3D SCANNING & 3D PRINTING 2/21/2019 GINGER CHICOS and JUAN PINTO TYPES OF 3D SCANNERS MOST COMMONLY USED IN CONSTRUCTION LASER PULSE (LIDAR) STRUCTURED LIGHT PHOTOGRAMMETRY 3D SCANNING TYPES OF 3D SCANNERS LASER

slide-1
SLIDE 1

3D SCANNING & 3D PRINTING

2/21/2019 GINGER CHICOS and JUAN PINTO

slide-2
SLIDE 2
slide-3
SLIDE 3

3D SCANNING

TYPES OF 3D SCANNERS

MOST COMMONLY USED IN CONSTRUCTION

  • LASER PULSE (LIDAR)
  • STRUCTURED LIGHT
  • PHOTOGRAMMETRY
slide-4
SLIDE 4

3D SCANNING

TYPES OF 3D SCANNERS

  • LASER PULSE (LIDAR)

calculates distances based on how long it takes laser to leave and bounce back to the scanner

slide-5
SLIDE 5

3D SCANNING

TYPES OF 3D SCANNERS

  • LASER PULSE (LIDAR)
  • Pros
  • Resolution
  • Accuracy 99.9+%
  • distance between scans
  • Cons
  • Cannot scan shiny or transparent

surfaces

  • Time duration of each scan
slide-6
SLIDE 6

3D SCANNING

TYPES OF 3D SCANNERS

  • STRUCTURED LIGHT

Projects light patterns onto

  • bjects and examines the edges the

pattern to calculate distance from scanner to object

slide-7
SLIDE 7

3D SCANNING

TYPES OF 3D SCANNERS

  • STRUCTURED LIGHT
  • Pros
  • Speed per scan
  • resolution
  • Cons
  • Sensitivity to too much light

exposure

  • Short distance between scans
  • Accuracy 99% (over 100ft, will

have 1ft discrepancy)

slide-8
SLIDE 8

3D SCANNING

TYPES OF 3D SCANNERS

  • PHOTOGRAMMETRY

Analyzes several photographs of static objects taken from different viewpoints to compute distances

slide-9
SLIDE 9

3D SCANNING

TYPES OF 3D SCANNERS

  • PHOTOGRAMMETRY
  • Pros
  • precision
  • Acquisition speed
  • Cons
  • Need powerful computer to run

algorithms

  • Dependent on the quality of

photographs

slide-10
SLIDE 10

3D SCANNING

WHY 3D SCAN?

  • SAVES TIME AND EFFORT
  • DATA CAN BE SHARED AND

REVIEWED AT ANY TIME

  • NOT DEPENDENT ON INCORRECT

(NON-EXISTING) AS-BUILTS

slide-11
SLIDE 11

3D SCANNING

EXAMPLES OF 3D SCAN

slide-12
SLIDE 12

3D SCANNING

EXAMPLES OF 3D SCAN

slide-13
SLIDE 13

3D SCANNING

EXAMPLES OF 3D SCAN

slide-14
SLIDE 14

3D SCANNING

EXAMPLES OF 3D SCAN

slide-15
SLIDE 15

3D SCANNING

EXAMPLES OF 3D SCAN

slide-16
SLIDE 16

3D SCANNING

EXAMPLES OF 3D SCAN

slide-17
SLIDE 17

3D PRINTING

3D PRINTING

slide-18
SLIDE 18

3D PRINTING

3D PRINTING

  • THE ABILITY TO MANIFEST AN IDEA IN A “SHORT”

AMOUNT OF TIME

https://massivit3d.com/solutions/3d-printers/

slide-19
SLIDE 19

3D PRINTING

3D PRINTING

TYPES OF 3D PRINTING

  • FUSED DEPOSITION MODELING (FDM OR FFF)

https://www.3dhubs.com/knowledge-base/introduction-fdm-3d-printing

slide-20
SLIDE 20

3D PRINTING

3D PRINTING

TYPES OF 3D PRINTING

  • STEREOLITHOGRAPHY (SLA)

https://www.3dhubs.com/knowledge-base/introduction-fdm-3d-printing

slide-21
SLIDE 21

3D PRINTING

3D PRINTING

TYPES OF 3D PRINTING

  • SELECTIVE LASER SINTERING (SLS)

https://www.3dhubs.com/knowledge-base/introduction-fdm-3d-printing

slide-22
SLIDE 22

3D PRINTING

3D PRINTING

TYPES OF 3D PRINTING

  • MATERIAL JETTING (MJ)

https://www.3dhubs.com/knowledge-base/introduction-fdm-3d-printing

slide-23
SLIDE 23

3D PRINTING

3D PRINTING

FUSED DEPOSITION MODELING (FDM OR FFF)

PROS:

  • EASIEST TO USE
  • WIDE RANGE OF MATERIALS
  • MOST COMMONLY AVAILABLE
  • ECONOMICAL
  • BEST FOR PROTOTYPING
  • LAYER RESOLUTION .1MM TO .3MM
slide-24
SLIDE 24

3D PRINTING

3D PRINTING

FUSED DEPOSITION MODELING (FDM OR FFF)

CONS:

  • LOWER FINISH RESOLUTION THAN SLA
  • ONLY SINGLE OR DUAL COLOR
  • MAX. PRINTING SIZE IS LIMITED (AVERAGE IS

8”X8”X8”)

slide-25
SLIDE 25

3D PRINTING

A GROWING TREND

BECOMING HOUSEHOLD TECHNOLOGY

  • SITE LOGISTIC PLANNING
  • UNDERSTAND YOUR

BUILDING

  • ENHANCE YOUR

PRESENTATION

  • LEAVE BEHIND A

STATEMENT

slide-26
SLIDE 26

3D PRINTING

WHY USE 3D PRINTING?

RECOGNIZABLE MEMENTOS

slide-27
SLIDE 27

3D PRINTING

3D PRINTING

slide-28
SLIDE 28

3D PRINTING

3D PRINTING

https://www.productchart.com/3d_printers/

PRICE RANGE $150 UP TO $10,000

slide-29
SLIDE 29

3D PRINTING

https://www.rolanddga.com/es/blog/2016/06/02/22/56/cool-3d-printing-infographic

3D PRINTING

slide-30
SLIDE 30

3D PRINTING

PRINTING TIME

3D PRINTING

slide-31
SLIDE 31

3D PRINTING

3D PRINTING

COMMON TERMS

  • FDM
  • FILAMENT- PLASTIC MATERIAL
  • CURA- COMPUTER SOFTWARE
  • HOT-END
slide-32
SLIDE 32

3D PRINTING

HOW DOES IT WORK?

SLICING SOFTWARE 3D PRINTER FILAMENT SPOOL HOT-END

slide-33
SLIDE 33

3D PRINTING

HOW DOES IT WORK?

HOT-END BED PLATE- LAYER RAPID COOLDOWN

slide-34
SLIDE 34

3D PRINTING

FACTORS TO CONSIDER:

  • OVERHANGS- CANTILEVERS, WALL

OPENINGS, “BRIDGING”

  • VOIDS
  • THICKNESS- WALLS, SPIRES,

COLUMNS

HOW DOES IT WORK?

slide-35
SLIDE 35

3D PRINTING

CASE STUDY

slide-36
SLIDE 36

3D PRINTING

DESIGN IDEA COMPUTER MODEL

HOW DOES IT WORK?

slide-37
SLIDE 37

3D PRINTING

COMPUTER MODEL “SLICING SOFTWARE”

HOW DOES IT WORK?

slide-38
SLIDE 38

3D PRINTING

SLICING SOFTWARE 3D PRINTER

HOW DOES IT WORK?

slide-39
SLIDE 39

3D PRINTING

SLICING SOFTWARE 3D PRINTER

HOW DOES IT WORK?

slide-40
SLIDE 40

3D PRINTING

HOW DOES IT WORK?

3D PRINTER PRESENTATION

slide-41
SLIDE 41

3D PRINTING

HOW DOES IT WORK?

3D PRINTER PRESENTATION

slide-42
SLIDE 42

3D PRINTING

HOW DOES IT WORK?

3D PRINTER PRESENTATION

slide-43
SLIDE 43

3D PRINTING

HOW DOES IT WORK?

3D PRINTER PRESENTATION

slide-44
SLIDE 44

3D PRINTING

CASE STUDY

slide-45
SLIDE 45

3D PRINTING

SITE LOGISTIC PLANNING

  • UNDERSTANDING YOUR

SITE

  • TRAILER AND EQUIPMENT

PLACEMENT

  • UNFORESEEN CONFLICTS
  • CONSTRUCTION

SEQUENCING

slide-46
SLIDE 46

3D PRINTING

SITE LOGISTIC PLANNING

slide-47
SLIDE 47

3D PRINTING

SITE LOGISTIC PLANNING

slide-48
SLIDE 48

3D PRINTING

SITE LOGISTIC PLANNING

  • SIZE 12”X12” BROKEN

INTO 6”X6”

  • LAYER HEIGHT= .3MM
  • 8-10 HOUR PER PRINT
  • 5 PRINTS TOTAL
  • TOTAL TIME OF 45-50

HOURS OF PRINTING

slide-49
SLIDE 49

3D PRINTING

SITE LOGISTIC PLANNING

slide-50
SLIDE 50

3D PRINTING

SITE LOGISTIC PLANNING

slide-51
SLIDE 51

3D PRINTING

SITE LOGISTIC PLANNING

slide-52
SLIDE 52

3D PRINTING

FUTURE OF 3D PRINTING?

slide-53
SLIDE 53

3D PRINTING

FUTURE OF 3D PRINTING?

  • REMOTE CONTROL

PRINTING

  • WEB MONITORING
  • EMERGENCY

CANCEL!

slide-54
SLIDE 54

3D PRINTING

FUTURE OF 3D PRINTING?

  • CONCRETE PRINTING
  • SAME CONCEPT OF X,Y

,Z PRINTING- MUCH LARGER SCALE

  • CONSISTENCY
slide-55
SLIDE 55

3D PRINTING

FUTURE OF 3D PRINTING?

  • STEEL PRINTING
  • CONSTRUCTION OF ORGANIC SHAPES

https://mx3d.com/projects/bridge-2/

slide-56
SLIDE 56

3D PRINTING

COMMENTS OR QUESTIONS?
