When foes are friends adversarial examples as protective technologies

Carmela Troncoso @carmelatroncoso Security and Privacy Engineering Lab

The machine learning revolution

2

Machine Learning )

Definition (Wikipedia)

Machine learning [...] gives "computers the ability to learn without being explicitly programmed" [and] [...] explores the study and construction of algorithms that can learn from and make predictions on data – such algorithms overcome following strictly static program instructions by making data-driven predictions or decisions, through building a model from sample inputs.

3

Data Machine learning Services

Machine Learning

4

Data Machine learning Services

Learning / Training Data Expected Output Model

Machine Learning

5

Data Machine learning Services

Learning / Training Data Expected Output Model Model New Data Output

Poisoning

6

Adversarial machine learning

Adversarial examples

Adversarial machine learning

Adversarial examples

7

Crafted testing samples that get misclassified by an ML algorithm

https://ai.googleblog.com/2018/09/introducing-unrestricted-adversarial.html

Model New Data Output

Poisoning

8

Crafted training samples that change the decision boundaries of an ML algorithm

Adversarial machine learning

Learning Data Expected Output Model

Adversarial examples Poisoning

9

Crafted testing samples that get misclassified by an ML algorithm Crafted training samples that change the decision boundaries of an ML algorithm

Adversarial machine learning is here to stay

10

11

Three ways of using adversarial examples as defensive technologies

Adversarial examples as security metrics Adversarial examples to defend from adversarial machine learning uses

For Privacy For Social Justice For Security

12

Three ways of using adversarial examples as defensive technologies

Adversarial examples as security metrics Adversarial examples to defend from adversarial machine learning uses

For Privacy For Social Justice For Security

13

Defending against adversarial examples?

Defending against adversarial examples?

Defending against adversarial examples?

Adversarial training

training on simulated adversarial examples

Does this solve security problems?

Adversarial training

training on simulated adversarial examples

Adversarial training

training on simulated adversarial examples

Does this solve security problems?

Images Random Noise

Does this solve security problems?

Malware Twitter Bots Spam ??? ??? ???

Does this solve security problems?

Malware Twitter Bots Spam ??? ??? ???

In security problems examples belong to a DISCRETE and CONSTRAINED domain FEASIBILITY COST How can we become the enemy?

Does this solve security problems?

Malware Twitter Bots Spam ??? ??? ???

In security problems examples belong to a DISCRETE and CONSTRAINED domain FEASIBILITY COST How can we become the enemy?

Does this solve security problems?

Malware Twitter Bots Spam ??? ??? ???

In security problems examples belong to a DISCRETE and CONSTRAINED domain FEASIBILITY COST How can we become the enemy?

Our approach: search as a graph

23

Number of followers: x Age of account: y

ML

Our approach: search as a graph

24

Number of followers: x Age of account: y

Number of followers: few Age of account: new

ML

Our approach: search as a graph

Number of followers: few Age of account: new

25

Number of followers: x Age of account: y

ML

Number of followers: few Age of account: 1 year Number of followers: few Age of account: 2 years Number of followers: few Age of account: 3 years

Our approach: search as a graph

Number of followers: few Age of account: new Number of followers: few Age of account: 1 year

26

Number of followers: few Age of account: 2 years Number of followers: few Age of account: 3 years

Number of followers: x Age of account: y

Number of followers: some Age of account: 1 year Number of followers: many Age of account: 1 year

ML

Number of followers: some Age of account: 1 year Number of followers: many Age of account: 1 year Number of followers: few Age of account: 3 years

Our approach: search as a graph

Number of followers: few Age of account: new Number of followers: few Age of account: 1 year

27

Number of tweets: few Age of account: 2 years

Number of followers: x Age of account: y

In security problems examples belong to a DISCRETE and CONSTRAINED domain FEASIBILITY COST How can we become the enemy?

ML

Number of followers: some Age of account: 1 year Number of followers: many Age of account: 1 year Number of followers: few Age of account: 3 years

Our approach: search as a graph

Number of followers: few Age of account: new Number of followers: few Age of account: 1 year

28

Number of tweets: few Age of account: 2 years

Number of followers: x Age of account: y

ML

$2 $4 $7 $2 $8 cost = $2 + $2 = $4 cost = $2 + $8 = $10

Number of followers: some Age of account: 1 year Number of followers: many Age of account: 1 year Number of followers: few Age of account: 3 years

Our approach: search as a graph

Number of followers: few Age of account: new Number of followers: few Age of account: 1 year

29

Number of tweets: few Age of account: 2 years

Number of followers: x Age of account: y

ML

$2 $4 $7 $2 $8 cost = $2 + $2 = $4 cost = $2 + $8 = $10

In security problems examples belong to a DISCRETE and CONSTRAINED domain FEASIBILITY COST How can we become the enemy?

The graph approach comes with more advantages

30

Enables the use of graph theory to

EFFICIENTLY find adversarial examples (A*, beam search, hill climbing, etc)

CAPTURES most attacks in the literature! (comparison base)

The graph approach comes with more advantages

31

Enables the use of graph theory to

EFFICIENTLY find adversarial examples (A*, beam search, hill climbing, etc)

CAPTURES most attacks in the literature! (comparison base)

Find MINIMAL COST adversarial examples if

• The discrete domain is a subset of Rm

For example, categorical one-hot encoded features: [0 1 0 0]

• Cost of each single transformation is Lp

For example, L∞([0 1 0 0], [1 0 0 0]) = 1

• We can compute pointwise robustness for the target classifier over Rm

A* search with a heuristic

Pointwise robustness over Rm

32

A* search with a heuristic

33

A* search with a heuristic

34

Minimal adversarial example found!

35

Minimal adversarial example found!

36

Minimal adversarial example found!

37

Confidence of the example

Is this really efficient?

l =d  just flip decision

38

Is this really efficient?

l >d  high confidence example

39

Is this really efficient?

l >d  high confidence example

40

Why is this relevant?

41

MINIMAL COST adversarial examples can become security metrics!

Cost can be associated with RISK Cannot stop attacks, but can we ensure they are expensive? Constrained domains security Continuous-domains approaches can be very conservative!

Applicability

42

Non-linear models:

• approximate heuristics
• transferability (basic attacks transfer worse than high confidence)

Faster search:

• tradeoff guarantees vs. search speed (e.g., hill climbing)

Other cost functions

Three ways of using adversarial examples as defensive technologies

Adversarial examples as security metrics Adversarial examples to defend from adversarial machine learning uses

For Social Justice For Security

43

For Privacy

Adversarial examples are only adversarial when you are the algorithm!

Machine learning as a privacy adversary

45

ML Privacy-oriented Literature

Data Service Avoid that learns about data

Machine learning as a privacy adversary

46

ML Privacy-oriented Literature

Data Service Avoid that learns about data Actively (maybe not willingly) provide data. Solutions like Differential privacy and Encryption are suitable

Machine learning as a privacy adversary

47

ML Privacy-oriented Literature

Data Service Avoid that learns about data Actively (maybe not willingly) provide data. Solutions like Differential privacy and Encryption are suitable No active sharing! Cannot count on

Adversarial examples as privacy defenses

48

Data Inferences

Adversarial examples as privacy defenses

49

Data Inferences

Goal: modify the data to avoid inferences Social networks data, browsing patterns, traffic patterns, location …

Adversarial examples as privacy defenses

50

Data Inferences

Goal: modify the data to avoid inferences Social networks data, browsing patterns, traffic patterns, location … Privacy solutions are also CONSTRAINED in FEASIBILITY and COST!

Protecting from traffic analysis

51

Encrypted traffic trace

ML

Apps, webs, words,…

Protecting from traffic analysis

52

Encrypted traffic trace

ML

Apps, webs, words,… Add 1 packet in position 1 Add 2 packets in position 1 Add 1 packet in position 2 Add 1 packet in position N Add 3 packets in position 1 Add 2 packets in position 2

… …

FEASIBLE perturbations:

• Add packets
• Delay packets

Protecting from traffic analysis

53

Encrypted traffic trace

ML

Apps, webs, words,… Add 1 packet in position 1 Add 2 packets in position 1 Add 1 packet in position 2 Add 1 packet in position N Add 3 packets in position 1 Add 2 packets in position 2

… …

FEASIBLE perturbations:

• Add packets
• Delay packets

COST is essential: packets on the network cost money!

54

Website fingerprinting

Machine learning To learn how websites traffic patterns look like

We consider the monitored / unmonitored problem We use CUMUL attack, non-linear and non-robustness metric

55

Comparison with existing defenses

Adversarial examples for privacy

56

Provide privacy in domains where the ML model is adversarial Privacy is also CONSTRAINED so the graphical approach can be used to

EFFICIENTLY find FEASIBLE adversarial examples

find MINIMAL COST adversarial examples Provide a BASELINE to compare defenses’ efficiency

Takeaways

• Adversarial machine learning is hard to defend from

… but this opens great opportunities for security and privacy applications

Adversarial machine learning as protective technologies

• New graphical framework to approach the search of adversarial examples

… we can use of graph theory to improve efficiency and provide guarantees

57

https://github.com/spring-epfl/ https://arxiv.org/abs/1810.10939

PETs

58

Security evaluation

https://spring.epfl.ch/en http://carmelatroncoso.com/
