Word Embedding Praveen Krishnan CVIT, IIIT Hyderabad June 22, 2017 - - PowerPoint PPT Presentation

Word Embedding

Praveen Krishnan

CVIT, IIIT Hyderabad

June 22, 2017

1

Outline

Introduction Classical Methods Language Modeling Neural Language Model Challenges of SoftMax Hierarchical Softmax Margin Based Hinge Loss Sampling Based Approaches Word2Vec

Noise Contrastive Estimation Negative Sampling

2

Philosophy of Language

“(...) the meaning of a word is its use in the language.”

• Ludwig Wittgenstein

Philosophical Investigations - 1953

Slide Credit: Christian Perone, Word Embeddings - Introduction

3

Word Embedding

◮ Word embeddings refer to dense representations of words in a

low-dimensional vector space which encodes the associated semantics.

◮ Introduced by Bengio et. al. NIPS’01. ◮ The silver bullet for many NLP tasks.

4

Word Embedding

The Syntactic and Semantic Phenomenon

◮ Morphology, Tense etc. ◮ Vocabulary Mismatch [Synonymy, Polysemy] ◮ Topic vs. Word Distribution

Reasoning vs. Analogy

w(athens) − w(greece) ≈ w(oslo)−? w(apples) − w(apple) ≈ w(oranges)−? w(walking) − w(walked) ≈ w(swimming)−?

5

Word Embedding

The Syntactic and Semantic Phenomenon

◮ Morphology, Tense etc. ◮ Vocabulary Mismatch [Synonymy, Polysemy] ◮ Topic vs. Word Distribution

Reasoning vs. Analogy

w(athens) − w(greece) ≈ w(oslo) − w(norway) w(apples) − w(apple) ≈ w(oranges) − w(orange) w(walking) − w(walked) ≈ w(swimming) − w(swam)

6

Word Embedding

◮ Sparse-to-Dense. ◮ Unsupervised learning. ◮ Typically learned as a by-product* of language modeling problem.

7

Classical Methods - Topic Modeling

Latent Semantic Analysis [Deerwester et. al. ’1990]

Project terms and documents into a topic space using SVD on term-document (co-occurrence) matrix.

8

Classical Methods - Topic Modeling

Latent Dirichilet Allocation [Blei et. al ’2003]

◮ Assumes generative probabilistic model of a corpus. ◮ Documents are represented as distribution over latent topics,

where each topic is characterized by a distribution over words.

Figure 1: Plate notation representing the LDA model. Source: Wikipedia

9

Language Modeling

Probabilistic Language Modeling

Given a set of words, does they form valid construct in a language. p(w1, . . . , wT) =

• i

p(wi|w1, . . . , wi−1) p(′high′,′ winds′,′ tonight′) >p(′large′,′ winds′,′ tonight′) Using Markov assumptions:- p(w1, . . . , wT) =

• i

p(wi|wi−1, . . . , wi−n+1)

Applications

Spell correction, Machine translation, Speech recognition, OCR etc.

10

Language Modeling

Probabilistic Language Modelling

◮ nGram based model:-

p(wt|wt−1, . . . , wt−n+1) = count(wt−n+1, . . . , wt−1, wt) count(wt−n+1, . . . , wt−1)

11

Language Model

Neural Probabilistic Language Model

Bengio et. al. JMLR’03

12

Language Model

Neural Probabilistic Language Model

p(wt|wt−1, . . . , wt−n+1) = exp(hTvwt)

• wi∈V exp(hTvwi) ⇒ Softmax Layer

Here h is the hidden representation of input, vwi is the output word embedding of word i and V is the vocabulary.

Bengio et. al. JMLR’03

12

Neural Probabilistic Language Model

◮ Associate each word in vocabulary a distributed feature vector. ◮ Learn both the embedding and parameters for probability function

jointly.

Bengio et. al. JMLR’03

13

Softmax Classifier

Figure 2: Predicting the next word with softmax

Slide Credit: Sebastian Ruder. Blog On word embeddings - Part 2: Approximating the Softmax.

14

Challenges of SoftMax

One of the major challenges in previous formulation is the cost of computing the softmax which is O(|V |) (typically > 100K)

Major works:-

◮ Softmax-based approaches [Bringing more efficiency]

◮ Hierarchical Softmax ◮ Differentiated Softmax ◮ CNN-Softmax

◮ Sampling-based approaches [Approximating the softmax using a

different loss function]

◮ Importance Sampling. ◮ Margin based Hinge loss. ◮ Noise Contrastive Approximation ◮ Negative Sampling ◮ ... 15

Hierarchical Softmax

◮ Uses a binary tree representation of output layer with leaves

belonging to each word in vocabulary.

◮ Evaluates at-most log2(|V |) nodes instead of |V | nodes. ◮ Parameters are stored only at internal nodes, hence total

parameters same as regular softmax. p(right|n, c) = σ(hTvn) p(left|n, c) = 1 − p(right|n, c)

Figure 3: Hierarchical Softmax: Morin and Bengio, 2005

16

Hierarchical Softmax

Figure 4: Hierarchical Softmax: Hugo Lachorelle’s Youtube lectures

◮ Structure of tree important for further efficiency in computation

and performance.

◮ Examples:-

◮ Morin and Bengio: Using synsets in WordNet as clusters of tree. ◮ Mikolov et. al.: Use Huffman tree which takes into account the

frequency of words.

17

Margin Based Hinge Loss

C&W Model

◮ Avoids computing the expensive softmax by reformulating the

• bjective.

◮ Train a network to produce higher scores for correct word windows

than incorrect ones.

◮ The pairwise ranking criteria is given as:-

Jθ =

• x∈X
• w∈V

max{0, 1 − fθ(x) + fθ(x(w))} Here x is the correct windows and xw is the incorrect windows created by replacing the center word and fθ(x) is the score output by the model.

18

Sampling Based Approaches

Sampling based approaches approximates the softmax by an alternative loss function which is cheaper to compute.

Interpreting logistic loss function

Jθ = − log exp(h⊤v′

w)

• wi∈V exp(h⊤v′

wi)

Jθ = − h⊤v′

w + log

• wi∈V

exp(h⊤v′

wi)

Computing gradient w.r.t. model params, we get ∇θJθ = ∇θE(w) −

• wi∈V

P(wi)∇θE(wi) where − E(w) = h⊤v′

w

19

Sampling Based Approaches

∇θJθ = ∇θE(w) −

• wi∈V

P(wi)∇θE(wi) The gradient has two parts:-

◮ Positive reinforcement for target word . ◮ Negative reinforcement for all other words weighted by its

probability.

• wi∈V

P(wi)∇θE(wi) = Ewi∼P[∇θE(wi)] To avoid this all sampling based approaches approximates the negative reinforcement.

20

Word2Vec

◮ Proposed by Mikolov et. al. and widely used for many NLP

applications.

◮ Key features:-

◮ Removed hidden layer. ◮ Use of additional context for training LM’s. ◮ Introduced newer training strategies using huge database of words

efficiently.

Word Analogies

Mikolov et. al. 2013

21

Word2Vec - Model Architectures

Continuous Bag-of-Words

◮ All words in the context gets

projected to the same position.

◮ Context is defined using both history

and future words.

◮ Order of words in the context does

not matter.

◮ Uses a log-linear classifier model.

Jθ = 1 T

T

• t=1

log p(wt | wt−n, · · · , wt−1, wt+1, · · · , wt+n)

Mikolov et. al. 2013

22

Word2Vec - Model Architectures

Continuous Skip-gram Model

◮ Given the current word, predict the

words in the context within a certain range.

◮ Rest of ideas follow CBOW.

Jθ = 1 T

T

• t=1
• −n≤j≤n,=0

log p(wt+j|wt) Here, p(wt+j | wt) = exp(v⊤

wtv′ wt+j)

• wi∈V exp(v⊤

wtv′ wi)

Mikolov et. al. 2013

23

Noise Contrastive Estimation

Key Idea

Similar to margin based hinge loss, learn a noise classifier which differentiates between a target word and noise.

◮ Formulated as a binary classification

problem.

◮ Minimizes cross entropy logistic loss. ◮ Draws k noise samples from a noise

distribution for each correct word.

◮ Approximates softmax as k increases.

Gutmann, M. et. al.’ 2010

24

Noise Contrastive Estimation

Distributions

◮ Empirical: (Ptrain) Actual distribution given by the training

samples.

◮ Noise: (Q)

◮ Easy to sample. ◮ Allows analytical expression to log pdf. ◮ Close to actual data distribution. E.g. Uniform or empirical

unigram.

◮ Model: (P) Approximation to empirical distribution.

Notation

For every correct word wi along with its context ci, we generate k noise samples ˜ wik from a noise distribution Q. The labels y = 1 for all correct words and y = 0 for noise samples.

Gutmann, M. et. al.’ 2010

25

Noise Contrastive Estimation

Objective Function

Jθ = −

• wi∈V

[log P(y = 1 | wi, ci) + k E ˜

wik∼Q[ log P(y = 0 | ˜

wij, ci)]] Using Monte Carlo approximation:- Jθ = −

• wi∈V

[log P(y = 1 | wi, ci) + k

k

• j=1

1 k log P(y = 0 | ˜ wij, ci)]

Gutmann, M. et. al.’ 2010

26

Noise Contrastive Estimation

The conditional distribution is given as:- P(y = 1 | w, c) = 1 k + 1Ptrain(w | c) 1 k + 1Ptrain(w | c) + k k + 1Q(w) P(y = 1 | w, c) = Ptrain(w | c) Ptrain(w | c) + k Q(w) Using model distribution:- P(y = 1 | w, c) = P(w | c) P(w | c) + k Q(w) Here P(w | c) = exp(h⊤v′

w)

• wi∈V exp(h⊤v′

wi) corresponds to softmax

function.

Gutmann, M. et. al.’ 2010

27

Noise Contrastive Estimation

NCE Trick

Treats the normalization denominator as a parameter that model can learn. Also called as self-normalization.

P(w | c) = exp(h⊤v ′

w)

Z(c)

The modified conditional distribution using Z(c) = 1 [Mnih et. al. 2012]:-

P(y = 1 | w, c) = exp(h⊤v ′

w)

exp(h⊤v ′

w) + k Q(w)

NCE Loss

Jθ = −

• wi∈V

[log exp(h⊤v ′

wi)

exp(h⊤v ′

wi) + k Q(wi)+ k

• j=1

log(1− exp(h⊤v ′

˜ wij)

exp(h⊤v ′

˜ wij) + k Q( ˜

wij))]

Gutmann, M. et. al.’ 2010

28

Negative Sampling

◮ Negative sampling (NEG) is a simplification of NCE. ◮ No longer approximates softmax as the goal is to learn high quality

word embedding thereby inappropriate for language modeling. Recall the conditional probability of NCE:- P(y = 1 | w, c) = exp(h⊤v′

w)

exp(h⊤v′

w) + k Q(w)

NEG sets kQ(w) = 1, which gives:- P(y = 1 | w, c) = exp(h⊤v′

w)

exp(h⊤v′

w) + 1 =

1 1 + exp(−h⊤v′

w)

Mikolov et. al. 2013

29

Negative Sampling

NEG Loss

Plugging back to logistic regression loss, we get:- Jθ = −

• wi∈V

[log 1 1 + exp(−h⊤v′

wi) + k

• j=1

log (1 − 1 1 + exp(−h⊤v′

˜ wij)]

Jθ = −

• wi∈V

[log σ(h⊤v′

wi) + k

• j=1

log σ(−h⊤v′

˜ wij)]

Here σ(x) = 1 1 + exp(−x) NEG loss is equivalent to NCE when k = |V | and Q is uniform.

Mikolov et. al. 2013

30

References

Sebastian Ruder, On word embeddings - Part 1, http: //sebastianruder.com/word-embeddings-1/index.html Sebastian Ruder, On word embeddings - Part 2: Approximating the Softmax, http://sebastianruder.com/ word-embeddings-softmax/index.html

31

Thanks for the attention.

32
