WOVEN WALL COVERING NOT JUST FLOORING Floover Wall Covering is a - - PowerPoint PPT Presentation

▶
woven wall covering not just flooring
SMART_READER_LITE
LIVE PREVIEW

WOVEN WALL COVERING NOT JUST FLOORING Floover Wall Covering is a - - PowerPoint PPT Presentation

Feb 03, 2023 332 likes •546 views

WOVEN WALL COVERING NOT JUST FLOORING Floover Wall Covering is a new application specially designed for walls which improves the last gluing versions. This is a combination of Floover Woven with a thin polyestirene backing. Light, easy to

slide-1
SLIDE 1

WOVEN WALL COVERING

slide-2
SLIDE 2
slide-3
SLIDE 3

NOT JUST FLOORING

Floover Wall Covering is a new application specially designed for walls which improves the last gluing versions. This is a combination of Floover Woven with a thin polyestirene backing. Light, easy to handle and install and without big maintainance requirements.
slide-4
SLIDE 4
slide-5
SLIDE 5 We will focus on some colors of 2016 trends, to make the new floover wallpaper collection

COLOR IDENTIFICATION

slide-6
SLIDE 6

range

WOVEN

Plank size: 2000 x 95 mm Wear Layer Thickness: 2.2 mm Total Thickness: 2.2 mm Embossing: Vinyl textile WV4017 White Stitch WV4018 Ecru Hem WV4019 Grey Stitch WV4006 Tranquility WV4002 Bold Beige WV4007 Spice WV4010 Reflection
slide-7
SLIDE 7
slide-8
SLIDE 8
slide-9
SLIDE 9 WV4002 Bold Beige
slide-10
SLIDE 10 WV4006 Tranquility WV4002 Bold Beige WV4010 Reflection WV4007 Spice WV4017 White Stitch WV4017 White Stitch

MIX & MATCH

WV4018 Ecru Hem WV4018 Ecru Hem WV4010 Reflection WV4007 Spice WV4019 Grey Stitch WV4019 Grey Stitch
slide-11
SLIDE 11 WV4017 White Stitch WV4010 Reflection
slide-12
SLIDE 12

#NOTJUSTFLOORING WOVEN:

Outdoor furniture

slide-13
SLIDE 13

Wallcovering Wallcovering & furniture Wallcovering Furniture Furniture Flooring Furniture Rug Accessories Stairs

slide-14
SLIDE 14 PHTHALATES FREE

TECHNICAL DATA SHEET

WALL COVERING

1 Woven Vinyl 70% PVC FR, 30% Polyester 2 Polyester Backing: 100% Polyester

1 2

Characteristics Test Woven Wall Covering Roll width 1,00 m Roll Length 30,00 m Roll diameter 0,22/0,24 m Thickness 1,50 mm Weight 760 gr/m² Chemical resistance EN 423 Class 0 Fire resistance EN 13501 B-S1 d0 UV resistance ISO 105-B02 ≥Grade 8 Fungus test ASTM G21 96 Grade 1 Skew and Bow EN 427 Max 2% Dimensional Stability EN 434:1994 0,05% (X + Y Direction) Curling EN 434:1994 1,5 mm Chemical Resistant Fire Retardant Ecological Silent UV Ray Resistant Waterproof
slide-15
SLIDE 15

WALL COVERING

TECHNICAL PROPERTIES/DETAILS

Floover wall covering is a woven vinyl collection available in difgerent decors. The textile nature
  • f this product and its fabrication process make it
have some aspects to be considered:
  • 1. BATCH LOT:
Because of textile process, the batch control must be considered, since is possible some little difgerence in color from 1 batch to another. It is specifjed in each roll label: Fab Week: 14 05 0032 Year Week Production Number Special designs can be considered, but must be an ap- proval process. Minimum 1000 m² and price must be +5% due to all set up process.
  • 2. SKEW AND BOW:
Due to the textile manufacturing process, there could ap- pear certain deviations that would afgect the fjnal result
  • f the roll. Deviation lower than 2,5 % must be accepted,
it means that for every lineal meter the threat mustn’t be deviated more than 2,5 cm.
  • 3. ROLL WIDTH:
The width of the roll is minimum 2000 mm, with possible + 50 mm. In case of narrow width it will be advice. Special width can be considered, but waste must be con- sidered and confjrmed in each case. Also pallet system will be afgected.
  • 4. ROLL LENGTH:
The length of the roll is min 10 m, some extra length can be considered in some cases. Special lengths can be considered, but waste must be considered and confjrmed in each case. Also pallet sys- tem will be afgected.
  • 5. DIRECTION OF THE ROLL:
It’s important for a design consistency, during installation. The direction of application must be respected.
  • 6. FLAWS:
No Flaws accepted <2,5%
slide-16
SLIDE 16

WALL COVERING

STORAGE

ROLLS:

Wallcovering roll size: 1,00 x 30,00 m Roll diameter: 0,22- 0,24 m

CARTON:

Carton size: 0,5 x 0,5 x 1,05 m There are four rolls in one carton. Pallet top view Pallet front view

PALLET:

1,10m x 1,10m 8 cartons/pallet

CONTAINER:

20 ft: 10 pallets/container Container top view Container front view Tube protection Specification for roll (m) Carton Pallet Container W L T M2 Pcs (EA) M2 Carton (EA) M2 Pallet (EA) M2 1,0 30,0
  • 30
4 120 8 960 10 9600 CE CERTIFICATION: On each label is specifjed the 4 certifjcates required for European CE certifjcation, in relationwith fmooring must be accomplish the EN-16:
  • 1. Energy Saving Environmenal PCP
  • 2. Sliping Security DS
  • 3. Emisions Security/Environmental HCHO
  • 4. Fire Resistance Security/Environmental B-S1 d0
slide-17
SLIDE 17

MARKETING TOOLS

WOVEN CATALOGUE 2016 WOVEN STRATEGY BOOK WOVEN SWING SET TAILOR MADE SWATCH

slide-18
SLIDE 18
slide-19
SLIDE 19
slide-20
SLIDE 20
