AE-705: Introduction to Flight Viscous Flow, Reynolds Number & Boundary Layers Athul Viswam Aerospace Engineering Department IIT Bombay AE-705 Introduction to Flight Lecture-05 Chapter-03 CONTENTS Introduction to Viscous Flow

slide-1
SLIDE 1

AE-705 Introduction to Flight Lecture-05 Chapter-03

AE-705: Introduction to Flight

Viscous Flow, Reynolds Number & Boundary Layers

Athul Viswam

Aerospace Engineering Department IIT Bombay

slide-2
SLIDE 2

AE-705 Introduction to Flight Lecture-05 Chapter-03

CONTENTS

 Introduction to Viscous Flow  Laminar and Turbulent Flow  Concept of Boundary Layer  Types of Boundary Layer  Flow Separation

slide-3
SLIDE 3

AE-705 Introduction to Flight Lecture-05 Chapter-03

Lets start with a simple experiment

slide-4
SLIDE 4

AE-705 Introduction to Flight Lecture-05 Chapter-03

?

slide-5
SLIDE 5

AE-705 Introduction to Flight Lecture-05 Chapter-03

Which one is thicker ??

https://en.wikipedia.org/wiki/Viscosity#/media/File:Viscosities.gif

slide-6
SLIDE 6

AE-705 Introduction to Flight Lecture-05 Chapter-03

 Resistance to relative motion ( friction??? )  Thicker  Higher Viscosity  Higher Viscosity  Lower flow rate 

Are gases viscous too??

Viscosity

slide-7
SLIDE 7

AE-705 Introduction to Flight Lecture-05 Chapter-03

Well, Good to know about viscosity! Let us calculate the pressure using Bernoulli’s principle Oye! Go and read my assumptions

slide-8
SLIDE 8

AE-705 Introduction to Flight Lecture-05 Chapter-03

Flow in a pipe

slide-9
SLIDE 9

AE-705 Introduction to Flight Lecture-05 Chapter-03

What about external flows? Can we have Laminar flow over aeroplane wings?

slide-10
SLIDE 10

AE-705 Introduction to Flight Lecture-05 Chapter-03

Laminar flow over a wing cross section

Source : **

slide-11
SLIDE 11

AE-705 Introduction to Flight Lecture-05 Chapter-03

Laminar flow over cylinder

Source : **

slide-12
SLIDE 12

AE-705 Introduction to Flight Lecture-05 Chapter-03

Laminar flow over a rectangular block

Source : **

slide-13
SLIDE 13

AE-705 Introduction to Flight Lecture-05 Chapter-03

Laminar flow over a flat plate

Source : **

slide-14
SLIDE 14

AE-705 Introduction to Flight Lecture-05 Chapter-03

Can we predict when would a Laminar flow becomes Turbulent?

slide-15
SLIDE 15

AE-705 Introduction to Flight Lecture-05 Chapter-03

I have made some efforts to study this. You will learn most of my theories later !! Who am I ?

slide-16
SLIDE 16

AE-705 Introduction to Flight Lecture-05 Chapter-03

A Short Quiz

Who is this famous scientist?

a) Ludwig Prandtl b) George Gabriel Stokes c) Osborne Reynolds d) Arnold Sommerfeld

Can you answer ?

https://en.wikipedia.org/wiki/Sir_George_Stokes,_1st_Baronet#/media/File:Ggstokes.jpg

slide-17
SLIDE 17

AE-705 Introduction to Flight Lecture-05 Chapter-03

Reynolds Number:

 Re No =

Inertial force Viscous force = ρVL μ

 Transition Re No  Critical Reynolds No  Critical Re No for Internal flow  3000 - 5000  For external flow  300000 – 500000  Best measure to compare flows  Re No Laminar nature

slide-18
SLIDE 18

AE-705 Introduction to Flight Lecture-05 Chapter-03

Re No : 100

http://www.neuroems.com/2014/03/15/blood-flow-through-the-brain-pt-1-overview/

slide-19
SLIDE 19

AE-705 Introduction to Flight Lecture-05 Chapter-03

Re No ~ 4 million

https://breakingmuscle.com/fitness/7-essential-swimming-tips-for-even-the-strongest-athletes

slide-20
SLIDE 20

AE-705 Introduction to Flight Lecture-05 Chapter-03

Re No ~ 109

http://www.cruisecritic.co.uk/news/news.cfm?ID=7096

Can you name this Ship ?

slide-21
SLIDE 21

AE-705 Introduction to Flight Lecture-05 Chapter-03

What happens when Re No is 2900 in a pipe? Will it be purely Laminar?

slide-22
SLIDE 22

AE-705 Introduction to Flight Lecture-05 Chapter-03

We usually compare the

  • rder of

magnitude

slide-23
SLIDE 23

AE-705 Introduction to Flight Lecture-05 Chapter-03

This is non-viscous flow in a pipe What would be the case with viscosity?

Laminar? Or Turbulent? So, will Reynolds no be low or high?

slide-24
SLIDE 24

AE-705 Introduction to Flight Lecture-05 Chapter-03

Viscous flow over a solid surface

Why didn’t the fluid in contact with solid surface move?

slide-25
SLIDE 25

AE-705 Introduction to Flight Lecture-05 Chapter-03

Viscous flow over flat plate

https://github.com/su2code/SU2/wiki/Laminar-Flat-Plate

Viscosity spoiled my flow field

slide-26
SLIDE 26

AE-705 Introduction to Flight Lecture-05 Chapter-03 https://en.wikipedia.org/wiki/Boundary_layer

Why don’t you split the domain in 2 regions ? One where viscous effects are significant Another with negligible viscous effects?

slide-27
SLIDE 27

AE-705 Introduction to Flight Lecture-05 Chapter-03

 First defined by the Father of Aerodynamics  Edge of BL – 99% of Freestream velocity

v δ = Boundary layer thickness Boundary layer

Boundary Layer

δ

slide-28
SLIDE 28

AE-705 Introduction to Flight Lecture-05 Chapter-03 Source **

I observed it first ! Who am I ? I formulated it first ! Who am I ?

slide-29
SLIDE 29

AE-705 Introduction to Flight Lecture-05 Chapter-03

Velocity profile 99% of v Transition to turbulence Laminar BL Turbulent BL

slide-30
SLIDE 30

AE-705 Introduction to Flight Lecture-05 Chapter-03

Transition Strips in WT Testing

M Mirzaei, MH Karimi, MA Vaziri, An investigation of a tactical cargo aircraft aft body drag reduction based on CFD analysis and wind tunnel tests, Aerospace Science and Technology, 2012

slide-31
SLIDE 31

AE-705 Introduction to Flight Lecture-05 Chapter-03

Transition Strips in WT Testing

M Mirzaei, MH Karimi, MA Vaziri, An investigation of a tactical cargo aircraft aft body drag reduction based on CFD analysis and wind tunnel tests, Aerospace Science and Technology, 2012

slide-32
SLIDE 32

AE-705 Introduction to Flight Lecture-05 Chapter-03

Sometimes, transition strips don’t work !

XL Wang, GY Fu, DP Duan, XX Shan, Experimental Investigations on Aerodynamic Characteristics of the ZHIYUAN-1 Airship, Technical Note, Journal of Aircraft, 2010,

slide-33
SLIDE 33

AE-705 Introduction to Flight Lecture-05 Chapter-03

Experiment v/s Numerical Simulation

  • S. Suman, S. Lakshmipathy, R. S. Pant, Evaluation of the assumed-transition-point criterion in context of

RANS simulations around Lighter-Than-Air vehicles, Journal of Aircraft, 50(2), 2013

slide-34
SLIDE 34

AE-705 Introduction to Flight Lecture-05 Chapter-03

Effect of Transition Location

Flow separation occurs CD ↓ as more surface is exposed to Laminar flow CD ↑ as more surface is exposed to flow separation

  • S. Suman, S. Lakshmipathy, R. S. Pant, Evaluation of the assumed-transition-point criterion in context of

RANS simulations around Lighter-Than-Air vehicles, Journal of Aircraft, 50(2), 2013

slide-35
SLIDE 35

AE-705 Introduction to Flight Lecture-05 Chapter-03

Real flow field

?

Source ** Video source : NIT Suratkal

slide-36
SLIDE 36

AE-705 Introduction to Flight Lecture-05 Chapter-03

Flow separation

 Viscous flow phenomenon  “Adverse pressure gradient” ?

Pressure decreases  favourable pressure gradient

slide-37
SLIDE 37

AE-705 Introduction to Flight Lecture-05 Chapter-03

Pressure increases  unfavourable pressure gradient

slide-38
SLIDE 38

AE-705 Introduction to Flight Lecture-05 Chapter-03

Distance Local pressure Direction of flow tendency

slide-39
SLIDE 39

AE-705 Introduction to Flight Lecture-05 Chapter-03

Distance Local pressure Actual direction of flow

How??

slide-40
SLIDE 40

AE-705 Introduction to Flight Lecture-05 Chapter-03

Because flow has momentum which drives the flow against pressure gradient But flow near the solid surface already lost most

  • f its momentum!!
slide-41
SLIDE 41

AE-705 Introduction to Flight Lecture-05 Chapter-03

So, guess what happens!!

slide-42
SLIDE 42

AE-705 Introduction to Flight Lecture-05 Chapter-03

What is happening in the separated flow region?

slide-43
SLIDE 43

AE-705 Introduction to Flight Lecture-05 Chapter-03

Reversed Flow

Source **

slide-44
SLIDE 44

AE-705 Introduction to Flight Lecture-05 Chapter-03 https://en.wikipedia.org/wiki/Flow_separation

slide-45
SLIDE 45

AE-705 Introduction to Flight Lecture-05 Chapter-03

Can you answer why is there a reversal of flow? Clue: pressure gradient

slide-46
SLIDE 46

AE-705 Introduction to Flight Lecture-05 Chapter-03

HOMEWORK: Flow Separation and Recirculation

slide-47
SLIDE 47

AE-705 Introduction to Flight Lecture-05 Chapter-03

Is laminar BL separation similar to turbulent BL separation?

slide-48
SLIDE 48

AE-705 Introduction to Flight Lecture-05 Chapter-03

Turbulent BL delays separation – higher momentum

slide-49
SLIDE 49

AE-705 Introduction to Flight Lecture-05 Chapter-03

Tired?

slide-50
SLIDE 50

AE-705 Introduction to Flight Lecture-05 Chapter-03

Let us watch cricket!!

slide-51
SLIDE 51

AE-705 Introduction to Flight Lecture-05 Chapter-03

SWING and REVERSE SWING?

slide-52
SLIDE 52

AE-705 Introduction to Flight Lecture-05 Chapter-03

Let us talk about Golf!

slide-53
SLIDE 53

AE-705 Introduction to Flight Lecture-05 Chapter-03

Why so many dimples?

slide-54
SLIDE 54

AE-705 Introduction to Flight Lecture-05 Chapter-03

What we have learnt till now?

 Viscous flow  Types of flow – Laminar & Turbulent  Transition  Reynolds no – effects  Boundary layer  Separation

QUESTIONS??
