2008 Ryder Scott Reserves Conference Evaluation Challenges in a Changing World “Tools for Evaluation”

A Review of the SOS Software Scott Wilson-Sr. VP., Ryder Scott Company

slide-2
SLIDE 2

1

Tools for Evaluation : A review of the SOS Software

  • Reservoir Surveillance and Prediction.
  • Production Engineering.
  • Integrated databases and custom features.
  • Easiest way to provide technology advances to
  • perations staff.

A Suite of Windows based Petroleum Engineering programs

  • riginally developed by ARCO from 1980-2000
slide-3
SLIDE 3

2

Tools for Evaluation : A review of the SOS Software

Forecast

Multi-Trend Decline Analysis

ProCast

Gas Field Deliverability Forecasting

SNAP

Nodal Analysis and Artificial Lift

PTA

Pressure Transient Analysis

EPEC

Excel Based P.E. Functions

Tank

Graphical Material Balance

Core Programs

slide-4
SLIDE 4

3

Tools for Evaluation : A review of the SOS Software Low Usage Programs

Patternflood BeamPump

Rod Pump Analysis

Wellbore

Wellbore Schematics

BubbleMap

Time Variable Bubble mapping Waterflood Pattern Balancing

slide-5
SLIDE 5

4

Tools for Evaluation : A review of the SOS Software

  • Designed and developed by

ARCO Engineers and Specialist programmers.

  • An 18 year effort by a 5-10 person team.
  • Specifically customized to meet

demonstrated operating district needs.

Growth Period 1980-1998

slide-6
SLIDE 6

5

Tools for Evaluation : A review of the SOS Software

  • Outsourced to Dwights and Geographix.
  • Suite broken into freestanding tools.
  • Formally abandoned when

BP acquired ARCO.

Harvesting Period 1998-2000

slide-7
SLIDE 7

6

Tools for Evaluation : A review of the SOS Software

  • RSC acquired the rights to maintain and

distribute the programs in 2000.

  • Specialized Oilfield Software (SOS)

registered users growing 2-5 users / day.

  • Licenses are provided free to clients.
  • Significant enhancements funded each year

by BP, ConocoPhillips, Petroskills, others.

Maintenance & user funded enhancements Starting in 2000

slide-8
SLIDE 8

7

Tools for Evaluation : A review of the SOS Software

5 10 15 20 25 BP ConocoPhillips Devon Energy Corp. Apache Corp. Dominion E&P, Inc. Chesapeake Energy Corp. Chevron Corp. ConocoPhillips Canada Repsol YPF Saudi Aramco Vico Indonesia New field Exploration Co. Niko Resources Ltd. Petro-Canada Weatherford Aera Energy LLC Edge Petroleum Corp. EnCana Corp. Oil India Ltd. Samson

  • St. Mary Land & Exploration Co.

Sw ift Energy Co. TNK-BP BP Alaska Khalda Petroleum Co. Nance Petroleum Corp. New field Exploration Pertamina Petrom S.A. Petronas Carigali Sdn Bhd Petroproduccion PetroSantander Inc. Prize Petroleum Company Ltd. Questar Exploration & Production Rally Energy Corp. Venoco, Inc. W&T Offshore, Inc. Whiting Petroleum Corp. 1 10 100 1000 USA Canada Indonesia India Argentina Malaysia United Kingdom Australia Russia Colombia Egypt Venezuela Pakistan Trinidad and Tobago Ecuador Saudi Arabia Vietnam China Romania Mexico Kazakhstan Libya Denmark Turkey Spain Japan The Netherlands Nigeria France Thailand Algeria Oman Myanmar Russian Federation Brazil United Arab Emirates Bulgaria Bolivia Registered Users

950 Registered users as of early 2008 Company Distribution Country Distribution

slide-9
SLIDE 9

8

Tools for Evaluation : A review of the SOS Software

Large User Coordinators : Single Point of Contact (SPOC)

ConocoPhillips : Tom Nations, Grant Dornan, David Lagerlef BP : Erin Authier- O’Brien, Scott LaVoie (SLB) Exxon Mobil : Juan Ulibari Cimarex : Eddie Fetkovitch Questar Market Resources : Chuck Stanley (?) Weatherford : Toby Pugh

Approximately 2500 total users

coordinators, training licenses not tracked through registration 5-6 University Licenses Managed By Professors Hundreds of Petroskills Nodal School Students

slide-10
SLIDE 10

9

  • Six different Forecasting Options
  • Arps in 4 mouse clicks
  • P/Z & Decline synchronization
  • WOR-Cum
  • GOR-Cum
  • Drilling Schedule / Type-well planning
  • Import Dwights Data, cut and paste, or

ODBC link directly to Client Databases The first system to model multi-trend Declines

Multi-Trend Decline Analysis

Forecast

  • Used to monitor 500,000 bopd at Prudhoe and Kuparuk
slide-11
SLIDE 11

10

Pipelines Compressors NGL Processing

An integrated Nodal/Network forecasting system

Integrated Gas Field Planning

Platforms Flow Splitters Well performance Pre-defined rates Manifolds

RO AST

P C

LNG Plants Line Loops CO2 removal

  • nine well performance models
  • eight pipeline/tubing hydraulics models
  • CBM Langmuir / Hydrate models
  • User defined design/analysis objects
  • “Spreadsheet” and Network interfaces
  • Reservoir/well/facility rate forecasting
slide-12
SLIDE 12

11

  • Critical lifting rates, mixture velocities, erosional

velocities, and PVT properties reported every 200 feet.

  • Complex wellbores with up-casing/tubing and down-annular for multi-zones
  • The standard gas lift design tool used by ConocoPhillips, BP, and soon Exxon
  • Links with fieldwide optimization models (Procast)
  • Fully editable presentation quality graphics

A state of the art Nodal system

Well Performance and Artificial Lift Analysis

NAP

S

2000 4000 6000 40000 80000 120000 160000 200000 240000 Bottom Hole Pressure (psig) Total Gas Rate (mscf/d) Y acheng 13-1 A1 static match Reservoir Data Pressure = 5557 kh = 18676.0 Skin = -1.00 Yca11999match.snp Density = 12.000 Perf Diam = 0.50 Penetration = 8.00 Rate vs. Pressure 09-Feb-99 08:18:36 Depth (MD) = 12130 WHPres = 3379 Tubing I.D. = 6.184 (s1)
  • Consistently judged easier to learn and use than all other Nodal packages
  • Simulator Hydraulics table builder for Eclipse,

VIP, PSIM, ACRES

  • Custom database connections for loading test data,

archiving datasets, and AI Batch troubleshooting.

  • Restriction and choke pressure drops
N u S n a p D e fa u lt D a ta S e t. sn p - S imu la to r T a b le O u tp u t: F T P - 5 0 0 . 0 0 0 W C U T - 0 . 0 0 0 6549 6006 5463 4921 4378 3836 3293 2750 2208 1665 1122 580
  • Multi-zone completions with crossflow.
  • User defined PVT and IPR
  • Relative permeability effects
  • Perforated & GP Completion effects
  • All meaningful Tubing Hydraulics correlations
  • Deviated, stimulated, and partially penetrated
  • Full featured multi-segment horizontal, multistage fractured wells, and PVT
slide-13
SLIDE 13

12

Gas Well Heat Transfer Spreadsheet

INPUT: variable: value: units: Comp mole % True V Depth

14500

'TVD

C1 90

Flow ID

2.75

inches

C2 10

Roughness

0.00065

inches

C3

SG gas

0.7

(air = 1.00)

C4

%H2S

0.00

%

C5

%CO2

3.50

%

C6

%N2

0.00

%

C7

Qg (+ for prod)

5000

mcfpd

C8

P wh

1200

psi Ambient Surface T

70

Deg F SI BHT

350

Deg F Heat Flux

0.992

btu/(hr-degf-ft) Est WHT =

54.25 F

heat cap

0.52

btu/(lb-degf)

gas jt effect

deg/psi

From Component Analysis Tc 380.7718 Deg R Pc 674.8221 Psia total error 0 btu/hr SG Gas 0.60233 (air = 1.00) Solve Tol. 500 btu/hr

heat cap

0.51474 btu/(lb-degf) Solve Loops 1 loops

Depth Fraction depth Amb temp WB temp WB prs density length delt temp ave temp dif heat loss/hr heat gain/hr diff

80 54 1200.00 5.531 145.0

  • 26
  • 18
  • 2574
  • 2574

0.02 290 60 50 1213.87 5.902 217.5

  • 10
  • 11
  • 11

0.05 725 40 50 1235.11 6.386 362.5 10 20 7260 7260 0.1 1450 30 60 1270.63 6.743 362.5 30 34 12132 12132 0.15 2175 40 77 1305.53 6.531 362.5 37 36 13038 13038 0.2 2900 60 95 1339.51 6.141 725.0 35 34 24214 24214 0.3 4350 100 132 1405.09 5.601 1450.0 32 30 43701 43701 0.5 7250 175 204 1529.61 4.991 1450.0 29 26 37497 37497 0.7 10150 250 273 1648.46 4.632 1087.5 23 23 25277 25277 0.85 12325 300 324 1735.15 4.457 1087.5 24 12 12739 12739 1 14500 350 350 1821.18 4.444

  • 16000
  • 14000
  • 12000
  • 10000
  • 8000
  • 6000
  • 4000
  • 2000

100 200 300 400

Features

Widely used Petroleum Engineering Utilities In Single-Cell functions

Excel Petroleum Engineering Calculator

EPEC

Gas Formation Volume Factor & Standing z Value Bg (RB/Mscf) z (vol/vol) 2 4 6 8 2 4 6 Pressure (1000's of psia) Bg 0.8 0.9 1.0 z Viscosity Mu Gas Mu Oil Mu Water 0.01 0.1 1 10 2 4 6 Pressure (1000's of psia) Viscosity (cp) Compressibility C gas C oil (us) C water C oil (apparent) 1 E-6 1 E-5 1 E-4 1 E-3 1 E-2 2 4 6 Pressure (1000's of psia) c (psi-1) Formation Volume Factor & Solution GOR Bo (RB/STB) Bw (RB/STB) Rs (Mscf/STB ) 0.9 1.0 1.1 1.2 1.3 1 2 3 4 5 Pressure (1000's of psia) Bo

  • r

Bw 0.0 0.2 0.4 0.6 Rs

PVT properties (HP41 Fluids Pak)

  • Z factor (CO2, H2S, N2)
  • Viscosity

Utility Functions

  • Table interpolation.
  • Pressure Drops (static, 2, 3 phase).
  • Text Parsing.

Incorporate complex math into Excel. Functions are used in your spreadsheets.

slide-14
SLIDE 14

13

State-of-the-art Well Test Design and Analysis

Pressure Transient Analysis

PTA

0.1 1.0 10.0 100.0 1000.0 0.10 1.00 10.00 100.00 tD/CD PD and Derivative 3-29-14-20 Pressure Build-up test Calculated Pressure Calculated Derivativ e Measured Pressure Measured Derivative H
  • mogeneous (Storage and Skin)
Permeability Skin East, No Flow West, No Flow N
  • rth, No Flow
South, Const. Press. Radius of Investigation [md] [0] [f t] [f t] [f t] [f t] [f t] 10/23/06 = = = = = = = 17
  • 0.2
2114 2114 274.1 747 1377 11:37:03 (Fixed) (Fixed) 1.669e+004 1.669e+004 17.08 39.64 Calculated Pressure Calculated Derivativ e Measured Pressure Measured Derivative H
  • mogeneous (Storage and Skin)
Permeability Skin East, No Flow West, No Flow N
  • rth, No Flow
South, Const. Press. Radius of Investigation [md] [0] [f t] [f t] [f t] [f t] [f t] 10/23/06 = = = = = = = 17
  • 0.2
2114 2114 274.1 747 1377 11:37:03 (Fixed) (Fixed) 1.669e+004 1.669e+004 17.08 39.64
  • Oil, Gas, or Water wells
  • Design and analysis options
  • drawdown, build-up,
  • injectivity, and fall-off testing.
  • Deliverability Analysis
  • Diagnostic Plots
  • Straight Line analysis
  • Manual Type Curve Matching
  • Automatic type curve matching
  • Text and graphical reports :

Simple cut and paste capability

slide-15
SLIDE 15

14

State-of-the-art Well Test Design and Analysis

Pressure Transient Analysis

PTA

50 100 150 1000 2000 3000 1200 1700 2200 2700

Delta Time(hrs) P re s s u re ( p s i) R a te (M s c f/D ) Gauge Selection/M anipulation

G auge B G auge A G auge C G as F low R ate G auge B G auge A G auge C G as F low R ate
  • Simulation of full test sequence

for test design and what-ifs

Multiple Gauges with effectively infinite point count

Well1 BU with Pulse Well2 BU with interference

slide-16
SLIDE 16

15

An integrated set of analytical tools Oil, Gas, Aquifers All common methods + Sills Unique “Outline Style” user interface

A comprehensive Material Balance Program

Material Balance Analysis and Forecasting

TANK

Tank is a powerful analytical tool for reviewing and predicting the performance of combination drive oil and gas reservoirs. Tank couples a general form of the material balance equation with a choice of analytical aquifer models, allowing it to handle a wide range of hydrocarbon fluid types and reservoir drive mechanisms. Given a reservoir’s performance history, Tank can be used to estimate original hydrocarbons in place and aquifer size and strength. Once these parameters have been quantified, Tank may be used to review and predict reservoir and aquifer performance using a variety of analytical techniques.

slide-17
SLIDE 17

16

Programs available for customization and implementation

Beampump, Bubblemap, Patternflood, and Wellbore

Patternflood:

A map based plotting and material balance package that balances voidage, influx, injection, and flux through a field’s waterflood patterns. Although data input is significant, resulting pattern balancing results can be used to more efficiently manage waterflood injection and withdrawal. The functionality in this program is superseded by both DSS and OFM.

slide-18
SLIDE 18

17

Tools for Evaluation : A review of the SOS Software Maintain and improve viable programs.

Petroskills funded SI units upgrade to SNAP Rebuild help files to be Windows Vista combatable. Add steam lift for SAGD producers. Confirm multi-stage fracture transient treatment in complex wellbores. Formalize relationships with Weatherford (jet pumps) and Exxon (Gas Lift).

Near-term Plans

slide-19
SLIDE 19

18

Tools for Evaluation : A review of the SOS Software

Formalize business systems for managing non-client (= paying) users. Continue to build user base to increase ability to maintain and organically grow program functionality.

Long-term Plans

slide-20
SLIDE 20

19

Tools for Evaluation : A review of the SOS Software

  • www.ryderscott.com
  • SOS Software menu item

1) Request passwords 2) Download software

Mike Wysatta Pam Leslie Scott Wilson

Questions?
