LPC DOCKET #: 170464 DXA studio 140 WEST STREET LPC Presentation September 18, 2018 SCALE As Noted 02 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
42’-0” 42’-0” BARCLAY ST. W A S H I N G WEST ST. T O 140 WEST STREET — VESEY STREET ELEVATION N S T . SCALE As Noted 01 894 6th Avenue N CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 VESEY ST. DATE September 18, 2018 dxastudio.com T 212 874 0567
PG 09 32’-0” 32’-0” 32’-0” BARCLAY ST. W A S H I N G WEST ST. T O 140 WEST STREET — WEST STREET ELEVATION N S T . SCALE As Noted 02 894 6th Avenue N CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 VESEY ST. DATE September 18, 2018 dxastudio.com T 212 874 0567
42’-0” 25’-0” BARCLAY ST. W A S H I N G WEST ST. T O 140 WEST STREET — BARCLAY STREET ELEVATION N S T . SCALE As Noted 03 894 6th Avenue N CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 VESEY ST. DATE September 18, 2018 dxastudio.com T 212 874 0567
PG 11 32’-0” BARCLAY ST. W A S H I N G WEST ST. T O 140 WEST STREET — WASHINGTON STREET ELEVATION N S T . SCALE As Noted 04 894 6th Avenue N CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 VESEY ST. DATE September 18, 2018 dxastudio.com T 212 874 0567
VESEY ST WEST ST BARCLAY ST BRICK MASONRY FLAT MASONRY DECORATIVE STONE WASHINGTON ST 140 WEST STREET — ELEVATION HISTORIC MASONRY DIAGRAMS SCALE As Noted 05 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
EXISTING MASONRY FOR PIN MTD LETTERING (BARCLAY ST) EXISTING MASONRY FOR PIN MTD LOGO SIGNAGE (WASHINGTON ST) EXISTING MASONRY FOR PIN MTD LETTERING (WEST ST) EXISTING BRICK FOR PIN MTD LETTERING (BARCLAY ST) 140 WEST STREET — EXISTING PHOTOS / PROPOSED AREAS FOR SIGNAGE SCALE As Noted 06 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
EXISTING MARSHALLS SIGNAGE/LIGHTING (VESEY ST) EXISTING MARSHALLS SIGNAGE (WASHINGTON ST) EXISTING MARSHALLS SIGNAGE/LIGHTING (VESEY ST) EXISTING LOUVERS (WASHINGTON ST) 140 WEST STREET — CURRENT APPROVED SIGNAGE/LOUVERS SCALE As Noted 07 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
BRACKET SIGNAGE (BROOKLYN PUBLIC LIBRARY) BRACKET SIGNAGE (16 SPRING ST) PIN MOUNTED LETTERING SIGNAGE (ROCKEFELLER CENTER) PIN MOUNTED LETTERING SIGNAGE (ROCKEFELLER CENTER) 140 WEST STREET — SIGNAGE PRECEDENTS SCALE As Noted 08 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
PG 13 12” BRONZE LETTERING SIGNAGE PIN MOUNTED AT FLAT MASONRY WASHINGTON ST & WEST ST 140 WEST STREET — STOREFRONT 12” PIN MTD SIGNAGE DETAIL SCALE As Noted 09 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
PG 14 HOLD AT LEAST 16” CLEAR FROM DECORATIVE STONE 24”X36” BOUNDING BOX FOR BRONZE LOGO SIGNAGE PIN MOUNTED AT FLAT MASONRY CENTERED ABOVE ENTRY. SIGN SURFACE AREA TO NOT EXCEED 6 SQFT. WASHINGTON ST & WEST ST 140 WEST STREET — STOREFRONT PIN MTD LOGO SIGNAGE DETAIL SCALE As Noted 10 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
10” HIGH RAISED BRONZE LETTERING PIN MOUNTED AT FLAT MASONRY WASHINGTON ST & WEST ST 140 WEST STREET — STOREFRONT 10” PIN MTD SIGNAGE DETAIL SCALE As Noted 11 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
24”X36” BOUNDING BOX FOR BRONZE LOGO SIGNAGE PIN MOUNTED AT FLAT MASONRY CENTERED ABOVE ENTRY . SIGN SURFACE AREA TO NOT EXCEED 6 SQFT. WASHINGTON ST & WEST ST 140 WEST STREET — STOREFRONT PIN MTD LOGO SIGNAGE DETAIL SCALE As Noted 12 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
1/4” DIAMETER PIN ATTACHMENTS TO MASONRY EX’G MASONRY JOINTS 12” BRONZE LETTERING SIGNAGE PIN MOUNTED AT FLAT MASONRY . 2” FROM FACE OF MASONRY LED ADHERED TO BACK OF LETTERING. CONDUIT COUPLED WITH PIN ATTACHMENT FLAT MASONRY SECTION ANCHORAGE ELEVATION 140 WEST STREET — SIGNAGE DETAILS - LETTERING SIGNAGE SCALE As Noted 13 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
1/4” DIAMETER PIN ATTACHMENTS TO MASONRY . APPROX. (4) PER SIGN 24”X36” BRONZE LOGO EX’G MASONRY JOINTS SIGNAGE PIN MOUNTED AT FLAT MASONRY CENTERED ABOVE ENTRY. SIGN SURFACE AREA TO NOT EXCEED 6 SQFT. LED ADHERED TO BACK OF LETTERING. CONDUIT COUPLED WITH PIN ATTACHMENT FLAT MASONRY SECTION ANCHORAGE ELEVATION 140 WEST STREET — SIGNAGE DETAILS - LOGO SIGNAGE SCALE As Noted 14 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
BRONZE SIGNAGE MOUNTING LOCATIONS FOR SURROUND CAP . TO BE NO BRACKET ATTACHMENTS TO WIDER THAN 3” MASONRY JOINTS. APPROX. (3) PER SIGN ACRYLIC SIGNAGE PANEL 24”X36” BRACKET SIGN PIN MOUNTED 13’-6” AT BRICK MASONRY JOINTS CENTERED ON ARCADE COLUMN 6” BRONZE LETTERING IN MINIMAL FONT IN ACRYLIC SIGNAGE PANEL EX’G MASONRY LIGHT SOURCE SECTION ANCHORAGE ELEVATION 140 WEST STREET — SIGNAGE DETAILS - BRACKET SIGNAGE SCALE As Noted 15 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
S S E R G O R P N I 140 WEST STREET — RENDERING - WEST ST/VESEY ST CORNER SCALE As Noted 16 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
140 WEST STREET — RENDERING - WEST ST/BARCLAY ST CORNER SCALE As Noted 17 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
32 6TH AVENUE 140 WEST STREET — SIGNAGE PRECEDENTS SCALE As Noted 18 894 6th Avenue CLIENT Magnum Real Estate 5th Floor PROJECT NUMBER 13.34 NYC 10001 DATE September 18, 2018 dxastudio.com T 212 874 0567
