Women in Big Data x Pinterest Welcome! Regina Karson, WiBD Chapter - - PowerPoint PPT Presentation

Women in Big Data x Pinterest

Welcome!

Regina Karson, WiBD Chapter Director Tian-Ying Chang, Engineering Manager

Goku: Pinterest’s in house Time-Series Database

Tian-Ying Chang

• Sr. Staff Engineer Manager

Pinterest

• Discover new ideas and find

inspiration to do the things they love ○ 300M+ MAU, billions pins

• Metrics for monitoring site health

○ Latency, QPS, CPU, memory

• Metric about product quality

○ MAU, Impression, etc

• Monitoring service needs to be fast,

reliable and scalable

Pinterest

• Graphite

○ Easy to setup at small scale ○ Down sampling support long range query well ○ Hard to scale ○ Deprecated at Pinterest’s current scale

• OpenTSDB

○ Rich query, tagging support ○ Easy to scale horizontally with underlying HBase cluster ○ Long latency for high cardinality data ○ Long latency for query over longer time range ■ No down sampling ○ Heavy GC worsened by combined heavy write QPS and long range scan

Monitoring at Pinterest

• HBase Schema

○ Row key: <metric><timestamp>[<tagk1><tagv1><tagk2><tagv2>...] (metric, tag key values are encoded in 3 bytes) ○ Column qualifier: <delta to row key timestamp(up to 4 bytes)>

• Unnecessary Scan

○ Query: m1{rpc=delete} [t1 to t2] ○ <m1><t1><host=h1><rpc=delete> ○ <m1><t1><host=h1><rpc=get> ○ <m1><t1><host=h1><rpc=put> ○ <m1><t2><host=h2><rpc=delete>

• Data size

○ 20 bytes per data point

• Aggregation

○ Read data onto one opentsdb and aggregate ○

• Ex. ostrich.gauges.singer.processor.stuck_processors{host=*}
• Serialization

○

• Json. Super slow when there are many many data points to return

Why OpenTSDB is not good fit

HBase RS HBase RS HBase RS

OpenTSDB

Goku is here to save

Statsboard (Read Client) Ingestor (Write Client) Kafka

OpenTSDB

HBase RS HBase RS HBase RS OpenTSDB

• Read/|Write requests are sent to a

random selected OpenTSDB box, and then routed to corresponding RS based

• n row key range
• Reads: raw data is read from individual

HBase RS, send to OpenTSDB box, then aggregated at openTSDB, then send result to client

Write Read

Statsboard (Read Client) Ingestor (Write Client) Kafka Goku Goku Goku Goku

Goku cluster

• A Goku box is not only storage

engine, but also: ○ Proxy that route requests ○ Aggregation engine

• Client can send requests to any Goku

box who will route requests ○ Scatter and Gather

Write Read

Two level sharding

• Group# hashed from metric name

○ E.g tc.metrics.rpc_latency

• Shard# hashed from metric + set
• f tagk and tagv

○ E.g.

• Control read fanout while easy to

scale out individual group

Goku

Shard config

Goku #1. Time Series Database based on Beringei

Beringei

• In-memory key value store

○ Key: string ○ Value: list of <timestamp, value> pairs

• Gorilla compression

○ Delta-of-Delta encoding on timestamps ○ Delta encoding on values

• Stores most recent 24 hours data

(configurable)

• One level of sharding to distribute
• Datapoint size reduced

○ from 20 bytes to 1.37 bytes

Disk

Beringei

Shard

Goku #2. Query Engine -- Inverted Index

Inverted Index

• A map from search term to its bitset
• Built along with processing incoming data

points

• Fast lookup when serve query
• Support query filters

• n the filter values and then iterate corresponding full

DISK

Goku Phase #1

Shard

Goku #3. Query Engine -- Aggregation

Aggregation

• Post-process after retrieving all relevant time

series

• Mimic OpenTSDB’s aggregation layer
• Support basic aggregators, including SUM,

AVG, MAX, MIN, COUNT, DEV and Downsampling

• Versus OpenTSDB

○ OpenTSDB does aggregation on a single instance since HBase RS don’t know how to aggregate ○ Goku does aggregation in two phases. First on each leaf goku node, and second on the routing goku node ○ Distribute the computation and save data on the wire

DISK

Aggregation

Goku Phase #1

Shard

AWS EFS

AWS EFS

• Store log and data files to recovery
• Posix compliant
• Data durability
• Operate it asynchronously, so latency isn’t an

issue

• Easy to move shard
• Easy to use on AWS

AWS EFS

Aggregation

Goku Phase #1

Shard

Phase #2 Disk based Goku

AWS EFS

Aggregation

Group

Goku Phase #2

Shard Distributed KV store(Rock Store) Hadoop job

Goku Phase #2 -- Disk based

• Hadoop job constantly

runs to compact data into disk with downsample

• Data stored into S3 for

better availability and low cost

• RocksDB is used for
• nline serving data

S3

• Replication

○ Currently dule write to two clusters for fault tolerance ○ Replication to improve availability and consistency

• More query possibilities

○ TopK ○ Percentile

• Analytics use case

○ Another big consumer of Time Series data

Next step for Goku

Thanks!

Scheduling Asynchronous Tasks at Pinterest

Isabel Tallam Data (Core Services) Team Pinterest

Why asynchronous tasks? Asynchronous task processing service Design considerations

Why asynchronous tasks?

SPAM S P A M % $ # *

%$#*

%$#* SPAM SPAM SPAM

Why asynchronous tasks? Asynchronous task processing service Design considerations

Pinlater

Asynchronous Task Processing Service

Pinlater features

• High throughput
• Easily create new tasks
• At-least-once guarantee
• Strict ack mechanism
• Metrics and debugging support
• Different task priorities
• Scheduling future tasks
• Python, Java support

Pinlater

Asynchronous Task Processing Service

Pinlater Servers Pinlater Servers

Pinlater Servers

Clients Pinlater Workers Pinlater Workers

Pinlater Workers

Storage

Master Slave

Storage

Master Slave

Storage

Master Slave

Clients

Clients

Pinlater components

insert request /ack

Pinlater

Asynchronous Task Processing Service

Pinlater Stats ~1000 different tasks defined ~8 billion task instances processed per day ~3000 Pinlater hosts

Why asynchronous tasks? Asynchronous task processing service Design considerations

Storage

Pinlater

Asynchronous Task Processing Service

Pinlater Servers Pinlater Servers

Pinlater Servers Storage

Master Slave

Storage Layer

Master Slave Storage

Master Slave

Cache

Pinlater

Asynchronous Task Processing Service

Pinlater Servers

Pinlater Servers

Clients Pinlater Workers

Pinlater Workers Pinlater Workers

Clients

Clients

insert request

Handling failures in the system

/ack timeout monitor

Storage

Master Slave

Pinlater Servers

Pinlater

Asynchronous Task Processing Service

Thank You!

Experimentation at Pinterest

Lu Yang Data (Data Analytics - Core Product Data) Team Pinterest

Outline

1 Background 2 Platform 3 Architecture

What is an a/b experiment?

It is a method to compare two (or more) variations of something to determine which

• ne performs better against your target metrics

OR

With Experiment Mindset

Idea → Feature Development → Release to small % of users → Measure impact → Release to 100% of users based on the impact of sample launch A randomized, controlled trial with measurement

Existing code

• CONTROL

Changed code

• ENABLED

Not in experiment All Users

Number of Experiments Over Time

New Experiments/wk

7

Languages and platforms

800+

Different Metrics

<5min

Experiment setup

8.3/10

Developer satisfaction score

140+

Experimentation by the Numbers

Outline

1 Background 2 Platform 3 Architecture

Typical Experiment Timeline

Experiments vary, but here is a typical timeline

Idea Form a hypothesis Analyze results Make Decision and Iterate Experiment Setup and Launch Iterate Feature Development

Experimentor

Platform

Gatekeeper

Platform

Languages: python, java, scala, go, … Platform: web, ios, android, ...

Experiment Dashboard

Platform

Outline

1 Background 2 Platform 3 Architecture

Batch processing Real-time analytics

Experiment Data Pipeline

Hbase

Airflow at Pinterest

Indy Prentice Data (Big Data Compute) Team Pinterest

What is a workflow?

Define

What to run, dependencies, etc. When to run it

Schedule

Scheduled with Pinball

*check it out at https://github.com/pinterest/pinball!

coordinator worker

train the visual search model make the search index rank the ads free spot!

worker

download all pin images count number of Pinterest users (get it?) find great recommendations calculate experiment metrics

Fixed number of workers and slots

Unfortunately…

free spot!

Fixed number of workers and slots

coordinator worker

train the visual search model free spot!

worker

free spot! free spot! free spot! free spot! calculate experiment metrics

Fixed number of workers and slots

coordinator worker

train the visual search model make the search index rank the ads find duplicate pin images

worker

calculate experiment metrics find great recommendations download all pin images count number of Pinterest users

Fixed number of workers and slots Shared environment

Unfortunately…

Shared host resources

coordinator worker worker

generate experiment metrics index the pins download all pin images count number of Pinterest users train the visual search model make the search index rank the ads free spot!

Shared codebase

coordinator worker worker

generate experiment metrics index the pins download all pin images count number of Pinterest users train the visual search model make the search index rank the ads free spot!

Fixed number of workers and slots Shared environment Implementation doesn’t scale

Unfortunately…

• Industry + community support
• Will it support our scale?

○ We think so

• Will it solve the problems with Pinball?

○ With Kubernetes executor

Enter Spinner

(get it???)

Jobs run in containers Containers are scheduled by kubernetes Scheduler submits jobs to run on k8s

Physical machine (8 CPUs, 10 GBs of disk space) Can’t touch this

Train the visual search model (4 CPUs, 4 GBs of disk space) Download all images (10 GBs of disk space) Generate experiment metrics (2 CPUs, 1 GB of disk space)

Enter Spinner

(get it???)

Jobs run in containers Containers are scheduled by kubernetes Scheduler submits jobs to run on k8s

train the visual search model make the search index rank the ads generate experiment metrics index the pins write 10TB of data to disk! count number of Pinterest users

Tasks Servers

Enter Spinner

(get it???)

Jobs run in containers Containers are scheduled by kubernetes Scheduler submits jobs to run on k8s

Autoscaling happens at k8s level Jobs run in isolated containers Lightweight maintenance

On Airflow...

• Integration with Pinterest k8s

infrastructure

• Scheduler scalability
• Integration with existing

composers

Airflow @ Pinterest

Adoption challenges

Machine Learning and Big Data on K8S at Pinterest

June Liu Infrastructure (Core Cloud - Cloud Management Platform) Team Pinterest

• Motivation
• Architecture
• Journey to K8S
• The Future

Agenda

Motivation

• Unify orchestration and big data

infrastructure

○ simplify tech stack and reduce operation

• verhead
• Trending in community support of ML

and BD workloads on K8S

• Better interfaces and richer feature

including CNI, CSI, Autoscaling, etc

Architecture

Journey to Kubernetes

Sidecar

No good support for sidecar lifecycle of run-to-finish Pod

• A lot of sidecars to nanny workloads

○ Security ○ Metadata ○ Logs ○ Metrics ○ Traffic, Service discovery ○ ...

Sidecar

No good support for sidecar lifecycle of run-to-finish Pod

• Kill Pod?

○ Pod recreated due to reconcile

• Force mark Pod state?

○ Confuses scheduler and Kubelet

• Docker kill sidecar?

○ Messed up with Restart Policy

• Inter container signals?

○ Not scalable in operation

Sidecar

No good support for sidecar lifecycle of run-to-finish Pod

• Write our own and contribute!

○ Main container obeys restart policy, sidecar always restart ○ Kill sidecar after main containers quits ○ Pod phase computed based on main container exit code

https://github.com/zhan849/kubernetes/tree/pinterest-sidecar-1.14.5

Volume

Is PVC really an option for serving models?

• Ideally

○ Flexibility to select storage medium ○ Data isolation ○ Dynamic provisioning saves money ○ ...

Volume

Is PVC really an option for serving models?

• Actually…

○ EBS provisioner is not efficient, nor is EC2 ○ ~100% 500s with batch EBS provisioning

Volume

Is PVC really an option for serving models?

• DescribeInstance: by name -> by ID (#78140)
• Optimize EBS provisioner cloud provider

calls (#78276)

Batch Size Total Calls Peak QPS Original Optimized Original Optimized 50 1360 116 52 8 75 1464 139 70 10 100 2427 157 75 8 150 4384 209 93 11

AutoScaling

Node scales slower than Pod

• This is expected or container becomes

meaningless

• Long tail scheduling Parameter Servers

and cause job to fail

• Use bogus pods with low priority as

cluster buffers to scale in advance

Our Future

Future Works

Node scales slower than Pod

• Gang scheduling
• Federation layer takes care of data /

network locality

• Fine-grained preemption, task queuing
• More caching storage options (PVC/EBS)

○ https://github.com/kubeflow/community/pull/263
