1 Who we are, and what we do? Driconeq is the world leading producer - - PowerPoint PPT Presentation
1 Who we are, and what we do? Driconeq is the world leading producer - - PowerPoint PPT Presentation
1 Who we are, and what we do? Driconeq is the world leading producer of drill pipes to the mining, quarrying, ground engineering and water well industries. The company also offers related equipment such as drill collars, drill bits, wrenches,
SLIDE 2
SLIDE 3
2 History
Driconeq was founded in 1995 following a relocation of Atlas Copco’s factory in Sunne. In 2001 the Driconeq brand started to gain recognition in the market place and a new growth phase began. During 2004 Driconeq expanded its operations by Investing 30 % in the heat treatment company Hảrdtekno. Acquiring a stake of 51 % in Advantage Inc and thereby strengthen its position on the US market. The remaining stake of Hảrdtekno was acquired during first half of 2007, securing heat treatment capacity for the projected growth. In 2011, Driconeq acquired Anceriz Industries (Pty) Ltd, a prominent South African developer and manufacturer of reverse circulation mining drilling products.
SLIDE 4
3 Business modell
Driconeq is to be the leading supplier of equipment in sink and rotation drilling. The organization is to be flexible and focused on customer needs and requests.
Quality policy
Our key words: Always deliver according to customers wishes Be efficient during production Deliver on time this is made in an healthy working environment which brings satisfaction to everyone, by constantly improvements in the business and by preventing lack of quality and by obeying current laws and standards associated with the business
SLIDE 5
4 Driconeq around the globe
Driconeq is a world wide company with units on three
- continents. The head quarters and production units are
positioned in Sunne and Kristinehamn, Sweden. In 2011, Driconeq acquired Anceriz Industries (Pty) Ltd which is based in Johannesburg, South Africa. Sale units are established in both Brazil and the United States.
Retailers are represented in a total
- f 70 countries around
the globe
70
SLIDE 6
5 Customer segments
Exploration In order to retrieve new findings of for example gold, exploration drilling is used. This technique involves pre-drilling and analyzing of the cuttings in several parts of a large area. Driconeq delivers Reverse circulation (dual wall) pipes, witch is a quick and effective method compared to core drilling in the search for minerals. Raise-boring is used through out the mining industry for example ventilation shafts or dumping shafts between different levels. This technique involves drilling a pilot hole between levels in a vertical or downwards angel. There after is the pilot bit exchanged for a reamer variegating in size up to six meters in
- diameter. Machines uses large
hydraulic cylinders to pull the reamer upwards as it rotates. Geothermal is a method for gaining energy out of the ground (earth) with the assistance of an heat pump. Most common is the use of DTH (down the hole hammer), but even traditional rotation drilling is used with this technique.
Bildförslag?
SLIDE 7
Customer segments continues
Water-well is the method for making water-wells. The depth variegating depending on world location but DTH
- r rotation-drilling is used for this
vertical type of drilling. Construction A hole is made to support the ground underneath for example a building, bridge or road construction by sending down concrete or steel pillars. Another type of drilling is used in construction, when installing pipes or cables, in areas were digging is impossible – HDD (Horizontal directional drilling). This drilling method allows you to avoid obstacles by steering the pipes around it. Mining is divided into Above and Under Earth drilling. Above earth uses both DTH and rotation drilling. Under Earth drilling uses Top hammer drilling or DTH to make the holes for the explosives. Oil and gas Retrieving oil and gas requires high quality tools and skilled
- perators. These drillings are often
made very deep and is made with rotation drilling witch uses tricone bit, drag bits, PCD-bit or a mud engine. For some applications directional drilling is made to reach the findings.
SLIDE 8
6 Where are we heading?
Vision
Driconeq - the global drill pipe manufacturer and supplier renowned for quality, competence, service/support, flexibility and commitment. Furthermore our vision contains a twofold increase in market shares until 2012 along with keeping our good reputation and satisfied customers.
Profile
Following keywords defines how Driconeq wants to be recognized by our customers: Highly focused on customer, high flexibility and problem solving abilities. High quality at the right cost High surety in supplies and short lead times High application and product knowledge
SLIDE 9
7 Quality
We are able to keep high and even quality thanks to long experience and by listening to our customers and employees. We constantly work with our Quality manual, based on ISO 9001 to keep high quality. It's in our greatest concern to always increase quality standards throughout the business. We also work on improving sales with all of our distributors.
SLIDE 10
8 Customer relationship
Our way of working with customers is based on: A close and healthy relation Problem solving, assistance and long experience Know how in several drilling methods Network based expertise Always take responsibility if problems occurs Make sure that production meets up with customer demands.
SLIDE 11
9 Employees
Driconeq is very proud over employees and co-workers. We see
- ur production unit as highly experienced. We recognize our
highly skilled personnel in CNC-programming along with unique competence in friction welding. Our production unit consists of 105 employees divided in three cities, 65 in Sunne, 10 in Kristinehamn and 30 in Johannesburg. The unit is divided into following areas: Logistics Sales organization Technique division Our worldwide sales unit consists of 1 employee in Brazil and 2 in the United States.
SLIDE 12
10 Machine park
Our production takes place in one of Europe's most top modern production facilities in Sunne and in a top modern annealing workshop in Kristinehamn. It's all In-house with full production control. The machine park consists of 2 friction welds 1 submerged arc welding machine 8 robot arm CNC-machines 7 CNC-lathes 3 CNC-milling cutters along with an automatic painting facility and annealing processor.
SLIDE 13
SLIDE 14
Drill pipes
Outside diameter (O.D)
Which tubes dimensions are important:
SLIDE 15
Drill pipes
Outside diameter (O.D) Wall thickness (Wall)
Which tubes dimensions are important:
SLIDE 16
Drill pipes
Outside diameter (O.D) Wall thickness (Wall) Length (L)
Which tubes dimensions are important:
SLIDE 17
Drill pipes
Outside diameter (O.D) Wall thickness (Wall) Length (L) Thread
Which tubes dimensions are important:
SLIDE 18
Drill pipes
Outside diameter (O.D) Wall thickness (Wall) Length (L) Thread Wrench flats/Clamp system
Which tubes dimensions are important:
SLIDE 19
Drill pipes
Hydraulic clamp system? When using hydraulic clamp jaws you may not use pipes with wrench flats. If this is done the jaws will squeeze on the tube instead of the extended tool joint. Drill pipes for rigs with hydraulic jaw system always has extended tool joint.
SLIDE 20
Drill pipes
The two main manufacturing processes Cold drawn: Uniform pipe wall thickness (± 4%). Low risk of ovality. Better friction welding with less risk of concentricities. Hot rolled: Uneven pipe wall thickness (± 10%). Softer material.
SLIDE 21
Drillpipes
Technical specification
Cold drawn, seamless tube (N-80) Yield strength, min. 552 N/mm2 [80060 psi] Tensile strength, min. 689 N/mm2 [100000 psi] Elongation min. 15 % Hot rolled (E355) Yield strength, min. 355 N/mm2 [51500 psi] Tensile strength, min. 490-630 N/mm2 [71000-91400 psi] Elongation min. 22 % Tool joints Surface hardness 58-62 HRC Case depth 0,1-0,2 mm Core hardness 32-36 HRC The hardness of thread gives a longer life time (at least 50% longer). All threads on tool joints are tested with an gauge that have A.P.I. certificate. All Driconeq products have a ID number that gives traceability back to steel, manufacturing and heat treatment.
SLIDE 22
Härdtekno
General information
Hảrdtekno was founded in 2004 as a venture between Driconeq and management. Specialized in heat treatment of metals up to dimensions of 1.0x1.7x2.2 meters or weights up to 3 metric tons Hảrdtekno carries out all heat treatment for Driconeq, employs 8 persons, and is located in Kristinehamn Highly automated production of latest technology One of the most modern heat treatment production plants in Europe 24h production with day time supervision Prominent know-how A production facility comprising 1680 sqm
Factory
SLIDE 23
Drill pipes
Manufacturing
Manufacturing of tool joints in a fully automatic robot cell.
SLIDE 24
Drill pipes
Manufacturing
Grinding weld zone
SLIDE 25
Subs and adapters
Rotation unit connection There are at least as many rotation unit connections as there are drill rig designs. Cross over adapter Most of the times, a cross over adapter is needed to connect the drill pipe to the rotation unit. Saver sub Is used to spare the life of the rotation unit connection as this end is opened and closed everytime you add or remove a drill pipe.
SLIDE 26
Product offering
Manufacturing
Connectors (threads) are integrated to a seamless pipe building a drill pipe Wide range of dimensions
Seamless pipe Connector Friction welding + with makes Fishing tools Inline-check-valves Wrenches Adapters Packers
Important for a complete product offering Essential for customers in drilling technology Constitute a fairly stable share of total sales
SLIDE 27
Different types and their use
RD 50-6 The classical cylindrical thread for 70 mm tubes. ACT/NWY Conical thread with API IF profile for 70 mm tubes. RD 70-4 Cylindrical thread for max torque. 2 3/8” Reg Conical thread for all round drilling. 2 3/8” IF Conical thread for max internal passage. 2 7/8” Reg Conical thread for normal and heavy duty rotary drilling. 2 7/8” IF Conical thread for max internal passage. 3 1/2” Reg Conical thread for all round drilling both percussion and rotary drilling with max torque. 3 1/2” IF Conical thread for max internal passage. 3 1/2” FH Conical thread for max internal passage. 4 1/2” Reg Conical thread for all round drilling both percussion and rotary drilling with max torque. Beco 3 1/2” Conical thread for rotary drilling. Beco 4 1/2” Conical thread for rotary drilling. Beco 5 1/4” Conical thread for rotary drilling.
SLIDE 28
Table diameter/thread
Drilltube diameter Recommended thread 70 mm Rd 50-6 ACT 76 (Rd 50-6) 2 3/8” Reg 89 RD 70-4 2 3/8” Reg 2 3/8” IF Buttress #21 2 1/2 Z (2 7/8” Reg) 102 (2 3/8” Reg) 2 7/8” Reg 2 7/8” IF 114 2 7/8” IF 3 1/2” Reg NC 35 3 1/2” IF Buttress #28 Drilltube diameter Recommended thread 127 mm 3 1/2” Reg 3 1/2” IF Beco 3 1/2” 140 4 1/2” Reg Beco 4 1/2” 159 Beco 4 1/2” 178 Beco 4 1/2” Beco 5 1/4” 194 Beco 5 1/4” 219 Beco 6” 273 Beco 6”
SLIDE 29
Fishing tools
In case of in hole pipe failures use: Conical female to grip outside the drill pipe Conical male to grip inside drill pipe
Wrenches
Wrenches for different applications as remove drillbit disconnect subs and pipes.
SLIDE 30
Lifting sling
Lifting slings for Pipes, Collars and Stabilizers
SLIDE 31
Reverse circulation
RC drill pipes OD 305 mm ID of inner tube 127 mm Length 6 meter. For drilling 130 meters deep holes Drilling diameter 660 mm For a geothermal power plant on Island.
SLIDE 32
Reverse circulation
RC drill pipes Inner tube fitted with proper guiding. Easy to replace inner tube Just to remove a circlip. Dimensions from 83mm outer pipe diameter up 305 mm, and length from 1 meter to 7.6 meter. All needed parts for RC drilling Interchangebles subs, dig out subs Lifting tools etc.
SLIDE 33
Reverse circulation
Cyklon with dry splitter
Total control over friction welding
Random sampeling of friction weld area
SLIDE 34
HDD pipes and subs
SLIDE 35
Drill String Selection
Information required that will help us select your drill string.
(NOTE! No core drilling equipment can be provided) GENERAL INFORMATION 1. Wich Model rig will be used for the drilling, and what is pullback of the rig if known? 2. What diameter holes Min and Max? 3. What depth holes- maximum? 4. What drilling Metod- Mud, Air? 5. Will the drilling be RC dual tube or Flood Reverse 6. Will the drilling be Rotary Mud/Air with tricone? 7. Will the drilling be DTH?
SLIDE 36
Drill String Selection
Drill pipes (conventional).
(NOTE! Do you run pin up or down?) GENERAL INFORMATION
1.
What length of Pipes are required, please specify metric or feet, NOTE maximum friction welded lenght we can manufacture is 10,668 meters [35 ft].
2.
Specify thread if possible, if not known we will use the recommended thread to suit the pipe diameter.
3.
Break out style IR/Schramm, Driltech etc?
4.
Flush Jointed pipes, are key flats required on all tool joints box and pin?
5.
Drill Pipes-EU-External Upsets. We do manufacture Drill Pipes External Upsets for CBM and Directonal Drilling, maximum Tool Joint Diameter 5 ½” (140mm) and length Range II (29-32ft), please specify your requirements or discuss with a Driconeq Salesperson.
SLIDE 37
