201 VERDE Mussetter Testimony: - Verde River fits in 3b or 3a category. - Braided rivers can be navigable. Fuller Rebuttal Slides p. 1 Q2 @ Clarkdale = 6600 cfs Q10 @ Tangle Ck = 61,000 cfs Fuller Rebuttal Slides p. 2 Where are the

slide-1
SLIDE 1

201

slide-2
SLIDE 2 Fuller Rebuttal Slides
  • p. 1

VERDE

Mussetter Testimony:
  • Verde River fits in 3b or 3a category.
  • Braided rivers can be navigable.
slide-3
SLIDE 3 Fuller Rebuttal Slides
  • p. 2
Q2 @ Clarkdale = 6600 cfs Q10 @ Tangle Ck = 61,000 cfs
slide-4
SLIDE 4 Fuller Rebuttal Slides
  • p. 3

Where are the “banks” for bankfull?

slide-5
SLIDE 5 Fuller Rebuttal Slides
  • p. 4
Boating channel Ordinary high water mark channel
slide-6
SLIDE 6 Fuller Rebuttal Slides
  • p. 5
Max Depth = 2.4 ft. Max Depth = 3.3 ft. Max Depth = 2.6 ft. Average for reach = 3.9 feet (maximum, 296 cfs) Modelled profile underestimates measured flow depths @ XS2 & 5 by ~ 1 ft.
slide-7
SLIDE 7 Fuller Rebuttal Slides
  • p. 6
296 cfs # Average Max Depth XS2 2.05 ft 2.4 ft XS4 1.95 ft 2.6 ft XS5 1.50 ft 3.3 ft Reach Avg. 3.9 ft
slide-8
SLIDE 8 Fuller Rebuttal Slides
  • p. 7
440 cfs MEI MEDIAN FLOW RATE (440 cfs) # Average Max Depth XS2 2.5 ft ? ft XS4 2.3 ft ? ft XS5 1.5 ft ? ft Reach Avg. ? ft
slide-9
SLIDE 9 Fuller Rebuttal Slides
  • p. 8
From MEI p. A.2
slide-10
SLIDE 10 Fuller Rebuttal Slides
  • p. 9
From MEI, p. A.4
slide-11
SLIDE 11 Fuller Rebuttal Slides
  • p. 10
From MEI, p. A.5
slide-12
SLIDE 12 Fuller Rebuttal Slides
  • p. 11
Spillway Crest = 2000’ Top of Spillway Gates = 2026’ “Normal Pool” Elevation Maximum Water Surface Elevation = 2051.9’
slide-13
SLIDE 13 Fuller Rebuttal Slides
  • p. 12
From BUREC – see Strand & Pemberton, 1982, USBR Erosion & Sedimentation Manual
  • The “delta” begins at the maximum water surface elevation (2051.9 ft, above Tangle Ck gage)
  • Clustering of data on Slides 79 & 81 point to flood deposition in reservoir delta.
slide-14
SLIDE 14 Fuller Rebuttal Slides
  • p. 13
Flow rate during 3/21/2015 site visit
slide-15
SLIDE 15 Fuller Rebuttal Slides
  • p. 14
Flow rate during 2/16/2015 site visit
slide-16
SLIDE 16 Fuller Rebuttal Slides
  • p. 15
slide-17
SLIDE 17 Fuller Rebuttal Slides
  • p. 16
