Vision One91 BURNSVILLE HIGH SCHOOL BOARD UPDATE MAY 28, 2015 Mark Hayes Mark Hovelson Eric Anderson Andy Hoffmann ATS&R Wenck Vision One91 B.H.S. AGENDA Construction Phasing / Bid Packages Bid Package #1 Scope

slide-1
SLIDE 1

Vision One91

BURNSVILLE HIGH SCHOOL BOARD UPDATE MAY 28, 2015

Mark Hayes Mark Hovelson Eric Anderson Andy Hoffmann ATS&R Wenck

slide-2
SLIDE 2

AGENDA

  • Construction Phasing / Bid Packages
  • Bid Package #1 – Scope
  • Project Update
  • Site
  • West Classroom / Tech. Addition
  • Activity Center Addition
  • Science / Classroom Addition
  • Preliminary Milestone Dates

Vision One91 – B.H.S.

slide-3
SLIDE 3

Construction Phasing / Bid Packages

Bid Package Issue Bid Award #1– Annex Alts./ 4/30/15 5/21/15 5/28/15 Demo./ Site Utilities #2 - Precast Wall 5/15/15 6/4/15 6/11/15 Panels #3 - Footings / Conc. 7/1/15 7/28/15 8/13/15 / Steel / Conc. Blk. #4 - Finishes / Mech. 9/1/15 9/24/15 10/8/15 / Elec. / Tech.

slide-4
SLIDE 4

Burnsville High School – Bid Package #1 Tech Lab

Classroom Construction Trades Auto Body Auto Shop

slide-5
SLIDE 5

Burnsville High School – Bid Package #1 Tech Lab Elevation Existing Elevation

slide-6
SLIDE 6

Construction Staging

Loss of 360 – 400 parking spaces during construction

slide-7
SLIDE 7

Site Plan

Existing Site

slide-8
SLIDE 8

Site Plan

PARKING

STAFF 250 STUDENT 637 VISITOR 14 BCTV 10 TOTAL 911 BUSES 31

  • SP. ED.

11

245 402 111 26 101 8 18

slide-9
SLIDE 9

Site Plan

WEST ADDITION

slide-10
SLIDE 10

Site Plan

ACTIVITY CENTER

slide-11
SLIDE 11

Site Plan

SCIENCE ADDITION

slide-12
SLIDE 12

Burnsville High School – Project Scope

Mechanical

  • Ice Storage
  • Chiller

B.E.S.T. West Addition

  • Classrooms
  • Commons
  • Tech Ed
  • Staff Planning
  • FTLA

Science Addition

  • Classrooms
  • Science

Labs

  • FTLA

Activities Addition

  • Health

Classrooms

  • PE Lockers
  • Community

Lockers

  • Athletic/ PE
  • CNA Lab
  • Pool Locker

Update Piano Lab

  • Sheet Music

Storage

  • Instrument

Storage

slide-13
SLIDE 13

Burnsville High School – West Addition Main Level

slide-14
SLIDE 14

Burnsville High School – West Addition Tech Ed House

slide-15
SLIDE 15

Burnsville High School – West Addition Administration

slide-16
SLIDE 16

Burnsville High School – West Addition Classroom/ FTLA

slide-17
SLIDE 17

Burnsville High School – West Addition Upper Level

slide-18
SLIDE 18

Burnsville High School – West Addition Lower Level

slide-19
SLIDE 19

Burnsville High School – West Addition Perspective

slide-20
SLIDE 20

Burnsville High School – West Addition Perspective

slide-21
SLIDE 21

Burnsville High School – West Addition Perspective

slide-22
SLIDE 22

Burnsville High School – Activities Addition Main Level

slide-23
SLIDE 23

Burnsville High School – Activities Addition Upper Level

slide-24
SLIDE 24

Burnsville High School – Activities Addition Perspective

slide-25
SLIDE 25

Burnsville High School – Activities Addition Perspective

slide-26
SLIDE 26

Burnsville High School – Science Addition Main Level

slide-27
SLIDE 27

Burnsville High School – Science Addition Upper Level

slide-28
SLIDE 28

Burnsville High School – Science Addition Perspective

slide-29
SLIDE 29

Task Start Finish Bid Package #1 Mobilization 6/15/15 Site Demolition 6/20/15 8/21/15 Annex Renovations 6/20/15 10/23/15

  • Reloc. of Underground Utilities

6/20/15 8/7/15

  • Reloc. of Long Jump/Pole Vault

6/20/15 8/21/15 Precast Wall Panel Erection 12/15/15 1/15/16 Roofing 1/4/16 2/15/16 Building Enclosure 2/15/16 3/15/16 Rough Interior Work 1/15/16 5/15/16 Interior Finishes 3/1/16 8/18/16 Parking Lots/Site Improvements 6/1/16 8/18/16 Project Substantial Completion 8/19/16

Preliminary Milestone Dates

slide-30
SLIDE 30

Thank You, Questions…
