Presented by Andrew Bartlet Samba Team - Catalyst / / June 2018

A Few things happened on the way to LMDB

Samba is a member project of the Sofuware Freedom Conseraancy

Andrew Bartlet and Catalyst’s Samba Team

• Samba Deaeloper since 2001
• Based in Wellington, New Zealand
• Team lead for the Catalyst Samba Team,

including:

–

Garming Sam

–

Douglas Bagnall

–

Gary Lockyer

–

Tim Beale

–

Joe Guo

–

Aarron Haslet

–

Jamie McClymont

Not really a story about LMDB

• LMDB prety much did what it said on the tn
• Instead LMDB taught us about Samba and LDB
• Numerous locking issues found and fied
• A new key-aalue layer added
• And so, so many tests

Customer request: 64-bit DB

• Concerned that the 4GB DB could be flled too quickly

–

Wantng to store g 100,000 users in a single domainn

• Main concern is the hard limit of TDB
• LMDB chosen as a modern key-aalue store

–

Used in OpenLDAP

Timeline

• LMDB was prototyped in Jan 2017

–

Garming Sam

–

Inspired by, but rewriten from Jakob Hrozek’s earlier prototype

• GUID-indei LDB implemented in July/August 2017

–

LMDB requires a maiimum 511 byte key length

• Primary deaelopment Jan → May 2018

–

Gary Lockyer

A new approach: Key/Value layer

• Jakob’s approach was to copy ldb_tdb and modify it
• Garming and I decided to instead add a key-aalue layer

–

Aaoid code duplicaton

–

Allow more than just LMDB (perhaps LMDBi, LeaelDB)

–

Share performance and correctness improaements with ldb_tdb

–

Like dbwrap in concept but specifc to LDB needs

Key-value API

• int (*store)(struct ltdb_priaate *ltdb, struct ldb_aal key, struct ldb_aal data, int fags)
• int (*delete)(struct ltdb_priaate *ltdb, struct ldb_aal key);
• int (*iterate)(struct ltdb_priaate *ltdb, ldb_ka_traaerse_fn fn, aoid *cti);
• int (*update_in_iterate)(struct ltdb_priaate *ltdb, struct ldb_aal key, struct ldb_aal key2,

struct ldb_aal data, aoid *cti);

• int (*fetch_and_parse)(struct ltdb_priaate *ltdb, struct ldb_aal key, int (*parser)(struct

ldb_aal key, struct ldb_aal data, aoid *priaate_data), aoid *cti);

Locking API

• Read Locks

–

int (*lock_read)(struct ldb_module *);

–

int (*unlock_read)(struct ldb_module *);

• Transactons

–

int (*begin_write)(struct ltdb_priaate *);

–

int (*prepare_write)(struct ltdb_priaate *);

–

int (*abort_write)(struct ltdb_priaate *);

–

int (*fjnish_write)(struct ltdb_priaate *);

Meta API

• int (*error)(struct ltdb_priaate *ltdb);
• const char * (*errorstr)(struct ltdb_priaate *ltdb);
• const char * (*name)(struct ltdb_priaate *ltdb);
• bool (*has_changed)(struct ltdb_priaate *ltdb);
• bool (*transacton_actve)(struct ltdb_priaate *ltdb);

First Hurdle: Locking

• Eaen the prototype found issuesn

–

Demonstrated the lack of whole-DB locking

–

Fiied for Samba 4.7 last year

• Probably behind many of our replicaton issues

Second Hurdle: More Locking!

• It just wouldn’t pass make testn

–

More strange failures in replicaton

• Unlock ordering issues in replicaton

–

highestCommitedUSN aisible before the data

–

Fiies proposed for backport to Samba 4.7 and 4.8

• Modifcaton without locks (at startup) in Samba 4.8

–

DB-init tme only, but not good

–

Added checks to key-aalue layer to preaent re-occurrence

Third hurdle: Maximum key size

• TDB has an unlimited key size
• LMDB is limited to 511 bytes
• LDB traditonally used the DN as the key

–

Addressed by the new GUID key system

But what about indexes?

• Indei created by putng indei key and aalue in the TDB key

–

@INDEX:SAMACCOUNTNAME:abartlet

• Original plan was to keep the indei in TDB

–

But the more we understood the locking the less we wanted to mii TDB and LMDB lock ordering

• Addressed by truncatng the indei and coping with multple matches

–

Ironically found and fied the 4.8 upgrade bug

–

But didn’t realise the importance before eaeryone notced

And what about performance?

• Three performance tools measured so far:

–

Make perfuest on our Hardware test seraer

• Old AMD Athalonn

–

Trafc replay tool in the cloud

–

Adding users and users into groups of my workstaton

Make perfest: a small dissapointment

• 30% performance lossn

–

LMDB uses write(), and a read-only mmap()

–

socket_wrapper intercepts write()

• Workaround:

–

Use Linui userspace namespaces instead of socket_wrapper

–

Patches to upstream this stll pending

• End result is no major change, perhaps 10% slower

Trafc replay

• This is a tool to replay an amplifed anonymous trafc capture
• Similar numbers to TDB
• Need to re-try with a larger DB

–

We think LMDB will show most strength at large sizes

Adding users and users into groups of my workstaton

• In a four-hour benchmark adding users and adding to one to four groups (in rotaton):

–

Samba 4.4: 26,000 users

–

Samba 4.5: 48,000 users

–

Samba 4.6: 55,000 users

–

Samba 4.7: 85,000 users

–

Samba 4.8: 100,000 users

–

Samba 4.9: 100,000 users (TDB)

–

Samba 4.9: 45,000 users (LMDB)

• Ouch. What went wrong!
• fsync()/fdatasync()/msync() stll called
• Patches quickly writen
• New numbers:

–

Samba 4.9: 100,000 users (TDB)

–

Samba 4.9: 124,000 users (LMDB, no fsync())

• Lesson:

–

Samba’s module stack is stll the slowest factor

TDB vs LMDB (latency vs number of users added)

Flame Graph

Search do.. replmd_.. ld.. sys.. std_e.. _tc_fre.. lt.. ltdb_search_and_return_base ltdb_se.. ldb_wait lmdb.. __p.. ldb_next_request _tc_fre.. extended_callback p.. ldb_module_done ltdb_s.. extended_callback_ldb _int_f.. _tc_fre.. ldb_w.. ltd.. _tc_fre.. ltd.. lt.. re.. std_ev.. new.. ldb_wait ldb_module_done ltdb_modify_i.. _tc_fre.. dsdb.. extended_replace_callback _tc_fre.. ldb_next_request ltdb.. _tc_fre.. de.. lt.. d.. _tevent.. ltdb_search std_.. _teve.. ldb_next_request h.. samldb_modify ltdb.. ldb_next_request lt.. es_callback _tc.. _.. pag.. td.. _talloc.. extended_callback_ldb _tc_fre.. __.. lt.. ldb_next_request ldb_next_request sy .. teve.. rdn_name_modify partition_req_callback _tc_fre.. ldb_next_request std_event_loop_once e.. ldb_module_send_entry _t.. ltdb_.. epoll.. ltdb.. _tc_fre.. _tc_fre.. _tc_fre.. ltdb_.. lt.. _teven.. epoll_e.. partition_req_callback dsdb_dn_parse_trusted __.. ldb_module_done ltdb_ca.. __.. s.. dsdb_next_callback _tc_fre.. lt.. do_.. password_hash_nee.. lm.. _tc.. ext.. _tc_fre.. [unknown] lt.. _talloc.. _tc_f.. epoll_.. _tc_fre.. ltdb_.. lt.. extended_dn_in_modify lt.. ld.. ltdb_.. dsdb_m.. py_ldb_modify PyEval_EvalFrameEx do.. ltdb_modify tombstone_reanimate_modify _tc_fre.. li.. ltdb.. tevent.. ent.. ld.. __.. lt.. ld.. pa.. un.. attr_handler ltdb_c.. ldb_module_done ltd.. lm.. epoll_event_loop_once _tc_fre.. ldb_next_request ltdb_se.. saml..

• perational_callback

lt.. d.. lt.. td.. ldb_next_request ld.. extended_callback ldb_next_request ldb_next_request teven.. _tc..

• bjectclass_modify

dsdb.. __GI.. lt.. _tc_fre.. acl_modify d.. lt.. __m.. _tc_fre.. ltdb_request_done lt.. lt.. ld.. d.. dsdb_mo.. log_modify _tal.. ldb_wait _tc_fre.. _.. __me.. [unknown] lt.. py_ldb_add ltdb.. ltdb_callback ltdb_s.. ld.. python ldb_next_request lt.. password_hash_mod.. ltdb.. ldb_dn_fr.. ge.. ldb_.. epol.. _t.. instancetype_mod _tevent_loop_once std_eve.. ldb_module_send_entry ldb_module_done

• bjectclass_attrs..

lt.. lm.. tevent_common_loop_timer_delay ldb_module_send_entry descriptor_modify _.. replmd_m.. ltdb_.. _int_mal.. _tc_fre.. _tal.. lmdb_.. tevent_.. _tc.. __memmo.. replmd_modify extended_dn_in_fjx _tc_fre.. _tc_fre.. _t.. _tev.. dsdb_next_callback vfs.. en.. _tc_fre.. lo..

OK, so not so bad

• We addressed the customer’s desire for scale

–

Currently limited to 6GB but that is compile-tme constant only

• Opens up new opportunites
• Current Status:

–

Stll accessed behind sam.ldb (a TDB)

–

Stll one-subtree per DB fle

LMDB: The future

• Use the LMDB b-tree propertes in for the indei

–

Allow prefi matching

–

Allow <= etc

• Use sub-databases:

–

Perhaps one per indei?

–

Perhaps one per sub-tree?

• Use nested transactons to make the indei safer

LMDB: Sharp Edges

• Difgerent locking behaaiour (no eiclusiae access)
• Files are sparse by default

–

DB operatons can fll the fle and partton without going aia a specifc resize

• Files are not eitended automatcally

–

The inaerse to the aboae, when a fle is full unlike TDB there is no auto-resize

–

Requires that the admin or Samba know the size up-front

• LDB / Samba has not required this kind of planning in the past
• Need real-world eiperience

Beyond LMDB: Supportng more connectons on each DC

• Samba 4.6 remoaes single-process restrictons on NETLOGON

–

Really important for 802.1i backed authentcaton

• Samba 4.7 supports a mult-process LDAP seraer

–

Actually reduces number of connectons you can ft in memory (oops)

• Samba 4.8 adds a prefork mode for LDAP

–

Great for a big AD DC with many, many clients

• Samba 4.9: should we make prefork the default?

–

Howeaer NETLOGON would be single-process in that mode (ouch)

New trafc_replay Performance tool

• We can now record and re-play trafc

–

Recreate a real-world load

–

Amplify the trafc

• Comparatae testng now possible between Windows and Samba
• Samba is now within about 50% of Windows performance

–

Against a single-CPU target system

–

Allows us to slow both down enough for the trafc_replay to saturate it

Performance against Samba and Windows

• 1 aCPU
• Catalyst Cloud
• Afuer 35i speed the tool

eihausts itself

• So this is not the upper bound

Wanted: More network captures

• We need more sample of network trafc

–

Anonymised with the trafc_summary.pl script

• Ideally with permission to publish (eg the Samba wiki)
• Diaerse real world loads will aaoid skewed perf testng

make perfest graphs

• April 2016

to Dec 2017

Catalyst development beyond performance

• Encrypted secrets (4.8)

–

Use a local fle key to encrypt DB secrets

–

(could then be network-deployed)

• Unii-compatble passwords (4.7)

–

Store and retrieae sha256/sha512 crypt() passwords to sync with other systems

• Audit Logging (4.7 and 4.9)

–

Output audit logs into JSON

• RODC support (4.7)

–

This was eiperimental untl now

• DNS Zone scaaenging (for 4.9)
• Demote cleans up own DNS records (4.9)
• Fine Grained Password Policy (4.9)
• Domain Backup (for 4.9)
• Domain Rename (for 4.9)

Catalyst's Open Source Technologies – Questons?

Want to work with my team at Catalyst to make your Samba scale? - talk to me in the hallway trackn
