136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 1 of 14
Location Map
Atlantic Terminal Atlantic Center Barclays Center A t l a n t i c A v e 4th Avenue L a f a y e t t e A v e n u e H a n s
- n
P l a c e St Felix Street Fort Greene Place F u l t
- n
A v e n u e Flatbush Avenue
136 Fort Greene Place
Brooklyn Academy of Music Historic District
SLIDE 4
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 2 of 14
Front Facade
1940’s tax photo 2019 photo
SLIDE 5
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 3 of 14
Existing Front Elevation
3/16” = 1’-0”
Proposed Front Elevation
3/16” = 1’-0”
Existing single pane, double hung wood windows to be replaced
- typical for 2nd and 3rd floors.
New Marvin ‘Ultimate wood double hung windows’ - wood exterior painted black.
- typical for 2nd and 3rd floors.
Existing wood brick-molding to be replaced - typical for 2nd and 3rd floors. Existing wood brick-molding and sills to be replaced. Existing single pane wood windows to replaced Existing single pane, double hung replacement windows to be replaced. 3’-5” 5’-1” Aluminum window surround to be removed. Existing wood brick molding under the aluminum cover to be replaced. Basement Parlor Floor 2nd Floor 3rd Floor New Marvin ‘Ultimate wood double hung windows’ - center mullion to match existing width - wood exterior painted black. New Marvin ‘Ultimate wood double hung windows’ - wood exterior painted black. muntin to align with interior shutters New hard wood brick molding at Parlor Floor windows. Check Rail positioned to align with
- riginal interiorwood shutters - as per
2005 LPC approval. See page 10. 4’-3” 4’-3”
EQ. EQ. 3/5 2/5.
SLIDE 6
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 4 of 14
Existing Rear Elevation
3/16” = 1’-0”
Proposed Rear Elevation
3/16” = 1’-0”
Existing aluminum, double hung windows to be replaced
- typical for 2nd and 3rd Floors.
Existing aluminum, double hung windows to be replaced. Existing oak brick moldings to remain Aluminum window surround to be removed - typical 2nd and 3rd Floors All wood brick-moldings (currently covered with aluminum) to be replaced - typical for 2nd and 3rd Floors. Existing rotted wood brick-moldings to be replaced New Marvin ‘Ultimate wood double hung windows’ - wood exterior painted black.
- typical for 2nd and 3rd floors.
New Marvin ‘Ultimate wood double hung windows’ - wood exterior stained and varnished to match existing wood molding. Horizontal muntin raised to match front windows New hardwood brick-molding painted black - typ. 2nd & 3rd Floors. Basement Parlor Floor Top of Deck 2nd Floor Top of Parapet 3rd Floor No change to basement level wood windows.
Roof at extension Roof at extension
SLIDE 7
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 5 of 14
Existing Parlor Floor Windows at the Rear Wall Extention
Existing rear windows are double hung aluminum windows in bad condition. The existing exterior wood moldings and frame are to remain. Existing rear windows are double hung aluminum windows in a bad state of repair. Aluminum Panning over the wood brick molding will be removed. The existing wood moldings are assumed to be in poor condition and will need to be replaced. The exposed wood moldings and frame for the two left-hand windows on the 2nd Floor are exposed and in very bad condition.
Existing 2nd & 3rd Floor Windows at the Rear Wall
SLIDE 8
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 6 of 14
View from Hanson Place Rear windows at upper fmoors are visible
136 Fort Greene Place Upper fmoors of rear facade are visible from Hanson Place
SLIDE 9
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 7 of 14
1-3/32" 1-7/32" 1-3/4" 2-7/32" 2" 4-9/16" 2-11/32" 2-1/4" 2" 1-1/8" 3-9/16" 4-25/32" 1-1/4" 4-1/4"
Window Head and Sill details Existing Head and Sill Detail - Basement, 2nd and 3rd Floors at Front Facade (all other windows are newer replacements) Proposed Head and Sill Detail - All windows
SLIDE 10
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 8 of 14
2-1/2" 2" 2" 2-1/2" 7/8" 7/8" 2-1/4" 2" 2" 2-1/4"
Window Jamb Detail Existing Jamb Detail - Basement, 2nd and 3rd Floors on the Front Facade (all other windows are newer replacements) Proposed Jamb Detail - All windows
Center mullions on front windows only.
SLIDE 11
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 9 of 14
Page 7
2/5 3/5
Windows on the parlor fmoor will be one over one windows pro-
120 Fort Greene Place, circa 2005 From 2005 Landmarks application for windows replacement 136 Fort Greene Place - diagram showing proposed proportions
2/5 3’-5” 5’-1” 3/5 5 Panel Shutters
Raised Check Rail precedent
SLIDE 12
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 10 of 14
2005 LPC approved drawings for front parlor windows with check rail positioned to align with interior shutters.
SLIDE 13
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 11 of 14
Basement Window Details Oringinal brick molding as they appear at the basement, second and third fmoor windows on the front facade. Center Mullion is 2” wood, plus the glazing putty
2” 1/4”
SLIDE 14
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 12 of 14
25.5” 25.5” EQ. EQ. 27” 26.5”
Basement Window Proportions Shutters designed to align with check-rail
SLIDE 15
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 13 of 14
Parlor Window Shutters - estimated original to the house
38.5” 40.5” 22.5”
Rectangular nail heads Wood dowel fasteners at corners Rectangular nails head (face) Exposed rectangular nail (rear)
SLIDE 16
136 Fort Greene Place, Brooklyn, NY
Window Replacement
February 11, 2020
Drawings prepared by Urban Matrix Architecture and Planning, PC 136 Fort Greene Place, Brooklyn, NY 11217 T: (646) 468 0467
page 14 of 14
Neighboring windows circa 1939 - 41
But many houses still had 5-Panel shutters in 1940 tax photos Almost all houses had one-over-one windows by 1940
120 Fort Greene Place 130 Fort Greene Place 132 Fort Greene Place 134 Fort Greene Place
