Empowering Security Teams

Fuzz Testing for Embedded Device Security Assurance (EDSA)

ISASecure EDSA Certification

Communication/Network Robustness Testing (CRT)

• “CRT examines the capability of the device

to

• adequately maintain essential functions while

being subjected to:

• normal and erroneous network protocol traffic at

normal to extremely high traffic rates (flood conditions). ISASecure.org

• ANSI and IEEE have defined robustness as

the degree to which a system or component can function correctly in the presence of invalid inputs or stressful environmental conditions

• -

Wikipedia

FUZZING

RANDOM TESTING, BLACK BOX TESTING

The standard definition of Fuzzing (according to the Standard Glossary of Software Engineering Terminology, IEEE) is “The degree to which a system or

component can function correctly in the presence of invalid inputs or stressful environmental conditions.”

Fuzzing

 Trigger system errors and faults by sending invalid data intentionally  The best way to find “zero day vulnerabilities”  Many global companies use fuzzing as part of the developing process

Microsoft Security Development Lifecycle (SDL)

For Programmers

Inputs are the triggers for outputs

LOGIC For Attackers

Inputs trigger possible problems

LOGIC

Unhandled (Unexpected) INPUT INPUT OUTPUT

Unexpected Consequence (Possible Vulnerability) “Unexpected input causes unexpected results.” (Michael Sutton)

All the input space Code/Spec

Unit test s Unit test s Unit test s Unit test s

Test Coverage

QA Vulnerable

Smart and Dumb Fuzzing

• Dumb Fuzzers
• has no built-in intelligence about the program being fuzzed
• generates completely random input

Smart Fuzzers like beSTORM

• has knowledge of the input format (e.g. a protocol

definition or rules for a file format)

• generates mostly valid input and only fuzz parts of

the input within that known format

beSTORM Client and Monitor module

beSTORM MAIN COMPONENTS

Protocol test coverage - beSTORM

 Generate comprehensive test cases to cover the entire protocol  Crawl through the entire protocol tree (beSTORM combinatorically goes through all possible test cases)  With comprehensive test coverage, beSTORM detects all vulnerabilities

Monitoring for Possible Vulnerabilities

• A powerful monitor detects if even the slightest buffer overflow, format

string, or memory exception occurs

• Runs automatically until all test scenarios are exhausted, trying the most

probable combinations first

Other forms of Monitor – Waveform Monitor

beSTORM main features

Export a “Proof of Concept” Perl script

 Recreate the vulnerabilities without needing beSTORM  Perl script is platform independent

This site can not be reached

ISCI EDSA ARP Testing Specs

EDSA ARP Fuzzing Project Walkthru

Select ARP fuzzing

ARP Fuzz Testing Configuration

Select EDSA ARP Test Requirements

Select Built-in Monitor & Start

ARP Load Testing Completed

 Detailed result report

beSTORM REPORTING

Smart Fuzzers like beSTORM

• has knowledge of the input format (e.g. a protocol

definition or rules for a file format)

• generates mostly valid input and only fuzz parts of

the input within that known format

Generation Fuzzer

Working with 61850 MMS Protocol

Snippets of 61850 MMS Scripts

beSTORM USE CASES

Critical Infrastructure, certified by the ISA Security Compliance Institute (ISCI) as an approved ‘CRT Test Tool’ for use in the ISASecure EDSAv1 and EDSAv2 beSTORM, used in the automotive industry for the new driverless security testing. Supports CANBus, CAN- FD,UDS, DoCAN, new generation of automotive head-end units and all types of ECUs Product Development and Lab Certification, Beyond Security is a member of the Microsoft SDL Pro Network that specialize in application security and have substantial experience and expertise with the methodology and technologies of the SDL

LOCATE FAULTS AND SECURITY VULNERABILITIES

Using Fuzzing method to detect zero day vulnerabilities before they are publicly discovered.

FULL TOOL SUITE

• 2ND Generation fuzz engine
• Self Learning Module and Propriety software

testing

• System Under Test monitoring engines
• Auto generation of proof of concept attacks
• Easy to customize

TEST ANY TARGET

• Servers
• Clients
• Applications/Software
• Hardware
• API
• DLL
• Libraries
• PLC

FIND 0 DAYS WITH beSTORM

• Provides the highest control and transparency for your testing of any tool in the market
• beSTORM, real fuzzing, and protocol description, field by field. No test cases, real

Fuzzing!

• Using the monitor, attach like a debugger, tells beSTORM there’s an exception and

exactly where and when problem is found (step back and forth). Then export and exploit via Python. Engineering can then test offline

• Monitor if application is answering with icmp ping, there’s also a process monitor,

providing detailed additional DUT information.

• Monitor via API, and when there’s a failure beSTORM can notify you via email
• beSTORM consolidated reports shows:
• exactly what problems were found.
• Shows everything that was tested and why.
• Shows all settings and tests that were done – Great for testing certification
• Adjust

t you

• ur spee

eed: adjust how many ses essio ions/sec.

• lower speed for slow devices
• Increase speed for time constraints,
• Prioritize the parts of your protocols you want tested first
• Change testing granularity
• Proprietary protocols, smart and intuitive Self-Learning. Add your own protocols

BeSTORM ADVANTAGES

KNOW THAT YOU’RE SAFE

Thank you!
