VEEMS Viswa Energy Efficiency Management System VEEMS ARCHITECTURE VEEMS DATA AGGREGATION Air Temperature Air Humidity Draft & Trim (Dynamic) Sea Water Temperature Delivered Power Rudder Angle & Heading Speed through water

slide-1
SLIDE 1
slide-2
SLIDE 2

VEEMS

Viswa Energy Efficiency Management System

slide-3
SLIDE 3

VEEMS ARCHITECTURE

slide-4
SLIDE 4
slide-5
SLIDE 5
slide-6
SLIDE 6

VEEMS – DATA AGGREGATION

Sea Water Temperature Air Temperature

Air Humidity

Current Heading Depth Below Keel Speed through water Speed over ground Draft & Trim (Dynamic) Rudder Angle & Frequency Delivered Power

slide-7
SLIDE 7

Operational & Energy Saving Factors

▪Trim optimisation ▪Hull & Propeller cleaning ▪Route / Voyage optimisation ▪Total Fuel Management - Benefit measurement ▪Quantification of savings – when any new technology like Mewis duct, new paints, etc.

slide-8
SLIDE 8

Environmental and Regulatory Factors

▪SEEMP and EEOI ▪MRV EU (EU – Measuring, Reporting, Verification) ▪Fuel change over ECA compliance record ▪ESI index (Reward from port to ship in reducing SOx, NOx) ▪EVDI – Existing Vessel Design Index – Rightship/Shipping Efficiency

slide-9
SLIDE 9

Performance Monitoring Factors

▪Performance monitoring and benchmarking ▪Engine Performance, SFOC (Specific Fuel Oil Consumption) ▪Auxiliary Engine – Power management, Performance & Optimization ▪Cylinder oil – feed rate, optimization etc ▪KWh/Nm, Kg/Nm – Other KPIs

slide-10
SLIDE 10

+ +

Fully automated system for Crew & office

VEEMS

Operational Factors Environmental Factors Performance & Engine Optimization

+

slide-11
SLIDE 11

Pre-installation Survey Configure VEEMS as per Ship Specifics

Installation

Communication Check Data Hosting & Monitoring VEEMS Office – Technical Person Embedding

Customer Support 24 x 7 – both Ship & Shore

slide-12
SLIDE 12

Hardware and Cabling Ship – “Plug & Play”

slide-13
SLIDE 13

DASHBOARDS & KPI REPRESENTATION

slide-14
SLIDE 14

VEEMS – Dashboard

slide-15
SLIDE 15

Major KPIs

slide-16
SLIDE 16

Major KPIs

slide-17
SLIDE 17

EEOI – EFFICIENCY SUMMARY

slide-18
SLIDE 18

Fuel Consumption Break-up

slide-19
SLIDE 19

VEEMS – On board – Automated Reporting

slide-20
SLIDE 20

M/E Load Diagram

slide-21
SLIDE 21

Operational KPIs

slide-22
SLIDE 22

Efficiency Summary Report

slide-23
SLIDE 23

Voyage Analysis

slide-24
SLIDE 24

Operational Profile Summary

slide-25
SLIDE 25

Emission Summary

slide-26
SLIDE 26

Multiple Parameters/KPIs Comparison

slide-27
SLIDE 27

Fuel Consumption Summary

slide-28
SLIDE 28

Voyage - shows plotted route and actual route

Singapore Durban

Plotted Route

slide-29
SLIDE 29

Ship Position data - every 6 minutes.

slide-30
SLIDE 30

Sea Current effect on ship movement

Red Color – Current against the ship Blue color - Favorable current Durban Singapore

slide-31
SLIDE 31

Sea Current - favorable/against

+ sea current is in favor of ship’s direction

  • sea current is in opposite direction as the ship
slide-32
SLIDE 32

Hull & Propeller Condition

slide-33
SLIDE 33

10% 30% 40% 50% 60% 20% 23 24 25 26 27 28 29 30 31 32 33 34 35 36

Months since dry-docking

% Increase in resistance

Normal Hull Condition Added Resistance more than 30% Added Resistance more than 50%

Hull Condition

Note: Hull cleaning cost should be compared to increase in fuel consumption due to increased resistance to arrive at the trigger point for hull cleaning.

slide-34
SLIDE 34

Hull Cleaning & Painting

35 38 25 30 34 41 46 51 55 30 32 10 20 30 40 50 60

% Increase in Resistance

% Added Resistance

Dry dock with painting - (Resistance drop 13%) Delayed Hull & Propeller Cleaning (Resistance drop 25%)

Fuel Savings % 4%

Tropical waters excess hull growth

slide-35
SLIDE 35

Before & After Hull Cleaning – Vessel In Tropical Waters

Fuel Savings % 4%

Vessel in Tropical Waters - Maximum Hull growth & loss of power Vessel in tropical waters and assuming that the marine growth & fouling would be maximum, hull cleaning resulted in a fuel saving of 6MT/day at 14 knots, 63% MCR on a fully loaded ship at similar weather conditions.

14 14 44 50

slide-36
SLIDE 36

Before & After Hull Cleaning – Vessel in Cold Waters

Vessel in Cold Waters - Minimal hull growth & loss of power

Vessel in cold waters and assuming that the marine growth & hull fouling would be minimal, hull cleaning resulted in a fuel saving of 1MT/day at 14 knots, 70% MCR on a fully loaded ship at similar weather conditions.

Fuel Savings % 4%

14 14 49 50

slide-37
SLIDE 37

Computation of Savings

Averaging the fuel savings in cold and tropical waters, about 3.5 MT/day [(6+1)/2] of fuel is saved – this is for a 50 MT/day vessel. With 280 sailing days a year = 3.5 MT x 280 days = 980 MT/year. Assuming fuel cost is US $250/MT, Annual fuel savings = US $ 245,000 Normalizing this data to make it uniform with a standard vessel consuming 75 MT/day (used for all other computations), savings will be US $367,500

slide-38
SLIDE 38

Hull & Propeller - Performance

slide-39
SLIDE 39
slide-40
SLIDE 40
slide-41
SLIDE 41

Trim Optimization

slide-42
SLIDE 42

Trim Optimization - VEEMS

slide-43
SLIDE 43

Trim Test # Time Date Dynamic Trim* (m) Ship Speed (knots) Shaft Power (kW) Mean Draft (m) True Wind Speed (knots) 1 10:30:00 AM 15-Sep-16

  • 2.00 F

17 19000 14 2.3 2 11:30:00 AM 15-Sep-16

  • 1.50 F

17.3 19002 14 3.1 3 12:30:00 PM 15-Sep-16

  • 1.00 F

17.8 19010 14 2.5 4 13:30:00 PM 15-Sep-16

  • 0.50 F

18.1 19003 14 2.9 5 14:30:00 PM 15-Sep-16 18 19001 14 2.4 6 15:30:00 PM 15-Sep-16 0.5 A 17.9 19006 14 3 7 16:30:00 PM 15-Sep-16 1.0 A 17.55 19010 14 2.4 8 17:30:00 PM 15-Sep-16 1.5 A 17.32 19004 14 2.6 9 18:30:00 PM 15-Sep-16 2.0 A 17 19005 14 2.9 * Measured using accelerometer based Trim Instrument which also corrects for ship's movement in multiple directions.

Trim Optimization

slide-44
SLIDE 44

Trim Optimization

  • 2.00 F
  • 1.50 F
  • 1.00 F
  • 0.50 F

0.5 A 1 A 1.5 A 2 A 17 Knots 17.3 Knots 17.8 Knots 18.1 Knots 18 Knots 17.9 Knots 17.55 Knots 17.32 Knots 17 Knots

  • 10,00
  • 5,00

0,00 5,00 10,00 15,00 20,00 15-Sep-16 15-Sep-16 15-Sep-16 15-Sep-16 15-Sep-16 15-Sep-16 15-Sep-16 15-Sep-16 15-Sep-16 10:30:00 AM 11:30:00 AM 12:30:00 PM 13:30:00 PM 14:30:00 PM 15:30:00 PM 16:30:00 PM 17:30:00 PM 18:30:00 PM

Speed Vs Trim

Dynamic Trim* (m) Ship Speed (knots)

Optimized Trim for best speed

slide-45
SLIDE 45

Ship Speed Fuel Setting unchanged voyage of 280 days Fuel Cost Original Trim 0.5m by aft 17.9 knots 97.5 MT/day 27300 MT US $ 6825000 Trim after Optimization 0.5 m by forward 18.1 knots at same fuel setting 95 MT/day 26600 MT US $ 6,650,000

Equivalent Fuel consumption over same distance

US $175,000 Fuel Savings 2.50%

Computation of Savings for Trim Optimization

slide-46
SLIDE 46

TRIM OPTIMIZATION

slide-47
SLIDE 47

TRIM OPTIMIZATION

slide-48
SLIDE 48

Total Savings

S No Description Fuel Savings Total Savings 1 Trim Optimization 2.5% US $175,000 2 Voyage JIT 12.16% US $ 851,200 3 Hull Condition 4% US $ 367,500 4 Total Fuel Management 2% US $ 150,000 TOTAL 20.66% US $ 1,543,700

Values based on a fuel consumption of 75 MT/day at 17 knots 280 days at sea, Total annual savings - US $1,543,700

slide-49
SLIDE 49

EU MRV

slide-50
SLIDE 50

VEEMS SYSTEM – APPROVED BY

slide-51
SLIDE 51
slide-52
SLIDE 52
slide-53
SLIDE 53
slide-54
SLIDE 54
slide-55
SLIDE 55
slide-56
SLIDE 56
slide-57
SLIDE 57
slide-58
SLIDE 58
slide-59
SLIDE 59
slide-60
SLIDE 60
slide-61
SLIDE 61
slide-62
SLIDE 62
slide-63
SLIDE 63

Automated EU MRV Report

slide-64
SLIDE 64

EU MRV Report – Fuel & Emission Breakup

slide-65
SLIDE 65

Emissions – Rolling Total – Easy to report EU & IMO

slide-66
