ynergy nergy

• tivation

WE CONSUME ALL OUR ENERGY FOR ENERGY

ABOUT US

Sem Transformator started activities by maintenance of the transformers continued with manufacturing. Within the progress, SEM integrated technology to his production. By the professional founders experience and the team’s harmony , SEM become one of the most important companies in the sector. Since 1993, production is done by the TSE (Turkish Standards Institute) certificate. With the references of ISO 9001: 2008, the company proved its success and quality. In the progress, the company focused on pre-sales services, production, after sales assistance and customer satisfaction and then in 2010, moved to his new plant which has bigger production capacity and fitted by technologic equipments. Today, Sem Transformator has established his brand name in local market and his place

• n international platform by exporting to more than 40 different countries in Europe, South America, Africa, Asia

and Middle East.

OUR MISSION

SEM Transformator determined his mission as foreseeing the needs of the sector and continuing production in international standards with increasing customer satisfaction becoming a leader in the sector.

OUR VISION

The aim of Sem Transformator is to maintain his production by using high quality raw materials and technological machines. This way Sem aims to achieve customer satisfaction with supplying products which are manufactured and tested with reliable methods. The vision of Sem Transformatör is to be a world transformer brand.

ABOUT US

SEM Transformator A.S. is a 35 years old family company now with around 170 employees as 40 White Collar and 130 blue collar. Most of the staff have experience of over 15 years in transformer manufacturing. Also in the last 6 - 7 years we developed our position in the market with investments on technology and production. We are developing our export markets as well.

2013 2014 2015 2016 2017

ANNUAL TURNOVER COMPARISION BY YEARS

PRODUCTS

SEM Transformator is manufacturing power and distribution transformers from 10 kVA up to 16000 kVA (up to 54 kV) with different types of voltage and cooling. Besides from standart products, SEM Transformator designS and manufactureS special transformers upon customized requests by the Customers

Distribution Transformers

• A distribution transformer's function is

straightforward: to step down the voltage and provide isolation between primary and

• secondary. Electrical energy is passed through

distribution transformers to reduce high- distribution voltage levels down to end-use levels.

• Distribution transformers normally have ratings

up to 5000 kVA.

• Cooling type can be ONAN, ONAF or KNAN
• number of phases: single-phase or three-phase
• Can be manufactured as hermetically sealed,

hermetically sealed with gas cushion or with conservator tank.

• HV Porcelain or Plug-in Bushings can be used.

Medium Power Transformers

• Rated power up to 16 MVA
• Rated voltage up to 54 kV
• Can be manufactured as hermetically sealed,

hermetically sealed with gas cushion or with conservator tank.

• Off-Circuit Tap Changer (OCTC) or On-Load

Tap Changer (OLTC)

• High capacity of cooling options such as

ONAN, ONAF, OFAF (also with K class insulating oil)

Special Transformers

• Dual HV and Dual LV Transformers.
• AutoTransformer
• 6 , 12, 24 Pulse Transformers
• Isolation Transformers
• Rectifier Transformers
• Earthing Transformers
• Transformers feeding

converters/inverters

PRODUCTION PLANT

• Sem Transformator, who becomes a brand

by its long-lived and reliable products, continues his production in his 18.000m² plant in Baskent Industrial Estate. Sem is improving and renewing his products and production by following up latest developments, requirements and demands closely in energy

• sector. Sem’s IEC standard products are tested

in international KEMA, CESI and ICMET laboratories and the TSE (Turkish Standards Institute) convenience of the products is

• certificated. Considering the compromise

between quality and competitiveness, Sem Transformatör represent the harmony of design, quality and technology.

PRODUCTION PROCESS

Design Engineering SEM Transformer design team use high technology manufacturing equipment in both standard transformers and special transformers projects. SEM Transformer

• ptimize quality and market competitiveness by standard

and special designs which are developed by SEM electrical & electronics engineers..

PRODUCTION PROCESS

We meticulously carry on all the steps from design to assembly in production..

Magnetic Core Production Assembly and Tank The magnetic core is manufactured using high- permeability and low-loss cold rolled silicon steel used for magnetic cores of the transformers. The core components which are cut in our high accuracy cutting line, are assembled by qualified specialists on special workbenches in order to prevent any deformation of the sheets, also assuring a perfect core alignment. Windings are produced strictly matching with design

• parameters. Upon customer request electrolytic copper
• r aluminum is used as conductor, press band paper is

used as insulator and proper wooden bars are used for

• cooling. Materials are chosen as temperature resistant

and cannot be dissolved in oil. Full automatic machines wound the windings. Windings are passed to next stage for montage. When fully completed, the primary and secondary windigs resemble two compact cylinders and they are assembled coaxially on the core legs. Terminal connections and insulation result in complete active part. Before filling the transformer with oil, the active part is dried in the oven at high temperature (107 oC ) and full

• vacuum. Transformer tank, cover, oil conservator and

corrugated walls and other metallic parts are also manufactured in SEM. Welded parts are checked with 3 different tests against oil leakage and pressure

• withstanding. Transformers are shot blasted or sand

blasted to protect against rust, corrosion and verify sticking or paint properly. Tank inside is varnished and out side is treated with one coat of undercoat and 3 coats of

• paint. Tanks can be hot dip galvanized up on customer

request.

PRODUCTION PROCESS

We meticulously carry on all the steps from design to assembly in production..

Magnetic Core Production Assembly and Tank The magnetic core is manufactured using high- permeability and low-loss cold rolled silicon steel used for magnetic cores of the transformers. The core components which are cut in our high accuracy cutting line, are assembled by qualified specialists on special workbenches in order to prevent any deformation of the sheets, also assuring a perfect core alignment. Windings are produced strictly matching with design

• parameters. Upon customer request electrolytic copper
• r aluminum is used as conductor, press band paper is

used as insulator and proper wooden bars are used for

• cooling. Materials are chosen as temperature resistant

and cannot be dissolved in oil. Full automatic machines wound the windings. Windings are passed to next stage for montage. When fully completed, the primary and secondary windigs resemble two compact cylinders and they are assembled coaxially on the core legs. Terminal connections and insulation result in complete active part. Before filling the transformer with oil, the active part is dried in the oven at high temperature (107 oC ) and full

• vacuum. Transformer tank, cover, oil conservator and

corrugated walls and other metallic parts are also manufactured in SEM. Welded parts are checked with 3 different tests against oil leakage and pressure

• withstanding. Transformers are shot blasted or sand

blasted to protect against rust, corrosion and verify sticking or paint properly. Tank inside is varnished and out side is treated with one coat of undercoat and 3 coats of

• paint. Tanks can be hot dip galvanized up on customer

request.

OUR SERVICES

Maintenance of Distribution and Power Transformers Changeable to defects, maintenance service is provided at our plant or on site. Our maintenance service includes;

• Maintenance of power transformers on site and site tests,
• Reparation of power transformers and plant tests,
• Maintenance of distribution transformers on site and site tests,
• Reparation of distribution transformers and plant tests,
• Conduction of seminars about production and maintenance of transformers,
• Conduction of seminars about defects and reparation of transformers.

ENVIRONMENTAL POLICY

We adopt environmental policy as a principle

• Controlling the elements that might damage environment in self working area.
• Providing educations about environment to increase consciousness of the society and staff.
• Following technologies which are protecting environment.
• Self improving and obeying the rules of environment.
• Using raw materials, natural resources and energy efficiently.
• Developing both economic and quality projects.
• Manufacturing with using the systems and education that minimizes possible negative effects on environment.

SEM TESTING

All of our transformers pass through the following routine tests

• Measurement of windings resistance (IEC 60076-1 item 10.2)
• Measurement of transformer turns ratio (IEC 60076-1 item 10.3)
• Measurement of short-circuit impedance and load loss (IEC 60076-1 item 10.4)
• Measurement of no-load loss and current ( IEC 60076-1 item 10.5)
• Measurement of insulation resistance (IEC 60076-3)
• Measurement of insulation of oil (IEC 60076-3)
• Applied voltage test (IEC 60076-1)
• Induced over-voltage withstand test (IEC 60076-1)

Test reports are supplied with transformers. Temperature rise is carried out as well. Type tests are made upon customer's request

TYPE TEST CERTIFICATES

SHORT CIRCUIT WITHSTAND

SEM QUALITY CERTIFICATES

Quality is our passion, quality is our business..

• Azerbaijan
• Georgia
• Iraq
• Libya
• Egypt
• Syria
• Iran
• Bahrain
• Yemen
• Palestine
• Sudan
• Turkmenistan
• Afghanistan
• Belgium
• Holland
• Denmark
• Spain
• England
• France
• Germany
• Iceland
• Ireland
• Romania
• Austria
• Finland
• Hungary
• Norway
• Cyprus
• Malta
• Ghana
• Nigeria
• Benin
• South Africa
• Burkina Faso
• Tanzania
• Ethiopia
• Kenya
• Jordan

SEM EXPORT

We are exporting more than 40 countries..

WHY CHOOSE US

Superior Service & Quality SEM is fully invested in your satisfaction. We strive to understand our customers’ needs. Our commitment to service helps us form long-term, close-working relationships to meet and exceed your expectations. Intelligent Solutions SEM has become a leader in developing efficient and intelligent solutions for electric sector. We use our experience and passion for problem solving to advance and manufacturing technologies to benefit humanity and society as a whole. Highly-Trained Employee Our highly-trained staff creates a deep commitment to the success of your project. Our goal is to provide superior service, deliver quality process equipment, and exceed your expectations. In short, we care, we ask, and we deliver ! ISO Certification One of the key advantages to the customer of ISO certification is the requirement that all equipment is pre-assembled prior to shipment to the job site. This fabrication step, coupled with mandated consistency in the procedures for project management, result in on-time delivery, trouble-free erection, and projects that meet deadlines.

OUR PARTNERS

THANK YOU FOR YOUR KIND ATTENTION. ANY QUESTIONS
