About LG

17 16 30

LG Corporation

Global R&D

Korea Thailand India Saudi Arabia Turkey (7 Global R&D Centers)

Proven research and development laboratory and facilities to lead technology and ensure product reliability

Brazil China

Precedent Technology Research (Seoul) Optimal Product Design (Changwon) Optimal Product Design (Jeonju)

Global Production Sites

10 Production sites with a total production capacity of more than 16 million units per year

Global Presence

Our products are sold in over 100 countries around the world

LG Electronics

: 27 : 48 : 04

2+4 Nos

2 D 2 Delhi/Pune & elhi/Pune & 4 R 4 Regional O egional Off ffice ice Pune Delhi Training Academy

Delhi Academy Pune Academy

India Production Sites

Pune (54 acres) – 2004 & Gr. Noida (47 acres) - 1998

Production site –Pune

Only Brand manufacturing 4th Generation VRF product range and 4 Way Cassette in India. Equipped with process control through Six Sigma and Relevant International Quality Assurance Accreditations with Environment Management System in place.

NABL certified VRF test bed

India’s one and only fully automatic psychrometric lab in compliance with AHRI / IS standards Accredited by NABL & Intertek of USA

Product Line-up

10/20/30 HP 4/5/6/8/10/12/14 HP 8 to 88 HP

Top Discharge Side Discharge Water Cooled VRF

Multi-V (Outdoor) : Product Line-Up

Low Static 0.63 to 2.0 Ton 1-Way Cassette 0.63 to 2.0 Ton Cassette 0.8 to 4.5 Ton Wall Mounted 0.63 to 2.0 Ton High Static Duct 0.63 to 8.0 Ton AHU Compact Cassette 0.63 to 1.5 Ton Ducted Split 12.5 &17 Ton Hydro Kit

• Mid. Temp. : 4HP & 10HP

High Temp.: 4HP & 8HP Eco V DX

Multi-V (Indoor) : Product Line-up

Single Package Fixed Speed 10-30 Ton Inverter 10, 12.5 & 15Ton Low Static Fixed Speed 1.5-2 Ton Ceiling Concealed Duct Fixed Speed 3.0 – 17 Ton Fixed Speed 3.0– 17 Ton Inverter 3.0- 8.0 Ton 4 Way Cassette Fixed Speed 1.5- 4.0 Ton Inverter 1.5- 4.0 Ton Floor Standing Inverter 3-4 Ton

Ducted Split 12.5 &17 Ton

Compact Cassette 1.5 & 2 Ton

Single CAC : Product Line-up

1 Stage 2 Stage R 134 A 50 Hz R 134 A 50 Hz R 134 A 50 Hz R 134 A 50 Hz 1000 2000 3000 4000 Tonnage ranges 1000 2000 3000 4000 OIL FREE GAS BEARING CENTRIFUGAL CHILLERS 100 200 300 400 500 1000 2000 3000 4000 AIR COOLED SCREW CHILLER (STD. EFFICIENCY) 100 200 300 400 500 AIR COOLED SCREW CHILLER (HIGH EFFICIENCY) 100 200 300 400 500 500 1000 2000 3000 4000 500 1000 2000 3000 4000 WATER COOLED SCREW 100 200 300 400 CENTRIFUGAL R 134 A 100 200 300 400

Chiller : Product Line-up

Water cooled Screw Chiller

Capacity: 75TR – 500 TR. Refrigerant: R134a Features: High performance Twin Rotor screw compressor, Oil separator inbuilt in compressor and condenser, Chilled water Operation from -15℃ to 40.6 ℃, Flooded / Falling Film Type of Evaporator. Applications: Commercial, Industrial & Infrastructure applications

Air cooled Screw Chiller

Capacity: 74TR – 500 TR Refrigerant: R134a Features: High performance Twin Rotor screw compressor, Low noise High Efficiency Fan, Individual Multi Circuit, Operation from 5℃ to 52 ℃ ambient, Flooded / Falling Film Type evaporator , Fin & Tube / MCHX type condenser. Applications: Commercial, Industrial & Infrastructure applications

Refrigerant: R134a Features: 1stage centrifugal compression cycle, Variable speed drive. Applications: Commercial, Industrial & Infrastructure applications

Water cooled Centrifugal Chiller- 1 Stage

Capacity:-250TR – 2000TR Refrigerant: R134a Features: 2stage with economizer, 50% less oil by using ball bearing, Automatic Valve(expansion device), Applications: Commercial, Industrial & Infrastructure applications. Capacity:-200TR – 3000TR

Water cooled Centrifugal Chiller- 2 Stage

Refrigerant: R134a Features: 29% low operation cost , High speed direct connection, closed impeller and variable diffusers . Applications: Commercial, Industrial & Infrastructure applications

Oil less Air Bearing Chiller

Capacity:-100TR – 300TR Refrigerant: R134a Features: High speed direct connection, closed impeller and variable diffusers . Applications: Commercial, Industrial & Infrastructure applications Capacity:-400TR – 1000TR

Magnetic Bearing Chiller

Why LG ?

 Most Attractive brand in INDIA for 2016  Highest Efficiency  Corrosion Resistance Black Fin Condenser in VRF.  Hot water Generation up to 80⁰C.  Highest No. of Patents in VRF Technology – 176 Patents.  NABL Certified Laboratory at Pune Factory.  Engineering Tools – CFD/LATS CAD, eQuest  2 Training Academy : Technical Training & Influencer Visit  LG can offer wide range of products

LG - Setting Standards for others to follow

Comprehensive HVAC and energy business domains expand with SAC Business unit products and solution

R-22 Fix Speed (10, 20, 30TR) R-410 Inverter (10, 12.5, 15TR)

Widest Range of Products & Systems

Reference sites

Institute Healthcare Government & Public Factory Commercial Office Developers IT/ITES Hospitality Mall/Multiplex

ETT, Noida Adani, Gujarat L&T Technologies, Bangalore North Block, Delhi RS Software, Kolkata HCL, Noida

DLF Crest (10,500 HP) Gurgaon Sunrise Symphony Kolkata Mahagun Mezzeria Noida DLF Commander’s Court Chennai Salarpuria Bangalore Bombay Realty Mumbai

Lemon Tree, Dehradun Clarks Inn, Hubli Atmantan Health Resort, Pune Monotel, Kolkata Holiday Inn Express, Chennai Taj President Vivanta, Mumbai

Central University Gulbarga Ascend International School Mumbai National Law University Cuttack IISER Bhopal IIT, Kharagpur Scottish School Gurgaon

Kiran Hospital Surat, Gujarat Kerudi Hospital Bagalkot, Karnataka Ayush Hospital Vijaywada Hope International Kakinada, Andhra Pradesh WB, 7 Hospital Kolkata Cloud 9 Hospital Gurgaon

Space Olympia Aurangabad Dilli Haat New Delhi Inspiria Mall Pune Topiwala Mall Mumbai Maruti Showroom Siliguri DMRC Delhi NCR

H K Diamond Surat Titan Coimbatore Mercedes Benz Pune Crompton Greaves Bhopal Stelis Biopharma Bangalore RVNL Dankuni, West Bengal

Multi V IV AHU

Nuclear Power Plant Kudankulam Centri : 850 TR -18 No.s Titan Hosur Screw : 150 ,280,132 - 2 No.s Tangedco Power Plant Chennai Screw : 150 TR – 3 No.s Hanil Automotive Chennai Screw : 500 TR – 2 No.s Adani Ahmedabad Screw : 150 TR – 3 No.s DSIDC Delhi Screw (Air) : 180 TR – 2 No.s

District Cooling District Cooling District Cooling

Al Meydan (UAE) Sheik Zayed Military City (UAE) Yas Island (UAE)

Centrifugal 13,000RT Centrifugal 20,000RT Centrifugal 15,000RT

Khalifa City (UAE) Motor City (UAE)

Centrifugal 20,000RT Centrifugal 80,000RT

Digital Media City

Total Capacity 54,000RT

• Absorption Chiller 1500RT x 14 units
• Centrifugal Chiller 1500RT x 14 units
• ICE Storage 3000RT x 4 units

Commercial Complex

Seoul World-Cup Stadium Incinerator Chiller Plant Distribution Pipeline (3 ~ 10 km) Digital Media City

Heat Pump Nuclear Power Plant

GS Power Plant Ul-jin Nuclear Power Plant

Centrifugal Heat pump 3,000RT Centrifugal 26,850RT

Pa-Ju District Heating Company Ko-Ri Nuclear Power Plant Centrifugal Heat pump 3,500RT

Centrifugal 22,360RT

Commercial Building

Korea World Trade Center

Absorption 55,440RT

Hanhwa life insuarance building

Absorption 2400RT

Power Plant

Nuclear Power Plant/ Military

Qurayyah Plant (Saudi) ELTA Radar Base camp (Israel)

Centrifugal 92,300RT Screw 200RT

Shuweihat Plant (UAE) Braka Plant (UAE)

Centrifugal 5,000RT Centrifugal 15,900RT

Commercial Building Office / Factory

Landmark Tower (Vietnam) Amkor Anam (Phillipine)

Centrifugal 14,150RT Centrifugal 1,000RT

Menara BTN (Indonesia)

Screw 300RT

PT.MIWON (Indonesia)

Centrifugal 6,000RT

CCF (Philippine)

• Centrifugal 1,000RT : 2 Units /
• Air Cooled Screw 150RT ; 4Units

Hotel Commercial Complex

API Hotel (UAE) Park Rotana (UAE) Wahat Al Khartoum (Sudan)

Centrifugal 5,100RT Centrifugal 5,000RT Centrifugal 3,750RT

Grosvenor House (UAE) Al Saad Complex (Qatar) Al Ain Intercon (UAE)

Centrifugal 2,700RT Centrifugal 830RT Centrifugal 6,200RT

Complex

INC Arena Dome (Philippine)

Centrifugal 1,700RT x 6 Units / AHU / Cooling Tower

Shopping Mall

Mangga Dua Square (Indonesia)

Centrifugal 1,400RT x 3 Units

Hotel

Holiday Inn Hotel (Phillipine)

Centrifugal 400RT

Ayodya Dan Resort (Indonesia)

Centrifugal 750RT

Factory Exhibition Center Commercial

Chongqing Taizheng Factory

Screw 750RT

Tianjin Dade electronic Factory

Screw 400RT

Jinan International Convention & Exhibition Center

Screw 1290RT

Suzhou New International Expo Center

Screw 810RT

Suzhou & Wuxi E-mart supermarket

Screw 800RT

Yanbian International Hotel

Screw 940RT

Thank You

Highest Corrosion Resistance

Ocean Black fin for corrosion resistance in addition to Hydrophilic coating

The black coating is heavy anti-corrosion treatment applied to industrial equipment. This special coating protects heat exchanger from high salinity, humidity & pollution. Water Resistant (Hydrophilic Coating) Corrosion Resistant (Black Coating) Aluminium Fin

Air source Water source

System Concept

Hydro kit works with various heat source.

Floor Heating Heating by Hot water

Domestic hot water Cooling by cold water Indoor Cooling &Heating

Guest Room Guest Lobby Gym Restaurant Bar Meeting Room Rest room Lift Lobby Conference Hall Shop

LG provides various commercial display products not only for guest room but also for public zone (such as lobby, restaurant, bar, etc.) in hotel so that hotel can enhance its brand image.

Signage Media Players

for Signage

Smart Signage Platform

Guest Hallway

Hospitality Dedicated Solution

LG STUDIO (Premium Kitchen Appliance)

Built-in Ref. (Bottom Freezer)

Built-in Oven Built-in Microwave Oven

Dish Washer

Built-in Cooktop Hood

• 750mm (Flagship)
• 600mm
• 600 / 900mm

Water Purifier
