A Brief Introduction to XNA

Eric Feng ACRD

Agenda

• Introduction
• Application Model
• History and Roadmap
• Games Powered By XNA
• XNA’s Modules
• Working pipeline
• Performance
• Tips and Golden Rules

XNA’s Not Acronymed

• What IS XNA?

– A managed framework for developing games on both PC and Xbox 360

• Graphics device, input, and audio management along with

math helpers

• Who is using XNA?

– Hobbyists – Students – Independent developers – And…., professionals

• Torpex Games, Hidden Path Entertainment, GarageGames

Inc.

XNA’s Not Acronymed (cont’d)

• Why XNA?

– Unmanaged background

• assembly, C, C++
• XNA exposed us to a new language ----- C#

– XNA allows for RAD

• Full games can be put together in obscenely short periods of time
• Allows developers to focus on content, gameplay, balancing over

technical issues

– XNA does things more intuitively than DirectX

• Render Targets
• Device Management

Game Technology Map

Realtime Rendering

Simulation Technology

Multiplayer Technology

Audio Content

Mesh/Material Content

3D Editors Animation Content

Cinematic Content

Process

Alias Maya Discreet 3D Studio Max SoftImage XSI Newtek Lightwave 3D Editor

Game Engines

Criterion Renderware Graphics Epic Unreal NDL Gamebyro (NetImerrse) Touchdown Entertainment Jupiter Id Quake/Doom Valve Half Life 2 Crytek CryEngine Vicarious Visions Intrinsic Alchemy Spinor GmbH Shark 3D Trinigy GmbH Vision Virtools (Prototyping) Game Engines

Criterion Renderware Studio Studio Game Asset Conversion

Converters

UI Creation/Menus

Perforce CVS Subversion Source Management VS SourceSafe VS Team System

Alienbrain Asset Management

World/Level Editors

XNA Pillars

Design/Content Creation Game Technology Process

Process/Build Asset Management Test Tools Developer Tools Game Technology Design/Content Creation

Realtime Rendering

Simulation Technology

Multiplayer Technology

Audio Content

Game Engines

Micro Forte BigWorld Criterion Renderware Graphics Epic Unreal NDL Gamebyro (NetImerrse) Touchdown Entertainment Jupiter Id Quake/Doom Valve Half Life 2 Crytek CryEngine Vicarious Visions Intrinsic Alchemy Spinor GmbH Shark 3D Trinigy GmbH Vision Virtools (Prototyping) Game Engines Criterion Renderware Studio Studio

Mesh/Material Content

3D Editors

Alias Maya Discreet 3D Studio Max SoftImage XSI Newtek Lightwave 3D Editor

Animation Content

Cinematic Content

Design Tool Format Converters Game Asset Conversion

Perforce CVS Subversion Source Management VS SourceSafe VS Team System Alienbrain Asset Management

UI Creation/Menus

World/Level Editors

Application Model

• The XNA Framework is divided into three

essential parts

– XNA Graphic Engine in the Microsoft.Xna.Framework.dll – XNA Game Application Model in the Microsoft.Xna.Framework.Game.dll – XNA Content Pipeline in the Microsoft.Xna.Framework.Content.Pipeline.dlls

XNA Content Pipeline

Microsoft.Xna.Framework.Content.Pipeline.dll

Game Application Model

Microsoft.Xna.Framework.Game.dll

Graphic Engine

Microsoft.Xna.Framework.dll

History and Roadmap

• XNA 1.0 – Aug. 2006

– Application Model, GameComponenents – GraphicDevice, Graphics – Audio, Input, Storage, Math

• XNA 2.0 – Dec. 2007

– Expanded Support for all version of VS2005 – MRT, device lost auto restore, occlusion query, etc. – Networking support!

• XNA 3.0 – Christmas. 2008??

– Add Zune support – Support for C# 3.0 for all platform(I can use LINQ! Oh, My…) – Content compression, Better FBX support

Games Powered By XNA

• XNA Car Racing Game

– The Racing Game Starter Kit is a complete XNA Game Studio game. This highly-anticipated project,

• riginally created for Microsoft by Benjamin

Nitschke of exDream Entertainment. – XNA car Racing Game is a 3D auto racing game that features advanced graphics, audio, and input

• processing. Race around the track and try to beat

the ghost car to achieve the best time.

Games Powered By XNA

• The Robot Game

– Robot Game was developed by Zepetto, a South Korean game development company. Previously released titles include Vulcanus and several games for mobile platforms. – Robot Game is a three-dimensional robot combat game that demonstrates the following components:

• Advanced graphics using shaders and post-processing effects
• Advanced particle system
• Collision detection, 3D positional sound, input, and screens

management

• Single-player mode and split-screen two-player versus mode
• Customizable game elements, such as robots, weapons, and items

Games Powered By XNA

• Singularis

– Developed with XNA 2.0 Sprite with Torque Builder, Singularious is a game about a single cell creature. – Story: The protozoa Proto has a ambitious goal - he want's to become the

most powerful entity of the universe! To reach his target, Proto invades into animals, travels through their bodies and settles down on their central nerve cord, where he gains control over them. When he has control over them, he uses his victims to get to the next, more powerful animal - until he gains control over the most powerful entity within the universe ... a floating, black cat!

Games Powered By XNA

• Other Games

– HurricanX – Action Game – RPG Starter Kit by XNA Creater Club – The Zune game

XNA’s Modules

• Let’s dig down

– Content Pipeline – Graphics

• Programable pipeline
• Effect system
• 2D Sprite

– Framework – Networking – Audio, etc.

Content Pipeline

Content Pipeline

• In action!

– To intrude the exist pipeline – Simple sample from my engine – Create a terrain from a heightmap

Add “Visibility” tag Add “AABB” tag Add “Effect” tag Material converter

Attach correct shader to meshes

Read the image Construct vertices Create a new material C r e a t e t o p o l o g y

What’s the cons of XNA’s Graphics

• GraphicsDeviceManager
• Render States
• Vertex and Index Buffers
• Shaders and Effects

XNA Framework

• GameServices container

– Loose coupling between modules

• Math Helper

– Vector, Color, Matrix, Quaternion,

• MeshBuilder

– Generate normal, texture coordinate, binormal, tangent in content pipeline

Working pipeline

• Let’s get our hands dirty!

3Ds Max Modeling Export to FBX Generate shader code files Generate XNB using content pipeline Display the models on screen

Performance

• Graphics

– Offload to the GPU – Choose an appropriate SpriteSortMode – Avoid StateBlock

• Optimize math where necessary
• Take advantage of multiple threads
• Profile on both Xbox and Windows

Performance

• Offload tasks from CPU to GPU

– Mesh Instancing – Particle 3D samples – Occlusion Query

Performance

• XNA Architecture on XBox360

Performance

• GraphicsDevice is somewhat thread-safe

– Cannot render from more than one thread at a time – Can create resources and SetData while another thread renders

• ContentManager is not thread-safe

– Ok to have multiple instances, but only one per thread

• Input is not threadable

– Windows games must read input on the main game thread

• Audio and networking are thread-safe

Golden Rules And Tips

• Tips

– Write the tests first and do not think about the implementation. – Try to make sure you test as much as possible. – Start the test constantly from this point on, even when you think it does not make sense.

Golden Rules And Tips

• Golden Rules

– Don’t use any external dlls if not required – Don’t wait with the testing – Don’t load content directly – Save games and loading other content – Test resolutions – Allow controlling everything with a gamepad – Debug and unit test on the Xbox 360

• Thank you.
• Demo Time
• Q & A
