Draft North Florida Regional Water Supply Plan Public Workshop at the University of North Florida October 25, 2016 Scott Laidlaw, P.G. St. Johns River Water Management District Amy Brown, Ph.D. Suwannee River Water Management District

slide-1
SLIDE 1

Draft North Florida Regional Water Supply Plan

Public Workshop at the University of North Florida

Scott Laidlaw, P.G.

  • St. Johns River Water Management District

Amy Brown, Ph.D.

Suwannee River Water Management District

October 25, 2016

slide-2
SLIDE 2

Outline of today’s discussion

2

  • North Florida Water Supply Partnership
  • Florida statutes and regional water

supply planning

  • North Florida Regional Water Supply

Plan - NFRWSP

slide-3
SLIDE 3

North Florida Regional Water Supply Partnership

3

slide-4
SLIDE 4

North Florida Regional Water Supply Partnership

  • Regional water supply planning

–Stakeholder Advisory Committee

  • Minimum flows and minimum levels
  • Groundwater modeling
  • Hydrologic data
  • Project development
  • Conservation and irrigation efficiency

4

slide-5
SLIDE 5

35 Stakeholder Advisory Committee meetings

5

Stakeholder Group SJRWMD Member SRWMD Member Public Supply Rick Hutton, P.E.

Gainesville Regional Utilities

Stephen Roberts

Lake City Utilities

Agriculture Kerry Kates

Florida Fruit and Vegetable Association

Thomas Harper

Harper Farms

Commercial/Power Generation Nancy Kilgo Veasey

JEA

James Cornett

Cornett’s Spirit of the Suwannee, Inc.

Environmental Patrick T. Welsh, Ph.D.

UNF and Save Our Lakes

Jacqui Sulek

Audubon Florida

Industrial/Mining

  • J. Michael O’Berry

Vulcan Materials Company

Terry L. Baker, P.E.

PotashCorp – Phosphate Division

Local Government Lee Pinkoson

Commissioner, Alachua County

Gene Higginbotham

Commissioner, Dixie County

slide-6
SLIDE 6

Outreach and collaboration

6

35 SAC meetings

slide-7
SLIDE 7

Regional water supply planning, §373.709, F .S.

The governing board of each water management district shall conduct water supply planning for a water supply planning region …, where it determines that existing sources of water are not adequate to supply water for all existing and future reasonable-beneficial uses and to sustain the water resources and related natural systems for the planning period.

7

slide-8
SLIDE 8

What is a regional water supply plan (RWSP)?

Constitutes an assessment of:

  • how much water needed over the planning horizon and
  • whether the traditional sources meet the demand

While:

  • protecting the water resources and related natural

systems and

  • identifying future water supply sources

8

slide-9
SLIDE 9

RWSP process

  • 20-year planning horizon
  • Conducted in open public process
  • Identifies supply sources/water resource

development projects to meet all reasonable- beneficial demands

  • Approved by Governing Board
  • Updated on a 5-year basis

9

slide-10
SLIDE 10

Is a RWSP similar to a capital facilities plan?

No –

– WSPs focus on sustainability of resources – Point to or identify options for water supply, strategies, and AWS projects

  • economic feasibility
  • environmental feasibility
  • technical feasibility

10

slide-11
SLIDE 11

Are users required to implement RWSP options?

No –

  • Water users are not required to implement any
  • f the options identified
  • Users may offer one of these alternatives to

mitigate impacts for new permits or when requesting increases in allocations

11

slide-12
SLIDE 12

Will a RWSP affect consumptive (water) use permits?

No –

  • This is a plan, not a regulatory requirement
  • The plan contains strategies

– conservation concepts – essential to all water use permits – reclaimed water and AWS feasibility evaluations – lowest quality source

12

slide-13
SLIDE 13

NFRWSP – planning process

  • NFSEG regional groundwater flow model
  • Water use and future projections
  • Water resource analysis
  • Water supply development and water

resource development projects

  • Water conservation and reuse

13

slide-14
SLIDE 14

NFSEG regional groundwater flow model overview

14

slide-15
SLIDE 15

Water ter use use and pr and projections

  • jections for t
  • r the

he NFRWSP NFRWSP ar area ea

15

Numbers may differ slightly due to rounding Values shown in million gallons per day. Values do not include NWFWMD, SWFWMD or Georgia

Category 2010 2035 Change % Change Public Supply 198 256 58 29 Domestic Self-Supply and Small Utilities 49 61 12 24 Agriculture 135 153 18 13 Commercial / Industrial / Institutional and Mining / Dewatering 121 132 11 9 Landscape / Recreation / Aesthetic 22 31 9 41 Power Generation 25 34 9 36

Total 550 667 117 21

slide-16
SLIDE 16

275,000 550,000 825,000 1,100,000 1,375,000 1,650,000 1,925,000 2,200,000 2,475,000 2,750,000 100 200 300 400 500 600 700 800 900 1000 1995 2000 2005 2010 2015 2020 2025 2030 2035 Population Million Gallons Per Day Year

Historic Water Use and Population -vs- Projected Water Demand and Population in NFRWSP

Public Supply Agriculture Commercial / Industrial / Institutional & Mining / Dewatering Landscape / Recreational / Aesthetic Domestic Self-Supply Power Generation Population

16

slide-17
SLIDE 17

The region’s challenge

WRD projects are predicted to reduce withdrawal effects to priority water bodies.

17

Estimate 667 mgd of water need at 2035 550 mgd in 2010 Range of recovery for the Lower Santa Fe and Ichetucknee MFLs 117 mgd potential needed by 2035

slide-18
SLIDE 18

Water resource analysis

  • Assessed the amount of fresh

groundwater available to meet 2035 demands using NFSEG model

  • Determined impacts to water resources

‒ groundwater quality ‒ wetlands ‒ MFLs ‒ spring flows ‒ non-MFL priority water bodies

18

slide-19
SLIDE 19

Analysis results determined that:

  • Traditional groundwater sources can meet

some, but not all, projected water needs

  • Water demand projections exceed fresh

groundwater availability

  • There are wells with elevated chlorides, and

increasing chloride trends

  • There are springs and rivers below MFLs
  • There are potential impacts to non-MFL

springs or other waterbodies

19

slide-20
SLIDE 20

Estimated changes in drawdown based on Demand Projections

20

2035 without WRD projects 2035 with WRD projects

slide-21
SLIDE 21

Groundwater quality concerns

Chloride Trends – Rate

  • f Change

Number of Wells Currently >250 mg/l Number of Wells Expected >250 mg/L by 2035 > 3mg/L per year 5 11 1 to 3 mg/L per year 1

21

slide-22
SLIDE 22

Surface water constraints

22

slide-23
SLIDE 23

Proposed Water Resource Caution Area

23

slide-24
SLIDE 24

Since constraints are not met

  • The plan identifies projects to meet future

demands while meeting the needs of the water resources

  • The projects include a combination of water

resource development, water supply development, conservation, reclaimed water or

  • ther projects
  • The total sum of projects exceeds the shortfall;

these projects are identified to show that future demands can be met through a combination of alternatives

24

slide-25
SLIDE 25

Opportunities and solutions

  • Water conservation
  • Recharge
  • Alternative water supply

– Surface water – Stormwater harvesting – Reuse

  • Collaboration

25

slide-26
SLIDE 26

Water conservation

26

  • Indoors
  • Outdoors
  • Rates
  • Education
slide-27
SLIDE 27

2035 Low and high water conservation potential

27

slide-28
SLIDE 28

28

Diversification of water supplies: Excess surface water or storm water

slide-29
SLIDE 29

Reuse options

29

Potable reuse Rebound (in feet) for 10 MGD injection Golf course irrigation Recharge Augmentation of surface waters used for irrigation Landscape irrigation

slide-30
SLIDE 30

20 2015 15 Reu euse se an and d was aste tewate ter r disp dispos

  • sal

al

30

slide-31
SLIDE 31

Water resource development projects

Type Number of Projects Quantity Water Produced (mgd) Estimated Cost ($M) Groundwater (LFA) 2 10.30 3.80 Surface Water 11 47.39 153.59 Seawater N/A N/A Reclaimed Water 3 7.50 9.65 ASR and Reservoirs N/A N/A Total 16 65.19 167.04

31

Note: Estimated costs are construction costs only

slide-32
SLIDE 32

Water supply development projects

Type Number of Projects Quantity Water (mgd) Estimated Cost ($M low range) Groundwater (IAS and LFA) 2 2.88 0.79 Stormwater/Surface Water 5 5.37 50.68 Reuse of RO Concentrate 1 0.75 1.24 Seawater N/A N/A Reclaimed Water 56 86.44 169.89 Total 64 95.44 222.60

32

Note: Estimated costs are construction costs only

slide-33
SLIDE 33

WSP Planning Pr WSP Planning Process

  • cess

33

WMDs - Update WSP every five years 6 Months – WMD Notifies PWS of projects in WSP 12 Months – PWS selects project(s) and informs WMD 18 Months – Facilities Work Plan adopted into Comp Plan Annually Nov. 15 – PWS submit Annual Report

After GB Approval Then Thereafter

slide-34
SLIDE 34

34

Importance of collaboration

  • Meet needs of commercial, agricultural, environmental and

urban uses

  • Meet needs of recreational and quality of life
  • Business and community leader engagement is vital
  • Working together to meet all the needs will ensure

a vital economy

slide-35
SLIDE 35

Activity 2014 2015 2016 2017

Stakeholder Outreach Develop, Evaluate, and Revise Project Benefits Draft Water Supply Plan Resource Assessment Stakeholder Input on Draft Plan Finalize Water Supply Plan Implement Water Supply Plan

35

Water Supply Plan Timeline

slide-36
SLIDE 36

How to submit comments

  • Go to: http://northfloridawater.com/watersupplyplan/draft.html
  • If you have several comments please use comment

review form (excel spreadsheet)

  • Otherwise you can submit on the embedded form

at the above web address or at: nfrwsp-comments@sjrwmd.com

36

slide-37
SLIDE 37

Questions?

37
