Welcome Iowa Mutual Insurance Association Wick Buildings, Inc. - - PowerPoint PPT Presentation

Wick Buildings, Inc. 405 Walter Road P.O. Box 38 Mazomanie, WI 53560

Welcome

Iowa Mutual Insurance Association

800-356-9682 WickBuildings.com

Larry Edema Have been with Wick Buildings for over 25 years Vice President of the Corporation National Sales Manager Past-chair of the NFBA

Served on the Board for over 13 years.

Wick Buildings, Inc.

Founded in 1954 by John F. Wick, Sr. (Over 180 employees) Manufacturer of post-frame building packages Over 73,720+ buildings completed (08/22/17) National headquarters in Mazomanie, Wisconsin Manufacturing facility/training center in Mazomanie, Wisconsin Over 110 + Builders serving 16 states Complete in-house Engineering, R&D, and Information Systems Buildings delivered on Wick tractor-trailers and offloaded

Wick Buildings, Inc.

National Headquarters

Mazomanie, Wisconsin

Wick Buildings, Inc.

Agricultural 45% Suburban 24.5% Equine 3.5% Commercial 27%

Post-Frame Building Construction Market Share

Introduction to Post-Frame Building Systems

• Identify the versatility and range of applications for

post-frame building systems

• Identify the structural features that make post-

frame building systems unique

• Introduce the basic design methods for structural

design of post-frame building systems

• Identify the available resources for design of post-

frame building systems

• Identify key performance characteristics of post-

frame building systems

Learning Objectives

POST-FRAME BUILDINGS: A LIGHT-COMMERCIAL MAINSTAY

“With so many structural framing options, building functions, and architectural finishes, post-frame building systems are limited only by the architect’s imagination and creativity.”

“Post-frame contributes very well to both the environment and the value for your dollar.” —Cheryl Ciecko, ALA AIA LEED AP CSI GGP, technical director,

WoodWorks, a nonprofit initiative of the Wood Products Council

• Versatility and range of

applications

• Structural features that

make these systems unique

• Key performance characteristics
• Resources for designing post-frame building

systems

LEARNING OBJECTIVES

Many architects, design professionals, code

• fficials and insurance companies are unfamiliar

with post-frame

• It is not commonly included in traditional

architectural school curricula

• They incorrectly equate post-frame construction

with post-and-beam construction

• They think post-frame is only for agricultural

buildings (i.e., barns, storage facilities, or horse facilities)

WHAT IS POST-FRAME?

POST-FRAME IS EVERYWHERE

CONVENIENCE STORES

RESTAURANTS

COMMERCIAL OFFICES AND VETERINARY CLINICS

RELIGIOUS SPACES

PRIVATE HOMES

PRIVATE HOMES

PUBLIC BUILDINGS

COMMUNITY BUILDINGS

RECEPTION HALLS

RETAIL STORES

POST-AND-BEAM CONSTRUCTION

Continuous Footer

• r Pier Foundation

Post Pinned Connection Girder (Beam) Floor Concrete Pier

POST-AND-BEAM CONSTRUCTION

Post Girder (Beam) Purlin

THIS IS POST-FRAME

Figure 1: Post-frame building with trusses supported by embedded posts

Primary Frames Wood Column Clear Span Truss Embedded Post Foundation Truss-to-Post Connection

THIS IS POST-FRAME

Figure 2: Post-frame building mounted on a concrete stem wall

Roof Purlin Wall Girt

Selection of ceiling & wall coverings for interior finished buildings Overhangs and decorative mansards Wainscot options Column size determined for roof & wind loads

PRIMARY FEATURES OF POST-FRAME

Truss Purlins Sheathing Wall girts Wood columns

PRIMARY FEATURES OF POST-FRAME

Engineered concrete footings Concrete sized to meet wind loads Treated column anchors to resist wind uplift Splash plank Frost wall and footing with any required reinforcement Splash plank Columns sized to meet wind loads Steel anchor designed to resist wind loads Treated sill plate Splash plank Columns sized to meet wind loads Steel anchor designed to resist wind loads Treated sill plate Thickened edge Monolithic concrete slab

THIS IS POST-FRAME PLAN VIEW

Purlin (24” o.c.) Post Girder (Header for

• penings)

Clear Span Truss

KEY FEATURES OF POST-FRAME

Eave Height Post Height Clear Span

Cross section

Post Footing Post Foundation Sidewall Post Truss Purlins Girts

Splashboard

• Wood sidewall columns
• Wide bay spacing - 8 ft. and greater
• Large clear spans - up to 100 ft.
• Embedded wood columns or concrete piers
• Attached wall and roof sheathing or cladding

form structural shearwall/structural diaphragm system for resisting lateral loads

KEY FEATURES OF POST-FRAME

• Solid-sawn, glued-laminated, or mechanically

(nail) laminated wood

• Nominal 6x6, 6x8, 8x8 or 8x10 cross section
• Typically spaced 4, 6, 8, 12 or 16 ft. on center

along sidewall

• Any portion of the wood post embedded directly

into the ground and 6 -12 in. above grade is pressure preservative treated to AWPA- recommended levels for ground contact

WOOD SIDEWALL COLUMNS

Spliced glued-laminated column

• 3-ply or 4-ply,

fabricated with 2x lumber

• Lower portion is

preservative treated

• Upper portion is

untreated

WOOD SIDEWALL COLUMN

WOOD SIDEWALL COLUMNS

Nail-laminated posts with treated bottom spliced to untreated top Preservative- treated splash board

WOOD SIDEWALL COLUMNS

Untreated Post Concrete Pier

PRESSURE PRESERVATIVE TREATMENTS

• Posts embedded in

the ground, specify:

• Use category UC4B
• r better per AWPA-

U1-09

• e.g., CCA@0.60 pcf

POST FOUNDATION OPTIONS: EMBEDDED TREATED COLUMNS

Treatment stamp

PRECAST OR CAST-IN-PLACE REINFORCED CONCRETE PIER

• Pre-cast reinforced concrete

pier with post attached above grade

• Entire assembly

pre-engineered

• Assembly usually fabricated

in factory and shipped to site as a single unit

PRE-CAST REINFORCED CONCRETE PIER

Reinforcement Cleat

CAST-IN-PLACE CONCRETE FOUNDATION WALL

Untreated Post Connection Hardware Cast-in-Place Concrete Foundation Wall

THICKENED CONCRETE SLAB

THICKENED CONCRETE SLAB

• Blow-molded plastic or HDPE

plastic protective barriers

• Provide moisture and insect

protection

• “Enhance protection of copper-

based chemical treated wood posts or laminated columns”

PROTECTIVE POST COVERS

• Pre-engineered metal plate connected 2x

lumber trusses typically spaced 4 - 8 ft. on center

• Heavier timber trusses for larger post and truss

spacings and aesthetic requirements

• Solid-sawn wood rafters spaced 2 - 4 ft.
• n center for shorter clear spans
• Glulam rafters for larger rafter spacings or clear

spans

ROOF FRAMING

ROOF FRAMING

Trusses Sidewall Column (connected to trusses)

• Posts are connected directly to the roof framing

if post and roof framing spacing are the same

• Posts and roof framing are often connected to

header beams if post and roof framing spacing are not the same

POST TO ROOF FRAMING CONNECTIONS

POST TO ROOF FRAMING CONNECTION

Block Height Block Connection is usually a pinned connection (not a moment-resisting connection)

POST TO ROOF FRAMING CONNECTION

POST TO ROOF FRAMING CONNECTION

SOLID SAWN POSTS

1½” Connection with truss fastened to slide of post and with bear block Connection with truss bearing on notch in post Typical post-to-truss connection details for a solid sawn post application

ROOF PURLIN PLACEMENT

Purlins oriented flat

• r “on edge,”

depending on truss and purlin spacing Purlins placed either

• n top or inset

between truss top chords or inset between roof rafters

ROOF FRAMING AND PURLINS

Truss Purlin 2 ft o.c. Connection to Post Connection 8 ft o.c.

• Typically 2x4 to 2x8 solid sawn lumber, spaced

24 - 32 inches apart

• Oriented “flat” on outside face of wall post for

smaller post and girt spacings and loads

• “On edge” between adjacent posts for larger

loads or post or girt spacings

WALL GIRTS

WALL GIRTS AND SHEATHING

Wall Girt Sheating

WALL GIRTS AND SHEATHING

SECONDARY FRAMING AND BRACING

• Corner bracing in upper chords of trusses
• Diagonal bracing for lower chords of trusses
• Lower chord stiffeners for trusses
• Cross-bracing of selected compression webs
• Continuous longitudinal bracing of long

compression webs and chords of trusses

• ANSI/ASAE (ASABE) EP 484 for diaphragm

design of metal-clad, post-frame rectangular buildings

• ANSI/ASAE (ASABE) EP 486 for shallow post

foundation design

• ANSI/ASAE (ASABE) EP 559 for design

requirements and bending properties for mechanically laminated columns

POST-FRAME TECHNICAL RESOURCES

• Structural design

procedures for post-frame building systems –Post Frame designer’s primary reference –NFBA.org

POST FRAME BUILDING DESIGN MANUAL

• Cost-effective
• Energy efficient
• Code compliance
• Sustainability and greenness
• Design flexibility
• Durability and strength

BENEFITS OF POST-FRAME

Examples of Post-Frame Applications in Commercial Buildings

Function/Size: Office Building, 16,000 SF Location: Grand Rapids, MI Posts: 3-ply, 2 x 6 glulam posts, 6 ft. o.c.; 0.6 pcf CCA below grade, 0.4 pcf above ground Post foundation: Post embedded in ground Roof framing: 42 to 78 ft. hip roof, 24 in o.c.; OSB sheathing Wall girts: 2x4, 16” o.c., flat Insulation: R-19 in walls; R-40 in ceiling Exterior finish: Glass and cultured stone Interior finish: Painted drywall and acoustical tile Cost: $89/SF

Function/Size: Veterinary Clinic, 48’ x 125’, 6,000 SF Location: Mattoon, IL Posts: 3-ply, nominal 2 x 6 nail-lam posts, 7’-6” o.c. Post foundation: Posts set on concrete foundation wall Roof framing: 48’ clear span trusses, 7’-6” o.c.; 2x4 purlins on edge, 24” o.c. Wall girts: 2x4 and 2x6, 32” o.c., flat Insulation: R-19 in walls; R-38 in ceiling Exterior finish: Ribbed steel roof panels; brick walls Interior finish: Drywall and suspended ceilings. Construction time: 6 months Cost: $150/SF

Function/Size: Church, 118’ x 168’ ft, 19,824+ SF Location: Salina, KS Posts: 4 ply, 2 x 8 nail-lam posts, 7’-6” o.c. Post foundation: 4 in. x 4 ft. deep cast-in-place concrete foundation wall Roof framing: Double 2x trusses, 7’-6” o.c.; 2x4 purlins on edge 24” o.c. Wall girts: 2x6, 32” o.c., flat Insulation: R-19 in walls; R-38 in ceiling Exterior finish: Painted steel siding and brick; wainscot in selected areas Interior finish: Sheetrock w/acoustical steel in gymnasium area Construction time: 7 months Cost: $92/SF

Function/Size: Volunteer Fire Company, 80’ x 100’; 8,000 SF Location: Lexington, NC Posts: 3-ply, 2 x 8 nail-lam, 8’ o.c.; 0.8 pcf CCA preservative treatment above/below ground Post foundation: Posts embedded in ground Roof framing: Single 2x, 80’ clear span trusses, 8’ o.c.; 2x4 purlins on edge, 24” o.c. Wall girts/sheathing: 2x4, 30” o.c., flat. Insulation: R-30 in walls; R-38 in ceiling Exterior finish: 26 gauge painted ribbed steel Interior finish: Steel sheathing in bay; sheetrock and suspended ceilings in office areas Construction time: 8 months Cost: $70/SF

Function/Size: Church 22,000 sq.ft. Location: Kokomo, IN Posts: 3-ply, nominal 2x6 nail-lam posts, 8’0” o.c. Post foundation: Posts set on poured concrete footings Roof framing: 84’ clear span truss (main building), 8”0” o.c. flat trusses for entry and carport Purlins on: 2x4s edge, 24” o.c. Wall girts: 2x6, 32” o.c., flat Insulation: R-19 in walls; R-38 in ceiling Exterior finish: Ribbed steel roof panels Interior finish: Drywall and suspended ceilings, slate floors Construction time: 7 months Cost: $99/SF

Applications of Post-Frame Buildings…

…are limited only by the designer’s Imagination and Creativity

***

We Are Here To Help…

800-356-9682 Visit Wick at WickBuildings.com Specifications and details available… Design review and engineering assistance THANK YOU! “Building You A Better Future”

WICK BUILDINGS Wick Buildings, Inc.

National Frame Building Association

What is the NFBA? The NFBA is the only national trade association that represents post-frame industry professionals Mission: To advance the post-frame industry Value Proposition: NFBA shapes the future of post- frame and provides our members with a measurable return on investment through networking, trade shows, technical support, education, research, codes/standards development and accreditation

Wick Buildings, Inc.

• National Frame Building

Association (NFBA)

• NFBA.org
• PostFrameAdvantage.com
• NFBA

8735 W Higgins Road Suite 300 Chicago, IL 60631 800-557-6957

MORE ABOUT POST-FRAME

THANK YOU!

Wick Buildings, Inc. 405 Walter Road, P.O. Box 38 Mazomanie, WI 53560 800-356-9682 WickBuildings.com

Questions and Comments?
