WHITE AND BIOCOAL PELLETS PRODUCTION WITH CARBONFX TM TECHNOLOGY PFI Annual Conference July 25, 2016 Who we are Airex Energy is a technology provider of biomass torrefac:on systems and a producer of high quality biocoal We are a spin-off of Airex


slide-1
SLIDE 1

July 25, 2016

WHITE AND BIOCOAL PELLETS PRODUCTION WITH CARBONFXTM TECHNOLOGY

PFI Annual Conference

slide-2
SLIDE 2

2 Confiden:al

Who we are

Airex Energy is a technology provider of biomass torrefac:on systems and a producer of high quality biocoal We are a spin-off of Airex Industries, a well established industrial equipment manufacturer We are commercializing our proprietary CarbonFXTM process, a simple, reliable and cost compeKKve technology plaIorm

slide-3
SLIDE 3

3 Confiden:al

CarbonFXTM technology

Wet sawdust Biocoal

Upgrading biomass through thermal treatment

Dry sawdust

White pellets Biocoal pellets Biochar Wood flour

slide-4
SLIDE 4

4 Confiden:al

Products

Hea:ng value Durability Bulk density Moisture Ash 9K – 10.5K BTU/lb > 97 % > 45 lb/]3 < 4% < 3%

Biocoal pellets Biochar White pellets

Carbon content Par:cle size Bulk density Moisture Ash 60% to 75% 0.1 – 2 mm 10 lb/]3 < 2% < 15%

Torrefied Wood flour

Hea:ng value Durability Bulk density Moisture Ash 8K BTU/lb > 97 % > 40 lb/]3 < 8% < 1% Par:cle size Bulk density Moisture Ash 40-80 mesh 10 - 13 lb/]3 < 1.5% < .5%

slide-5
SLIDE 5

5 Confiden:al

Technology roadmap

2012

2015

Self-contained 2 units sold Capacity 100 kg/hr output

2 tons/hr output Commercial

Status

Scaling up capacity

2010

Experimental 10 kg/hr output

slide-6
SLIDE 6

6 Confiden:al

Becancour plant

  • Loca:on : Becancour, Qc
  • Capacity of 2 tons/hour
  • Investment : CAD$6.5M
  • Feedstock : sawdust / recycled wood
  • End-product : biocoal pellets, white

pellets, biochar, torrefied wood flour

slide-7
SLIDE 7

7 Confiden:al

Becancour plant

Silo 1 Silo 2 Silo 3

CarbonFX

Hammer mill Flash drying

Bin Pellet mill Silo 4 Silo 5

Conveyors Heat exchanger

slide-8
SLIDE 8

8 Confiden:al

Becancour plant

Capacity White pellets 35K t/year Biocoal pellets 15K t/year Biochar 8K t/year Torrefied wood flour 20K t/year

  • Flexible plant :
  • Feedstock : sawdust, woodchips or C&D wood
  • End-products :
  • Cost compeKKve plant : A biocoal plant for the price of a

white wood pellet plant

  • No market risk : white pellet produc:on
slide-9
SLIDE 9

9 Confiden:al

Becancour plant

slide-10
SLIDE 10

10 Confiden:al

Becancour plant

slide-11
SLIDE 11

11 Confiden:al

Becancour plant

slide-12
SLIDE 12

12 Confiden:al

Becancour plant

slide-13
SLIDE 13

13 Confiden:al

Becancour plant

  • Built to run 24/7
  • Staff of 2 operators/shi], 1 mechanic and 1 plant director
  • Safety features : 2 dust collectors, enclosed conveyors and

silos, magnets, sprinklers (building and inside silos), heat detec:on in silos, spark detec:on/suppression systems, explosion vents

  • Propane/natural gas for start-up and pilot flame
  • Automa:on : automated plant with minimal operator

interven:ons

  • Maintenance : rugged and proven equipment used in wood

industry (sizing equipment, conveyors, extrac:on systems, pellet mill, instrumenta:on)

Main features

slide-14
SLIDE 14

14 Confiden:al

Compe::ve edge

Cost compe::ve technology

  • No biomass boiler required for process heat
  • Integrated pre-drying system
  • Perform as a high-efficiency biomass dryer

Incremental technology development Scalable technology

  • Proven mulK-cyclone design
  • From proof-of-concept to demonstra:on plant ð risk management
  • Smallest footprint of the industry : residence :me of

3 seconds vs 30 min for other technology

slide-15
SLIDE 15

15 Confiden:al

Partners

Funding Partners R&D Partners

slide-16
SLIDE 16

16 Confiden:al

Ready for biocoal produc:on ?

CarbonFXTM technology available in Q3 2016 Becancour plant open for site visit What we offer : Plant engineering Procurement and commisionning Operators training Plant op:miza:on and support

slide-17
SLIDE 17

17 Confiden:al

Informa:on

Guy Veilleux VP Engineering 450.661.6498 x218 gveilleux@airex-energie.com

Office : 2500 Bernard-Lefebvre Laval Becancour plant : 4170 Boul. Laprade Bécancour
