1 EXISTING SITE N.T.S. STAR VALLEY RANCH ASSOCIATION BARN / SILO - - PDF document

PROPOSED SITE PLAN

N.T.S.

EXISTING SITE

N.T.S.

1

SITE PLAN

EXISTING MAINTENANCE SHOP LOWER LEVEL ACCESS PARKING (6) LOWER LEVEL ACCESS SERVICE COURT S L O P E D O W N EGRESS PARKING (5) H.C. H.C. FIRST FLOOR ENTRY TO #1 TEE BOX PAVED FORECOURT (PATIO) TO DRIVING RANGE C A R T P A R K I N G 8’ CART PATH LOWER LEVEL ACCESS TO OVERFLOW PARKING AT U.S.F.S. LOT DROP-OFF AND PICK-UP PARKING (7) PARKING (9) P A R K I N G ( E X I S T I N G ) ( 1 4 ) C E D A R C R E E K D R I V E #1 TEE

THE PROPOSED NEW STAR VALLEY RANCH ASSOCIATION BARN / SILO REDEVELOPMENT WILL REPLACE THE EXISTING BARN AND SILO STRUCTURES IN THEIR CURRENT LOCATIONS. AT THE LOWER LEVEL, THE NEW BARN / SILO REDEVELOPMENT WILL INCLUDE CART STORAGE, GENERAL PURPOSE STORAGE, MECHANICAL EQUIPMENT, SERVICE TOILET, AND STAIR AND ELEVATOR ACCESS, TOTALING 5,536 SQUARE FEET. THERE ARE ACCOMMODATIONS FOR FUTURE EXPANSION. AT THE FIRST FLOOR LEVEL, THE NEW BARN / SILO REDEVELOPMENT WILL INCLUDE A PRO SHOP, LARGE MULTI-PURPOSE SPACE, OFFICES, MEETING SPACES, RESTROOMS, KITCHEN AND BAR AREAS, STORAGE AND MECHANICAL SPACES, AND STAIR AND ELEVATOR ACCESS, TOTALING 6,261 SQUARE

• FEET. WRAP-AROUND COVERED PORCHES WILL PROVIDE FOR

PROTECTED ENTRY ACCESS, COVERED OUTDOOR DINING AND VIEWS TO THE GOLF COURSE, TOTALING 1,770 SQUARE FEET. THE NEW BARN / SILO REDEVELOPMENT WILL PROVIDE FOR IMPROVED VEHICULAR AND PEDESTRIAN CIRCULATION AROUND THE SITE, A SERVICE COURT FOR DELIVERIES, A FORMAL DROP- OFF AND PICK-UP NEAR THE FRONT ENTRY, AND WILL INCLUDE A TOTAL OF 41 PARKING SPACES ON SITE. OVERFLOW PARKING WILL STILL BE AVAILABLE ON THE ADJACENT US FOREST SERVICE

• LOT. THE NEW BARN / SILO REDEVELOPMENT WILL PROVIDE

FOR IMPROVED COMMUNITY AND GOLF SERVICES, AND YEAR- ROUND USE. OVERALL DESIGN LAYOUT AND EXTERIOR MATERIAL SELECTIONS WILL TAKE ADVANTAGE OF CONSTRUCTION AND COST EFFICIENCIES, WHILE STILL REMAINING RESPECTFUL OF THE VISUAL CHARACTERISTICS OF THE SITE, AND THE OLD BARN AND SILO STRUCTURES.

PROJECT NARRATIVE

STAR VALLEY RANCH ASSOCIATION BARN / SILO REDEVELOPMENT

STAR VALLEY RANCH, WYOMING JANUARY 8, 201 3

MULTI PURPOSE 53’ x 32’ KITCHEN 21’ x 24’ BAR 21’ x 24’ COVERED OUTDOOR DINING 20’ x 44’ ELEV. STO./ MECH. 15’ x 9’ STAIRS WOMEN 25’x12’ MEN 25’ x 12’ JAN. KIT. SER. 8’x13’ MEETING 19’ x 13’ STO./ COPY/ BREAK 10’ x 13’ OFFICE 12’ x 13’ MEMBER SERVICES 12’ x 13’ OFFICE 12’ x 13’ OFFICE 12’ x 13’ MAN. OFFICE 12’ x 13’ FUTURE EXPANSION 50’ x 24’ VEST. 10’ x 10’ COVERED PORCH 42’ x 10’ COVERED ENTRY PORCH 50’ x 10’ PRO SHOP 25’ x 25’ DIS. DIS. VIEW TO #1 TEE BOX COVERED PORCH 10’ x 19’

LOWER LEVEL PLAN

N.T.S.

FIRST FLOOR PLAN

N.T.S.

2

FLOOR PLANS

STORAGE 44’ x 24’ (FUTURE TENANT) CART STORAGE (27) 106’ x 32’ FUTURE EXPANSION 50’ x 24’ MECHANICAL /STORAGE 25’ x 18’ (3) (9) (15) ELEV. TIOLET 10’ x 9’ STAIRS RETAINING WALL CART PATH PRO SHOP ABOVE SERVICE COURT

S.F. SUMMARY

LOWER LEVEL 5,536 S.F.

S.F. SUMMARY

FIRST FLOOR 6,261 S.F. COVERED PORCHES 1,770 S.F.

STAR VALLEY RANCH ASSOCIATION BARN / SILO REDEVELOPMENT

STAR VALLEY RANCH, WYOMING JANUARY 8, 201 3

EAST ELEVATION

N.T.S.

NORTH ELEVATION

N.T.S.

WEST ELEVATION

N.T.S.

SOUTH ELEVATION

N.T.S.

3

ELEVATIONS

STAR VALLEY RANCH ASSOCIATION BARN / SILO REDEVELOPMENT

STAR VALLEY RANCH, WYOMING JANUARY 8, 201 3

4

RENDERINGS

STAR VALLEY RANCH ASSOCIATION BARN / SILO REDEVELOPMENT

STAR VALLEY RANCH, WYOMING JANUARY 8, 201 3
