Videofon MV JSC

//Contents

//1 About Videofon MV 2 //2 Scope of business 4 //3 Integrated security systems 6 //4 Projects 8 //5 Safe City 10 //6 Security system designing 12 //7 Access control system

14

//8 Automated control systems

16

//9 Adler – Alpika-Service 22 //10 Energy effi ciency 24 //11 Automatic system of control, metering and wireless data transmission from utility metering devices (AMR)

28

//12 MEP systems 30 //13 Equipment 32 //14 Partners 34 //15 Our customers 36 //16 Certifi cates 38 //17 Contact 40

3

//1 About Videofon MV

Videofon MV, JSC was founded in 2000. Our company is a system integrator and focuses on design engineering, production, and implementation

• f a variety of innovative products in the areas of

automation at large-scale industrial and transportation enterprises, integrated security systems at facilities of any complexity rating, energy efficiency at industrial enterprises, communication and monitoring of MEP equipment. We owe our success on the Russian market to continuous investments into development of our own technologies and close attention to our clients’ live needs. The above factors ensure our company’s dynamic growth; allow us to broaden our geographical reach and enable our expansion into new markets. Videofon MV implements a range of activities comprising: Concept development Hardware engineering Sost ware engineering Testing Production Designing Equipment delivery Installation Commissioning Maintenance Besides, our company develops hardware for: Integrated security systems; Thermal imaging monitoring systems; GLONASS/GPS satellite monitoring systems; Road, rail and water transport control systems; Installation of MEP monitoring systems.

5

//2 Our scope of business

The business of the company is divided into diff erent lines related to large-scale government and commercial procurements. Our hardware and sost ware solutions ensure security at various industrial, transportation and retailing enterprises; infrastructure facilities; municipal facilities; banking and fi nancial institutions. The company carries on activities related to: Integrated security systems; Automated process control systems; Industrial energy effi ciency systems; Thermal imaging MEP monitoring systems; MEP systems; Automatic metering systems for energy consumption billing; MEP communication and monitoring systems.

7

//3 Integrated Security System

The system consists of: Video Surveillance System; Thermal Imaging Video Surveillance System; Perimeter Security System; Access Control System; Radar Monitoring System; Lighting System; Technical Security Equipment; Public Address System; Communication System; Cabling System; Electrical Power Supply System of TSE (Technical Security Equipment); Security and Fire Alarm System; Automatic Parking Management System; Sabotage and Terrorist Kill Device Identifi cation Detection Equipment; Special Communication Center Equipment; Automatic Fire Fighting System.

9

//4 Projects

Integrated security system of the Sochi Olympic sites

Videofon MV equipped Mountain cluster Olympic sites in Krasnaya Polyana with integrated security

• systems. The system comprised:

The integrated Mountain Cluster Security System covers eight 5.5 kilometer-long perimeters and include 10 car check points and 18 entry check points equipped with screening systems. The unique Aerostat-based Video Surveillance System provides an image transmission to a mobile command center and opens up new opportunities for outdoor facilities video surveillance. Video Surveillance System; Thermal Imaging Video Surveillance System; Aerostat-based Video Surveillance System; Perimeter Security System; Access Control System; Lighting System; Technical Security Equipment; Sabotage and Terrorist Kill Device Identifi cation Detection Equipment; Public Address System; Special Communication Center Equipment; Cabling System; Electrical Power Supply System of TSE (Technical Security Equipment).

Integrated security system of the Adler — Alpika-Service combined highway/railway

In the years 2012-2014 our company equipped the Adler – Krasnaya Polyana combined highway/railway with an integrated security system. The system consists of: The length of the road under security is 48 km. Total number of video cameras is 1997 pieces. All security systems transmit their signals to 68 guard booths, 6 guards, a unifi ed command centre, and EMERCOM Crisis Management Center. Video Surveillance System; Thermal Imaging Video Surveillance System; Perimeter Security System; Access Control System; Radar Monitoring System; Lighting System; Technical Security Equipment; Public Address System; Communication System; Cabling System; Electrical Power Supply System of TSE (Technical Security Equipment); Tunnel ventilation system; Tunnel smoke exhaust system; Tunnel fi re fi ghting system; Tunnel alarm system.

11

//5 Safe City project

Videofon MV is one of the parties who contributed most of all into implementation of the Moscow Safe City project. Over 16 000 residential buildings have been equipped with CCTV cameras and intercoms in Moscow between 2003-2013 and security services were provided for a score of public facilities (schools, kindergartens, hospitals, shopping malls, etc.). Our R&D team has a long experience in engineering

• f not innovative video surveillance systems alone. It

has also designed unique video analysis technologies equipment including face capture and recognition; traffic monitoring; license plate, carriage number, and cargo container number recognition. Videofon MV equipped with its security systems: Novorossiysk marine passenger terminal Volgograd airport A number of Federal Security Service and the Ministry of Defense of the Russian Federation facilities Over a thousand commercial facilities and various establishments within Russia and abroad Sochi central railway station Hosta railway station

13

//6 Security system designing

Videofon MV provided for the technical security equipment engineering as part of the Administration and retail complex with an underground parking of the Moscow International Business Center (also known as Moscow-City). The project consists of the following subsystems: Security and Fire Alarm System; Structured Cabling for Technical Security Equipment; Public Address System; Access Control System; Security Lighting System; Automatic Parking Control System; CCTV System.

15

//7 Access Control System

Biometrics is one of the most promising areas in the sphere of personal identification. The biometrical control system is based on identification of individual’s unique biological data like a facial features, fingerprints, and iris. The facial recognition scanning system stands out, since physical contact with the device is not necessary that opens up vast access control opportunities.

17

Our company designs and successfully introduces automated systems intended for controlling various work cycles including traffic control systems.

//8 Automated Control Systems

Our services: Designing Equipment delivery Sost ware engineering Installation Pre-commissioning Staff training Commissioning Maintenance

19

//8 Automated Control Systems

Advantages of the integrated automation: Higher level of industrial safety; Higher level of anti-terrorist protection; Energy source cost saving; Stability increase; Improvement of labour effi ciency of operators; Downsizing; Facilitated interaction of operators; Improved working conditions for your staff ; Cost saving. We are focused on: Turn key automated process control systems for enterprises of various industrial sectors; Client-oriented automation solutions at every production level; Completing and integration of control, management, and dispatch systems for industrial business organizations; Maintenance of the systems installed.

21

We computerize process control systems at complex industrial facilities, which imply:

■ Control systems of critical subsystems (ventilation,

automatic fire alarm system, automatic fire fighting system, lighting system, power supply, water supply, etc.);

■ Basic process control systems including every

accounting and record keeping instruments, as well as technical process and safety compliance;

■ General activities control centre suitable for external

monitoring by means of a remote access and/or

• ther control centres.

//8 Automated Control Systems

23

//9 Adler — Alpiko-Service

Videofon MV company was one of the major contractors in the combined highway/railway construction from Adler to Alpiko-Service mountain resort between 2012- 2014. The company performed works on: Automation of traffi c control system (Transport stream automated control system and Traffi c automated control system); traffi c, automatically controlled road signs, dynamic message road panels, automatic weather stations, radar systems, traffi c lights. Video surveillance; Cable-stayed bridge control system; Geotechmonitoring systems. All information can be transmitted to a command centre and an auxiliary command centre.

25

//10 Energy effi ciency

To enhance the energy effi ciency level in your

• rganization, we have a number of solutions in our

hands which cover: Energy auditing (under FL No. 261); Energy performance certifi cate working out; Inhouse energy effi ciency policy elaboration; Automated control system engineering and introduction; Engineering and introduction of a situation centre. Results: GHG reduction; Water consumption reduction; Energy source cost saving; Inhouse energy effi ciency improvement.

27

//10 Energy efficiency

Energy saving is evaluated with regard to the following: Comparison of actual loads and energy consumption plans; Energy saving confi rmation; Anticipated investments; Cost effi ciency/pay-off ; Technical and commercial risks; Technical support program development; Measuring equipment rate evaluation and data collection for monitoring and goal setting.

29

ACMS is designed for automatic reading, conversion and transmission via communication networks of multi-rate meters data received from utility metering devices of electrical and heating energy, natural and

• ther industrial gases, and hot and cold water as well in

residential, municipal and industrial buildings.

//11 ACMS

/Automatic system of control, metering and wireless data transmission from utility metering devices

ACMS renders possible:

■ Centralized collection of information fl

• ws received

from automatic meter reading devices, along with monitoring of technical equipment condition;

■ Arouses public interest in installation of aff

• rdable

wireless equipment (based on radio channel transmission) which allows data transmission from apartment metering devices without extra engineering works;

■ Early receipt of true metering data from a unifi

ed data collection center (unifi ed operator) which saves the eff

• rts of the managing companies and information

and accounting centers (UIAC) with regard to the collection of the data by human force;

■ Real-time information receipt related to any

equipment tampering or potential gas or water leakages;

■ Other services that may be delivered to organizations

• r individuals (bill itemization; installation of fl
• oding

sensors, security and fi re alarm systems; insurance services, etc.)

31

//12 MEP systems

In the years 2012-2014 Videofon MV equipped highway and railway tunnels with ventilation systems that can be fully operated by means of a command center due to automatic control systems.

Implemented systems:

■ Supply and exhaust ventilation systems that

can be controlled remotely by a command centre by means of ACS;

■ Composite smoke exhaust and ventilation

damper system, microcontroller-operated dampers of FDVS series (Fire Damper of Ventilation System) including contaminated control areas and automatic fi re alarm system;

■ Noise attenuation systems for ventilation

chambers, ventilation shast s, adits, and linkages in order to adjust noise level of ventilation systems in tunnels and linkages; airfoils for creating an air fl

• w of supply and

exhaust systems;

■ Air conditioning and ventilation system for the

purpose of the supply and exhaust ventilation systems operating mode;

■ Industrial air conditioners. Cooling with

chillers equipped with hydromodules (pump units) and dry coolers. Two circuit mechanism with a complicated operating temperature

• chart. Automatic local heating control of

supply vent systems with radiant heaters was installed. The ventilation systems are powered to a high standard via SREP system (backup power supply);

■ Tunnel jet ventilation systems (28 jet fans in

total).

MEP systems:

Automatic fi re alarm system; Automatic fi re fi ghting system; Automatic gaseous fi re suppression system; Air conditioning, cooling and heating; Telephone system; Sewage treatment system; Electrical power supply; Transformer substations of 10/0,4 kV; Electric lighting; Backup electrical power supply; Local ventilation; Smoke exhaust ventilation; Electric clock system.

33

//13 Equipment

Videofon MV is a manufacturer of thermal imaging cameras for video surveillance. We make eff ective 24-hour and all-weather monitoring and surveillance devices which will impress you with a wide range

• f functions providing maximum possible user’s

conveniences, the options of remote control and image transmission to IP systems, and which off er solutions for any challenge you may have. With our sost ware you can make maximum use of the video surveillance system to meet the challenges of: Surveillance; Object or any activity detection; Process equipment and system monitoring; Fire detection; Security; Video analysis; Metering of power consumption; Automatic alert in case of any failure or breakdown.

35

//14 Our partners

and others.

37

//15 Our customers

Russian Railways SC Olympstroy SC Rosatom Federal Security Service of the Russian Federation Ministry of Defence of the Russian Federation Federal Drug Control Service of the Russian Federation Ministry of Internal Aff airs of the Russian Federation EMERCOM of Russia Ministry of Health of the Russian Federation Moscow City Government Moscow City Prefectures Department of Housing, Utilities and Amenities of the City of Moscow Department of Healthcare of the City of Moscow Department of Education of the City of Moscow Department of Physical Fitness and Sport of the City of Moscow Directorate for Registry Offi ces of the City of Moscow Department of Information Technology of the City of Moscow Directorate for Magistrates of Moscow City and Moscow region

39

//16 Certifi cates

• 1. Sensitive Security-Associated Operation(s)

Admission Certifi cate (for capital construction projects).

• 2. Security-Associated Operations Admission

Certifi cate (scheduling and designing; for capital construction projects).

• 3. Indoor Fire Security Means Installation,

Repairs, and Maintenance License.

• 4. Telematic Communication Services License.
• 5. Weapons And Military Equipment Engineering

License

• 6. Weapons And Military Equipment

Manufacturing License

• 7. Weapons And Military Equipment Repairs

License

• 8. Information Security Product Associated

Works License

• 9. National Security Information Preventive

Measures and/or Services License (technical information protection related issues)

• 10. National Security Information Preventive

Measures and/or Services License (technical counterintelligence denial measures)

• 11. National Security Information Associated

Operations License.

• 12. Certifi

cate of electrical laboratory registration

• 13. Conformity certifi

cate (ISO 9001:2008)

• 14. Conformity certifi

cate of Technologic Interactive Platform of CCTV Cabling of Cyclop cipher

//17 Contact

Head offi ce: 2nd Yuzhnoportoviy Proezd 20a/4, Moscow 115088 Tel.: +7 495 921 32 15 +7 495 921 32 16 Fax: +7 495 921 32 19 e-mail: info@videofonmv.ru Site: http://videofonmv.ru/
