1) SAIN INATH ATH ENGG G WO WORKS PUNE 2) SACHIN IN FO FORGE E

To be a M e a Manu nufactu cture re of ni niche he pr precisi ision

• n forging

ging and nd forge ge based d compo ponents nents Using ng Hot and nd Warm Techn hnology logy and nd to be a c compl plete ete solutio lution n pr provid vider er of cho hoice ce to the he globa

• bal

l cus usto tomers ers

 Incoporated - 2002 / 03  Plant Location - Sanaswadi Pune  Nature of Company - Pvt. Ltd. Company  Regd. Office - Gat No 943, SANASWADI,

TAL – SHIRUR, DIST – PUNE MAHARASHTRA, INDIA PIN – 412 207

 Chairman - Mr. K.P.Changulpai  Managing Director - Mr. Sachin.K.Changulpai

 Product Range –

Forging, Machining & Subassembly

 Weight Range –

50 Grams – 4.5 Kgs Per Piece.

 Material Grades –

Aluminum ( 2000 Series, 6000 Series and 7000 Series)

 Manufacturing Technology –

Precision Hot Forging, Warm Forging, Precision Machining

 Total Plant Area - 80000 Sq Feet  Employee Strength - 75 Nos  Production Capacity - 400 Tons Per Month  Manufacturing Divisions –

Press Forging, Hammer Forging, Ring Rolling, Machine Shop

 Quality Certification -

ISO 9001-2015 ( TUV )

Chairman M.D (Marketing) G.M (Engineering) Production Head Quality Head Tool Room Head Maintenance Head 2 Production Shift In charge / 2 Quality Inspector / 1 Supervisor / 2 Maintenance tech.

 Sachin forge is equipped Computer-aided Die Design.  Software – Power Shape (CAD), Del cam (CAM) , Future

Turn (TURNING)

 Deform Forging Simulation Software to achieve the

components ok in first trial.

SR. NO MACHINES Make 1 SHILPI V.M.C (1 Nos)

Table Size - 900*450*450

ACE (INDIAN) 2 V.M.C JAPAN 2 E.D.M (1 Nos) INDIAN 3 HEAVY LATHE (3 Nos) INDIAN 4 MILLING (2 Nos) ITALY

UNITS Press / Hammer Make Weight Range (Kgs) Aluminium Average Weight Aluminium Production per Month Min Order Per Month

750 Ton Verson Shell forging Mechanical Press Long Stroke 750 mm 2 to 4.5 4 Kgs 60,000 3,500 1300 Tons Ajax Mech Press 0.2 to 1.8 1.5 1.50.000 5.000 1.5 Ton Basant (Drop Hammer) 0.3 to 3 1.75 1.50.000 5.000

UNITS Press / Hammer Make Weight Range (Kgs) Aluminium Average Weight Aluminium Production per Month Min Order Per Month

1000 Ton Hydraulic Russian 0.1 to 1.5 0.45 50,000 5,000 600 Ton Hydraulic Press Russian 0.1 to 1 0.4 50,000 5,000 400 Ton Hydraulic Press Russian 0.1 to 0.75 0.3 50,000 5,000

Cold Forging presses for Case Canisters

PROCESS Make Type Average Weight Production per Shift

Normalizing (LOW AND HIGH CARBON STEEL) Continuous Type INDIAN 400 Kgs Per Hour Pusher Type Any 4 Tons Solution Hardening T6 (Aluminium Alloys) INDIAN 500 KGS BATCH SIZE ANY 2 TONS APPROX 2 Aging Furnaces INDIAN 500 KGS BATCH SIZE ANY 1000 KGS

Sr No Machines Nos Make

1

Mori Seiki C.N.C SL-2

Chuck Mount 315mm

1 Japan

2

Mori Seiki C.N.C SL-3

Chuck Mount 400mm

1 Japan

3

Jyoti C.N.C

Chuck Mount 180 mm Between Center 450 mm

1 Indian

4

Jobber Ace

Chuck Mount 200mm Between Center 450mm

1 Indian

5

Okuma V.M.C

1 Japan

6

Shilpi Die and Mould Ace

1 Indian

7

Jing Fa Turning Machine

1 Japan

Sr No Machines Nos Make

1

L.M.W Turning Machine (C.N.C)

Year Of Manufacturing 2010 Chuck Mount 315mm

2 Indian

2

L.M.W Turning Machine (C.N.C)

Year Of Manufacturing 2010 Chuck Mount 200 mm

1 Indian

3

Haas Turning Machines

Year Of Manufacturing 2010 Chuck Mount 200 mm

1 American

4

V.M.C Machines

Year Of Manufacturing 2010

3 indian

5

Jobber Ace

Chuck Mount 200mm

2 Indian

6

Takisawa

2 JAPAN

Our continued efforts in increasing quality standards and delivering high quality products has earned us an esteemed clientele which include : -

 Ordnance & Ammunition Factories in India  Cimco Pipes ( 61mm/81mm/120mm )

(RHEINMETALL DENEL MUNITION)

61mm Upper and lower shell with Tail Unit 81mm Upper and lower Shell With Tail Unit (HE) 81 MM ILLU Shell with Tail Unit 51 mm ILLU with Lower Set 81 mm Mark III Lower Body 120mm Upper and Lower (7075) Tail Unit Al 2024 (2 piece) ( PLEASE SEE PHOTOS )
