Wisycom and Semafor

WISYCOM PRESENTATION

PRODUCTS OVERVIEW RF DISTRIBUTION RF OVER FIBRE NEW TECHNOLOGIES Monitor Roadshow 2019 OCTOBER 2019 Björn Zabell

Wisycom presentation

Wisycom designs, produces and shares experience and know-how. With more than 30 years of experience in RF technology Wisycom is recognized as one of the main player in the worldwide market of Audio equipment for Broadcast, Live and Location Sound applications. Research & Development Focused on innovation and best quality Wisycom’s team of engineers design the most sophisticated RF solutions for microphones, IFB and reportage system using the latest technological instruments and the most advanced software. Production All Wisycom products are 100% Made in Italy, synonymous of reliability, flexibility and careful quality control on each product. Customer Service International TV, Radio broadcasters, Audio operators and Sound engineers can find in Wisycom team a true partner ready to offer worldwide constant presence and support for the realization of any project.

Wisycom presentation

BIG SPORT EVENTS OUTDOOR AND ENG STUDIO BROADCAST RF DISTRIBUTION LIVE SHOWS LOCATION SOUND

WHERE CAN WISYCOM BE FOUND?

Spectrum evolution

WHY ULTRAWIDE BANDWIDTH? The reason is simple: Digital Dividend, 4G and in future 5G are progressively reducing the UHF spectrum available for radio-microphones. It’s not a secret that the 700-800MHz band will be totally gone in the close future and we do expect the 5G to be reduced too in EU as well as it is, for example in USA. This make the market asking for more flexible device and here is where Wisycom steps in.

2010/2014 790/840 MHz 2017/2020 700/790 MHz DVB T2? Further channel squeezing for 4k? Single Frequency Network (SFN)

EUROPE

2010/2014 700/800 MHz

2014 AUCTION

Effective 2016 600/700 MHz DVB T2? Further channel squeezing for 4k? Single Frequency Network (SFN)?

USA

Working smoothly in those present/future spectrum scenarios, is therefore one essential feature for the newest wireless systems: Main technical parameters involved are related to: ü Bandwidth agility (capability of wide-tuning) ü Spectral efficiency (width of my modulation or minimum channel spacing) ü Spectral clean (capability of generate low intermodulation)

Wireless Audio Requirements

SUMMARIZING FUTURE TV SHRINKING WILL:

REDUCE

BAND AVAILABLE FOR WIRELESS MIC

INCREASE

TV SIGNAL LEVELS & INTERFERENCES WIRELESS MIC MUST BE USE

LESS BANDWIDTH

WIRELESS MIC MUST BE

MORE ROBUST TO INTERFERENCES

Spectrum evolution

NARROWBAND TRANSMISSION

100 kHz 200 kHz

Wisycom offers different options to be as most efficient as possible RF wise, optimizing it’s carriers by reducing the band occupation and being able of fitting a huge number of transmitters in a smaller amount of space. This new narrowband technology allow the user to have only 200KHz of separation between the two carriers, compared to the 400Khz that we’re used to with wide band analogue and 500 to 600KHz for the average digital system. All this, moreover, is done without loosing any sensitive audio quality as the audio is incredibly linear up to 17KHz.

Digital MIC (500/600 kHz ch. spacing) FM & “DSP Enhanced FM” MIC (300/400 kHz ch. spacing) “Narrowband DSP Enhanced FM” MIC (200/250 kHz ch. spacing)

Spectrum evolution

• On the right figure, the spectrum of 3 couples of microphones

using different modulation.

• Level is the minimum level that system allows to work (i.e. you

RF squelch). System robusteness: “Narrowband-dsp-FM” is at least 15 dB more robust than Digital” and 3 dB more robust than legacy FM. 15 dBuV could be a good example of noise on a TV channel after the 700 MHz shitch off: à Under this condition coverage will be heavily reduced and 15 dB of extra margin will be very important for medium to big installations (i.e. theater, studios).

500/600 kHz 300/350 kHz 200/250 kHz 10 dBuV 15 dBuV 20 dBuV 25 dBuV 30 dBuV

DIGITAL Narrowband DSP-FM Channel Noise (*)

12/15 dB 6 dB

Filter area under the noise level is the actual internal system interference. Wider bandwidth brings to an higher internal noise. Digital Mic have about 1/2 dB more noise than an FM system. standard FM has about 3/4 dB more noise than Narrowband DSP FM. Average digital system needs at least 13 dB S/N,

• f distance from noise

level Wisycom analogue Wideband 6dB MINIMUM RX LEVEL TO WORK WITH DIFFERENT TECHNOLOGIES & 15 dbuV of noise (RBW 200kHz)

MRK980

MRK980 TRUE DIVERSITY DUAL RECEIVER

Wisycom MRK980 is a true diversity, ultra-wideband dual channel receiver. With its 1090MHz of band switching, it ensures the users an exceptional band flexibility, combined with a superb selectivity and inter-modulation immunity, for best operating performances

• f the wireless microphone systems. MRK980 also features an internal DSP processor,

Wisycom famous Multicompanding system, new Dante compatibility and a completely and renewed user interface, which make this system easy and quick to setup.

MAIN FEATURES

• Two channels True Diversity receiver (full DSP processed)
• Up to 1090 MHz bandwidth from 170MHz to 1160Mhz
• Push to talk (PTT) incorporated
• Multicompander system
• Dante machine syncronized
• Wideband and Narrowband DSP-FM operation
• Expansion boards slot for RFoF and monitor functions

MRK980 – Expansion Board EXP1

EXP1 is an optional accessory which can be mounted on MRK980 dual channel receiver. This expansion board enables three different features:

• Zoning signal distribution
• External monitoring

cascade

• Two GP OUT

This new board transform the MRK980 into a customizable and incredibly versatile receiver, with several unique options. The external audio monitoring function allows several MRK980 to be connected in cascade through the “Monitor I/O”, in

• rder

to enable an additional auxiliary audio output common to all receivers. Activated by a front panel button, it allows an additional audio monitoring interface to be obtained, in addition to the standard headphones output: this auxiliary slot consists of two mini XLR 5 pins: 1 IN, 1 OUT.

SELECT AUDIO SOURCE

Unit 1 Unit 2 Unit 3 Unit 4

EXTERNAL MONITORING CASCADE

EXP1

MRK980 – Expansion Board EXP1

The Zoning (or N Diversity) signal distribution function consists of connecting different MRK980 receiver audio

• utputs in cascade. These receivers are all tuned to the same frequencies and connected through 3 pin XLR
• connectors. This type of configuration results in having the audio signal shared between the MRKs, so it’s analyzed

by the receivers and the one with the best quality signal will be picked to send the audio out. In the example below we have three different zones (3x A / B antennas) connected to three distinct MRK980s. The receivers, in turn, are connected to each other through the expansion board auxiliary audio outputs. In the “master” receiver Main audio output (Unit 3) we will have the best audio signal resulting from the comparison

• f the three MRK980s in relation to the areas of use.

A1 – B1 Unit 1 Unit 1 Unit 2 Unit 3 A1 – B1 Unit 2 A1 – B1 Unit 3

ZONING (OR N DIVERSITY)

MRK980 – Expansion Board EXP2

EXP2 is an optional accessory which can be mounted on MRK980 dual channel receiver. This expansion board enables three different features:

• Zoning I/O
• External monitoring

cascade

• RF over Fiber Rx modules

EXP2

MRK980 – EXP2 MFL TT-- Antenna A Antenna B

These two wideband receiving optical modules allow the MRK980 to receive RF over fiber signals from a source like Wisycom MFL and open the door to a completely new way of receiving antennas signals from further areas. This implementation massively enlarge the MRK980 reception possibilities by allowing to replace the regular coax cable with optical patches which have an average loss of 0.4dB per Km

• nly!

RF OVER FIBER MODULES

LINEAR series & channel density

MTP40S LINEAR MTB40S MPR50 - IEM

TRANSMITTERS

MTH410 MPR52 - ENG

• 232 Mhz of Bandswitching
• 2400 preloaded frequencies
• LINEAR technology
• Up to 100mW RF power
• Up to 14 hours of battery life
• 790 Mhz of Bandswitching
• 2400 preloaded frequencies
• Dual channel atnenna diversity

Receiver

• USB connection
• Up to 6 hours of battery life
• 230 Mhz of Bandswitching
• 2400 preloaded frequencies
• Stereo channel true diversity

Receiver

• USB connection
• Up to 6 hours of battery life

RECEIVERS

MAT288 Matrix/Combiner

MAT288 is a unique device able to select and combine radiofrequency feeds in a matrix of up to 8 diversity inputs. It allows your control room to smoothly select one or more studio to work with! MAIN FEATURES

• Diversity combiner 8:1 or 8:4 or 2 x 4:2 (sw configurable)
• Wide bandwidth 150-840 MHz operation
• Redundant power supply, AC and DC powered
• Remote management and monitor of alarms thru Ethernet 10/100 base TX
• Antenna booster supply toggled on each input independently
• Voltage and current monitoring on each booster supply with alarm
• Programmable attenuators on each inputs
• Remote boost control (for gain/bandwidth) with a bidirectional data link thru coax (input BNCs)
• light window where the user can enter their own text to identify the 8 areas

MAT288 WITH LFA ANTENNAS

This slide shows how the MAT288 can turn a complex antenna system into a very reliable and controlled one. With the MAT288 we can control and monitor the RF conditions of 8 different Diversity areas, by checking the RF levels and turning ON and OFF the un needed locations to avoid the risk of non wanted interferences. Through the MAT we can also control and monitor the receiving antennas LFA (or BFA booster). This allow to have a full RF control on your computer from where you can easily modify every single device parameter and keep them monitored through the entire show. The MAT288 has three different configuration: 8:1, 8:4 (example below) and 2x4:2 which make this device very versatile.

LFA ANTENNAS LFA ANTENNAS LFA ANTENNAS LFA ANTENNAS LFA ANTENNAS LFA ANTENNAS LFA ANTENNAS LFA ANTENNAS

1 2 3 4 5 6 7 8

MAT288 MAT288 – RF Matrix Combiner

• Wideband RF Matrix (470-960)
• 8 different areas control
• Antenna remote control & monitoring
• Ethernet conenction for remote control

via Wisycom Manager

• Configurable in 8:1, 8:4 or 2x4:2

MAT288 Matrix/Combiner

Studio RF Example (Madrid)

STUDIO CONTROL ROOM STUDIO STUDIO STUDIO STUDIO STUDIO

Studio RF Example (Madrid)

Studio 1 (S1) Studio 2 (S2) Studio 3 (S3) Studio 4 (S4) Studio 5 (S5) Studio 6 (S6)

A1 A2 B1 B2 A1 A2 B1 B2 A1 A2 B1 B2 A1 A2 B1 B2 A1 A2 B1 B2 A1 A2 B1 B2

MAT288 (S1, S2, S3) CONFIGURATION 8:1 MAT288 (S4, S5, S6) CONFIGURATION 8:1 4x SPL2216 60x MRK980 True diversity dual channel receivers

24 x LFA filtered antennas

SPL 2208 CONTROL ROOM

MTK952 Dual Channel IEM Stereo Transmitter

MTK952 is a unique high power dual channel stereo transmitter buitl for IEM and IFB applications. It’s unique RF power of 2000mW together with an incredible audio definition thatnks to the ENS compander, have made this unit a must into boradcast and live world applications where big venues must be covered without losing any kind of relaibility. MAIN FEATURES

• 330MHz of bandwidth
• 2400 preloaded channels
• 2000mW of Max RF power out
• M/S master slave I/O for Iso Frequency applications
• Remote control via Ethernet
• Dual stereo channel
• Multicompandig system
• Digital Synthesis via DSP processor
• Intermodulation cancelling
• 0.4ms delay
• 20Hz to 20KHz audio response (mono) and 30Hz to 19Khz (Stereo)

Antennas and Boosters

LBNA2 ADBA ADB BAW LBN2 BAW

High RF robustness Gain up 15 dB High RF robustness Gain up 15/22 dB

Directional Directional Omni-directional Omni-directional High RF robustness Gain up 27 dB Integrated filter

LFA BAA BAA

+15 dB +22 dB

BFA BFA

• 12/+27dB

RF over FIbre

The optical fiber that enables light transmission is actually an assembly of 3 subcomponents: The core is made of glass (or, more accurately, silica) and it is the light-carrying part. The surrounding cladding provides the difference in refractive index that allows total internal reflection of light through the core. The coating, which is usually one or more layers of polymer, protects the core and cladding from from environmental and mechanical damages that might affect their optical or physical properties. The coating has no optical properties affecting the propagation of light within the fiber. RF OVER FIBER SYSTEM

RF over Fibre

Multimode fiber has light traveling in the core in many rays, called modes. The core may have an overall diameter of 9 µm for singlemode or 50 µm or 62.5 µm for multimode transmission. The cladding has an overall diameter of 125 µm. Combining the core and cladding diameters is the source of

• ptical fiber descriptors,

such as 50/125 µm or 62.5/125 µm The core diameter and its refractive index characteristics determine the light propagation path or paths within the fiber’s core. Singlemode fiber has a much smaller core, only about 9 microns, so that the light travels in only one ray (mode.)

Rf over Fibre

Optical Fibre

Core/ Cladding Æ

Single/Multi-mode Wavelenght λ

Attenuation

Bandwidth 62,5/125 µ Multi-mode 1st window 850 nm 4 dB/km 160 MHz/km 62,5/125 µ Multi-mode 2nd window 1310 nm 2 dB/km 200 MHz/km 50/125 µ Multi-mode 1st window

Standard Fibres nowadays available:

850 nm 3 dB/km 400 MHz/km 50/125 µ Multi-mode 2nd window 1310 nm 1 dB/km 800 MHz/km 9/125 µ Single-mode 2nd window 1310 nm 0,4 dB/km >20 GHz/km 9/125 µ Single-mode 3 rd window 1550 nm 0,2 dB/km >200 GHz/km

Wisycom MFL fiber system

MFL xxxx is the base of any Wisycom RF over Fibre Link. It’s 4 configurable laser slots have made this machine an iper configurable device can be adapted for any kind of application, indoor or out door, when the coax cables are not an option and something more reliable is required. MAIN FEATURES

• 490MHz of bandwidth
• 4 configurable Tx or RX laser slots
• SC / APC connectors for single mode fibers
• DC 12V redundant PSU
• Auxiliary port for external data (e.g. Camera signal)
• Internal RF filter tunable and band pass
• RF bars indation
• MUX/DEMUX sytem
• Remote control via Ethernet on Fibre
• Adjustable gain to compensate potential loss
• Bias to power up to 4 antennas

Wisycom MFL fiber system

Up to 4 plug-in boards (TX or RX) Up to 4 Tunable filter (only for TX fiber module) Optional (BF1) Wisycom MFL is a modular device which can accomodate up to 4 fiber modules (Tx or Rx) Both Transmitter and Receiver modules can work in: ANT mode: For remote antenna receiption IFB mode: For remote intercom/IEM transmittion for iso-frequency areas ANT mode layout: For remote antenna receiption

TX fiber MODULE ANT mode RX fiber MODULE ANT mode

FOR RECEPTION

T R MRK960 MAT288/ MAT244

CWDM LASERs to fit many RF channels over a single fiber Optional (OMS)

Tx1 Tx2 MFL-RRTT MFL-TTRR MTK952N

Master/Slave Option

A 2 x PAW Max power 200mW MRK960

TxA Rx2 TxB Rx1

B

RxA Tx2 RxB Tx1

Tx1+Tx2

Description: Two transmitting antennas on the remote area powered by the PAW Rf amplifier and one for local transmission (combined with CSA121T). Two antennas received on the local area, two receiving antennas on the remote area. Boosters powered directly by the MFL. Two ways configuration.

RFoF Example: full duplex with PAW

OB – VAN RACK MFL RRRR 2:1 Combiner REMOTE AREA FIBERBOX LFA/BFA booster RECEIVERS HIGH POWER TRANSMITTER

This is a situation where a large coverage is required on the field and reporters don’t want to carry big and heavy bags around the golf

• pitch. Our solution is to switch onto a RF over

fiber system, where you have a Local base (OB Van) and a remote area (playing field). We easily cover the full environment with receiving antennas running on the fiber patch and boostered directly from the Fiberbox, and a MTK952N 2Watts transmitter for IFB

• purpose. Note that the Fiberbox has three

different PSU possible combinations, so the

• nly thing you need to lay down is the fiber

patch, no power chords are needed!

Reporter only carries an handed mic and a bodypack receiver.

Example: RF over Fibre - Golf

MFL-RR-- MFL-TTRR

MAT288 MRK960 CSI16T MTK952

STUDIO A STUDIO B STUDIO C STUDIO D STUDIO E STUDIO F STUDIO G

CONTROL ROOM

RF OVER FIBRE SYSTEM MATRIX TRUE DIVERSITY RECEIVERS IEM/IFB TRANSMITTERS COMBINER

Fibre patch Transmission Reception

MFL-RRTT MFL-TT--

Example: TPC (Switzerland)

In this example all the receiving antennas are combined and controlled by the MAT288 located inside the central control room. Four of the remote areas (Studios D, E, F and G) are linked to the control room through the RF over fiber system. Studios A, B and C are connected through standard coax cable. MFL system allows you through the MUX/DEMUX system to use one single fiber patch to both receive and transmit signals from local to remote areas. Remote active antennas are all filtered thanks to the new Wisycom booster BFA which incorporates three different filtering modes.

CABBAGE STAGE

MFL TTRR

CONTROL ROOM

This setup shows how Wisycom RF over Fiber system is used to cover different areas in Times Square during the NYE celebretions. On the remote Cabbage Stage we re-amplify the RF signal with a MTK952 in Slave mode (up to 2Watts with ISO frequency), Militay Island and Main Stage use a PAW compact power amplifier (21dB Gain), 45° Street, which is just a intermediate antenna pole, uses a complete Fiberbox system with MFLC and MPA221 power amplifier (up to 2Watts) and lithium batteries for stand alone use.

45° STREET

MFLC TTRR

Example: New Year Eve – New York

LFA/BFA booster PAW booster MILITARY ISLAND

MFL TTRR

MAIN STAGE

MFL TTRR

RF OVER FIBRE SYSTEM

Tx MAT244 Rx
