E.Coli pen Draw with your own color. Todays topics 1. Why E.coli Pen 2. Experiments 3. How to use Q. What do you think of the artificial genetic mutation? Results of iGEM JAPAN Survey 2% 32% Bad 66% Good No respons No response
SLIDE 2
SLIDE 3
- Q. What do you think of the
artificial genetic mutation?
SLIDE 4
66%
32% 2%
Bad Good No respons
n=1284
Negative feeling for Biotechnology and Genetic Engineering
Results of iGEM JAPAN Survey
No response
SLIDE 5
A r t Science
Enjoy and understand the biotechnology
Bio Art
SLIDE 6
A r t Science
Science and Art meet in Kyoto Art Science
SLIDE 7
Previous Bio Art
Only in laboratories Need equipments
SLIDE 8
New Bio Art Tool E.Coli Pen
SLIDE 9
New Bio Art Tool E.Coli Pen
SLIDE 10
Theory of three primary colors
Promoter 1 RFP Promoter 2 GFP Promoter 3 CFP CFP GFP RFP
To make various inks
SLIDE 11
- 1. Why “E.coli Pen ”
- 2. Experiments
- 3. How to use
Today’s topics
SLIDE 12
500 1000 1500 2000 2500 3000
pSB6A1 (Low Copy Vector) pSB1A2 (High Copy Vector) Fluorescent density
[%]
select
The best vector for GFP expression
SLIDE 13
The best promoters for E.coli Pen
Controlled by easily available substances
Different sensitivity to substances
Not used in previous iGEM
SLIDE 14
Oxidative stress
Cell death
Cancer
Promoters responding to H2O2
Diabetes Hypertension Arteriosclerosis Wrinkle Aging etc...
SLIDE 15
Survival ratio of E.coli under H202 stress
We used concentration of H202 , from 1 nM to 1 mM
50 100 150 200 250 0.000001 0.0001 0.01 1 100
H202 concentration Number of colonies/plate
[mM]
1 nM 1 mM
SLIDE 16
Seven promoters responsive to H2O2
Inactive form Active form H2O2
SLIDE 17
sodA ahpC sufA acrAB
- xyR
dps yaiA Promoters Binding
Seven promoters responsive to H2O2
Transcription… Active form
SLIDE 18
ahpC sufA We have selected ahpC and sufA promoters.
Seven promoters responsive to H2O2
SLIDE 19
OxyR activates the transcription of ahp operon
SLIDE 20
5 10 15 20 25 30 10 20 30 40 50 60 70 80 less 1nM 10nM 100nM 1µM 10µM 100µM 1mM
(min.)
H2O2
ahpC promoter activity
Green Fluorescence/O.D.(488 nm)
1 mM 10 µM No treatment
SLIDE 21
- xyR
H2O2
suf A suf B suf C suf S suf E
Reduced form Oxidized form Dimer OxyR binds to the OBR activates the transcription of the suf operon
OxyR activates the transcription of suf operon
OBR OBR
SLIDE 22
0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 10 20 30 40 50 60 70 80 90 less 1nM 10nM 100nM 1µM 10µM 100µM 1mM
H2O2
Depends on Concentration
1 mM 100 µM 10 µM
No treatment
sufA promoter activity
Green Fluorescence/O.D.(488 nm)
SLIDE 23
Making inks
RFP : GFP = 2 : 1 RFP : GFP = 1 : 2 GFP Control (PBS) RFP
Promoter Promoter
SLIDE 24
GFP
sufA
GFP
ahpC
GFP
acrAB
GFP
dps
GFP
- xyR
GFP
sodA
GFP
yaiA
CFP CFP CFP CFP
We designed many parts
YFP RFP CFP YFP RFP YFP RFP YFP RFP CFP CFP YFP RFP YFP RFP YFP RFP
SLIDE 25
- 1. Why “E.coli Pen ”
- 2. Experiments
- 3. How to use
Today’s topics
SLIDE 26
How to use
the ‘‘E.coli pen’’
SLIDE 27
1
Make your own color.
SLIDE 28
Select the tubes ‘‘ E.coli ’’ or ‘‘ H2O2 ’’.
SLIDE 29
Knock the pen and make color.
SLIDE 30
Under the black light
Make color as you like.
SLIDE 31
Anti-contamination system
to keep the color
SLIDE 32
SLIDE 33
2
Draw with your own color!
SLIDE 34
Finished! Un
SLIDE 35
3
Irradiated with the black light.
SLIDE 36
Irradiate your works.
SLIDE 37
SLIDE 38
SLIDE 39
fin.
SLIDE 40
Very important item to enjoy Bio Art
?
SLIDE 41
Pinch?
SLIDE 42
How to use
This
SLIDE 43
- hint. E.coli smells not good...
SLIDE 44
Like this!
SLIDE 45
Thank you for your attention !
