Who we are? � We, the company Büscherhoff special packaging are one of the leading companies with regards to the production of special film packaging. In three production sites 250 employees produce a diversified spectrum of special film packaging materials. Additionally we have three existing and two in the build up phase sales and service offices worldwide.

Who we are? � We are an independent company, which has developed the Multilayer Flexitank and introduced it into the market. With the help of much experience made during last years regarding the production of Flexitanks, we have developed one of the highest-quality Flexitank. Our Flexitanks are TÜV-approved, FDA-conform and they are being made in a DIN EN ISO 9001: 2000 certified production.

What we produce? � The product range offered by us includes the film production, FFS-block bags and container liners for installation in 20’ - 40’ containers up to our Flexitanks with a volume from 10,000 to 28,000 litres. » Extrusion On our extrusion lines we manufacture several different films. From normal tube film to Coex- films up to our patented electric “conductive grid film”. » FFS - Blockbags For bulk materials of 10 - 50 kg we produce special equipped bag packaging solutions of tube film or flat film well adapted for the needs and requirements from sides of our customers.

What we produce? » Inliner We produce your individual Inliner out of very different materials such as Polyethylene and Polypropylene films, aluminium laminated films (PET-ALU-PE), barrier films as EVOH and PA, conductive PE grid film, also laminated with ALU. The Inliners are being used to protect the filled material as inlay for Big Bags, drums and octabins, sewn-in or drawn-in. Product samples

The Flexitank

The Flexitank � Advantages of the Flexitank More than 40 % payload compared to IBC, » drums Global availability » Short assembly costs, no disassembly » costs No product contamination through non- » returnable use Kosher-Certificate is possible » No cleaning and subsequent cleaning » costs Favourable sea freight compared to a tank » container up to 60% Environment aspect (recyclable, no chemical » cleaning etc.)

The Flexitank � How they look like: - Standard flexitank with Deltaframe bulkhead:

The Flexitank � How they look like: - Formstable for trailer and REFA-Container

The Flexitank � What can be transported? You can transport many different liquids from the foodstuff and chemical industry, not falling under the Ordinance on Hazardous Substances. Chemical materials: oils, emulsions, dispersions, latex, silicones, silicates, » colours etc. Foodstuff materials: wines, edible oils, fruit juices, concentrates, molasses, water » etc. � Limited Flexitanks are limited due to the maximal weight of the container or trucks. We provide our Flexitanks for different volumes from 10,000 litres up to 28,000 litres. So we can react to the different specific weights of the liquids. One other limitation is the container construction, thus Flexitanks can be only transported in Heavy Duty Container. We plan to break this limitation with our new developed form-stable Flexitank.

What we produce? » Container liners We produce container liners for 20’ to 40’ Container. These container liners are made out of transparent or conductive PE-film (patented by BSV). The production exclusively takes place according to the requirements of customer. PE-Container liner Conductive container liner

Containerliner � Containliner 20‘ with 2 drainhoses

Containerliner � Containerliner 20‘ with 3 drainhoses

Containerliner � Containerliner 20‘ for rear loading / loading outside the middle

Containerliner � Containliner 20“ with fishtail Art.-Nr. 010897 V ersion 11 20.12.2007 0 8 Folienzuschnitt aufkleben ! Co ntainerliner : PE; 140 µm (F o00290) 0 2 6000mm lang 3 1 2450mm breit 2420mm hoch 0 3 8 0 0 8 0 1 0 1 0 Entlüftungsschlauch (500mm lang) 2 0 1 Ø 320 (Schlauch 520 mm flach) 640 x 430 mm 300 mm (Fo00821) (Schlauc h 1070 mm fla ch) 300 m m 0 0 0 5 5 5 ( FO01248 ) 8 8 8 0 9 ����������������������������������������������� 750 430 ������������������������������� ����������������������� 6000 mm + - 150 320 900 Art. 900117 Kunststoffösen eingeschweisst mit Gummiband und Einlaufschläuche 2 x 3 mtr . langes doppelseitiges Aufkleber Kunststoffhaken (1000 mm la ng) Klebeband am B oden = (Art. 300197 ) 300 mm von der Außenseite S iehe Z eichnung F ischmaul!!! Gum mibänder (Art.600201) werden mit T esa (Art. 300014 )angek lebt

Containerliner � fitted Containerliner

Containerliner � Rear loading with rotary feeder

Containerliner � Granulate thrower • Granulatwerfersystem zur heckseitigen Beladung von Schüttgütern in Fracht • - Container 20-40” - Beladezeiten von 15-25 Minuten - Einfaches Handling - Sichere Beladung - Wurfweiten bis 12 Meter - Produktschonend

Containerliner � Filling of the Containerliner

Containerliner � Filling of a 20‘ Container

Containerliner � Loaded Container with woven rear panel and steel bars

Containerliner � Containerliner 30‘ with fishtail

Containerliner � Fitted 30‘ Containerliner with fishtail

Containerliner � Discharge of a 30‘ Container with a discharge skirt

Containerliner � Discharge process with rotary feeder
