, you will be able to design for much smaller tanks reducing capex, footprint and maintenance. USPs - >100x higher surface area compared to traditional media, smaller footprint, long life > 5 years

PV A BIOCHIP PU FOAM

Overview of products in Arvind KaiGO

Filter press

KaiPRESS is specially designed to de-water sludge coming from clarification tanks and other solid liquid separation applications. USPs – Various plate MOCs (PP/CI/SS), range of sizes, option for manual/hydraulic operation, long life

Belt press and thickeners

KaiBELT is rapidly turning out to be a good alterative to the manual Filter press. Fully automatic with option for thickener, it gives upto a 30% solid consistency at outlet. USPs – Best of technology ensuring a long life and zero maintenance, low footprint, high solid consistency at

• utlet

Overview of products in Arvind KaiGO

Jet mixers

KaiJET is a surface mounted mixer which sucks atmospheric air and pushes it into the water. The design maximizes the oxygen transfer and maintains optimum mixing. USPs – SS316 metal parts giving long life, easy installation and maintenance, highly energy efficient

Diffusers

KaiGO offers diffusers of various types – tubes / disc in different MOCs (Silicon, EPDM) and pore sizes as per the

• application. We use the highest quality membranes ensuring consistent air transfer and a long life.

Diffusers are offered with both retrievable and fixed installation. USPs – Best in class membrane quality, optimum pores, long life and consistent air transfer

Ozonator

Ozone is a very strong disinfectant & oxidant, 50 times more effective and 3000 times faster on killing bacteria than chlorine which is used as a deodorizer, detoxifier and a coagulant. Due to these properties ozone is widely used in air, water and waste water treatment in various applications. USPs - "High Barrier Quartz Electrode“, IGBT based high frequency resonance inverter, High concentration ozone

• utput 100 - 130 grams / m3

Overview of products in Arvind KaiGO

ETP and RO Chemicals

KaiChem is our basket of several chemicals used in waste water treatment –

• Color removing chemicals
• Coagulants
• Polyelectrolytes
• RO antiscalants, cleaning and biocides

KaiGO’s coagualants can be used alone or in combination with aluminum base inorganic coagulants, providing a consumption reduction of 30-60% and reducing the volume of sludge. RO chemicals eliminates scaling and fouling in membrane systems, prevents algae/fungus/microbial growth etc.

Operations & Maintenance

KaiGO offers precise and dependable Operations and Maintenance services

Highly Trained people

Zero downtime Reduced Opex Long life of capital equipment Keep updated with latest technology Compliance to safety norms No budgetary risk

KaiGO Operations and Maintenance service

Your plant

Expert support Spares and consumables covered Preventive maintenance Coverage of all legal and IR requirements Daily adherence to input and

• utput values

1 2 3 4 5 6

Detailed product descriptions

KaiMembrane –RO/UF/NF Membrane

Introduction to UF/NF/RO Membrane

Hydranautics offers a wide range of ultrafiltration and microfiltration modules based on polymeric hollow fibers. All membranes solutions offered can be used as a replacement of conventional treatment systems combining benefits of high permeate quality and low footprint requirements. Using Hydranautics ultrafiltration products, RO membranes may be used downstream more safely while

• perating at higher fluxes with longer intervals between cleans.

Range UF NF RO Process Separation Membrane Elements HYDRACAP ESNA SWC – Sea Water Composite Daily RO series HYDRACAP MAX NANO – BW CPA – Composite Polyamide Daily NF series HYDRASUB NANO – SW ESPA – Energy Saving Polyamide Dairy UF series HYDRA Core LFC – Low Fouling Composite San RO HYDRA pro Features

• High performance membrane elements ideal for high purity

water

• Ultra low pressure, energy saving brackish water membranes
• Hollow fiber membrane for membrane bioreactor applications
• Low Fouling
• High rejection membranes

KaiMBR – Membrane Bio Reactor

Introduction to MBR

KaiMBR submerged modules are used for Membrane Bioreactor (MBR) processes. Submerged MBR process is most often used to treat municipal/industrial wastewater but can be used in drinking water applications as well. KaiGO’s product line includes options that vary the fiber thickness to optimize the product selection depending on the application.

Features

• Symmetric TIPS PVDF technology eliminates the risk of delamination and minimizes the impact of

abrasion

• Long membrane life due to high mechanical and superior chemical strength
• Double decker skid design leads to lower energy consumption
• High permeability due to permanent hydrophilicity
• Stable high flux reduced fouling
• Minimum footprint due to double decker skid design
• Extreme pH and oxidant tolerance to remove severe fouling and restore performance
• Extreme caustic and oxidant tolerance provides long life, even during challenging applications.

Range Model no KaiMBR T1510 KaiMBR T2215 KaiMBR T3020 Pore size 0.04um 0.04um 0.04um Filtration area 15m2 22m2 30m2

KaiCF – Micron Cartridge Filter

Introduction to Micron Cartridge Filter

KaiCF cartridge is constructed of thermally bonded polypropylene microfibers to ensure high efficiency. The filter incorporates a rigid polypropylene center core for increased collapse strength and durability. This thermal bonded micro-fiber construction has minimal fiber release, consistent flow rate and superior filtration performance. It is also not brittle or prone to breakage problems like resin-bonded

• cartridges. Unique micro-grooves provide added surface area. The recommended temperature limit of 40° F to 175° F allows it to be

used in many hot water applications.

Features

• Free of surfactants, binders and adhesives
• Excellent flow with low pressure drop
• High dirt holding capacity
• 100 % Polypropylene for wide chemical compatibility
• High strength & pressure resistance
• Will not impart taste, odour or colour to the liquid being filtered
• One piece construction up to 1016 mm & more

Range

• Available in Spun & Wound type construction
• 1 to 50 Micron rating
• Available from 10”, 20”, 30” & 40” Length and 2.5”, 4” & 4.5” Dia

KaiTUBE – Pressure Tube

Introduction to Pressure Tube

FRP KaiTUBE pressure vessels are membrane housings for industrial and commercial water treatment applications such as desalination, reverse osmosis (RO) manufactured with the best industry practices and the highest quality standards applied to continuous innovation, KaiTUBE FRP pressure vessels feature threaded ports, a quick lock system, flat sealing and multi-porting facilities, fail-safe shells and a single-piece head.

Features

• User friendly design of end cap assembly with single piece moulded seal

plate, high quality seal ring, heavy duty aluminum bearing plate and stainless steel locking ring to enable tool free operation.

• Mirror finish internal diameter with tolerance of ±0.1 mm to facilitate

easy loading & unloading of membranes

• Meets ASME standards, all drawings available on request
• Hydro test pressure is 1.1 times of design pressure
• Burst pressure is 6 times of the design pressure
• All models supplied with saddle and SS straps, Victaulic couplings

available on request

Range

• Available in 2.5”, 4” and 8” end port, side port and multi port

configurations

• Pressure ratings of 150 psi, 300 psi, 450 psi, 600 psi, 1000 psi, 1200 psi

KaiTANK – FRP Pressure Vessel

Introduction to FRP Pressure Vessel

FRP Pressure vessel is a container made of Fiber reinforced plastic designed to hold filter media at a pressure substantially different from the ambient pressure. These are widely used in Water softening & RO pre-treatment filtration application.

Features

• Made from High quality FRP resin
• Suitable for drinking water application
• Lighter in weight provides Easy installation
• Corrosion free operation
• Longer life cycle
• Lower maintenance cost
• All Top and Bottom opening vessels are provided with

Vacuum Breaker as standard Accessory

• 100% tanks are hydro tested & supplied with test certificate

Range

• 8” x 44” to 13” x 54” available in 2.5” Top Open
• 14” x 65” and 16” x 65” available in 4” Top Open / 4” Top and Bottom Open
• 18” x 65” to 36” x 72” available in 4” Top and Bottom Open
• 42” x 72” to 63” x 86” available in 6” Flange Top and Bottom Open

KaiPUMP – High Pressure Pump

Features

• Pump casing thickness is 1.5 mm compared to 1.0 mm available in market.
• Top and bottom casings are made of SS304 investment casting
• Cartridge type & split type mechanical seal is given as option, hence there is no need to replace

the complete mechanical seal.

• Mechanical seal has replaceable rings fitted with rubber cup. Hence most of the time only seal

faces can be replaced instead of the complete seal.

• Pump Flanges at bottom casing has two options - Oval CI type & round SS304 type flange –

provided for easy pump maintenance.

• Pump shaft has 4-grooves for fitment of impellers.

Range

Flow Range: 0.6 – 24 M3/Hr with different models Pressure Range: 1.7 – 24.5 Bar with different models Available in MOC SS304, SS316 & Duplex

Introduction to High Pressure Pump

KaiPUMP is used to convey variety of mediums from tap water to industrial liquid at diverse temperatures and with different flow rates and pressure. A pressure is built within the pump as the flow progresses that enables it to move content to a longer distance. It can be used for both positive and negative displacement application. It has many applications like industrial boosting, industrial conveying, water treatment, and irrigation.

KaiDOSE – Motorized dosing pumps

Introduction to Dosing pump

KaiDOSE motorized dosing pumps are driven by an electrical motor which is generally coupled

• utside the pump and suitable for larger volume dosing application.

Features

• Available in PP, PTFE, SS 316, SS 316L, SS 304, Hastelloy ‘C’, Alloy 20 as per the chemical

compatibility.

• Hydraulic Dosing Pump available in Single and Double diaphragm options.
• In-built PRV in Hydraulic Dosing Pump

Range Type Flow rate Pressure Mechanical 0 – 800 LPH 0 – 4 Kg/cm2 Hydraulic 0 – 3000 LPH 0 – 10 Kg/cm2 Plunger 0 – 5000 LPH 0 – 70 Kg/cm2

KaiDOSE – Electronic dosing pumps

Introduction to Dosing pump

KaiDOSE electronic dosing pump is a positive displacement pump. It pumps a very precise flow rate of a chemical or substance into either a tank or stream. Solenoid pushes the diaphragm via a SS stud which in turn pushes the liquid into the system. Solenoid is actuated by a solid state electronic circuit which controls the desired dosing volume.

Features

• Inbuilt Air relief valve
• Solid PTFE Diaphragm
• Double NRV check valves
• Minimum SPM of 120
• Optional digital display of SPM
• Optional auto dosing

Range Flow rate Pressure 0 – 6 LPH 4 Kg/cm2 0 – 10 LPH 2 Kg/cm2 / 3 Kg/cm2 0 – 20 LPH 4 Kg/cm2 0 – 30 LPH 4 Kg/cm2

KaiVALVE – Valves

Introduction to Valve

Valves are mechanical devices that control the flow and pressure within a system or process. They are essential components of a piping system that conveys liquids, gases, fluid, slurries etc. KaiVALVE can be provided as manually operated or be automated (with Actuator, Pneumatic or Hydraulic)

Features

• Available from 1” to 40” in size and 150# to 2500# Class
• Meets universal defined standards BS / API / ASME / AWWA
• Smooth operations with zero leakage.
• Additional requirement can be provided such as stem extension, by-pass arrangements,

alternate trims and all other customization required by customer.

• Best in class quality and finishing
• Shortest delivery period.

Range Type of valve Gate valve Globe valve Check valve Ball valve Butterfly valve Diaphragm valve Strainer Non return valve

KaiMPV – Multi Port Valve

Introduction to Multi Port Valve

Multiport valve are also known as backwash valve or filter-control valve, the multiport valve offers a variety of functions with a simple twist of the valve handle. These are used in pools with sand or DE filtering systems, RO Pre-treatment filtration systems & Water Softener application for regeneration.

Features

• Made from Virgin engineering plastic
• UV Resistant Material
• High quality spider rings & pressure springs provides smooth handling
• Optimal flow rate & lower pressure drop
• Top mount & Side Mount options
• For Softener provided with built in Injector for uniform regeneration.
• 100% tanks are hydro tested & supplied with test certificate

Range

• Port size options available: 3/4”, 1” & 1.5”
• Side mount & Top mount options
• Can be provided for 4 kg/cm2 & 6 kg/cm2 working pressure

KaiGO – DAF

Introduction to UF/NF/RO Membrane

The KaiGO DAF is high efficiency two phase separation machine which removes the suspended solids, grease, oil and the non-non soluble organics. This is combined process of flocculation and floatation. Wastewater then enters the flotation zone and microbubbles from the white water attach to the particle surface and affect the particle density, causing the suspended solids to float to the surface of the DAF where they are skimmed by a chain and flight and separated into the sludge hopper. The treated wastewater is continuously removed at several points inside the DAF and is discharged through pipe weirs into an effluent chamber.

Applications

• Poultry processing
• Mining Industry
• Chemical Industry
• Paper Industry
• Textile Industry
• Tannery

Features

• Compact design
• Modular design
• Prefabricated and preassembled
• Minimum site erection time
• High efficiency with minimum cost
• Guaranteed 90% TSS reduction

KaiGO – MBBR

Introduction to MBBR

MBBR is used in the Aeration tank to reduce the biological sludge present in the water. Bacteria grows on the surface of MBBR media that eats the biological matter present in the water. To increase the growth of bacteria in the tank we need to maintain the desired level

• f dissolved oxygen. Dissolved oxygen level is maintained by providing aeration through diffusers. Selection of MBBR media is very

important as it has an impact on civil structure, operating cost and sometimes on capital cost as well. Shape MOC Life Surface area Tank size HRT Diffuser type Conventional Flower shaped PP/PE It’s life is less since it breaks under hydraulic pressure Usually from 400-500 m2/m3 It requires big tank as it needs more media to grow bacteria and reduce biological matter 10-12 hrs Coarse Bubble KaiMBBR Disc, Cube, Webbed shaped PVA, HDPE, PU It’s life is more as it can withstand hydraulic pressure because of its unique construction Up to 100 times more than conventional Smaller tank as the media has more surface area to grow bacteria Reduces compared to conventional Fine/Coarse Bubble

PVA BIOCHIP PU FOAM

Surface Area MOC Filling ratio MLSS PVA 46,000 m2/m3 PVA 10% Up to 10,000 Biochip 5500 m2/m3 HDPE 10% Up to 10,000 PU foam 3000 m2/m3 PU 30% Up to 10,000

KaiPRESS – Filter Press

Introduction to Filter Press

KaiPRESS is specially designed to de-water sludge coming from clarification tanks and other solid liquid separation applications. The capacity depends on the character of the sludge. The solid liquid mixture is fed through pumps in the filter press, which is made from a number of recessed filter plates forming chambers.

Features

• Available Plate MOC options: PP / CI / SS
• Available Filter Cloth MOC options: PP / Nylon / Polyester

Range

• Plate sizes available from 305 x 305 mm to 1500 x 1500 mm
• Available Open / Closer options: Manual / Lever Operated Hydraulic /

Panel Operated Hydraulic

• Available Cake thickness options: 30 mm to 50 mm

KaiBELT – Belt Press

Introduction to Belt Press

KaiGO provides the most efficient sludge dewatering unit “KaiGO Belt press”. It has two zones, 1. Thickening zone – In this zone flocs are created from the sludge fed. 2. Pressing zone – In this zone several rollers press the flocs created previously KaiGO Belt press has an ability to give 30% solid consistency at outlet compared to 20% given by other players in the market. Moreover, it comes with belt tracking system, washing arrangement, and completely automated control panel.

Features

• Higher percentage of solid consistency at outlet
• Low footprint area
• Easy installation and maintenance free
• Belt press with Thickener enhances the dewatering process
• Best in class warranty terms and service support

Range

We can provide the product according to the requirement of the customer.

KaiGO – Diffuser

Introduction to Diffuser

Diffusers are critical to the aeration process. Aeration tanks are used to reduce the biological matter present in the water by creating an atmosphere that is suitable for the growth of microbes. Diffusers are generally a tube or disc, covered with a membrane having small

• pores. Diffusers are arranged at the bottom of the tank connected with a central air blower from which pressurized air is fed into the
• diffusers. This air passes through small pores in the membrane creating bubbles which oxidize the water.

Bubble Shape MOC Size Fine Coarse Tube Disc EPDM Silicone 63*750mm, 63*1000mm, 90*1000mm (Tube) 9” and 12” (Disc) 3” and 6” (Coarse) Range Features

• Long life due to high quality and genuine EPDM/Silicone

Membrane

• High Tensile Strength ensures good membrane memory &

consistent performance

• Optimum pores for good oxidation
• High quality retrievable accessories
• Best in Industry service and warranty terms

KaiOZO – Ozonator

Introduction to Ozonator

KaiOZO Ozone system consists of next generation high frequency IGBT based water cooled Ozone generator, Industrial PSA oxygen generators, Ozone contractors and sensors with instrumentation for water & air disinfection treatment. Ozone is a very strong disinfectant & oxidant, 50 times more effective and 3000 times faster on killing bacteria than chlorine which is used as a deodorizer, detoxifier and a coagulant. Due to these properties ozone is widely used in air, water and waste water treatment in various applications.

Features

• "High Barrier Quartz Electrode" to give high concentration ozone and high operating life.
• Water Cooled Electrode gives constant ozone output.
• IGBT based high frequency resonance inverter for longer life and power saving.
• All the machines are checked using state of art ozone sensors. (UV adsorption based)
• Special coating to prevent corrosion on PCB
• PSA industrial oxygen generators to give oxygen at 85 - 90% purity
• High concentration ozone output 100 - 130 grams / m3

Applications

• Disinfection : Ozone kills Bacteria and virus by cellular lyses
• Colour Removal : Ozone bleaches organic colouring matter
• Odour Removal : Ozone oxidises odour and taste causing compounds
• COD/BOD reduction : Ozone oxidises COD and BOD
• Micro-flocculation : Ozone assists in micro-flocculation in the filters
• Oxidation of Inorganic Compounds : Ozone forms metal oxides which can be filtered

KaiGO – Jet Mixer

Introduction to Jet Mixer

KaiGO Jet mixer is a mounted adjustable angle in the water with the motor portion and air intake mechanism above the surface and the propeller portion below the surface. The motor rotates the hollow shaft that in turn moves the propeller. This activity forces water at a high velocity through and near the propeller blades, creating a partial vacuum at the end of the shaft. Atmospheric air above the waterline is drawn in through the air Intake port and into the hollow shaft. Propeller creates turbulence and flow that breaks up the air bubbles, mixes the basin and disperses oxygen. The horizontal water movement maximizes bubble hang time maximizing oxygen transfer.

Features

• Superior horizontal mixer that provides total mixing
• Optimum oxygen transfer that increases the DO level in water
• All metal parts are made of SS316 that provides maximum corrosion resistance
• Easy installation and low maintenance
• Highly energy efficient
• UV Protected HDPE floats and housing
• Integrated shells has properties of durability, anti fouling and anti leaking

Range

Capacity:- 5, 7.5, 10, 15, 20 HP

KaiCHEM – ETP Chemicals

Introduction to ETP Chemicals KaiGO’s coagulants are based on polyacrylamide co-polymers providing the complete range of ionicities and molecular weights necessary to meet optimal performance for each applications. Our polymers are available in solid, emulsion and liquid forms. They can be used alone or in combination with aluminum base inorganic coagulants, providing a consumption reduction of 30-60%, dramatically reducing coagulation times, not only succeeding in reducing the treatment cost but also reducing the volume of the treated sludge and it’s disposal cost. KaiGO presents KaiPOLAN and KaiCATON series of anionic and cationic polyelectrolytes for wide range of applications from water treatment to waste water treatment, mainly used for effluent treatment of inorganic suspended solids. By neutralizing the electric charge of sludge particles, these electrolytes promote flocculation effectively. Name Description KaiCOLOR 4102 Polyamine Medium Concentration KaiCOLOR 4103 Polyamine High Concentration KaiFLOC Coagulant Range Name Description KaiPOLAN 12 Medium Molecular Anionic Polyelectrolyte KaiPOLAN 22 High Molecular Anionic Polyelectrolyte KaiCATON 32 Cationic Polyelectrolyte Colour Removal & Coagulant Polyelectrolytes

KaiCHEM – RO Chemicals (1/2)

KaiCHEM CARE antiscalants are designed to eliminate scale and reduce fouling in membrane systems, regardless of the feed water source. KaiCHEM KLEAN membrane cleaners ensure maximum element life and restore flux rates close to that of new membranes. KaiCHEM BIO range of non-oxidizing biocides are highly effective in prevention and reduction of algae, fungus and microbial growth on various types of membranes. KaiCHEM FRESH is a combination of high quality polymers and sequestering agents that take care of seeding process & crystal formation on membrane surface when water is in stagnant while plant not in service. It is specifically designed to control the precipitation of all kind of inorganic salts and silt as well. The product is also effective in dispersing any other foreign matter and slimes etc. Thus, membrane chocking is reduced. KaiCHEM SPERSE is a formulation developed for application in thermal distillation systems. Controlled dosage rate of KaiCHEM SPERSE have been proven to be highly effective in the operating conditions found in vapor compression, multi effect and multi stage distillation plants and thermal compression to control scale properties precipitation of CaCO3 & CaSO4. Introduction to ETP Chemicals

KaiCHEM – RO Chemicals (2/2)

Range Name Description KaiCHEM CARE 01 General Antiscalant KaiCHEM CARE 1001 General Antiscalant KaiCHEM CARE 2001 Silica up to 120 ppm, Iron upto 2.5 ppm KaiCHEM CARE 3001 Alkaline Antiscalant KaiCHEM CARE 4001 High Sulphate & Fluoride KaiCHEM CARE 5001 High Silica (120 - 200 ppm), Sulphate, & Iron upto 3 ppm KaiCHEM CARE 6001 High TDS with 80 - 85 % Recovery KaiCHEM CARE 7001 High TDS in Reject with 250 ppm Silica , 5 PPM Iron Oxide, 4 PPM Calcium

• Fluoride. (Good for Sea Water Application)

KaiCHEM FRESH – 11 Membrane flushing chemical to reduce cleaning cycle KaiCHEM SPERSE – ME Thermal Antiscalant for Evaporators KaiCHEM KLEAN – LP Low pH membrane Cleaner KaiCHEM KLEAN – HP High pH membrane Cleaner KaiCHEM KLEAN – SI Acidic Silica Cleaner, can be mixed during Low pH Cleaning KaiCHEM BIO – 01 Membrane preservation KaiCHEM BIO – 11 Microbiological control KaiCHEM BIO – 21 Microbiological contamination

Thank you!

Contact :- 18008439988 (toll free), +917930136056 Email id :- support.kaigo@arvind.in HO address :- KaiGO division, c/o Arvind Envisol Ltd.,

Arvind mill premises, Naroda road, Ahmedabad – 380025, India

References
