Session 6 Nevada DOT/USDOT FHWA Road Weather Integrated Mobile Observations (IMO 1, 2 & 3) Projects

8/31/2017 2

2017 Road Weather Management Stakeholder Meeting Minneapolis, Minnesota June 19-21, 2017

Nevada Integrated Mobile Observations (NIMO) Project

Nevada DOT

• Denise Inda
• Rod Schilling
• Jim Whalen
• Israel Lopez
• Gary Molnar
• Mark Aragon
• And others

University of Nevada, Reno

• Jeffrey LaCombe
• Eric Wang
• Pablo Rivera
• JP Braz
• Amanda Nelson
• Destiny Phan
• Tamzin Atkins
• Kyle Gorsiski
• Cody Zampella

8/31/2017 3

NIMO Project Overview

• 1. Project Update
• 2. Moving Forward
• 3. Sustainability Planning
• 4. Lessons Learned

8/31/2017 4

NIMO 1 Homegrown System

• Driven by need to use EDACS radio network

NIMO 1 Sensor Package Inventory

NIMO 2.0 Vehicle Hardware

7

Off-the-Shelf Serial Devices: Road Watch

• Air Temperature
• Surface Temperature

Also useable for:

• Vaisala Surface Patrol
• OBD Scan Tools
• EDACS Radios

Multiplexer Remote WX Sensors

Weather Sensors (I2C)

(remote mount on vehicle)

• Air Temperature
• Barometric Pressure
• Relative Humidity
• Dew Point

Main Processor

(Android-OS Cellular Phone)

• GPS (location, time)
• Cellular data link
• Accelerometers
• Compass
• Bluetooth OBD link

Custom Sensors: Pulse Counters

• Spreader shaft speed

NIMO 2.0 Cost Comparison

8

Item IMO 1 IMO 2

Main Processor System $800 $100 EDACS capable radio $900 $0 Device Multiplexer $173 Custom Weather Sensor $75 Roadwatch sensor w/RS232 $750 $750 Airmar GPS/weather sensor $1,000 $0 OBD/J1939 Scan Tool $625 $150 Custom cabling $100 Custom mounting hardware $150 Non-Recurring Totals: $4,325 $1,248 Recurring Data Expenses $36/month **Does NOT include costs of instrumenting spreader

NIMO Phase 3 Dedicated Short Range Communications (DSRC) System

8/31/2017 9

DSRC Site Locations

8/31/2017 10

18 Locations

Vehicle Routes

Cellular DSRC

8/31/2017 11

18 DSRC Locations 32 Miles DSRC 54 Miles Cellular

8/31/2017

NIMO 3 Vehicles

• 9 Snow plows with instrumented spreader

motors and 1 freeway service patrol vehicle

• 5 in Reno
• 3 in Carson City
• 2 in Lake Tahoe

District II IMO Inventory

UNIT # YEAR MAKE MODEL DESCRIPTION 2272 2007 PETERBILT 357 TANDEM AXLE DUMP TRUCK 1915 2007 PETERBILT 357 TANDEM AXLE DUMP TRUCK 0763 2009 PETERBILT 367 TANDEM AXLE CAB AND CHASIS 2275 2007 PETERBILT 357 TANDEM AXLE DUMP TRUCK 3200 2007 PETERBILT 357 TANDEM AXLE DUMP TRUCK 2274 2007 PETERBILT 357 TANDEM AXLE DUMP TRUCK 3319 2009 PETERBILT 367 TANDEM AXLE CAB AND CHASIS SWL 0323 2007 PETERBILT 367 TANDEM AXLE CAB AND CHASIS 0267 2001 INTERNATIONAL 5000 AWD R1 2012 FORD E240 FREEWAY SERVICE PATROL VAN/PU

12

8/31/2017 13

Item IMO 1 IMO 2 IMO 3

Main Processor System $800 $100 $400 EDACS capable radio $900 $0 $0 Device Multiplexer $0 $173 $0 Custom Weather Sensor $0 $75 $200 Roadwatch sensor w/RS232 $750 $750 $750 Airmar GPS/weather sensor $1,000 $0 $0 OBD/J1939 Scan Tool $625 $150 $0 Comet sensor $600 Arada Locomate $1,200 Cradlepoint cellular modem $800 Custom cabling $100 $150 Custom mounting hardware $150 $150 $4,325 $1,248 $4,250 Recurring Data Expenses $36/month $15/month **Does NOT include costs of instrumenting spreader Non-Recurring Totals:

NIMO Cost Comparison

Session 6 Sensor Selection & Placement

8/31/2017 14

2017 Road Weather Management Stakeholder Meeting Minneapolis, Minnesota June 19-21, 2017

NIMO 3 On Board Units (OBU)

Arada Locomate Comet T7511 Ethernet Weather Sensor Head

• Barometric Pressure
• Air Temperature
• Humidity

Technologic Systems

CPU (Main Computer)

Cradlepoint IBR1100

Cellular Modem, GPS

Roadwatch

(not included in costs)

• Air Temperature
• Surface Temperature

Adam 6051

Ethernet DIO/counter

Custom Sensors

• Windshield Wiper Sensor
• Spreader Rate Sensor
• Spreader Material Sensor

8/31/2017 15

“NIMO 3” Sensor Package

8/31/2017 16

NIMO 3 Sensor Package Inventory

8/31/2017 17

Plow On-Board Hardware

Mirror Mounted Air Temp - Atmoshperic Pressure Airmar and Omega Sensor Rear Mounted Spreader Rate Custom Sensor Behind Passenger Seat Mounted OBU – ARADA System Mirror Mounted Air/Pavement Temp – Roadwatch Sensor Roof Mounted Multi-band Diversity Antenna Cell, WiFi & GPS Mobile Mark Sensor

FSP Van On-Board Hardware

Under Front Bumber Mounted Air/Pavement Temp – Roadwatch Sensor Inside Van Rack Mounted OBU – ARADA System

Michigan DOT Sensor Selection Placement

Black box data logger Eurotech, Kansas City ReliaGATE 10-20 ReliaCELL 10-20

Surface Patrol Surface Temp

Surface Patrol Air Temp & Humidity Dedicated Short Range Communication (DSRC)

Accelerometer with ultrasonic distance

Michigan DOT Snow Plow AVL Equipment

Wing Plow Mercury Switch Sensor Cell and GPS Antenna

Under Body Blade Hydraulic Pressure Sensor

Air/Road Temp

MDSS Monitor Forecast & Treatment Recommendations

Camera

(picture every 60 seconds)

Data Logger Connected to DICKEY-john System (mounted behind drivers’ seat)

Min innesota DOT Snow Plo low AVL E Equip ipment

MDC/AVL Ameritrak AT-500 Connected to Spreader Controller/CANBUS MDC/AVL Mower Application Ameritrak AT-500 Plow Truck Display Screen Forecast/Treatment Recommendations/Radar MDC/AVL Light Duty install Ameritrak AT-500

Min innesota DOT Snow Plo low AVL E Equip ipment

Roof Mounted Cellular/GPS Antenna Mirror Mounted Pavement/Air Temp Sensor Vaisala Surface Patrol Operator AVL Input Screen Plow Camera AXIS M3004-V Fixed Dome Network Camera

Min innesota DOT Snow Plo low AVL E Equip ipment

Linksys LRT214 Router Arada RSU-1 Comcast BCI SMC D3 Cable Modem AmeriTrak Data Center ‘SvrDsrc’ All Other Arada RSUs

OBU install in MnDOT Plow Truck RSU Install on Catwalk over I-35W Communication Protocol for Ameritrak Data Center DSRC/MDC/Comcast

Session 7 DSRC FCC & FAA Licenses

8/31/2017 25

2017 Road Weather Management Stakeholder Meeting Minneapolis, Minnesota June 19-21, 2017

DSRC FCC & FAA Licenses

• NIMO DSRC FCC/FAA Site Registration Procedure:

The following procedure is required for adding DSRC radios to new and existing ITS poles: 1. Verify whether or not an FAA study is required. This can be done quickly by going to TOWAIR, http://wireless2.fcc.gov/UlsApp/AsrSearch/towairSearch.jsp and entering the geographical coordinates, site elevation, and structure height. Do not assume that an airport is not in the vicinity of the ITS pole location. Allow 30 days with all processes and resources to complete. 2. If the TOWAIR determination indicates a structure registration is required, then a study request must be submitted to the FAA. This study takes up to 45 days to complete. Also, the FAA may require additional lighting and/or markings on the pole. Allow 90 days with all processes and resources to complete. 3. Upon completion of the FAA study and approval, an FCC Form 854 (application for antenna structure registration) must be submitted; this will take up to 45 days for approval. Allow 90 days with all processes and resources to complete. 4. Follow up with the FCC requirement for local public notification and amend the current structure registration application – allow 30 days.

8/31/2017 26

DSRC FCC & FAA Licenses

• NIMO DSRC FCC/FAA Site Registration Procedure:

Local Public Notice: A. You must provide local notice of your proposed tower through publication in a local newspaper or other appropriate means, such as by following the local zoning public notice process. The local notice must contain the following information: B. The Form 854 File Number; C. The geographical location, the structure height, and anticipated lighting for the proposed new or modified structure; D. A statement that interested persons may review the application by going to www.fcc.gov/asr/applicatons and entering the Form 854 file Number;

8/31/2017 27

DSRC FCC & FAA Licenses

• NIMO DSRC FCC/FAA Site Registration Procedure:

Local Public Notice: E. A statement that interested persons may raise environmental concerns about the proposed structure filing a Request for Environmental Review with the Federal Communications Commission; F. A statement that the Federal Communications Commission strongly encourages interested parties to file Requests for Environmental Review online, and that the instructions for making such filings can be found at www.fcc.gov/asr/environmentalrequest; and G. The mailing address for interested parties that would prefer to file a Request for Environmental Review by paper copy; FCC Requests for Environmental Review, Attn: Ramon Williams, 445 12th Street SW, Washington, DC 20554. H. You may provide local notice under both this process and the Commission’s procedures implementing Section 106

• f the National Historic Preservation Act (NHPA) through a single publication, provided the notice explains the

different procedures for public participation under each of these processes. I. You will be required to report the local notice date in Part 2 of your Form 854 filing. If local notice is not provided before the requested national notice date, you must amend your Form 854 submission to request a new national notice date.

8/31/2017 28

DSRC FCC & FAA Licenses

8/31/2017 29

DSRC FCC & FAA Licenses

• NIMO DSRC FCC/FAA Site Registration Procedure:

The following procedure is required for adding DSRC radios to new and existing ITS poles: 5. Upon completion of the amended structure registration, RSU site registration can be completed online with FCC approval within 30 days. In summary, FCC licensing and registration of a communication site may take up to 270 days depending on the location and FCC/FAA requirements.

8/31/2017 30

DSRC FCC & FCC License

• Remaining to date
• DSRC FCC/FAA Site Registration:

1. I580 / Mill Street FAA Determination completed, FCC structure registration submitted 2. I580 / Plumb Lane FAA Determination completed, FCC structure registration submitted 3. I580 / Neil Road FAA Determination completed, FCC structure registration submitted 4. I580 SB before exit 59 Registration completed 5. SR431 WB / DMS#4 Registration completed 6. I580 / Parker Ranch Registration completed 7. I580 / Bower’s DMS#1 Registration completed 8. I580 / Washoe Valley Registration completed 9. I580 / Galena Creek Bridge Registration completed 10. I580 / Steamboat Hills Registration completed 11. I580 / Northgate (Carson) FAA Determination completed, FCC structure registration submitted 12. I580 / Exit 61 (Virginia St) FAA Determination completed, FCC structure registration submitted 13. I580 / Exit 63 (Peckham) FAA Determination completed, FCC structure registration submitted 14. I580 / Galena Forest Registration completed 15. I580 / Brown’s Creek Registration completed 16. I580 / 5th St (Carson) Registration completed 17. I580 / Moana FAA Determination completed, FCC structure registration submitted 18. I580 / I80 Interchange FAA Determination completed, FCC structure registration submitted

8/31/2017 31

Minnesota DOT DSRC FCC & FAA License

• Filed initial application for main Statewide DSRC license with FCC on June 3rd,

2016.

• Able to file DSRC License from FCC online by using our State of MN account.
• FCC granted main general Statewide DSRC license in January, 2017.
• Filed the application to register the (5) DSRC locations on January 20th, 2017.
• Fully granted license including the specific DSRC sites on March 1st, 2017.
• Full process took 9 months.
• Info that was needed for each DSRC site:
• Site lat/long (decimal degrees, minutes, seconds)
• Site elevation (feet or meters)

Surface Patrol Surface Temp

Michigan DOT Experience - FCC license for DSRC

• DSRC radio registration requirements are found in 47 C.F.R,

Parts 90 and 95. A geographic area license must be obtained before submitting individual locations

• Information regarding antenna (not transmitter)

manufacturer is required to complete registration

• The application process is straightforward and everything is

submitted online

• An FCC Registration Number from FCC is required to start the

application; most states already have one, even if they haven’t used it for ITS before

• Licenses takes at least a month from submission to approval.

The biggest lag seems to be between submission and when the review starts, review to approval only takes a few days

• FCC phone support line is responsive and helpful
