A Global company ROSENBERG GROUP ROSENBERG VENTILATOREN-ECOFIT-ETRI FOUNDED IN 1981 WITH HEADQUARTERS IN KUNZELSAU GERMANY 14 PRODUCTION FACILITIES IN EUROPE, ASIA & NORTHAMERICA 45 SALES OFFICES IN ALL CONTINENTS 1400 EMPLOYEES WORLDWIDE

slide-1
SLIDE 1

ROSENBERG GROUP

ROSENBERG VENTILATOREN-ECOFIT-ETRI

FOUNDED IN 1981 WITH HEADQUARTERS IN KUNZELSAU GERMANY 14 PRODUCTION FACILITIES IN EUROPE, ASIA & NORTHAMERICA 45 SALES OFFICES IN ALL CONTINENTS 1400 EMPLOYEES WORLDWIDE

A Global company

V020916 dc

slide-2
SLIDE 2

Germany - France - Italy - Czeck Republic - Hungary - Croatia Spain - Turkey - Egypt - China - Singapur - Canada - Mexico

AC & EC MOTORS (EXTERNAL ROTOR MOTORS) FAN IMPELLERS AIR HANDLING & ENERGY RECOVERY UNITS SHEET METAL PARTS AND ACCESORIES CAST ALUMINIUM PARTS

https://www.youtube.com/watch?v=LGYqcm1zMI4

Integrated manufacturer

V020916 dc

slide-3
SLIDE 3

14 to 40“ diameter 500 to 19,500 CFM Available with EC or AC MOTOR Low Sound Spectrum Multilple materials and Fin configuration

Axial

V020916 dc

slide-4
SLIDE 4

12 to 28“ diameter, backward curved inclined 600 to 11,000 CFM Available with EC or AC motor Factory balanced Multilple materials and configurations

Plug Fans

V020916 dc

slide-5
SLIDE 5

7 to 22“ diameter, forward inclined curve Up to 7,000 CFM Available with EC or AC motor Multilple materials and configurations available

Blowers

V020916 dc

slide-6
SLIDE 6

Up to 11,000 CFM per fan Built in redundancy Compact and Flexible Retrofit and new designs

V020916 dc

EC FAN GRID

slide-7
SLIDE 7

7

COMPACT & MODULAR DESIGN Unobox

slide-8
SLIDE 8

Our fans are powered by our

  • wn external rotor motor.

5 different sizes available. AC & EC configuration

OUR MOTORS

slide-9
SLIDE 9

What about it?

EC TECHNOLOGY

slide-10
SLIDE 10

10

INTELLIGENT AND EFFICIENT MOTORS

EC TECHNOLOGY

Information Energy

slide-11
SLIDE 11

11

COMMITMENT WITH ENERGY WISE SOLUTIONS

EC MOTORS

* According to: DIRECTIVE 2009/125/EC of the European Parliament and of the Council of 21 October 2009

Air is our element… we offer intelligent solutions to move air efficiently no matter whether it is… Requirements which must be fulfilled… by increasing energy efficiency to step up the protection of the environment and the security of the energy supply*…

slide-12
SLIDE 12

EC MOTORS

Electronically Commutated Motor

Commutation means the position-dependent switching of the electric current.

slide-13
SLIDE 13

13

… move air efficiently… Technology

Source: DC – Motor Wikimedia.org * BDC = Brushed DC Motor, ** BLDC = Brushless DC Motor

AC

BDC

*

EC

No Commutation Mechanical Commutation Electrical Commutation (BLDC**)

slide-14
SLIDE 14

14

AC Motors

Type of Electrical Motors

14

Squirrel Cage Aluminum Alloy Rotor Winding Stator – Housing Life Time Variable Speed Control Lamination Rotor Flange

slide-15
SLIDE 15

15

BDC Motors

Types of electric motors

15 Source: DC – Motor Wikimedia.org * BDC = Brushed DC Motor, no Rosenberg product

Stator not shown Winding Commutator Rotor Shaft Variable Speed Control Life Time

slide-16
SLIDE 16

16

EC Motor

Types of electric motors Permanent Magnets Hall Sensors Rotor Cable Inlet Electronic Stator Windings Variable Speed Control Life Time

slide-17
SLIDE 17

17

Principles of operation

Technology

slide-18
SLIDE 18

18

Principles of operation

Technology

18 Source: 1-Cent Coin wikipedia.org * Power Section device opened

Alternating Current Direct Current Motor Voltage Rectifier DC link Inverter
slide-19
SLIDE 19

19

Principles of operation

Technology

M

U V W + −

M

U V W + −

M

U V W + −

M

U V W + −

M

U V W + −

slide-20
SLIDE 20

20

Life Time

Technology

Source: VFD danfoss.com

AC EC EC VFD

slide-21
SLIDE 21

21

Variable Speed Control

Technology

Permanent Magnet Hall-Sensor

Position detection by Hall Sensors: a) Commutation b) Speed Sensing

slide-22
SLIDE 22

22 22

AC EC 50-65 % 70-85 %

> 90 %

1-phase 3-phase

IE4

*

Generation of auxiliary phase Ohmic losses, Slippage Ohmic-, Friction, Magnetic Loses

slide-23
SLIDE 23

The Rosenberg Group 23

All of this in one package

EC-Technology-What is included??? AC-Fan Motor Protection Shielding VFD Power supply

for accessories 10 V & 24 V

Integrated Control Soft-Start PFC / Power filter EMC-Filter

slide-24
SLIDE 24

24

ROSENBERG’S EC MOTOR FAMILY

EC MOTOR PORTAFOLIO

GD 84 4” GD 112 5” GD 150 6” GD 220 8”

slide-25
SLIDE 25

Rosenberg Group

CONTINUOUSLY IMPROVING AND TESTING TO ACHIEVE AND IMPROVE PERFORMANCE ROSENBERG TESTING & RESEARCH LABORATORY IS TUV CERTIFIED (GERMANY & FRANCE) PERFORMANCE DATA 100% TESTED IN ALL OUR PRODUCTS

Research, Development & Testing

V020916 dc

slide-26
SLIDE 26

The Rosenberg Group 26

ROSENBERG FANS EC FAN GRID

RETROFITING OLD AIR HANDLING UNITS

  • EC MOTOR TECHNOLOGY
  • ON DEMAND SPEED PREPARED
  • EASY CONTROL SET UP
  • REDUNDANT
  • ENERGY EFFICIENT
  • LESS FOOTPRINT
  • EASY TO INSTALL AND MAINTAIN
slide-27
SLIDE 27

27

Theory of Using Fans in Parallel ECFanGrid

Air Flow is multiplied by maintaining the Pressure 2x2 GKHM 500

slide-28
SLIDE 28

28

Theory of Using Fans in Parallel Théorie d’utilsation de ventilateurs en parallèle

ECFanGrid

Air Flow is multiplied by maintaining the Pressure

3x3 GKHM 355

slide-29
SLIDE 29

29

Setting at our Certified Testing Laboratory ECFanGrid

3x3 GKHM 355 2x2 GKHM 500

slide-30
SLIDE 30

30

Benefits of an ECFanGrid vs Single Fan AHU ECFanGrid

Compact & Flexible Ease of Replacement & Maintenance More Uniform Air Distribution Less Low Frequency Noise Integrated Speed Control Easy to Clean Redundancy / High Availability Weight Reduction

Efficiency

Possible Operating Loss Difficult Replacement Maintenance of Belts Variable Frequency Drive Bigger Footprint

slide-31
SLIDE 31

31

Flexibility ECFanGrid

Quelle: Schere manufac.de

Fits Always

slide-32
SLIDE 32

32

Flexibility ECFanGrid

Quelle: Schere manufac.de

Fits Always

7 Fans

533 1067 1600 10750 21500 32250 43000

6 Fans

slide-33
SLIDE 33

405

33

Compactness ECFanGrid

Save up to 50 % Space!

1.19 2.37 4

slide-34
SLIDE 34

34

slide-35
SLIDE 35

35

slide-36
SLIDE 36

? ? ? ? ? ? ? ? ? ?

36

Retrofit Replacement Issues ECFanGrid

?

slide-37
SLIDE 37

37

Ease of Installation ECFanGrid

slide-38
SLIDE 38

38

Ease of Replacement ECFanGrid

slide-39
SLIDE 39

39

Redundancy – 3x3 ECFanGrid ECFanGrid manually… …automatic

Fail Safe – Emergency Mode Included

slide-40
SLIDE 40

40

Air Distribution ECFanGrid

High Spot Air Velocities and an Uneven Air Flow …

slide-41
SLIDE 41

41

Air Distribution ECFanGrid

Less Spot Air Velocity and a more Uniform Air Flow

slide-42
SLIDE 42

42

Noise ECFanGrid

Less Low Frequency Noises Moins de bruit de basse fréquence

slide-43
SLIDE 43

43

Easy to Clean ECFanGrid

Easy to Clean, because ground is accessible

slide-44
SLIDE 44

44

Customer Interface Interface ECFanGrid

https://www.youtube.com/watch?v=psv8jkR1G94

Group Alarm Potential Free

  • r

24 V Speed Control 0-10 V Enable Potential Free

FOR ALL THE FANS TOGETHER

slide-45
SLIDE 45

45

Wiring Cabinet ECFanGrid

Main Switch Signals 24 V Supply Terminals n Fuses

slide-46
SLIDE 46

46

Markets ECFanGrid

Retrofit New AHU

slide-47
SLIDE 47

47

Retrofit KIT

ECFanGrid Adaptive. Fits in all AHU’S. Manufacturer doesn’t matter. Complete. The Kit includes all mechanical parts (Fans, Cabinet, Grid, Screws). Documented. Installation Guide available. Wiring Diagrams available. Mobile. Fits through standard doors and stairways.

slide-48
SLIDE 48

48

Retrofit Kit – Installation

ECFanGrid

slide-49
SLIDE 49

49

Retrofit Selection

ECFanGrid

https://www.youtube.com/watch?v=l0H_fne4YMw https://www.youtube.com/watch?v=2u2_evJd5Wg

slide-50
SLIDE 50

The Rosenberg Group

DATE: AUGUST 2013

SCOPE: SUBSTITUTION OF ONE BELT DRIVEN CENTRIFUGAL FAN INSIDE CUSTOM AHU

AIR VOLUME: 14,000 CFM

50

20 HUNTER ST. W. HAMILTON ON.

BELL CANADA – RETROFIT

slide-51
SLIDE 51

The Rosenberg Group Wednesday, November 13, 2013 51

SPACE RESTRICTIONS

SITE OUTLOOK

slide-52
SLIDE 52

The Rosenberg Group Wednesday, November 13, 2013 52

DISADVANTAGES

OLD CENTRIFUGAL BELT DRIVEN FAN

  • SINGLE MOTOR- NO REDUNDANCY
  • BELT DRIVE- EFFICIENCY LOSES &

MAINTAINANCE PROBLEMS

  • SPACE RESTRAINT
  • LONGER NOISE FILTERS
  • NEED OF A VFD TO CONTROL SPEED
slide-53
SLIDE 53

The Rosenberg Group Wednesday, November 13, 2013 53

FAN HANDLING AND ACCESIBILITY

ROSENBERG EC PLUG FAN

  • EASY TO HANDLE INTO THE JOBSITE
slide-54
SLIDE 54

The Rosenberg Group Wednesday, November 13, 2013 54

RETROFITTING WITH EC FANS

NEW EC FAN GRID

  • BUILT IN REDUNDANCY
  • EASE OF CONTROL
  • EASE OF INSTALLATION
  • UNIFORM PROFILE AIR

VELOCITIES

  • NOISE REDUCTION
  • EFFICIENT
slide-55
SLIDE 55

The Rosenberg Group Wednesday, November 13, 2013 55

ENERGY SAVINGS

AIR HANDLING UNIT RETROFIT WITH EC FAN GRID

Existing Fan (1) 79.50 A 14, 000 cfm 22.37 kW Replacement Fan Array (6 fans) 39.40 A 18, 000 cfm 13.34 kW

40% ENERGY SAVINGS (22.37 kW – 13.34 kW) x 365 day/year x 24 h/day x 0.10 $/kW = 7,910 $/year

* Considering constant speed – Variable speed case savings are

significantly higher with shorter payback EC MOTOR = NO VFD

slide-56
SLIDE 56

56

slide-57
SLIDE 57

57

Questions & Answers ECFanGrid

Flyer, Contact, References, Installation Videos, …

www.ECFanGrid.com
