Training Workshop – Environmental Site Assessment

OCTOBER 2019

slide-3
SLIDE 3

Phase I & II Training Workshop

1. Phase I ESA Introduction

  • 2. Phase I ESA Simulation – Historical Review
  • 3. Phase I ESA Simulation – Site Visit
  • 4. Break
  • 5. Case Study
  • 6. Phase II ESA Presentation

3

slide-4
SLIDE 4

PHASE I ESA

slide-5
SLIDE 5

Phase I ESA

Phase I ESA Introduction Presentation of the Guides, Standards and Regulations Steps : 1. Mandat

  • 2. Access to Information Requests
  • 3. Historical Research
  • 4. Site Visit
  • 5. Report

5

slide-6
SLIDE 6

Phase I ESA Introduction

6 PHASE I ESA

The environmental assessment allows us to determine the current and/or historical presence of potential sources of contamination which may have affected the environmental quality of the subject site.

  • Historical Review
  • Identification of current and former site activities
  • Site Visit
  • Identification of current and former site activities
  • Identification of building construction, infrastructure and other elements
slide-7
SLIDE 7

Phase I ESA Introduction

7 PHASE I ESA

  • Required by financial institutions for financing and mortgages
  • Multi-unit residential buildings (more than 6 units)
  • Commercial and industrial properties
  • Due diligence
  • Regulatory Cases
  • Cessation of designated activity
  • Change of land use
  • Authorization requests (eg. Article 22 of the Environment Quality Act (EQA))
slide-8
SLIDE 8

Guides, Standards and Regulations

8 PHASE I ESA

  • Canadian Standards Association (CSA)
  • CSA Z768-01 (reconfirmed 2016) – Phase I Environmental Site Assessment
  • Ministry of the Environment and the Fight against Climate

Change (MELCC)

  • Site Characterization Guide (2003)
  • Action Guide (2019)
  • Environment Quality Act (LQE, Q-2)
  • Land Protection and Rehabilitation Regulation (Q-2, r. 37)
slide-9
SLIDE 9

Step 1 – Confirmation of Mandate

9 PHASE I ESA

  • Information required for offer of services
  • Site address, surface area and current land use
  • Contact information of the client and site owner
  • Commence of work following acceptance of mandate
  • Report generally available 10 to 205 business days following the Site visit
  • Determine the language of the report before beginning the work
  • Obtaining pertinent site documentation
  • Certificat of location or any other plans of the property and building
  • Previous environmnental and geotechnical reports
  • A letter of authorization signed by the Site owner
  • All other pertinent documents
slide-10
SLIDE 10

Step 2 – Access to Information

10 PHASE I ESA

  • MELCC
  • Énergir (formerly Gaz Métropolitain)
  • City / Municipality / Borough
  • Régie du bâtiment du Québec (RBQ), if listed in the Petroleum

Equipment Registry

  • Environment and Climate Change Canada (ECCC)
  • Opta Intelligence Informationnelle – fire insurance documents
  • CDPNQ – if study is subject to Section IV.2 of the EQA
slide-11
SLIDE 11

Step 3 – Historical Research

11 PHASE I ESA

  • Preliminary verification of available documents
  • Aerial Photographs and Satellite Images
  • Fire Insurance Plans
  • Land Use Maps
  • Topographic Maps
  • Geological Maps
  • Municipality
  • Bibliothèque et Archives nationales du Québec
  • Other online sources
slide-12
SLIDE 12

Step 3 – Historical Research

12 PHASE I ESA

  • Site-specific documents
  • Valuation roll – Québec municipal
  • Québec Land Registre – property land titles
  • Registre et répertoire des entreprises du Québec (REQ, iCRIQ)
  • Répertoire d’entreprises canadiennes
  • Directory of Canadian Companies
  • Consultation of government databases and inventories
  • Phase I ESA search list
  • 250 m search radius with the exception of:
  • Hydrogeological information system (HIS) – 1 km radius
slide-13
SLIDE 13

Step 3 – Historical Research

13 PHASE I ESA

  • Consultation of

databases and inventories

slide-14
SLIDE 14

Step 3 – Historical Research

14 PHASE I ESA

slide-15
SLIDE 15

Step 4 – Site Visit

15 PHASE I ESA

  • Information to obtenir for the site visit
  • Date and time of site visit
  • Meeting point
  • Name and coordinates of the site contact
  • Ensure that all the areas and rooms of the building will be made available during

the site inspection, with the exception of residentiel apartments

  • Documents and items to bring to the site visit
  • Phase I Inspection checklist
  • Aerial photograph or other useful site plan
  • Camera
  • Flashlight

TAKE PHOTOS!!

slide-16
SLIDE 16

Step 4 – Site Visit

16 PHASE I ESA

  • Site Visit:
  • Arrive 15 minutes early
  • Identify occupants of adjacent and neighbouring properties
  • Elements to verify outside on the site and on adjacent and neighbouring

properties:

  • Condition of exterior surfaces
  • Presence of secondary buildings
  • Condition of exterior walls
  • Pipes stemming from walls or ground
  • Type of roof
  • Identification of heating and/or cooling

systems

  • Natural gas entry
  • Water entry
  • Debris and material on the ground
  • Storage tanks and other storage
  • Evidence of backfill
  • Drains and drainage ditches
  • Monitoring wells
slide-17
SLIDE 17

17 PHASE I ESA

slide-18
SLIDE 18

Step 4 – Site Visit

18 PHASE I ESA

  • Complete the inspection checklist with the site representative
  • Give examples of elements of importance
  • If there are industrial activities on site
  • Ask for a description of the process
  • Ask for a list of products and raw materials used
  • Ask for a list of finished products
  • According to the process used, verify the existence of a cerificate of authorization or of a

permit to discharge into the sewers and/or atmosphere

  • Conduct a building inspection with the site representative
  • Validate the information collected with the inspection checklist
  • Inspect all rooms and areas of the building
slide-19
SLIDE 19

Step 4 – Site Visit

19 PHASE I ESA

  • Elements to verify inside the building
  • Building construction
  • Wood frame vs steel
  • Walls (brick vs concrete)
  • Exterior cladding (aluminum siding, brick, stucco, vinyl, etc.)
  • Interior cladding (wood, gypsum, plaster, etc.)
  • Concrete foundations vs stone and mortar
  • Number of storeys, presence of basement
  • Interior garage
  • Condition of the floors, presence of cracks or staining
slide-20
SLIDE 20

Step 4 – Site Visit

20 PHASE I ESA

  • Elements to verify inside the building
  • Heating system
  • Centale water, central forced air, electric baseboards, heatpump, HVAC, radiant heater,

suspended units

  • Fuel source for the heating system (current and former) – coal, fuel oil, propane, natural

gas, electricity, wood

  • Identification of current and/or former heating system elements – furnace, boiler, heat

pump, HVAC unit, chimney, fuel oil storage tank, fuel feed et return lines

  • Aboveground and/or underground storage tanks
  • Fuel oil, gasoline, diesel, propane, glycol, used oil, etc.
  • Fill and vent pipes, level-o-meter, fuel pump, feed line
slide-21
SLIDE 21

21 PHASE I ESA

slide-22
SLIDE 22

22 PHASE I ESA

slide-23
SLIDE 23

23 PHASE I ESA

slide-24
SLIDE 24

Step 4 – Site Visit

24 PHASE I ESA

  • Elements to verify inside the building
  • Mechanical equipment
  • Dock leveller – hydraulic vs manual
  • Lifting apparatus (lift, platform) – electric vs hydraulic
  • Elevator and freight elevator – electric vs hydraulic
  • Garbage compactor
  • All other mecanical equipment
  • Interior drainage
  • Floor drains
  • Oil-water separator
  • Grease trap
  • Decantation and neutralization bassin
  • Sump with or without pump
  • Floor trench or gutter
slide-25
SLIDE 25

25 PHASE I ESA

slide-26
SLIDE 26

26 PHASE I ESA

slide-27
SLIDE 27

Step 4 – Site Visit

27 PHASE I ESA

  • Elements to verify inside the building
  • Hazardous materials
  • Type (household maintenance products, chemical products, etc.)
  • Storage, use
  • Non hazardous residual materials
  • Domestic waste, recyclables
  • Storage, disposal
  • Hazardous residual materials
  • Type (used oil, used oil filters, process waste, etc.)
  • Storage, disposal
slide-28
SLIDE 28

28 PHASE I ESA

slide-29
SLIDE 29

Step 4 – Site Visit

29 PHASE I ESA

  • Special attention substances
  • Polychlorinated Biphenyls (PCB)
  • Transformers, fluorescent light ballasts
  • Asbestos containing material (ACM)
  • Insulation, floors tiles, ceiling tiles, plaster, etc.
  • Lead
  • Paint, plumbing
  • Urea formaldehyde foam insulating material (UFFI)
  • Mould
  • Ozone depleting substances (ODS)
  • Air conditiong units containing chlorofluorocarbons (CFC)
slide-30
SLIDE 30

30 PHASE I ESA

slide-31
SLIDE 31

Step 5 – Report

31 PHASE I ESA

  • Mandate, context and objectives
  • Historical research data
  • Responses to access to information requests
  • Public inventories and regulatory review data
  • Site visit observations
  • Figures
  • Photographic record
  • Identification of environmental risks
  • Conclusions and recommendations
slide-32
SLIDE 32

Phase I ESA Simulation – Historical Review

Former road maintenance yard

Presentation of the site

  • History
  • Figures of environmental risks

Aerial Photographs and Satellite Images Historic maps and plans

  • Topographic Maps
  • Land Use Maps
  • Fire Insurance Plans

32

slide-33
SLIDE 33

Site Presentation - History

33 PHASE I ESA SIMULATION - HISTORY

  • Context of the study
  • Change in land use
  • Current Land Use
  • Fuel distribution, storage and maintenance workshop
  • Historic Land Use
  • Road maintenance yard
  • Importer and manufacturer of iron works and metal
  • Foundy
  • Tar and coal refinery
  • Machine shop
  • Manufacturing of chemical products
  • Manufacturing of paint, ink and varnish
slide-34
SLIDE 34

Site Presentation – Figure of Risks

34 PHASE I ESA SIMULATION - HISTORY

slide-35
SLIDE 35

Aerial Photographs and Satellite Images

35 PHASE I ESA SIMULATION - HISTORY

1949

slide-36
SLIDE 36

Aerial Photographs and Satellite Images

36 PHASE I ESA SIMULATION - HISTORY

1966

slide-37
SLIDE 37

Aerial Photographs and Satellite Images

37 PHASE I ESA SIMULATION - HISTORY

1973

slide-38
SLIDE 38

Aerial Photographs and Satellite Images

38 PHASE I ESA SIMULATION - HISTORY

1983

slide-39
SLIDE 39

Aerial Photographs and Satellite Images

39 PHASE I ESA SIMULATION - HISTORY

2002

slide-40
SLIDE 40

Aerial Photographs and Satellite Images

40 PHASE I ESA SIMULATION - HISTORY

2018

slide-41
SLIDE 41

Historic Maps and Plans – Topographic Maps

41 PHASE I ESA SIMULATION - HISTORY

1909

slide-42
SLIDE 42

Historic Maps and Plans – Topographic Maps

42 PHASE I ESA SIMULATION - HISTORY

1971

slide-43
SLIDE 43

Historic Maps and Plans – Topographic Maps

43 PHASE I ESA SIMULATION - HISTORY

2003

slide-44
SLIDE 44

Historic Maps and Plans – Topographic Maps

44 PHASE I ESA SIMULATION - HISTORY

1846

slide-45
SLIDE 45

Historic Maps and Plans – Topographic Maps

45 PHASE I ESA SIMULATION - HISTORY

1949

slide-46
SLIDE 46

Historic Maps and Plans – Topographic Maps

46 PHASE I ESA SIMULATION - HISTORY

1990

slide-47
SLIDE 47

Historic Maps and Plans – Fire Insurance Plans

47 PHASE I ESA SIMULATION - HISTORY

1909

slide-48
SLIDE 48

Historic Maps and Plans – Fire Insurance Plans

48 PHASE I ESA SIMULATION - HISTORY

1940

slide-49
SLIDE 49

Historic Maps and Plans – Fire Insurance Plans

49 PHASE I ESA SIMULATION - HISTORY

1950

slide-50
SLIDE 50

Phase I ESA Simulation – Site Visit

Petro-T

  • Site location
  • Current site use
  • Neighbouring properties

50

slide-51
SLIDE 51

Site Location

51 PHASE I ESA SIMULATION - VISIT

slide-52
SLIDE 52

BREAK

slide-53
SLIDE 53

Case Study

Petro-T

  • Site visit observations
  • Problems encountered and limitations
  • Potential risks identified
  • Recommendations

53

slide-54
SLIDE 54

PHASE II ESA

slide-55
SLIDE 55

Phase II ESA

Phase II ESA Introduction Presentation of the Guides, Standards and Regulations Steps : 1. Characterization Plan

  • 2. Offer of Services and Mandate
  • 3. Planification of Site Work
  • 4. Site Work
  • 5. Compilation, Interpretation and Report

55

slide-56
SLIDE 56

Guides, Standards and Regulations

56 PHASE II ESA

  • Canadian Standards Association (CSA)
  • CSA Z769-00 (reconfirmed 2013) – Phase II Environmental Site Assessment
  • MELCC
  • Site Characterization Guide (2003)
  • Action Guide (2019)
  • Sampling Guide for Environmental Analysis – Booklet 1: Generalities (2008)
  • Sampling Guide for Environmental Analysis – Booklet 3: Groundwater Sampling (2012)
  • Sampling Guide for Environmental Analysis – Booklet 5: Soil Sampling (2010)
  • Update of Section 5.3.3 of Booklet 5 : Samples for Volatile Organic Counpounds Analysis

(2016)

  • Environment Quality Act (LQE, Q-2)
  • Land Protection and Rehabilitation Regulation (Q-2, r. 37)
  • Regulation Respecting the Burial of Contaminated Soils (Q-2, r. 18)
slide-57
SLIDE 57

Guides, Standards and Regulations

57 PHASE II ESA

  • Canadian Council of Ministers of the Environment (CCME)
  • Canadian Soil Quality Guidelines for the Protection of Environmental and Human Health
  • Canadian Water Quality Guidelines for the Protection of Aquatic Life
  • Guidance Manual for Environemental Site Characterization in Support of Environmental and

Human Health Risk Assessment – Volume 1: Guidance Manual (2016)

  • Guidance Manual for Environemental Site Characterization in Support of Environmental and

Human Health Risk Assessment – Volume 2: Checklists (2016)

  • Guidance Manual on Sampling, Analysis, and Data Management for Contaminated Sites –

Volume 1: Main Report (1993)

  • Subsurface Assessment Handbook for Contaminated Sites (1994)
slide-58
SLIDE 58

Step 1 – Characterization Plan

58 PHASE II ESA

  • Characterization plan
  • Objectives of characterization
  • Financial transaction, cessation of designtaed activity, redevelopment of the site, etc…
  • Historic data and current use
  • Surface area of the site
  • Environmental risks
  • Site work
  • Number of soundings (targeted, random or systematic 625 m2)
  • Type of soundings (boreholes, monitoring wells, trenches)
  • Analytical parameters (based on risks)
slide-59
SLIDE 59

Presentation of Site – Risks

59 PHASE II ESA

slide-60
SLIDE 60

Step 2 – Offer of Services and Mandate

60 PHASE II ESA

  • Offer of Services
  • Mandate and detailed steps
  • Limitations and exclusions
  • Schedule
  • Deliverables
  • Costs and Payment Modalities
  • Professional fees, site work, project management, report
  • Subcontractors (drillers, laboratory, private locates)
  • Authorization of Mandate
  • Written confirmation of offer of services
  • Informations for accessing the site (contact, dates, etc…)
slide-61
SLIDE 61

Step 3 – Planification of Site Work

61 PHASE II ESA

  • Location of Underground Services
  • Info-Excavation
  • Municipality
  • Private locate firm
  • Subcontractors
  • Drillers, excavators
  • Laboratory (jars, bottles, coolers)
  • Supplies (monitoring wells, sampling equipment)
  • Soil cuttings and waste water management
  • Signaling and surveyor, if necessary
  • Health and Safety Program
  • Risk analysis
  • Characterization Program
  • Location, depths
  • Type and quantity of samples, analyses
slide-62
SLIDE 62

Step 3 – Planification of Site Work

62 PHASE II ESA

slide-63
SLIDE 63

Step 3 – Planification of Site Work

63 PHASE II ESA

slide-64
SLIDE 64

Step 4 – Site Work

64 PHASE II ESA

  • Location of underground services
  • Health and Safety (H&S) Meeting
  • Underground services
  • Work-related risks
  • Sounding and Sampling
  • Soil description, evidence of contamination
  • Sampling and identification of samples
  • Monitoring well installation, if planned
  • Location of soundings
  • Fill in laboratory chain of custody forms
  • Deliver samples to the laboratory (cold)
  • Site Documents
  • Site forms (sounding logs, daily reports, H&S)
  • Photographs and site plans
  • Subcontractor work orders
slide-65
SLIDE 65

Step 4 – Site Work

65 PHASE II ESA

slide-66
SLIDE 66

Step 4 – Site Work

66 PHASE II ESA

slide-67
SLIDE 67

Step 4 – Site Work

67 PHASE II ESA

slide-68
SLIDE 68

Step 4 – Site Work

68 PHASE II ESA

slide-69
SLIDE 69

Step 4 – Site Work

69 PHASE II ESA

slide-70
SLIDE 70

Step 5 – Compilation, Interpretation and Report

70 PHASE II ESA

  • Analysis of Site data
  • Sample selection for laboratory analysis
  • Reception of analytical results
  • Interpretation of results and follow-up with client
  • Reporting
  • Figures
  • Sounding logs
  • Results tables and laboratory certificates of analysis
  • Photographs of site work
  • Conclusions and recommendations
  • Transmission of report
  • Planification of next step, if required
slide-71
SLIDE 71

Step 5 – Compilation, Interpretation and Report

71 PHASE II ESA

slide-72
SLIDE 72

Step 5 – Compilation, Interpretation and Report

72 PHASE II ESA

slide-73
SLIDE 73

THANK YOU

WSP, A CHOICE PARTNER
