What you should remember for today

Algorithms are mechanical recipe to compute something. Structure of prokaryotic genes. Each genome has uneven codon preferences. Basic form of the Bayes Theorem (earlier this term?)

Learning outcomes for today?

1.Interpret algorithms expressed as pseudocode. 2.Describe the limitations of assuming an equivalence between long ORFs and expressed gene products in prokaryotes. 3.Compute and interpret the following prediction performance measures:sensitivity, specificity and F-score. 4.Desribes how GeneMark learns the structure of genes in prokaryotes. 5.Explain why GLIMMER attempts to consider data from longer k-mers.

Open Reading Frames

Finding Genes v.1.0

ORF : Open Reading Frame. Since codons are words of 3

• characters. Finding a START and one of three possible STOP

codons constitute a reading frame.

STOP codon

TAA, TGA, TAG

START codon

ATG (also code for protein character M)

Open Reading Frames

Finding Genes v.1.0

There are 6 possible frames : Some organisms even manage to

• verlap genes using two reading frames!

Sequence as in the DB

TCCAACTCGGGGTCCGCATCGCTCCGCCGGCGACCGACGAAGCCG

Three first frames

TCC AAC TCG GGG TCC GCA TCG CTC CGC CGG CGA CCG ACG AAG CCG A T CCA ACT CGG GGT CCG CAT CGC TCC GCC GGC GAC CGA CGA AGC CGA TC CAA CTC GGG GTC CGC ATC GCT CCG CCG GCG ACC GAC GAA GCC GA

But DNA is a double strand…

5’-TCCAACTCGGGGTCCGCATCGCTCCGCCGGCGACCGACGAAGCCG-3’ 3’-AGGTTGAGCCCCAGGCGTAGCGTGGCGGCCGCTGGCTGCTTCGGC-5’

ORF ≠ Gene

Finding Genes v.1.0

In bacteria : It is OK to assume that all genes are ORFs. Not all ORFs are genes!

• Find the longest possible sequence beginning with an ATG, and

terminating by a TAA, TAG, TGA.

• There may be multiple ATG inside the gene, but only a single stop

codon.

• Real genes will have a regulatory regions upstream of ORF. Use

pattern detection to do this.

• Real genes are typically 100-500 codons long.
• Real genes tend to have a bias in the composition of their

characters.

Control sequences

Finding Genes v.1.0

Regulatory sequence : Promote the translation of a gene. Sequence found in 5’ of gene.

Gene density

Finding Genes v.1.0

Bacteria : < 10 Mb genomes usually, >85% gene coding sequences. Eukaryotic genomes : 13 Mb – 10,000Mb genomes. 70% in Baker’s yeast (Saccharomyces cerevisiae ) 25% in Fruit fly (Drosophila melanogaster) 1-3% in flowering plants. Intron : Discontinuity in the sequence of a gene. ~150 bp exon (coding DNA) interspaced with introns (non- coding; few hundreds to thousand bp). 95% human genes have at least 1 intron. 80% fruit fly 5 % Yeast

A procedure to identify ORFs in prokaryotic genomes

Starting at the first base in the genome, find the position of the first START codon. Once a START codon is found, find the position of the first STOP codon that is in the same frame. Consider all nucleotides including and in-between the position

• f the first nucleotide in START and the last nuclotide in STOP

to be an ORF. Repeat from the end of this gene until the whole genome has been scanned.

Tentative Pseudocode

lastSTOP = 0 start = 0 stop = 0 for as long as start is smaller than the length of the genome SET start as the index of the next ATG after lastSTOP. FIND the next in-frame STOP codon SET stop as the index of the third base of the STOP codon WRITE start and stop

ORFs and genes aren't the same

It is straightforward to determine the probability of and ORF to be spurious if you know its length.

lastSTOP = 0 start = 0 stop = 0 while start != -1: # Find the first ATG after lastSTOP start = genome.find("ATG", lastSTOP) # Find the first in-frame STOP codon for i in range(start, len(genome), 3): codon = genome[i:i+3] if codon in ["TAA","TGA","TAG"]: stop = i + 2 break print start, stop, stop - start

Tentative Pseudocode II

lastSTOP = 0 start = 0 stop = 0 minGenLen = 300 for as long as start is smaller than the length of the genome SET start as the index of the next ATG after lastSTOP. FIND the next in-frame STOP codon SET stop as the index of the third base of the STOP codon IF (stop - start) IS LARGER THAN minGenLen WRITE start and stop SET lastSTOP to stop OTHERWISE INCREMENT lastSTOP by 1

lastSTOP = 0 start = 0 stop = 0 while start != -1: # Find the first ATG after lastSTOP start = genome.find("ATG", lastSTOP) # Find the first in-frame STOP codon for i in range(start, len(genome), 3): codon = genome[i:i+3] if codon in ["TAA","TGA","TAG"]: stop = i + 2 break # Is the ORF long enough? if stop - start >= minGeneLength: print start, stop, stop - start lastSTOP = stop + 1 else: lastSTOP = lastSTOP + 1

The Confusion Matrix

True Positives (TP) False Positive (FP) False Negative (FN) True Negative (TN) Real Codon Not Real Codon Predicted as Codon Ignored as Codon

Sensitivity

(TP) (TP) (FP) (FN) (FN) (TN) Real Not Real Predicted Ignored

The proportion of real codons that are correctly classified as such. Sn = TP / (TP + FN)

Specificity

(TP) (TP) (FP) (FP) (FN) (TN) Real Not Real Predicted Ignored

The proportion of predicted codons that are real ORF boundaries. Sp = TP / (TP + FP)

F-score

(TP) (TP) (FP) (FP) (FN) (FN) (TN) Real Not Real Predicted Ignored

The harmonic mean of Sn and Sp. F = 2 * Sn * Sp / (Sn + Sp)

An example

100 100 50 50 10 10 1000 Real Not Real Predicted Ignored

Sn = 100 / (100 + 10) = 0.909 Sp = 100 / (100 + 50) = 0.666 F = (2 * .9 * .66) / (.9 + .66) F = 0.769

This classifier is thus more sensitive than specific.

Using Signal

Given two ORFs of exactly the same length. One is a gene while the other is an “accident”. Tell them apart.

• There can be a difference in signal.
• This difference will be genome-dependent.
• The classifier needs to learn what is this

difference.

• This must be done without assuming that the

ORF is known.

Open Reading Frames

Finding Genes v.1.0

When given a fragment of sequences, it can be in either 6 frames, or NOT in a gene. The classification is thus a 7-way classification problem.

Sequence as in the DB

TCCAACTCGGGGTCCGCATCGCTCCGCCGGCGACCGACGAAGCCG

Three first frames

TCC AAC TCG GGG TCC GCA TCG CTC CGC CGG CGA CCG ACG AAG CCG A T CCA ACT CGG GGT CCG CAT CGC TCC GCC GGC GAC CGA CGA AGC CGA TC CAA CTC GGG GTC CGC ATC GCT CCG CCG GCG ACC GAC GAA GCC GA

But DNA is a double strand…

5’-TCCAACTCGGGGTCCGCATCGCTCCGCCGGCGACCGACGAAGCCG-3’ 3’-AGGTTGAGCCCCAGGCGTAGCGTGGCGGCCGCTGGCTGCTTCGGC-5’

Training set

Dataset for which we already know the classification and is assumed to be a uniform sample of the data to be classified in the future.

• BLAST results of known genes (prior knowledge).
• Sample from long ORFs.

GeneMark

Is a Markov Model based approach. A statistically averse person may prefer the term: k-mer An approach that is somewhat similar to the de Bruijn graphs.

GeneMark training

Principle Store the probability of all Possible hexamer (6-mer) in Each possible frames, and In non-coding regions.

GeneMark table example

For a given frame F A T C G AAAAA

0.1 0.1 0.7 0.1

AAAAT

0.05 0.15 0.7 0.1

AAAAC

0.1 0.1 0.7 0.1

AAAAG

0.11 0.1 0.69 0.1

AAATA

0.1 0.4 0.4 0.1

AAATT

0.2 0.3 0.2 0.3

..... ... ... ... ...

Training for GeneMark

DERIVE probabilities for frame F bndrs <==CREATE A list of gene boundaries sampling the frame F. probs <== CREATE a table enumerating each possible k-mers ASSOCIATE a count of 0 for A,T,C,G for each k-mers. for each gene boundary pairs in bndrs

• rf <== SLICE the matching genome sequence

for each hexamer in orf Nuc <== Last nucleotide of the word prefix <== First k nucleotides ADD 1 to the count of nucleotide Nuc occuring after prefix CONVERT all counts into probabilities

GeneMark table example

For a given frame F A T C G AAAAA

0.1 0.1 0.7 0.1

AAAAT

0.05 0.15 0.7 0.1

AAAAC

0.1 0.1 0.7 0.1

AAAAG

0.11 0.1 0.69 0.1

AAATA

0.1 0.4 0.4 0.1

AAATT

0.2 0.3 0.2 0.3

..... ... ... ... ...

Classifying with GeneMark

Find the frame F with the highest posterior probability INPUT: 1 sequence s of lenght 12, 7 tables of hexamer frequencies T = {F1,F2,F3,F4,F5,F6,NC} a sequence s OUTPUT: a coding frame or the answer non-coding bestFrame = None bestProb = 0.0 for each frame F in [1,2,3,4,5,6,nc]: freq <== GET table in T which correspond to F Lkl <== EVALUATE the likelihood of s given freq prior <== SET to 0.5 if freq is NC, or 1/12 otherwise P <== EVALUATE the posterior probability of frame given s if P > bestProb: bestFrame = FR bestProb = P RETURN bestFrame

Classifying with GeneMark

Principle

For a sequence s of length 12: Compute the likelihood of s in all 7 frames Find the frame with highest posterior probability

Likelihood in GeneMark

s = abcdefghi ||||||||| 123123123 abcde.... P2(abcde) abcdef... P2(f|abcde) .bcdefg.. P3(g|bcdef) ..cdefgh. P1(h|cdefg) ...defghi P2(i|defgh)

Bayesian Posterior Probability

(that the segment is in frame 3, given sequence s)

s = abcdefghi

Point of discussion about GeneMark

• 7-way classification will pick up on genes,

regardless of frames.

• Supervised training – is the training set

appropriate?

• Is 6-mer appropriate?
• What if we use longer K-mers?
• What if we use shorter K-mers?

Glimmer 3 – State of the art

• Interpolated Markov Model
• Training set based on long ORFs.
• Consider all k-values from 2 to 8.
• Attempt to compute the likelihood with k = 8 IF

the data is not too sparse (400 instances counted).

• Use interpolation to when the data for k is

different than for k-1.

• 95% Accuracy !
