Wire rope sling manufacture for the offshore industry in Angola for the offshore industry in Angola 1 February 2012 Table of content 1. Presentation 1. Presentation 2 2. Review of norms and standards Review of norms and standards 3. How

slide-1
SLIDE 1

Wire rope sling manufacture for the offshore industry in Angola for the offshore industry in Angola

1

February 2012

slide-2
SLIDE 2

Table of content

  • 1. Presentation
  • 1. Presentation

2 Review of norms and standards

  • 2. Review of norms and standards

3 Ho to chose a lifting set ?

  • 3. How to chose a lifting set ?
  • 4. Our range of services
  • 5. FAQ

2 2

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-3
SLIDE 3

Our Organization

ORTEC Group Key Figures

5600 employees worldwide 5600 employees worldwide 900 M$ turnover Present on over 300 client sites 18 subsidiaries in 15 countries 80 establishments in France Main activities: Main activities:

Maintenance Construction works E i t Environment Energy Engineering I d t i l l i Industrial cleaning

2 branches in Angola since 1997

For more information go to www ortec fr

3 3

For more information, go to www.ortec.fr

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-4
SLIDE 4

Our Organization

FRIEDLANDER Angola: our activities

 Piping Works (Oil & Gas and Industry): Fabrication and Installation  Supports and Structures: Fabrication and Installation  EPCC Contracts for Onshore and Offshore  M i t R ti j b  Maintenance: Routine jobs  Well Jumpers, Subsea Structures: Fabrication at quay side  Sea fastening  Procurement  Shut Downs: Preparation and site work For more details contact our General Manager: direction angola@friedlander-international com

4 4

For more details, contact our General Manager: direction.angola@friedlander-international.com

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-5
SLIDE 5

Our Organization

ORSLING history

1997:Creation of FRIEDLANDER Angola 1997:Creation of FRIEDLANDER Angola Onshore and offshore activities for Oil & Gas Fabrication of DNV 2.7-1 certified equipments q p Need for corresponding lifting sets 2007: Creation of ORSLING (as brand belonging to FRIEDLANDER Angola) in

  • rder to respond internally to the need

f End of 2010: Fabrication workshop moved with FRIEDLANDER new construction yard within SONILS base 5 people permanent team

5 5

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-6
SLIDE 6

Basic definitions

1 l li 4 l li ith h kl Components of a lifting set 1 leg sling 4 legs sling, with shackles

Top link (triple) Soft eye termination Hard eye termination (without thimble) (with thimble) p ( p ) Marking plate

2 legs sling, with hooks

Top link (simple) Wire rope Ferrule Thimble Shackle

6 6

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-7
SLIDE 7

Basic definitions

Technical terms

 WLL: (Working Load Limit) maximum weight that the accessory is allowed to lift (in metric tons or  WLL: (Working Load Limit) maximum weight that the accessory is allowed to lift (in metric tons or in kg)  BL: (Breaking Load) minimum force needed to break a cable (in N or in kN)  R ti T t l f t i ith t th lifti t ( T + P l d)  Rating: Total mass of a container without the lifting set (= Tare + Payload)  Tare: Mass of the container when empty  Payload: Maximum mass that can be transported by a container (P= R-T)  Fore runner / top leg: Single leg sling used to elongate a 4 legs sling (the assembly can be referred as 5 legs sling), often used for DNV 2.7-1 lifting set fabrication to allow the top link to arrive at the correct elevation  Angle: Unless otherwise notified, the angle used to define a sling is always the angle between

  • ne leg and the vertical (in degrees)

 Swaging: Method of assembly by pressing a ferrule containing the cable between dyes of  Swaging: Method of assembly, by pressing a ferrule containing the cable between dyes of specific dimensions  DAF: (Dynamic Amplification Factor) Enhancement factor of the WLL to take the movement of the load into account

7 7

load into account

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-8
SLIDE 8

Basic definitions

Applicable norms and standards Di i i d f b i ti Dimensioning and fabrication: DNV 2.7-1  Standard for certification of offshore containers EN 12079 2  E N ( f DNV 2 7 1) EN 12079-2  European Norm (copy of DNV 2.7-1) DNV 2.7-3  Standard for certification of portable offshore units EN 13414-1  European Norm for wire rope sling manufacture EN 13414 1  European Norm for wire rope sling manufacture Choice of accessories: EN 13411-3  European Norm for swaging and choice of thimble EN 1677  European Norm for component for slings EN 13889  European Norm for shackles EN 12385  European Norm for steel wire ropes

8 8

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-9
SLIDE 9

Table of content

  • 1. Presentation
  • 1. Presentation

2 Review of norms and standards

  • 2. Review of norms and standards

3 Ho to chose a lifting set ?

  • 3. How to chose a lifting set ?
  • 4. Our range of services
  • 5. FAQ

9 9

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-10
SLIDE 10

DNV 2.7-1 / EN 12079-2 review

 Limitations:

  • Maximum rating is 25T
  • The DNV 2.7-1 standard corresponds only to offshore containers

p y fabrication, but the part concerning the lifting sets is often used as reference for the fabrication of slings for other offshore equipments

  • Enhancement factor to be applied for the calculation of the WLL

(see table 8-1 at right side)

  • Minimum WLL = 7 000 kg
  • Certified process of fabrication
  • Top link dimension: recommended > 270 x 140mm
  • When unloaded, the top link must not be above 1300mm from the

p floor

  • Maximum angle of a sling with vertical = 45°
  • The shackles from a lifting set can not be separated from the

g p sling

  • Hard eye assembly only
  • Specific marking

10

Specific marking

10

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-11
SLIDE 11

EN 13414-1 review

 Limitations:

  • Wire rope sling fabrication, from 8 to 60mm
  • Specific marking

p g

  • Swaging conform to EN 13411-3
  • WLL to be calculated for angles from 0° to 45° from vertical (and from 45° to 60° for some

specific assemblies) p )

  • The weakest part must be the cable, not the top link
  • Shackles must have higher WLL than the leg they are connected to
  • Calculation of the WLL for usual cases:
  • Calculation of the WLL for usual cases:
  • For 1 leg sling: WLL = (BLmin x KT) / (g x ZP), with:
  • BLmin = Minimum Breaking Load of the cable (given by the supplier)
  • ZP = 5 (safety factor)
  • g = 9.80665 N/kg
  • KT = termination coefficient (0.9 for swage assembly)
  • For multi legs sling: WLL = (BLmin x KT x KL) / (g x ZP), with:
  • KL = coefficient for leg number and angle = Nlegs x cos(β), with β = 45°
  • KL = 1.4 for 2 legs slings, and KL = 2.1 for 3 and 4 legs slings (4 legs slings are calculated as 3 legs slings)

11 11

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-12
SLIDE 12

Table of content

  • 1. Presentation
  • 1. Presentation

2 Review of norms and standards

  • 2. Review of norms and standards

3 Ho to chose a lifting set ?

  • 3. How to chose a lifting set ?
  • 4. Our range of services
  • 5. FAQ

12 12

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-13
SLIDE 13

How to chose a lifting set ?

 Number of legs:  Number of legs:

  • Given by the design of the equipment to lift

 Requested certification

  • Offshore or onshore ?
  • One time lift for installation or movable equipment ?
  • Company specifications
  • Company specifications

 Calculation of the minimum WLL of the sling

  • Weight of the equipment to lift
  • DAF to apply (generally given by Company specification)
  • Example: in TOTAL specifications, DAF = 1.30 for offshore lifting (<150T), and DAF = 1.10 for onshore

 Use of a spreader bar:  Use of a spreader bar:

  • Can lower the stress on the equipment during lifting
  • Can reduce the length of the sling

C ll b tt t l f th lifti ( i ll f l f b i t )

  • Can allow better control of the lifting (especially useful for subsea equipments)
  • May modify the stability of the equipment (to be checked in every particular case)
  • Must be subject to specific calculation note

13

j p

13

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-14
SLIDE 14

How to chose a lifting set ?

WLL calculation

Wi B ki L d Si l l WLL 2 l WLL 4 l WLL DNV 2 7 1 S d d h kl Wirerope Diametre (mm) Breaking Load (kN) * Single leg WLL (Tons) 2 legs WLL (Tons) 4 legs WLL (Tons) DNV 2.7-1 max rating (Tons) Standard shackle size (Tons)**

8 44,7 0,82 1,16 1,74 N/A 1 13 118 2 17 3 06 4 59 N/A 3 25 13 118 2,17 3,06 4,59 N/A 3,25 16 179 3,28 4,64 6,97 N/A 4,75 18 226 4,15 5,86 8,80 3,9 4,75 22 338 6 20 8 77 13 16 8 6 5 22 338 6,20 8,77 13,16 8 6,5 26 472 8,66 12,25 18,37 13,5 9,5 32 715 13,12 18,55 27,83 25 13,5 36 904 16 59 23 46 35 19 (25) 17

WLL calculated for each diameter according to EN 13414-1***, using steel cable 6 x 36 WS + IWRS in grade 1960 with maximum angle of 45° and ferrule terminations

36 904 16,59 23,46 35,19 (25) 17 40 1120 20,55 29,06 43,59 (25) 25

grade 1960, with maximum angle of 45°, and ferrule terminations

* Figures from EN 12385-4, table 9 and Traction Levage catalog ** Any bigger size of shackle can be used as long as it can enter the thimble Never use smaller size unless a specific calculation note has been issued 14 14 *** Amendment A1, 2005, allows to calculate the WLL of a sling using grade 1960 breaking load

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-15
SLIDE 15

Table of content

  • 1. Presentation
  • 1. Presentation

2 Review of norms and standards

  • 2. Review of norms and standards

3 Ho to chose a lifting set ?

  • 3. How to chose a lifting set ?
  • 4. Our range of services
  • 5. FAQ

15 15

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-16
SLIDE 16

Our range of services

 Sling fabrication following EN 13414-1

Wire rope sling fabrication

 Sling fabrication following EN 13414 1

  • Aluminum ferrule assembly
  • Cable 6 x 36 grade 1960, in diameters 8, 13, 18, 22, 26, 32, 36 and 40mm
  • One to five legs slings
  • Hard or soft eyes
  • WLL from 0.82T to 20.55T for single leg slings
  • WLL from 1.74T to 43.59T for 4 legs slings
  • Possibility for conical ferrules and hook ending

 DNV 2.7-1 lifting sets

C tifi d t i l d d

  • Certified material and procedures
  • Specific calculation note, validated by Bureau Veritas
  • Third party certificates

16

Third party certificates

16

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-17
SLIDE 17

Our range of services

 Hooks

Supply of lifting equipments and accessories

 Hooks

  • With safety latch, range of WLL corresponding to our wire rope diameters

 Endless round soft slings

  • Various sizes from 1T to 10T

 Weld-on pivoting links

  • From 1T to 15T, particularly handy for sea fastening

From 1T to 15T, particularly handy for sea fastening

 Turnbuckles

  • Type G6313

 Wire rope clamps

  • Type CROSBY G450, corresponding to our range of wire rope diameters

 Bow Shackles  Bow Shackles

  • Type CROSBY G-2130, from 1T to 25T

This range of equipments can evolve following your requests ask for our latest list

17

This range of equipments can evolve following your requests, ask for our latest list.

17

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-18
SLIDE 18

Our range of services

 Load test

Other services

 Load test

  • Test bench with 1 500 kN capacity
  • Destructive and non destructive tests
  • Third party certificates

 Engineering

  • Equipment survey
  • Calculation notes for special lifting sets, like non symmetrical slings
  • Assistance to find the best solution for each case
  • Coordination with other departments from FRIEDLANDER Angola for fabrication of:
  • Spreader bars
  • Spreader bars
  • Certified offshore containers (baskets, tool boxes, gas racks,…)
  • Offshore structural extensions

18 18

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-19
SLIDE 19

Table of content

  • 1. Presentation
  • 1. Presentation

2 Review of norms and standards

  • 2. Review of norms and standards

3 Ho to chose a lifting set ?

  • 3. How to chose a lifting set ?
  • 4. Our range of services
  • 5. FAQ

19 19

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-20
SLIDE 20

Some answers to the most frequent questions you have:

 What are the advantages of conical ferrules for swaging?

  • It is safer for manual handling, as there are no more free strands out of the ferrule
  • The profiled end has less risk to catch a sharp edge while dragging the sling

Conical end, covering Specific dyes for swaging the free strands Hole for control of wire rope extra length Cylindrical body, similar to “standard” ferrules

 Are you sure it is allowed for DNV 2.7-1 lifting sets fabrication?

  • Yes: DNV 2.7-1 standard states that: “The terminations of wire rope legs shall be ferrule

secured eyes with thimbles, and comply with EN 13411-3 or other recognized standard.” (§8.3.2.2 Wire rope slings). The conical ferrules and corresponding swaging procedure we use are conform to EN 13411-3 (type C) therefore to DNV 2 7-1

20

use are conform to EN 13411 3 (type C), therefore to DNV 2.7 1.

20

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-21
SLIDE 21

Some answers to the most frequent questions you have:

 Why are you only using cables from diameter 18 to 32mm for DNV lifting sets ?

  • Even for the low ratings, the minimum WLL is 7000 kg (DNV 2.7-1, table 8-1)
  • Reference to EN 13414-1 for the cable  BLmin = (WLL x g x ZP) / (KT x KL) with:
  • ZP = 5 (safety factor)

9 80665 N/k

  • g = 9.80665 N/kg
  • KT = 0.9 (for swage termination)
  • KL = 2.1
  • BLmin = 179 840 N for the cable of a 4 leg sling
  • 18mm is the smallest cable size with BL > 179 840 N  not allowed to use smaller *
  • We use the same calculation for the maximum size, maximum rating is 25T, that gives a WLL
  • f 27 590 kg  BLmin = 708 830 N
  • 32mm is the smallest cable size with BL > 708 830 N  no need to use bigger

* It is actually possible to use a smaller size of cable by reducing the angle for a particular use ,if a specific t d d l l ti t i i d b t ll d ’t d it t id i f th li

21

non standard calculation note is issued, but we usually don’t do it to avoid misuse of the slings.

21

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-22
SLIDE 22

Some answers to the most frequent questions you have:

 What standards could I follow for a load > 25T as DNV 2.7-1 can’t apply?

  • First of all, the standard of each Company should apply
  • For onshore or one time lifting offshore, EN 13414-1 is most often used
  • DAF might be added for offshore use
  • DNV 2.7-3 Standard covers offshore equipments that are regularly lifted, up to 50T
  • No specific description of lifting sets
  • Reference to DNV 2.7-1  same lifting sets up to 25T
  • Above 25T, enhancement factor can be extrapolate at the constant value of 1.1
  • For other cases, a specific calculation note can be done for the lifting set

22 22

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-23
SLIDE 23

Some answers to the most frequent questions you have:

 Can you certify an existing sling ?

  • We can only make a certificate of conformity for our own manufactured products
  • Several issues occur to certify a sling fabricated by another manufacturer:
  • What material was used ? It is not possible to check the steel grade of the wire rope by mere visual

inspection

  • How was it assembled ? The process of assembly and the quality control along it are critical for the

certification of the final product

  • Alternative: we can make a load test under third party survey
  • Alternative: we can make a load test under third party survey

 Can you assemble a sling using our own material ?

  • Yes, if the material is compatible with our fabrication process. The composition of the cable is

a particularly important point to check, for compatibility with our swaging equipment. But the certification of the assembly is subject to the material certificate

 Can you modify an existing sling ?

  • Only if the sling was manufactured by ORSLING (same issues as for certification)

23 23

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-24
SLIDE 24

Some answers to the most frequent questions you have:

 Why should we work with ORSLING?

  • Quality of our final product, coming from the quality of the materials we use, the training and

dedication of our personnel

  • Reactivity of our workshop for emergency fabrication  we use to deliver urgent lifting sets on

the same day we receive the order the same day we receive the order

  • Fabrication inside SONILS base  no delay for material delivery
  • Frame contract with Bureau Veritas  reactivity for third party certification

y y

  • Adaptability to manufacture customized lifting sets
  • Pro-activity from our management and our engineering department to propose you the best

solution for your needs

  • Collaboration with other departments of FRIEDLANDER Angola to propose complete lifting

solutions like spreader bars or certified baskets solutions, like spreader bars or certified baskets

  • Local content: 100% up to the Operation Manager !

24 24

Contact:

  • perations2.angola@friedlander-international.com

+244 923 678 609

slide-25
SLIDE 25

F RIE DL ANDE R Ang ola F RIE DL ANDE R Ang ola

Rua Co mmandante K ima K ye nda Bo avista L uanda E mail : dire c tio n.ang o la@ frie dlande r-inte rnatio nal.c o m T e l : +244 917 750 692 / 932 339 292

ORSL ING

E mail : o pe ratio ns2.ang o la@ frie dlande r-inte rnatio nal.c o m T e l : +244 923 678 609

www.o rsling .c o m

25

T e l : +244 923 678 609

www.o rsling .c o m
