3. Back to fundamentals Bits, bytes and all that CL1 2003/4-3 1 - - PowerPoint PPT Presentation

3. Back to fundamentals Bits, bytes and all that CL1 2003/4-3 1 2 Once upon a time CL1 2003/4-3 Analogue and Digital Modern computers are digital computers Given a quantity (e.g. voltage somewhere) Decide if theres a


slide-1
SLIDE 1

CL1 2003/4-3 1

  • 3. Back to fundamentals

Bits, bytes and all that

slide-2
SLIDE 2

Once upon a time …

CL1 2003/4-3 2

slide-3
SLIDE 3

Analogue and Digital

  • Modern computers are digital computers
  • Given a quantity (e.g. voltage somewhere)

– Decide if there’s a voltage (1) or no voltage (0)

  • Fast; lots of very simple decisions made very quickly
  • Easy to transmit - degradation has to be extreme before you get

error

  • Alternative were analogue computers

– Very restricted; utterly unlike digital computers – Analogue computation lurks in the sidelines

CL1 2003/4-3 3

slide-4
SLIDE 4

The binary bit (see handout)

  • The basic unit handled by all processes in a

digital computer is the binary bit.

  • It may take the value 0 or 1.
  • 3 bits: 000, 001, 010, 011, 100, 101, 110, 111

– 8 (23) possibilities. Represent numbers 0 - 7 – ... Or numbers –4 to +3, or 0 to 1 in steps of 1/8 – … or North, North-East, East, … – … red, green, blue, cyan, yellow, magenta, black, white … etc. etc. – any collection of 8 things.

CL1 2003/4-3 4

slide-5
SLIDE 5

Collections of bits - 1

  • 8 bits together can represent 256 (28) possible values:

– Numbers 0 to 255; (or –128 to +127); or a character. – A group of 8 bits is called a byte or an octet

  • 10 bits together can hold 210 or 1024 possible values;

1024 is close to 1000 and ‘K’ in computer terminology usually means 1024 rather than 1000.

  • Powers of 2 are ‘round’ numbers in computing terms
  • Binary numbers are unwieldy (200310 =

111110100112) and are usually represented in octal (base 8) or hexadecimal (base 16) notation.

CL1 2003/4-3 5

slide-6
SLIDE 6

Base N examples

In normal (base 10) arithmetic, 1234 stands for…

  • 1 * 1000 + 2 * 100 + 3 * 10 + 4 * 1

i.e..

  • = 1 * 103 + 2 * 102 + 3 * 101 + 4 * 100

In Base 2, 1101 means

  • 1 * 23 + 1 * 22 + 0 * 21 + 1 * 20 (= thirteen)

In Base 8 (octal), 123 means

  • 1 * 82 + 2 * 81 + 3 * 80 (= eighty-three)

In Base 16 (hexadecimal), 1D means

  • 1 * 161 + D * 160 (= twenty-nine)

[‘D’ = 13]

CL1 2003/4-3 6

slide-7
SLIDE 7

Hexadecimal

  • Hexadecimal arithmetic is base 16
  • Digits are 0-9 and A-F
  • There is a relationship between hexadecimal and

binary = each hex digit represents four binary bits

  • 200310 is 111110100112 which is 111| 1101 | 0011

= 7D3 in hexadecimal

  • Written 0x7D3, #7D3 etc.
  • (similarly octal digits each represent 3 binary bits)

CL1 2003/4-3 7

slide-8
SLIDE 8

Note …

  • You will not be asked to do hex or octal arithmetic

in an exam but might be asked to ‘count on your fingers’ in binary, hex or octal

  • Key issue here is to recognise these numbers when

you see them and have some idea of what lies behind them

  • Why for instance numbers like 32, 64, 255 (256)

are significant

  • See handout for more background

CL1 2003/4-3 8

slide-9
SLIDE 9

Collections of bits - 2

CL1 2003/4-3 9

  • The maximum number of bits a processor can

handle in a single operation is called the word length and in modern machines is typically 32 or 64.

  • 2word length - 1 is the largest (unsigned) integer the

computer can conveniently store exactly.

  • The power of a processor depends on the raw

processor speed and the word length among other things.

  • The speed of a computer system depends on many
  • ther factors as well.
slide-10
SLIDE 10

Examples

  • GENERAL PROTECTION FAULT, addr = 2FEF

3C00 [“Blue Screen of Death”; hex address of where error occurred].

  • <body bgcolor=“#F0F0C0”> [hex number

describing amounts of Red, Green and Blue (RGB) in a Web page colour, range 0-255]

  • 129.215.128.57 [Internet ‘IP’ address; each

number will be between 0 and 255]

  • Computer ‘MAC’ address: 00-C0-86-4A-07-F6

CL1 2003/4-3 10

slide-11
SLIDE 11

Units of measure

1 byte

  • 1

20 100 1 Kilobyte Kb 1 Thousand 210 220 230 240 250 ~103 1 Megabyte Mb 1 Million ~106 1 Gigabyte Gb 1 Billion (US) ~109 1 Terabyte Tb 1,000 Billion ~1012 1 Petabyte Pb 1,000,000 Billion ~1015

CL1 2003/4-3 11

slide-12
SLIDE 12

A few sample data sets

12

300 page novel 0.5 Mb screen capture of a PC screen at high resolution 2.3 Mb 3 minute sound track recorded as MP3 2 Mb 30 second video clip at low resolution 2 Mb Edinburgh telephone directory 20 Mb Typing 4 characters/second, 8 hrs/day for a year 42 Mb Corporate Customer database, e-Science n Tb Library of Congress 100 Tb Video of your entire life 1 Pb Human brain, big e-science n Pb

slide-13
SLIDE 13

Size limits

  • A computer needs to be able to index each

separate byte in memory or a file (e.g. byte 123 in file ‘fred’).

  • The limits on memory and file sizes (also disk

blocks) will be binary ‘round numbers’.

  • This is why you may find memory on a PC is

limited to 4Gb or hard disks on old PCs are limited to 2Gb etc. etc.

CL1 2003/4-3 13

slide-14
SLIDE 14

Characters are coded

  • One per byte, ASCII encoding:
  • A

0x41 (0)100 0001

  • B

0x42 (0)100 0010

  • C

0x43 (1)100 0011

  • c

0x63 (0)110 0011 (lower-case)

  • Ctrl-A

0x01 (1)000 0001

  • Can only represent 128 characters this way
  • 8th bit is reserved for error detection - parity
  • Even parity even number of ‘1’s in code

CL1 2003/4-3 14

slide-15
SLIDE 15

Some characters don’t travel well

  • ASCII

7 bits+1 128 values

  • €, ¥, §, à, é, ç as coded need 8 bits
  • Alternatives:
  • Latin 1(extended ASCII) 8 bits

256 values

  • Unicode

16 bits 65536 values

  • But then …
  • “$” “local currency symbol” (£,$, …) etc.

CL1 2003/4-3 15

slide-16
SLIDE 16

Email character quoting

  • I went to see “Une Femme Française” at the
  • Filmhouse. Tickets were £6.50

Becomes

  • I went to see =B4=B4Une Femme

Fran=E7aise=B4=B4 at the Filmhouse. Tickets were =A36.50. Or..

  • <html><body>I went to see “Une Femme

Fran&#123;aise” at the Filmhouse. Tickets were &#163;6.50.</html></body>

CL1 2003/4-3 16

slide-17
SLIDE 17

Encoding Binary files

  • Need general mechanism for sending

programs, images etc. as text mail attachments

– 1. Method of encoding binary file – 2. Some means of telling far end what it is

  • Multimedia Internet Mail Extension (MIME)

CL1 2003/4-3 17

slide-18
SLIDE 18

CL1 2003/4-3 18

slide-19
SLIDE 19

Your frog is in the mail …

CL1 2003/4-3 19 From: "John Butler" <jhb@ed.ac.uk> To: <asw@dcs.ed.ac.uk> Subject: frog Date: Mon, 01 Oct 2002 11:45:36 +0100 date, timezone MIME-Version: 1.0 Content-Type: image/gif; file type name=“FROG.GIF" Content-Transfer-Encoding: base64 file encoding Content-Disposition: attachment; filename=“FROG.GIF" R0lGODdhgwBwAPcAAP///97W1s7Gxntzc+/e3pyMjJSEhMalpYxzc7WUlKWEhJxzc3taWiEYGBAI CBgICGsYGGsICL0YEM4YELUQCL0QCJwYELUYEIwQCJwQCLVaUnMQCKWlpZRCObUpGFIQCMaUjL2E e4xSSrVCMaUpGM5rWoQhEM6Ec61jUsYxEGtKQlo5MTEQCLU5GNY5EHtCMa1aQq1SOaU5GNZzUmMx Ib1aOXsxGOeljLVzWoxKMc5KGJRrWueEWkohEMZKGM69tWtaUt6Uc1IxISkYEJxSMc7OzrWEa2NC MYRSOc5rOdZaGLWlnM6Uc85aGK2UhM6ce4xjSrVzSrVaIZyEc4RrWs6EUueUWrVrOcZjIdZrIc6t lJRzWu+te7WEWuela5xrQsZ7OdZ7MZxaIcZrIca9tYR7c0IxIb1rIb21rbWtpVpSSufGpdathHtj Sr2Ua96te86UWhgQCEoxGNaMQt6MOdZ7IWtjWue9jOe1e86cY8aUWoRSGLWUa4xjMc6MObV7MdaM Ma2chOe1c96ta9alY6V7Qr2MSs6EIYRzWq2MWt6lUs6MKd6UKda9lO+9a86cSr2MOeelOZyEWt61 a97OrfferefOnOfGhM6ta2tSIc6cOZxzIbWEIe/n1rWtnJSMe4yEc1JKOda9hO/OhN61WtalOc6c … etc. … encoded file

slide-20
SLIDE 20

Base64 Binary file encoding

  • Take 3 bytes of the file (3 * 8 = 24 bits)
  • Encode as 4 * 6-bit characters (4 * 6 = 24); add ‘0’
  • Repeat.
  • File increases in size by 25% but doesn’t get mangled

en route

  • MIME-type lets receiving mail process know what sort
  • f file it is
  • Alternatives: uuencode (Unix), binhex (Mac)

CL1 2003/4-3 20

slide-21
SLIDE 21

CL1 2003/4-3 21

Key Points

  • Computers manipulate bits (0,1) very quickly
  • Binary numbers are unwieldy, use hex or
  • ctal instead – understand counting in hex etc.
  • Characters encoded as ASCII
  • Need some encoding to send non-text

information over email, e.g. MIME-encoding

  • Recoginse encoding when you see it
